Crankcase Emission Control System - Hev: Overview Kia Optima III

Scheme 434

Scheme 435

1. After disconnecting the vapor hose from the PCV valve, remove the PCV valve.
2. Reconnect the PCV valve to the vapor hose.
3. Run the engine at idle, then put a finger over the open end of the PCV valve and make sure that intake manifold vacuum can be felt. NOTE: The plunger inside the PCV valve will move back and forth based on the vacuum.
4. If the vacuum is not felt inspect PCV operation, if operating correctly clean or replace the vapor hose.

Scheme 436

Scheme 437

1. Disconnect the vapor hose (A).
2. Remove the PCV valve (B).
