Automatic Transaxle Control System - Hev: Specifications Hyundai Sonata VI

Automatic Trans 18 illustrations ~220 words

Specifications

Type: Negative Thermal Coefficient Type

Temp. (°C)°FResistance (kohms)
(-40)-4046.8
(-20)-4.015.6
(0) 32.05.88
(20) 68.02.51
(40) 104.01.17
(60) 140.00.59
(80) 176.00.32
(100) 212.00.18
(120) 248.00.11
(140) 284.00.07
(165) 329.00.04

TRANSAXLE OIL TEMPERATURE SENSOR SPECIFICATIONS CHART

Scheme 86

Scheme 86

Scheme 87

Scheme 87: Circuit Diagram

Type: Hall effect sensor

Operation condition (°C)°F((-) 40 ~ 150)) -40 ~ 302
Air gap (mm) in.(0.95~1.65) 0.037 ~ 0.065
Output voltage (V)High1.18 ~ 1.68
Low0.59 ~ 0.84

INPUT SPEED SENSOR SPECIFICATIONS CHART

Scheme 88

Scheme 88: Circuit Diagram

Scheme 89

Scheme 89: Signal Waveform

Scheme 90

Scheme 90

Type: Hall effect sensor

Operation condition (°C)°F((-) 40 ~ 150)) -40 ~ 302
Air gap (mm) in.(0.25 ~ 1.9) 0.00984 ~ 0.0748
Output voltageHigh1.18 ~ 1.68
Low0.59 ~ 0.84

OUTPUT SPEED SENSOR SPECIFICATIONS CHART

Scheme 91

Scheme 91: Circuit Diagram

Scheme 92

Scheme 92: Signal Waveform

Scheme 93

Scheme 93

Direct control VFS [E/C]

Control type: Normal low type

Control Pressure kpa (kgf/cm 2 , psi)9.81 ~ 500.14 (0.1 ~ 5.1, 1.42 ~ 72.54)
Current value (mA)50~850
Internal resistance (ohms)5.1

ENGINE CLUTCH CONTROL SOLENOID VALVE SPECIFICATIONS CHART

Scheme 94

Scheme 94: Circuit Diagram

Direct control VFS[26/B]

Control type: Normal low type

Control Pressure kpa (kgf/cm 2 , psi)9.81 ~ 500.14 (0.1 ~ 5.1, 1.42 ~ 72.54)
Current value (mA)50 ~ 850
Internal resistance (ohms)5.1

BRAKE CONTROL SOLENOID VALVE SPECIFICATIONS CHART

Scheme 95

Scheme 95: Circuit Diagram

Scheme 96

Scheme 96: Circuit Diagram

Direct control VFS[LINE Pressure]

Control type: Normal high type

Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value (mA)50 ~ 850
Internal resistance (ohms)5.1

LINE PRESSURE CONTROL SOLENOID VALVE SPECIFICATIONS CHART

Scheme 97

Scheme 97: Circuit Diagram

Direct control VFS[35R/C]

Control type: Normal high type

Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value (mA)50 ~ 850
Internal resistance (ohms)5.1

CLUTCH CONTROL SOLENOID VALVE SPECIFICATIONS CHART

Scheme 98

Scheme 98: Circuit Diagram

Direct control VFS [UD/B]

Control type: Normal high type

Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value (mA)50 ~ 850
Internal resistance (ohms)5.1

UNDERDRIVE BRAKE CONTROL SOLENOID VALVE SPECIFICATIONS CHART

Scheme 99

Scheme 99: Circuit Diagram

Direct control VFS [OD/C]

Control type: Normal high type

Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value (mA)50 ~ 850
Internal resistance (ohms)5.1

OVERDRIVE CLUTCH CONTROL SOLENOID VALVE SPECIFICATIONS CHART

Scheme 100

Scheme 100: Circuit Diagram

ON/OFF Solenoid Valve (SS-A, SS-B)

Control type: Normal low type

Control pressure kpa (kgf/cm 2 , psi)490.33 (5.0, 71.12)
Internal resistance (ohms)10 ~ 11

SS-A SOLENOID VALVE SPECIFICATIONS CHART

Scheme 101

Scheme 101: Circuit Diagram

ON/OFF Solenoid Valve (SS-A, SS-B)

Control type: Normal low type

Control pressure kpa (kgf/cm 2 , psi)490.33 (5.0, 71.12)
Internal resistance (ohms)10 ~ 11

SS-B SOLENOID VALVE SPECIFICATIONS CHART

Scheme 102

Scheme 102: Circuit Diagram

Type: Combination of output signals from 4 terminals

Power supply (V)12
Output typeCombination of output signals

INHIBITOR SWITCH SPECIFICATIONS CHART

PP-RRR-NNN-DD
S11100000
S20111000
S30001110
S40000011

INHIBITOR SWITCH SIGNAL CODE REFERENCE CHART

Scheme 103

Scheme 103: Circuit Diagram
