Replace Seal - Intake Manifold Opel Astra G

DOHC Petrol Engine 13 illustrations ~645 words

Remove

  1. 1. Open bonnet
  2. 2. Disconnect battery
  3. 3. Raise vehicle
  4. 4. Place collecting basin underneath.
  5. 5. Drain coolant • Open radiator drain plug • Collect coolant • Close drain plug
  6. 6. Remove intake manifold bracket (3) from intake manifold • 1 bolt (2) • Detach 1 vacuum hose (1).
  7. 7. Detach wiring harness plug (5) from tank vent valve (4) • 1 wiring harness plug
  1. 8. Lower vehicle
  2. 9. Remove air cleaner housing (5) and air intake manifold (3) • 1 mass air flow meter wiring harness plug (4) • Unclip tank ventilation hose (1) • 1 fastening bolt (2) • 1 clip
  1. 10. Detach tank vent valve hose (1) • 1 clip • Disengage tank vent valve hose in direction of arrow
  1. 11. Lower fuel pressure • Via test connector (1) in conjunction with KM-J-34730-91 (2) – Collect exiting fuel in a suitable container - observe safety regulations and national legislation
  1. 12. Remove fuel line (2) from fuel distribution pipe • Detach using KM-796-A (1)
  1. 13. Remove coolant hose (2) from throttle body (1) • 1 clip – Expose coolant hose – 3 clips
  1. 14. Remove coolant hose (1) from coolant flange (2) • 1 clip
  1. 15. Remove engine control unit with engine control unit bracket from intake manifold • Remove ground cable (8) – 1 bolt (9) • Wiring harness plugs, engine control unit (1) and (3) – Detach in direction of arrow and remove) • Disconnect wiring harness plug (2) • Remove 1 wiring harness plug bracket – 2 bolts (5) • 3 tightening bolts (4), (6) and (7)
  1. 16. Remove wiring harness plug (1) from suction pipe pressure gauge (2) • 1 wiring harness plug
  1. 17. Remove brake force amplifier vacuum line (1) • From intake manifold – 1 hose
  2. 18. Remove throttle body wiring harness plug (2) • 1 wiring harness plug
  1. 19. Expose engine wiring harness • 2 clips (1) and (2) • Unclip cable channel (3) – Lay engine wiring harness to one side
  1. 20. Remove engine vent pipe (1) • From cylinder head cover (3) – Detach safety clamp (2)
  1. 21. Remove intake manifold (2) from cylinder head • Bolts (1) and (3) • Lift intake manifold up and off • Remove seal

Install

  1. 22. Fit intake manifold to cylinder head • Replace seal • 5 bolts – Tightening torque 8 Nm
  2. 23. Fit engine vent pipe • On cylinder head – Ensure correct fitting
  3. 24. Route engine wiring harness • Route engine wiring harness • 2 clips • Clip in cable channel
  4. 25. Install throttle body wiring harness plug • 1 wiring harness plug – Lock wiring harness plug
  5. 26. Fit brake force amplifier vacuum line • On intake manifold – 1 hose
  6. 27. Install throttle body wiring harness plug • 1 wiring harness plug
  7. 28. Install engine control unit with engine control unit support on intake manifold • 3 fastening bolts – Tightening torque 8 Nm • 1 install ground cable – 1 bolt • 1 wiring harness plug bracket – 2 bolts • Attach engine control unit wiring harness plug and lock
  8. 29. Install throttle body coolant hoses • on throttle body • 1 clip – Route coolant hose – 3 clips • On thermostat housing – 1 clip
  9. 30. Attach fuel line to fuel distribution pipe
  10. 31. Connect tank vent valve hose • 1 clip
  11. 32. Install air cleaner housing and air intake manifold • Place 1 mass air flow meter wiring harness plug • Clip in tank ventilation hose • 1 fastening bolt • 1 clip – Tightening torque 3.5Nm
  12. 33. Raise vehicle
  13. 34. Raise vehicle • 1 bolt – Tightening torque 8 Nm • Attach 1 vacuum hose • Attach tank vent valve wiring harness plug
  14. 35. Lower vehicle
  15. 36. Top up coolant or ensure correct quantity is present.
  16. 37. Programme transient memory
  17. 38. Close bonnet
