Hydraulic System - Hev: Specifications Kia Optima III

Automatic Trans 8 illustrations

Specifications

PumpPumping capacityAbout 6.46cc per one revolution
TypeInternal gear
MotorTypeBrushless DC motor (3 phases)
TorqueRated 1.5 N.m
Speed range100~2, 500 rpm

Scheme 624

Scheme 624: Circuit Diagram
Scheme 624: Circuit Diagram

Scheme 625

Scheme 625: Component Location
Scheme 625: Component Location

Scheme 626

Scheme 626: Removal
Scheme 626: Removal

Scheme 627

Scheme 627
Scheme 627

Scheme 628

Scheme 628
Scheme 628

Scheme 629

Scheme 629
Scheme 629
  1. Remove the under cover (A). Tightening torque: 7.8 ~ 11.7 N.m (0.8 ~ 1.2 kgf.m, 5.7 ~ 8.6 lb-ft)
  2. Disconnect the Electric Oil Pump (EOP) connector (A).
  3. Disconnect the Electric Oil Pump (EOP) connector (A) and clips (B).
  4. Remove the Electric Oil Pump (EOP) (A).
  5. Installation is the reverse of removal. NOTE: Adding automatic transaxle fluid. (Refer to «Service Adjustment Procedure»(ref-535749-S35189662132013031200000) .
Operating voltage(V)12
Current15 ~ 20A (normal), 45A (Max.)

Scheme 630

Scheme 630: Components Location
Scheme 630: Components Location

Scheme 631

Scheme 631: OPU connector and terminal function
Scheme 631: OPU connector and terminal function
