Automatic Transaxle Control System - 2.4L - Except Hev: Overview Hyundai Sonata VI

Automatic Trans 8 illustrations ~303 words

Scheme 731

Scheme 731: COMPONENTS LOCATION

Scheme 732

Scheme 732: Components

Scheme 733

Scheme 733: Removal

Scheme 734

Scheme 734

Scheme 735

Scheme 735
  1. Remove the center console assembly. (Refer to " «INTERIOR»(ref-424764) " .)
  2. Remove the control cable (A).
  3. Remove the shift lever assembly (B) by removing the bolts (A-4ea). Tightening torque: 8.8 ~ 13.7 N.m (0.9 ~ 1.4 kgf.m, 6.5 ~ 10.1 lb-ft)
  4. Remove the shift cable assembly in the vehicle after removing the nuts (B) and the retainer (A). Tightening torque: 9.8 ~ 16.7 N.m (1.0 ~ 1.7 kgf.m, 7.2~12.3 lb-ft)
  5. Remove the cable from the bracket at transaxle assembly side (Refer to " «AUTOMATIC TRANSAXLE»(ref-424740-S22154837112011100100000) " ).
  6. Remove the shift cable at cabin room.

Description

  1. Integrated one unit for input & output speed sensor
  2. Differential current type (low: 7mA, high: 14mA)
  3. Failsafe: 4th gear hold (D), 2nd ~ 4th manual shift (S)
  1. Integrated one unit for input & output speed sensor
  2. Differential current type (low: 7mA, high: 14mA)
  3. Failsafe: 4th gear hold (D), 2nd ~ 4th manual shift (S)
ItemSpecification
TypeCombination of output signals from 4 terminals
Power supply12V
Range detection7-position (P, R, N, D, X, Y, Z)
Failsafe1st, 2nd gear is prohibited.

INHIBITOR SWITCH DESCRIPTION CHART

Scheme 736

Scheme 736: Removal

Scheme 737

Scheme 737

Scheme 738

Scheme 738
  1. Set room side lever and T/M side lever to "N" position.
  2. Remove the battery and the battery tray. (Refer to " «CHARGING SYSTEM»(ref-424742) " .)
  3. Remove the air cleaner assembly. (Refer to " «INTAKE MANIFOLD»(ref-424737-S24638074692011100100000) " .)
  4. Remove the shift cable mounting nut (B).
  5. Disconnect the inhibitor switch connector (A).
  6. Remove the manual control lever (A) and the washer (B) after removing a nut (C). CAUTION: When installing, fix the manual control lever and the inhibitor switch with Ø5mm (0.1969in.) fixing jig. And then tighten the inhibitor assembly mounting bolts.
  7. Remove the inhibitor assembly (A) after removing the bolts (2ea). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: When installing, tighten the inhibitor assembly mounting bolt lightly.
