TCM Learning

When shift shock is occurred or parts related with the transaxle are replaced, TCM learning should be performed.

In the following case, TCM learning is required.

Transaxle assembly replacement
TCM replacement
TCM upgrading

Scheme 838

TCM learning condition ATF temperature: 40~100°C (104~212°F)
TCM learning procedure Stop learning Repeat the below shift pattern four times or more with stepping on the brake. Driving learning Drive the vehicle through all gears at D range. Drive from stop to 1st to 2nd to 3rd to 4th to 5th to 6th with keeping fixed throttle open. Down shift from 6th to 5th, 5th to 4th, 4th to 3rd, 3rd to 2nd, 2nd to 1st. Repeat the above driving pattern four times or more. Up-shift throttle open : 15~25%

Scheme 839

Scheme 839: CIRCUIT DIAGRAM

Scheme 840

Scheme 840: [Vehicle Components]

Scheme 841

Scheme 841: [Transaxle Components]

2. TCM Terminal Function

Connector [CHG-AG]

Pin	Description	Pin	Description
1		54
2	Line pressure control solenoid valve (LINE_VFS)	55
3	Torque converter control solenoid valve (T/CON_VFS)	56
4	35R clutch control solenoid valve (35R/C_VFS)	57
5		58
6		59
7	Inhibitor switch signal "S1"	60
8	Inhibitor switch signal "S2"	61
9	Inhibitor switch signal "S3"	62
10	Inhibitor switch signal "S4"	63
11		64
12		65	ON/OFF solenoid valve B (SS-B)
13		66	ON/OFF solenoid valve B (SS-A)
14		67	Battery (B+)
15		68
16		69	Oil temperature sensor (+)
17		70
18		71
19		72
20		73	Output speed sensor signal
21		74	Sports mode up switch
22		75
23	Underdrive brake control solenoid valve (UD/B_VFS)	76
24	26 brake control solenoid valve (26/B_VFS)	77
25	Overdrive clutch control solenoid valve (OD/C_VFS)	78
26		79
27		80
28		81
29		82
30		83
31		84
32		85
33		86	Solenoid supply power 1
34		87	Solenoid supply power 2
35		88	Battery (B+)
36		89
37		90	Output speed sensor power
38		91	Input speed sensor power
39		92
40		93
41		94	Input speed sensor signal
42		95	Sports mode down switch
43		96
44	Ground (Power 1)	97
45	Ground (Power 2)	98
46	Shift lock solenoid	99
47		100
48	Oil temperature sensor (-)	101
49		102
50		103
51		104
52	Sports mode select switch	105
53

PIN DESCRIPTION CHART

TCM Terminal Input/Output Signal

Connector [CHG-AG]

Pin	Description	Condition	Input/output value
Pin	Description	Condition	Type	Level
1
2	Line pressure control solenoid valve (LINE_VFS)		Output	0V/Battery voltage level
2	Line pressure control solenoid valve (LINE_VFS)		Output	9V < Battery voltage level < 16V
3	Torque converter control solenoid valve (T/CON_VFS)		Output	0V/Battery voltage level
3	Torque converter control solenoid valve (T/CON_VFS)		Output	9V < Battery voltage level < 16V
4	35R clutch control solenoid valve (35R/C_VFS)		Output	0V/Battery voltage level
4	35R clutch control solenoid valve (35R/C_VFS)		Output	9V < Battery voltage level < 16V
5
6
7	Inhibitor switch signal "S1"	High	Input	0V/Battery voltage level
7	Inhibitor switch signal "S1"	Low	Input	9V < Battery voltage level < 16V
8	Inhibitor switch signal "S2"	High	Input	0V/Battery voltage level
8	Inhibitor switch signal "S2"	Low	Input	9V < Battery voltage level < 16V
9	Inhibitor switch signal "S3"	High	Input	0V/Battery voltage level
9	Inhibitor switch signal "S3"	Low	Input	9V < Battery voltage level < 16V
10	Inhibitor switch signal "S4"	High	Input	0V/Battery voltage level
10	Inhibitor switch signal "S4"	Low	Input	9V < Battery voltage level < 16V
11
12
13
14
15
16
17
18
19
20
21
22
23	Underdrive brake control solenoid valve (UD/B_VFS)		Output	0V/Battery voltage level
				9V < Battery voltage level < 16V
				Power supply : V_SOL2
24	26 brake control solenoid valve (26/B_VFS)		Output	0V/Battery voltage level
				9V < Battery voltage level < 16V
				Power supply : V_SOL2
25	Overdrive clutch control solenoid valve (OD/C_VFS)		Output	0V/Battery voltage level
				9V < Battery voltage level < 16V
				Power supply : V_SOL1
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44	Ground (Power 1)		Ground	0V
45	Ground (Power 2)		Ground	0V
46	Shift lock solenoid	High	Output	0V/Battery voltage level
46	Shift lock solenoid	Low	Output	9V < Battery voltage level < 16V
47
48	Oil temperature sensor (-)		Ground	0V
49
50
51
52	Sports mode select switch	Sport mode	Input	0V/Battery voltage level
52	Sports mode select switch	Other	Input	9V < Battery voltage level < 16V
53
54
55
56
57
58
59
60
61
62
63
64
65	ON/OFF solenoid valve B (SS-B)	High	Output	0V/Battery voltage level
65	ON/OFF solenoid valve B (SS-B)	Low	Output	9V < Battery voltage level < 16V
66	ON/OFF solenoid valve A (SS-A)	High	Output	0V/Battery voltage level
66	ON/OFF solenoid valve A (SS-A)	Low	Output	9V < Battery voltage level < 16V
67	Battery power (B+)	ON	Power	0V/Battery voltage level
67	Battery power (B+)	OFF	Power	9V < Battery voltage level < 16V
68
69	Oil temperature sensor (+)	ON	Input	0V/3.3V
69	Oil temperature sensor (+)	OFF	Input	0V/3.3V
70
71
72
73	Output speed sensor signal	High	Input	0.7V/1.4V
73	Output speed sensor signal	Low	Input	0.7V/1.4V
74	Sports mode up switch	Up ON	Input	0V/Battery voltage level
74	Sports mode up switch	Other	Input	9V < Battery voltage level < 16V
75
76
77
78
79
80
81
82
83
84
85
86	Solenoid supply power 1	ON	Power	0V/Battery voltage level
86	Solenoid supply power 1	OFF	Power	9V < Battery voltage level < 16V
87	Solenoid supply power 2	ON	Power	0V/Battery voltage level
87	Solenoid supply power 2	OFF	Power	9V < Battery voltage level < 16V
88	Battery power (B+)	ON	Power	0V/Battery voltage level
88	Battery power (B+)	OFF	Power	9V < Battery voltage level < 16V
89
90	Output speed sensor power	ON	Power	0V/7.5V
90	Output speed sensor power	OFF	Power	0V/7.5V
91	Input speed sensor power	ON	Power	0V/7.5V
91	Input speed sensor power	OFF	Power	0V/7.5V
92
93
94	Input speed sensor signal	High	Input	0.7V/1.4V
94	Input speed sensor signal	Low	Input	0.7V/1.4V
95	Sports mode down switch	Down ON	Input	0V/Battery voltage level
95	Sports mode down switch	Other	Input	9V < Battery voltage level < 16V
96
97
98
99
100
101
102
103
104
105

PIN DESCRIPTION CHART

Scheme 842

Scheme 842: Circuit Diagram

Scheme 843

Signal Code Table

	P	P-R	R	R-N	N	N-D	D
Signal 1	1	0	0	0	1	1	1
Signal 2	0	0	0	1	1	0	0
Signal 3	1	1	0	0	0	0	0
Signal 4	1	1	1	1	1	1	0

SIGNAL CODE CHART

Scheme 844

Scheme 844: Circuit Diagram

Scheme 845

Scheme 845: Removal

Scheme 846

Scheme 847

Make sure vehicle does not roll before setting room side shift lever and T/M side manual control lever to "N" position.
Remove the battery and the battery tray. (Refer to " «CHARGING SYSTEM»(ref-424742) " )
Remove the air cleaner assembly. (Refer to " «INTAKE MANIFOLD»(ref-424823-S25009977002011100100000) " )
Remove the shift cable mounting nut (B).
Disconnect the inhibitor switch connector (A).
Remove the manual control lever (A) and the washer (B) after removing a nut (C). CAUTION: When installing, affix the manual control lever and the inhibitor switch with Ø5mm (0.1969 in.). Then tighten the inhibitor assembly mounting bolts.
Remove the inhibitor assembly (A) after removing the bolts (2ea). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: When installing, tighten the inhibitor assembly mounting bolt lightly, so that necessary adjustments can be made. Tighten to specifications.
