Description
The Evaporative Emission Control System prevents fuel vapor stored in fuel tank from vaporizing into the atmosphere. When the fuel evaporates in the fuel tank, the vapor passes through vent hoses or tubes to a canister filled with charcoal. The canister temporarily holds the vapor in the charcoal. The ECM will control the system in order to draw the gathered vapor into the combustion chambers during certain operating conditions. Engine manifold vacuum is used to draw the vapor into intake manifold.
Scheme 11
A ratchet tightening device on the threaded fuel filler cap reduces the chances of incorrect installation, which seals the fuel filler. After the gasket on the fuel filler cap and the filler neck flange contact each other, the ratchet produces a loud clicking noise indicating the seal has been set.
Scheme 12
Scheme 13
Scheme 14
Scheme 15
Scheme 16
- Turn the ignition switch OFF and disconnect the battery negative (-) cable.
- Lift the vehicle.
- Disconnect the canister close valve connector (A).
- Disconnect the ventilation hose (B).
- Remove the fuel tank air filter after removing 2 bolts (C).
- Release the lever (A) and then rotate the canister close valve (B) in the direction of the arrow in figure.
- Remove CCV from the fuel tank air filter after coinciding installation parts (A, B).
- Replace new fuel tank air filter.
