Safety Precaution

This hybrid system uses a DC 270V voltage system. Be sure to follow safety instructions below. Failure to follow safety instructions may result in serious injury or electrocution.

WARNINGA caution label for high voltage is attached to the high voltage components. The color of the high voltage cables and connectors are orange. Do not touch any of these high voltage components, cables, and connectors without proper Personal Protection Equipment (PPE).

Note. High Voltage Component: High Voltage Battery Pack Assembly, Power Relay Assembly (PRA), BMS ECU, Hybrid Power Control Unit (HPCU), Hybrid Drive Motor, HSG, Electric A/C Compressor, Low DC/DC Converter (LDC), Power Cable, Electric Compressor etc.

WARNINGFor your safety when servicing the hybrid vehicle: Wear Personal Protection Equipment (Insulation Gloves and Safety Glasses). Do not carry any metallic object (watch, ring etc.) which can cause short circuit. Use insulated tools Before wearing the protective gear, make sure that they are not torn or broken and free of moisture.

Note. Personal Protection Equipment: Insulating Gloves, Safety Glasses

Insulating Gloves Safety Glasses

Scheme 425

Scheme 425
WARNINGUse Mega Ohm Tester when measuring insulation resistance of the high voltage system.

Specification: High Impedance Digital Volt/Ohm Meter (DVOM) "Category 3"

Leads and Meter rated to 1, 000 voltage.

WARNINGBe sure to shut off the high voltage circuit shown in the procedures below before working on any high voltage system component (Refer to High Voltage Shutoff Procedure . Turn the ignition switch off and disconnect the auxiliary 12V battery negative (-) cable. Remove the safety plug (Turning the ignition switch ON with the safety plug removed may damage the hybrid control system). Wait for more than 5 minutes so that the capacitor in the high voltage system can be naturally discharged. Remove the rear seat and partition tray trim (Refer to REAR SEAT . Remove the high voltage front cover (A). Measure the voltage between the inverter positive and negative power cable terminals.

Scheme 426

Scheme 426

Below 30V: High voltage circuit properly shut

More than 30V: High voltage circuit faulty

CAUTIONAttach the 'High Voltage Caution Car Topper' to the vehicle roof to inform other people of danger of high voltage.

Scheme 427

Scheme 427

Scheme 428

Scheme 428
WARNINGBe sure to follow instructions below when repairing the high voltage cable.
  1. Check the voltage of the high voltage connector, terminal or busbar before repairing. Below 30V: High voltage circuit properly shut More than 30V: High voltage circuit faulty
  2. Be careful not to short circuit between positive (+) and negative (-) terminals.
  3. Insulate the high voltage connector or terminal with an insulation tape after disconnecting.
  4. Tighten the high voltage terminal with the specified torque.
CAUTIONThe high voltage battery must be always handled horizontally during repairing or storage. Otherwise, there may be decline in battery performance or its life may be shortened.
CAUTIONExposing the high voltage battery to intense heat may cause deterioration. Do not bake over 70°C (158°F)/30 min or 80°C (176°F)/20 min when painting.

Hybrid Vehicle Refrigerant Recovery/Charging Precautions

  1. Since the electric compressor uses high-voltage, you should use PVE oil which have high Volumetric Resistivity.
  2. Do not use the same A/C recovery/charging station as conventional belt-driven compressors.
WARNINGIf the PVE oil of the system gets mixed PAG oil, then dielectric breakdown due to decreased volumetric Resistivity can occur and inoperative A/C compressor may result, A/C compressor may not work.

High Voltage Shutoff Procedure

WARNINGShut off the high voltage circuit before doing any work related with the high voltage system (Battery Pack Assembly, Power Relay Assembly, HPCU, BMS ECU, Hybrid Drive Motor, Inverter, HSG, LDC Power Cable, Electric Compressor, and so on).

Scheme 429

Scheme 429

Scheme 430

Scheme 430

Scheme 431

Scheme 431

Scheme 432

Scheme 432

Scheme 433

Scheme 433
  1. Turn the ignition switch OFF and disconnect the auxiliary 12V battery negative (-) cable.
  2. Remove the safety plug. Open the safety plug service cover (A). Pull out/down the lever (A) in the direction of the arrow after lifting the locking hook (B), and then pull the safety plug.
  3. Wait for more than 5 minutes so that the capacitor in the high voltage system can be naturally discharged.
  4. Make sure that the capacitor has been discharged. Remove the rear seat and partition tray trim (Refer to «REAR SEAT»(ref-535762-S08009109772013031200000) . Remove the high voltage front cover (A). High voltage front cover installation bolt: 7.8 ~ 11.8N.m (0.8 ~ 1.2kgf.m, 5.8 ~ 8.7lb-ft) Measure the voltage between the inverter positive and negative power cable terminals. Below 30V: High voltage circuit properly shut More than 30V: High voltage circuit faulty WARNING: If the measured voltage is more than 30V, check the removal of the safety plug again. If it is above 30V even though the safety plug is properly removed, there must be any serious problem in high voltage circuit. In this case, do the DTC troubleshooting first (Refer to DTC Guide); don't do any work related to the high voltage system.
