Automatic Transaxle Control System - Hev: Removal & Installation Hyundai Sonata VI

Automatic Trans 7 illustrations ~722 words

Installation

In the case of the vehicle equipped with immobilizer or button engine start system, perform "Key Teaching" procedure together (Refer to IMMOBILIZER SYSTEM DIAGNOSIS - HEV or " BUTTON ENGINE START SYSTEM " ).

  1. Installation is reverse of removal.
  1. Installation is the reverse of removal. NOTE: After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. Adding automatic transaxle fluid. (Refer to " «HYDRAULIC SYSTEM (FLUID)»(ref-419426-S29914393642011091200000) " ) Bleed air from the hybrid motor cooling system using GDS. (Refer to " «HYBRID MOTOR COOLING SYSTEM (COOLANT)»(ref-419396-S05583012852011091200000) " )
  1. Installation is the reverse of removal. NOTE: After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. Adding automatic transaxle fluid. (Refer to " «HYDRAULIC SYSTEM (FLUID)»(ref-419426-S29914393642011091200000) " ) Bleed air from the hybrid motor cooling system using GDS. (Refer to " «HYBRID MOTOR COOLING SYSTEM (COOLANT)»(ref-419396-S05583012852011091200000) " )
  1. Installation is the reverse of removal. NOTE: After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. Adding automatic transaxle fluid. (Refer to " «HYDRAULIC SYSTEM (FLUID)»(ref-419426-S29914393642011091200000) " ) Bleed air from the hybrid motor cooling system using GDS. (Refer to " «HYBRID MOTOR COOLING SYSTEM (COOLANT)»(ref-419396-S05583012852011091200000) " )

Removal

Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY " )

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY " )

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY " )

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY " )

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY " )

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY " )

  1. Installation is the reverse of removal. NOTE: Bleed air from the hybrid motor cooling system using GDS. (Refer to " «HYBRID COOLING SYSTEM (COOLANT)»(ref-419396-S05583012852011091200000) " )

Scheme 145

Scheme 145: Shift Lever
Scheme 145: Shift Lever

Scheme 146

Scheme 146: Shift Lever Assembly Replacement
Scheme 146: Shift Lever Assembly Replacement

Scheme 147

Scheme 147
Scheme 147

Scheme 148

Scheme 148
Scheme 148
  1. Remove the center console assembly. (Refer to" «INTERIOR CONSOLE»(ref-419431-S07116233592011091200000) )" )
  2. Disconnect sports mode connector (A).
  3. Remove the shift cable (B).
  4. Remove the shift lever assembly (B) by removing the bolts (A-4ea). Tightening torque: 9.8 ~ 14.7 N.m (1.0 ~ 1.5 kgf.m, 7.2 ~ 10.9 lb-ft)
  5. Installation is the reverse of removal. NOTE: Make sure vehicle does not roll before setting room side shift lever and T/M side manual control lever to "N" position.

Scheme 149

Scheme 149: Control Cable Replacement
Scheme 149: Control Cable Replacement

Scheme 150

Scheme 150
Scheme 150

Scheme 151

Scheme 151
Scheme 151
  1. Remove the center console assembly. (Refer to " «INTERIOR CONSOLE»(ref-419431-S07116233592011091200000) )" )
  2. Remove the control cable (B).
  3. Remove the control cable assembly in the vehicle after removing the nuts (B) and the retainer (A). Tightening torque: 9.8 ~ 14.7 N.m (1.0 ~ 1.5 kgf.m, 7.2 ~ 10.9 lb-ft)
  4. Remove the nut (C).
  5. Remove the cable (B) from the bracket (A) at transaxle assembly side. (Refer to " «AUTOMATIC TRANSAXLE»(ref-419408-S12633267762011091200000) " ).
  6. Remove the control cable inside of cab.
  1. Installation is the reverse of removal. NOTE: Make sure vehicle does not roll before setting room side shift lever and T/M side manual control lever to "N" position.
