Specification
| Piece | 3pcs |
|---|---|
| Spool | 20ea |
| Control | Full line pressure variable control Torque converter release control |
| Solenoid valve | VFS : 6ea ON/OFF: 2ea |
| Pressure adjusting | 7ea Line pressure (1), Reducing pressure (2), PCV (4) |
| Terminal type | Module |
VALVE BODY SPECIFICATIONS CHART
Scheme 705
Scheme 706
Scheme 707
Scheme 708
Scheme 709
- Remove the battery and the battery tray. (Refer to " «CHARGING SYSTEM»(ref-424742) " )
- Remove the under cover (A).
- Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. (Refer to " «AUTOMATIC TRANSAXLE SYSTEM»(ref-424740-S22154837112011100100000) " )
- Remove the valve body cover (A) and eyebolt (B). Tightening torque: 12.8 ~ 14.7 N.m (1.3 ~ 1.5 kgf.m, 9.4 ~ 10.8 lb-ft) 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~ 32.6 lb-ft) CAUTION: The gasket of the eyebolt use new one. NOTE: Remove installation bolts in the engine room first and then remove others under the vehicle.
- Remove the plate and the defend spring (A) after removing the bolt. Tightening torque: 24.5 ~ 35.3 N.m (2.5 ~ 3.6 kgf.m, 18.1 ~ 26.0 lb-ft)
- Remove the bolt (3ea) after disconnecting the solenoid valve (B) connector and the oil temperature sensor connector (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
- Remove the valve body assembly (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
| Item | Function | Piece | Specification |
|---|---|---|---|
| VFS | 26/B T/Con | 2 | Control pressure: 9.81~500.14kpa (0.1~5.1kgf/cm 2 , 1.42~72.54 psi) Current value: 50~850mA Low Type, 5.1ohms |
| Line pressure control | 1 | Control pressure: 500.14~9.81kpa (5.1~0.1kgf/cm 2 , 72.54~1.42psi) Current value: 50~850mA High Type, 5.1ohms | |
| 35R UD OD | 3 | Control pressure: 500.14~9.81kpa (5.1~0.1kgf/cm 2 , 72.54~1.42psi) Current value: 50~850mA High Type, 5.1ohms | |
| On/Off | SS-A SS-B | 2 | Control pressure: 490.33kpa (5.0kgf/cm 2 , 71.12psi) 10~11ohms Low Type |
SOLENOID VALVE SPECIFICATIONS CHART
| SS-A | SS-B | UD-VFS | OD-VFS | 35R-VFS | 26-VFS | |
|---|---|---|---|---|---|---|
| N/H | N/H | N/H | N/L | |||
| N, P | ||||||
| 1 | Delta | Delta | ||||
| 2 | ||||||
| 3 | ||||||
| 4 | ||||||
| 5 | ||||||
| 6 | ||||||
| L | ||||||
| R |
SOLENOID VALVE OPERATION TABLE
Scheme 710
Scheme 711
Scheme 712
Scheme 713
- Remove the battery and the battery tray. (Refer to " «CHARGING SYSTEM»(ref-424742) " )
- Remove the under cover (A).
- Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. (Refer to " «AUTOMATIC TRANSAXLE SYSTEM»(ref-424740-S22154837112011100100000) " )
- Remove the valve body cover (A) and eyebolt (B). Tightening torque: 12.8 ~ 14.7 N.m (1.3 ~ 1.5 kgf.m, 9.4 ~ 10.8 lb-ft) 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~ 32.6 lb-ft) CAUTION: The gasket of the eyebolt use new one. NOTE: Remove installation bolts in the engin room first and then remove others under the vehicle.
- Remove the bolt (3ea) after disconnecting the solenoid valve connector (B) and the oil temperature sensor connector (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
- Remove the solenoid valve (A) after removing the solenoid support. CAUTION: When installing, apply the ATF oil or White Vaseline to the O-ring not to be damaged.
