OBD-II System Readiness Tests

1. Catalyst monitoring The catalyst efficiency monitor is a self-test strategy within the ECM or PCM that uses the downstream Heated Oxygen Sensor (HO2S) to determine when a catalyst has fallen below the minimum level of effectiveness in its ability to control exhaust emission.
2. Misfire monitoring Misfire is defined as the lack of proper combustion in the cylinder due to the absence of spark, poor fuel metering, or poor compression. Any combustion that does not occur within the cylinder at the proper time is also a misfire. The misfire detection monitor detects fuel, ignition or mechanically induced misfires. The intent is to protect the catalyst from permanent damage and to alert the customer of an emission failure or an inspection maintenance failure by illuminating the MIL. When a misfire is detected, special software called freeze frame data is enabled. The freeze frame data captures the operational state of the vehicle when a fault is detected from misfire detection monitor strategy.
3. Fuel system monitoring The fuel system monitor is a self-test strategy within the ECM or PCM that monitors the adaptive fuel table The fuel control system uses the adaptive fuel table to compensate for normal variability of the fuel system components caused by wear or aging. During normal vehicle operation, if the fuel system appears biased lean or rich, the adaptive value table will shift the fuel delivery calculations to remove bias.
4. Engine cooling system monitoring The cooling system monitoring is a self-test strategy within the ECM or PCM that monitors ECTS (Engine Coolant Temperature Sensor) and thermostat about circuit continuity, output range, rationality faults.
5. O2 sensor monitoring OBD-II regulations require monitoring of the upstream Heated O2 Sensor (H2OS) to detect if the deterioration of the sensor has exceeded thresholds. An additional HO2S is located downstream of the Warm-Up Three Way Catalytic Converter (WUTWC) to determine the efficiency of the catalyst. Although the downstream H2OS is similar to the type used for fuel control, it functions differently. The downstream HO2S is monitored to determine if a voltage is generated. That voltage is compared to a calibrated acceptable range.
6. Evaporative emission system monitoring The EVAP. monitoring is a self-test strategy within the ECM or PCM that tests the integrity of the EVAP. system. The complete evaporative system detects a leak or leaks that cumulatively are greater than or equal to a leak caused by a 0.040 inch and 0.020 inch diameter orifice.
7. Air conditioning system monitoring The A/C system monitoring is a self-test strategy within the ECM or PCM that monitors malfunction of all A/C system components at A/C ON.
8. Comprehensive components monitoring The comprehensive components monitoring is a self-test strategy within the ECM or PCM that detects fault of any electronic powertrain components or system that provides input to the ECM or PCM and is not exclusively an input to any other OBD-II monitor.
9. A/C system component monitoring

Requirement

If a vehicle incorporates an engine control strategy that alters off idle fuel and/or spark control when the A/C system is on, the OBD II system shall monitor all electronic air conditioning system components for malfunctions that cause the system to fail to invoke the alternate control while the A/C system is on or cause the system to invoke the alternate control while the A/C system is off.

Additionally, the OBD II system shall monitor for malfunction all electronic air conditioning system components that are used as part of the diagnostic strategy for any other monitored system or component.

Implementation plan

No engine control strategy incorporated that alters off idle fuel and/or spark control when A/C system is on. Malfunction of A/C system components is not used as a part of the diagnostic strategy for other monitored system or component.

Scheme 283

Scheme 284

Scheme 285

Scheme 286

Scheme 287

Scheme 288

ECM Terminal Function

Connector (CHG-AG)

CONNECTOR PIN REFERENCE CHART

Connector (CHG-BG)

CONNECTOR PIN REFERENCE CHART

ECM Terminal Input/Output signal

Connector (CHG-AG)

CONNECTOR PIN REFERENCE CHART

Connector (CHG-BG)

CONNECTOR PIN REFERENCE CHART Pin No. Description Condition Type Level 1 ECM ground Idle DC -0.3 ~ 0.5V 2 ECM ground Idle DC -0.3 ~ 0.5V 3 Battery power (B+) IG OFF DC Max. 1.0V IG ON Battery Voltage 4 ECM ground Idle DC -0.3 ~ 0.5V 5 Battery power (B+) IG OFF DC Max. 1.0V IG ON Battery Voltage 6 Battery power (B+) IG OFF DC Max. 1.0V IG ON Battery Voltage 7 - 8 Crankshaft Position Sensor (CKPS) signal input Engine Running Pulse High : 4.5 ~ 5.5V Low : -0.3 ~ 0.5V Frequency: 850Hz (Idle), 3, 000Hz (3, 000 RPM) 9 - 10 Brake Switch 2 signal input Brake OFF DC Battery Voltage Brake ON Max. 0.5V 11 - 12 - 13 - 14 - 15 Electrical load signal input Lamp OFF DC Battery Voltage Lamp ON -0.3 ~ 0.5V 16 Alternator PWM signal output Idle Pulse High: Battery Voltage Low: Max. 1.5V Frequency: 125Hz 17 - 18 Cooling Fan Relay (High) control output Relay OFF DC Battery Voltage Relay ON Max. 1.0V 19 Immobilizer Lamp control output Lamp OFF DC Battery Voltage Lamp ON -0.3 ~ 1.2V 20 - 21 - 22 Injector (Cylinder #2) (High) control output Engine Running PWM 23 Injector (Cylinder #2) (Low) control output Engine Running Pulse 24 - 25 Sensor ground Idle DC -0.3 ~ 0.5V 26 - 27 Brake Switch 1 signal input Brake OFF DC Max. 0.5V Brake ON Battery Voltage 28 - 29 Camshaft Position Sensor (CMPS) (Bank 1/Intake) signal input Engine Running Pulse High: 4.5 ~ 5.5V Low: -0.3 ~ 0.5V Frequency: 7Hz (Idle), 25Hz (3, 000 RPM) 30 Camshaft Position Sensor (CMPS) (Bank 1/Exhaust) signal input Engine Running Pulse High: 4.5 ~ 5.5V Low: -0.3 ~ 0.5V Frequency: 7Hz (Idle), 25Hz (3, 000 RPM) 31 - 32 LIN communication signal input 33 Cooling Fan Relay (Low) control output Relay OFF DC Battery Voltage Relay ON -0.3 ~ 1.2V 34 - 35 - 36 - 37 Malfunction Indicator Lamp (MIL) control output Lamp OFF DC Battery Voltage Lamp ON -0.3 ~ 1.2V 38 - 39 Injector (Cylinder #3) (High) control output Engine Running PWM 40 Injector (Cylinder #3) (Low) control output Engine Running Pulse 41 Battery power (B+) IG OFF DC Max. 1.0V IG ON Battery Voltage 42 - 43 - 44 Sensor shield Idle DC -0.3 ~ 0.5V 45 Sensor ground Idle DC -0.3 ~ 0.5V 46 Sensor ground Idle DC -0.3 ~ 0.5V 47 Sensor ground Idle DC -0.3 ~ 0.5V 48 - 49 - 50 - 51 - 52 - 53 Main Relay control output Relay OFF DC Battery Voltage Relay ON -0.3 ~ 1.2V 54 - 55 - 56 Injector (Cylinder #4) (High) control output Engine Running PWM 57 Injector (Cylinder #4) (Low) control output Engine Running Pulse 58 Battery power (B+) IG OFF DC Max. 1.0V IG ON Battery Voltage 59 - 60 CAN (Low) Recessive Pulse 2.0 ~ 3.0V Dominant 2.75 ~ 4.5V 61 - 62 Knock Sensor (KS) signal input Knocking Variable Frequency -0.3 ~ 0.3V Normal 0V 63 Clutch Switch signal input S/W OFF DC Battery Voltage S/W ON -0.3 ~ 0.5V 64 - 65 - 66 - 67 - 68 Variable Intake Solenoid (VIS) Valve control output Active DC Max. 1.0V Inactive Battery Voltage 69 Starter Relay control output Relay OFF DC Battery Voltage Relay ON -0.3 ~ 1.2V 70 Fuel Pump Relay control output Relay OFF DC Battery Voltage Relay ON -0.3 ~ 1.2V 71 Engine speed signal output Engine Running Frequency High: Battery Voltage Low: -0.3 ~ 1.0V Frequency: 21Hz (Idle), 100Hz (3, 000 RPM) 72 - 73 Injector (Cylinder #1) (High) control output Engine Running PWM 74 Injector (Cylinder #1) (Low) control output Engine Running Pulse 75 Battery power (B+) IG OFF DC Max. 1.0V IG ON Battery Voltage 76 - 77 CAN (High) Recessive Pulse 2.0 ~ 3.0V Dominant 2.75 ~ 4.5V 78 Vehicle speed signal input 79 - 80 - 81 - 82 Starter Control Switch signal input S/W OFF DC -0.3 ~ 0.5V S/W ON Battery Voltage 83 - 84 CVVT Oil Control Valve (OCV) (Bank 1/Exhaust) control output Idle Pulse High: Battery Voltage Low: -0.3 ~ 1.0V Frequency: 300Hz 85 CVVT Oil Control Valve (OCV) (Bank 1/Intake) control output Idle Pulse High: Battery Voltage Low: -0.3 ~ 1.0V Frequency: 300Hz 86 Purge Control Solenoid Valve (PCSV) control output Inactive Active Pulse High: Battery Voltage Low: Max. 1.0V Vpeak: 42.0 ~ 60.0V Frequency: 20Hz 87 Canister Close Valve (CCV) control output Active Inactive Pulse High: Battery Voltage Low: Max. 1.0V Vpeak: 42.0 ~ 60.0V 88 Heated Oxygen Sensor (HO2S) (Bank 1/Sensor 1) Heater control output Engine Running Pulse High: Battery Voltage Low: -0.3 ~ 1.0V Frequency: 8 ~ 10Hz Duty: 0 ~ 100% 89 Heated Oxygen Sensor (HO2S) (Bank 1/Sensor 2) Heater control output Engine Running Pulse High: Battery Voltage Low: -0.3 ~ 1.0V Frequency: 8 ~ 10Hz Duty: 0 ~ 100% 90 Fuel Pressure Regulator Valve (High) control output Engine Running PWM 91 Fuel Pressure Regulator Valve (Low) control output Engine Running Pulse

Scheme 289

Scheme 290

Scheme 291

Scheme 292

Scheme 293

Scheme 294

Scheme 295

Scheme 296

Scheme 297

Scheme 298

Scheme 299

Scheme 300

Scheme 301

VIN Programming Procedure

VIN (Vehicle Identification Number) is a number that has the vehicles information (Maker, Vehicle Type, Vehicle Line/Series, Body Type, Engine Type, Transmission Type, Model Year, Plant Location and so forth. For more information, please refer to GENERAL INFORMATION . When replacing an ECM, the VIN must be programmed in the ECM. If there is no VIN in ECM memory, the fault code (DTC P0630) is set.

Scheme 302

Scheme 303

1. Select "VIN Writing" function in "Vehicle S/W Management".
2. Select "Write VIN" in "ID Register".
3. Input the VIN. WARNING: Before inputting the VIN, confirm the VIN again because the programmed VIN cannot be changed.
4. Turn the ignition switch OFF, then back ON.

Throttle Position Sensor (TPS)

1. Connect the GDS on the Data Link Connector (DLC).
2. Start the engine and measure the output voltage of TPS 1 and 2 at C.T. and W.O.T. Specification: Refer to «SPECIFICATION»(ref-429632-S19842216412011101500000) .
3. Turn the ignition switch OFF and disconnect the scantool from the DLC.
4. Disconnect the ETC module connector and measure the resistance between the ETC module terminals 1 and 2.

Specification: Refer to SPECIFICATION .

ETC Motor

1. Turn the ignition switch OFF.
2. Disconnect the ETC module connector.
3. Measure resistance between the ETC module terminals 3 and 6.
4. Check that the resistance is within the specification.

Specification: Refer to SPECIFICATION .

Bank 1/Intake

1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
2. Disconnect the camshaft position sensor connector (A).
3. Remove the installation bolt (B), and then remove the sensor.

Scheme 304

Bank 1/Exhaust

1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
2. Disconnect the camshaft position sensor connector (A).
3. Remove the hanger and the protector.
4. Remove the installation bolt (B), and then remove the sensor.

Scheme 305

HO2S (Bank 1/Sensor 1)

ITEM SPECIFICATION CHART

HO2S (Bank 1/Sensor 2)

VOLTAGE SPECIFICATION CHART

ITEM SPECIFICATION CHART

Scheme 306

Bank 1/Sensor 1

SULEV

Scheme 307

Scheme 308

ULEV

Scheme 309

Scheme 310

Bank 1/Sensor 2

SULEV

Scheme 311

Scheme 312

ULEV

Scheme 313
