Engine Cooling System - Hev: Specifications Kia Optima III

Cooling System (Mechanical) 12 illustrations ~151 words

Specifications

ItemsSpecifications
Operating temperature22~185°F (-30~85°C)
Operating voltageDC 9~16V
Rated voltageDC 12V
Rated current (No load)300mA or less

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47: Components
Scheme 47: Components

Scheme 48

Scheme 48: Schematic Diagram
Scheme 48: Schematic Diagram

Scheme 49

Scheme 49: Circuit Diagram
Scheme 49: Circuit Diagram

Scheme 50

Scheme 50: Removal
Scheme 50: Removal

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53
  1. Remove the front bumper. (Refer to " «FRONT BUMPER»(ref-535727-S27245768842013031200000) ")
  2. Remove the headlamps. (Refer to " «HEAD LAMPS»(ref-535728-S07950528432013031200000) ")
  3. Remove the air guards (A).
  4. Unfasten the 2 bolts (A) and 2 fasteners (B).
  5. Disconnect the AAF (Active air flap) actuator connector (A).
  6. Remove the AAF (Active air flap) assembly (A).
  7. Installation is the reverse of removal.

Scheme 54

Scheme 54: Disassembly
Scheme 54: Disassembly

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57
  1. Separate the duct (A) from the AAF (Active air flap) (B).
  2. Remove the actuator cover (A) from the housing (B).
  3. Remove the actuator (A) from the housing (B).
  4. Remove the link (A) and flaps (B) from the housing (C).
  5. Assembly is the reverse of disassembly.

Note. When assembling, the link and flaps should be in full open position.
