Automatic Transaxle Control System - Hev: Adjustments Hyundai Sonata VI

Automatic Trans 1 illustration

Adjustment

Adjusting method for T/M control cable

Scheme 115

Scheme 115: Adjustment
Scheme 115: Adjustment
  1. Make sure vehicle does not roll before setting room side shift lever and T/M side manual control lever to "N" position.
  2. Connect room side shift lever and control cable.
  3. Push cable to "F" direction shown to eliminate FREE PLAY.
  4. Tighten adjusting nut (A). Tightening torque: 9.8 ~ 14.7 N.m (1.0 ~ 1.5 kgf.m, 7.2 ~ 10.9 lb-ft)
  5. After adjusting, check to be sure that this part operates as designed at each range of T/M side corresponding to each position of room lever.
