Automatic Transaxle System - 2.4L - Except Hev: Removal & Installation Hyundai Sonata VI

REPLACEMENT

Note. ATF of 6 speed automatic transaxle doesn't be replaced. But, if the vehicle is severe use or business use, replace ATF every 60,000 miles for severe usage. Severe usage is defined as Driving in rough road (Bumpy, Gravel, Snowy, Unpaved road, etc) Driving in mountain road, ascent/descent Repetition of short distance driving More than 50% operation in heavy city traffic during hot weather above 32°C (89.6°F). Police, Taxi, Commercial type operation or trailer towing, etc

Scheme 683

1. Remove the drain plug (A) and reinstall the drain plug after draining ATF totally. Drain plug tightening torque: 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~32.6 lb-ft) CAUTION: The gasket of the drain plug use new one.
2. Fill the oil about 5 liters.
3. Check the oil level. (Refer to «OIL LEVEL CHECK PROCEDURE»(ref-424740-S17509594172011100100000) .)

Scheme 684

Scheme 685

Scheme 686

Scheme 687

Scheme 688

Scheme 689

Scheme 690

Scheme 691

Scheme 692

Scheme 693

Scheme 694

Scheme 695

Scheme 696

Scheme 697

Scheme 698

Scheme 699

1. Remove the following items; Air duct (A) and engine cover (B). (Refer to " «INTAKE AND EXHAUST SYSTEM»(/hyundai/sonata/vi-2009-2014/remont/exhaust/#engine-intake-system-and-exhaust-system-24l-except-hev) " .) Air cleaner assembly (C). (Refer to " «INTAKE AND EXHAUST SYSTEM»(/hyundai/sonata/vi-2009-2014/remont/exhaust/#engine-intake-system-and-exhaust-system-24l-except-hev) " .) Battery and battery tray (D). (Refer to " «CHARGING SYSTEM»(ref-424742) " .)
2. Disconnect the solenoid valve connector (A) and inhibitor switch connector (B).
3. Remove the shift cable (C) after removing the nut (A) and the bolt (B). Tightening torque: 9.8 ~ 14.7 N.m (1.0 ~ 1.5 kgf.m, 7.2 ~ 10.8 lb-ft) 14.7 ~21.6 N.m (1.5 ~2.2 kgf.m, 10.9 ~15.9 lb-ft)
4. Remove the ground line (B) after removing the bolt (A).
5. Disconnect the hose (B) after removing the automatic transaxle fluid cooler hose clamp (A).
6. Remove the wiring bracket installation bolt (A).
7. Remove the automatic transaxle upper mounting bolt (A-2ea) and the starter motor mounting bolt (B-2ea). Tightening torque: 42.2 ~ 54.0 N.m (4.3 ~5.5 kgf.m, 31.1 ~ 39.8 lb-ft)
8. Using the SST (09200-38001), hold the engine and transaxle assembly safely.
9. Remove the automatic transaxle mounting support bracket bolt (A). Tightening torque: 68.6 ~ 93.2 N.m (7.0 ~ 9.5 kgf.m, 50.6 ~ 68.7 lb-ft)
10. Lift the vehicle with a jack.
11. Remove the under cover (A).
12. Remove the Sub frame assembly. (Refer to " «FRONT SUSPENSION SYSTEM»(ref-424761) " .)
13. Remove the drive shaft assembly. (Refer to " «DRIVE SHAFT ASSEMBLY»(ref-424762) " .)
14. Remove the dust cover (A).
15. Remove the torque converter mounting bolt (A-4ea) with rotating the crankshaft. Tightening torque: 45.1 ~ 52.0 N.m (4.6 ~ 5.3 kgf.m, 33.3 ~ 38.3 lb-ft)
16. Remove the automatic transaxle with a jack after removing the mounting bolt (A-4ea, B-2ea). Tightening torque: 29.4 ~ 41.2 N.m (3.0 ~ 4.2 kgf.m, 21.7 ~ 30.4 lb-ft) 42.2 ~ 54.0 N.m (4.3 ~5.5 kgf.m, 31.1 ~ 39.8 lb-ft)

Installation

1. Installation is the reverse of removal. CAUTION: After replacement or reinstallation procedure of the automatic transaxle assembly, must perform procedures below. Power steering fluid replacement and air bleeding (Refer to " «GENERAL INFORMATION»(ref-424766) " .) Adding automatic transaxle fluid. (Refer to " «AUTOMATIC TRANSAXLE SYSTEM»(ref-424740-S22154837112011100100000) " .) NOTE: When replacing the automatic transaxle, reset the automatic transaxle's values by using the GDS.
