Automatic Transaxle Control System (A6MF2) - 2.4L: Removal & Installation Kia Optima III

Automatic Trans 16 illustrations ~1314 words

Installation

  1. Installation is reverse of removal. NOTE: In the case of the vehicle equipped with immobilizer or button engine start system, perform "Key Teaching" procedure together. Refer to «TEACHING PROCEDURES»(ref-429553-S12950411932011101500000) .
  1. Installation is the reverse of removal. NOTE: After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. Continue to apply liquid gasket at application points at the valve body cover with Ø2.5 mm (0.0984 in.) thickness. Liquid gasket Part name : Threebond 1281B or LOCTITE FMD-546 Adding automatic transaxle fluid. Refer to «HYDRAULIC SYSTEM (FLUID)»(ref-429640-S06039938592011101500000) .
  1. Installation is the reverse of removal. NOTE: After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. Continue to apply liquid gasket at application points at the valve body cover with Ø2.5 mm (0.0984 in.) thickness. Liquid gasket Part name : Threebond 1281B or LOCTITE FMD-546 Adding automatic transaxle fluid. Refer to «HYDRAULIC SYSTEM (FLUID)»(ref-429640-S06039938592011101500000) .
  1. Installation is the reverse of removal. NOTE: After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. Continue to apply liquid gasket at application points at the valve body cover with Ø2.5 mm (0.0984 in.) thickness. Liquid gasket Part name : Threebond 1281B or LOCTITE FMD-546 Adding automatic transaxle fluid. Refer to «HYDRAULIC SYSTEM (FLUID)»(ref-429640-S06039938592011101500000) .

Removal

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. Refer to VALVE BODY .

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. Refer to VALVE BODY .

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. Refer to VALVE BODY .

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. Refer to VALVE BODY .

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. Refer to VALVE BODY .

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. Refer to VALVE BODY .

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. Refer to VALVE BODY .

Scheme 208

Scheme 208: Removal
Scheme 208: Removal

Scheme 209

Scheme 209
Scheme 209

Scheme 210

Scheme 210
Scheme 210
  1. Remove the battery and the battery tray. Refer to «BATTERY»(ref-429624-S21182795222011101500000) .
  2. Remove the under cover (A). Tightening torque: 7.8 ~ 11.8 N.m (0.8 ~ 1.2 kgf.m, 5.8 ~ 8.7 lb-ft)
  3. Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. Refer to «HYDRAULIC SYSTEM (FLUID)»(ref-429640-S06039938592011101500000) .
  4. Remove the valve body cover (A) and eyebolt (B). Tightening torque: 13.8~14.7 N.m (1.3~1.5kgf.m, 9.4~10.8 lb-ft) 34.3~44.1 N.m (3.5~4.5kgf.m, 25.3~32.6 lb-ft) CAUTION: Always replace the gasket of the eyebolt use new one whenever loosening eyebolt. NOTE: Remove installation bolts in the engine compartment first.
  5. Remove the bolt (3 ea) after disconnecting the solenoid valve connector (A) and the oil temperature sensor connector (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
  6. Remove the solenoid valve (A) after removing the solenoid support.

Scheme 211

Scheme 211
Scheme 211
  1. Installation is the reverse of removal.

Note. When installing, apply the ATF oil or white Vaseline to the O-ring (A) not to be damaged. Continue to apply liquid gasket at application points at the valve body cover with Ø2.5 mm (0.0984 in.) thickness. Liquid gasket Part name : Threebond 1281B or LOCTITE FMD-546 Adding automatic transaxle fluid. Refer to HYDRAULIC SYSTEM (FLUID) .

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. Refer to VALVE BODY .

Scheme 212

Scheme 212: Removal
Scheme 212: Removal

Scheme 213

Scheme 213
Scheme 213

Scheme 214

Scheme 214
Scheme 214
  1. Remove the battery and the battery tray. Refer to «BATTERY»(ref-429624-S21182795222011101500000) .
  2. Remove the under cover (A). Tightening torque: 7.8 ~ 11.8 N.m (0.8 ~ 1.2 kgf.m, 5.8 ~ 8.7 lb-ft)
  3. Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. Refer to «HYDRAULIC SYSTEM (FLUID)»(ref-429640-S06039938592011101500000) .
  4. Remove the valve body cover (B) and eyebolt (A). Tightening torque: 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~ 32.6 lb-ft) 13.8 ~ 14.7 N.m (1.3 ~ 1.5 kgf.m, 9.4 ~ 10.8 lb-ft) CAUTION: Always replace the gasket of the eyebolt use new one whenever loosening eyebolt. NOTE: Remove installation bolts in the engine compartment first.
  5. Remove the bolt (3 ea) after disconnecting the solenoid valve connector (A) and the oil temperature sensor connector (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
  6. Remove the solenoid valve (A) after removing the solenoid support.

Scheme 215

Scheme 215
Scheme 215
  1. Installation is the reverse of removal.

Note. When installing, apply the ATF oil or white Vaseline to the O-ring (A) not to be damaged. Continue to apply liquid gasket at application points at the valve body cover with Ø2.5 mm (0.0984 in.) thickness. Liquid gasket Part name : Threebond 1281B or LOCTITE FMD-546 Adding automatic transaxle fluid. Refer to HYDRAULIC SYSTEM (FLUID) .

  1. Installation is the reverse of removal.

Scheme 216

Scheme 216: Components
Scheme 216: Components

Scheme 217

Scheme 217: Shift Lever Assembly Replacement
Scheme 217: Shift Lever Assembly Replacement

Scheme 218

Scheme 218
Scheme 218

Scheme 219

Scheme 219
Scheme 219
  1. Remove the center console assembly. Refer to «INTERIOR (CONSOLE)»(ref-429563-S42679254862011101500000) .
  2. Disconnect sports mode connector (A).
  3. Remove the shift cable (B).
  4. Remove the shift lever assembly (B) by removing the bolts (A-4 ea). Tightening torque: 9.8 ~ 14.7 N.m (1.0 ~ 1.5 kgf.m, 7.2 ~ 10.9 lb-ft)
  5. Installation is the reverse of removal. NOTE: Make sure vehicle does not roll before setting room side shift lever and T/M side manual control lever to "N" position.

Scheme 220

Scheme 220: Control Cable Replacement
Scheme 220: Control Cable Replacement

Scheme 221

Scheme 221
Scheme 221

Scheme 222

Scheme 222
Scheme 222
  1. Remove the center console assembly. Refer to «INTERIOR (CONSOLE)»(ref-429563-S42679254862011101500000) .
  2. Remove the control cable (B).
  3. Remove the control cable assembly in the vehicle after removing the nuts (B) and the retainer (A). Tightening torque: 9.8 ~ 14.7 N.m (1.0 ~ 1.5 kgf.m, 7.2 ~ 10.9 lb-ft)
  4. Remove the nut (C).
  5. Remove the cable (B) from the bracket (A) at transaxle assembly side. Refer to «AUTOMATIC TRANSAXLE»(ref-429639-S03792191982011101500000) .
  6. Remove the control cable inside of cab.
  1. Installation is the reverse of removal.

Note. Make sure vehicle does not roll before setting room side shift lever and T/M side manual control lever to "N" position.

Scheme 223

Scheme 223: Adjusting Method For T/M Control Cable
Scheme 223: Adjusting Method For T/M Control Cable
  1. Make sure vehicle does not roll before setting room side shift lever and T/M side manual control lever to "N" position.
  2. Connect room side shift lever and control cable.
  3. Push cable to "F" direction shown to eliminate FREE PLAY.
  4. Tighten adjusting nut (A). Tightening torque: 9.8 ~ 14.7 N.m (1.0 ~ 1.5 kgf.m, 7.2 ~ 10.9 lb-ft)
  5. After adjusting, check to be sure that this part operates as designed at each range of T/M side corresponding to each position of room lever.
