Automatic Transaxle Control System - 2.4L - Except Hev: Specifications Hyundai Sonata VI

Automatic Trans 16 illustrations ~667 words

Specification

ItemSpecification
TypeHall Effect Sensor, 2pins (Power: 9V, Signal)
Operation condition40 ~150°C [-40 ~ 302°F]
Sensor length52.7~52.9mm (2.0748~2.0827in.)
Air gap0.95~1.65mm (0.0374~0.0650in.)

INPUT SPEED SENSOR SPECIFICATIONS CHART

Scheme 715

Scheme 715: Removal

Scheme 716

Scheme 716

Scheme 717

Scheme 717

Scheme 718

Scheme 718

Scheme 719

Scheme 719

Scheme 720

Scheme 720
  1. Remove the battery and the battery tray. (Refer to " «CHARGING SYSTEM»(ref-424742) " .)
  2. Remove the under cover (A).
  3. Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. (Refer to " «AUTOMATIC TRANSAXLE SYSTEM»(ref-424740-S22154837112011100100000) " .)
  4. Remove the valve body cover (A) and eyebolt (B). Tightening torque: 12.8 ~ 14.7 N.m (1.3 ~ 1.5 kgf.m, 9.4 ~ 10.8 lb-ft) 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~ 32.6 lb-ft) CAUTION: The gasket of the eyebolt use new one. NOTE: Remove installation bolts in the engine room first and then remove others under the vehicle.
  5. Remove the plate and the defend spring (A) after removing the bolt. Tightening torque: 24.5 ~ 35.3 N.m (2.5 ~ 3.6 kgf.m, 18.1 ~ 26.0 lb-ft)
  6. Remove the bolt (3ea) after disconnecting the solenoid valve connector (A) and the oil temperature sensor connector (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: Be careful not to damage the harness lock connector.
  7. Remove the valve body assembly (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
  8. Disconnect the input & output speed sensor connector (A).
  9. Remove the input & output speed sensor (B) after removing the bolts (2ea). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
ItemSpecification
TypeHall Effect Sensor, 2pins (Power: 9V, Signal)
Operation condition40 ~150°C [-40 ~ 302°F]
Sensor length30.1~30.3mm (1.1850~1.1929in.)
Air gap0.8~1.25mm (0.0315~0.0492in.)

OUTPUT SPEED SENSOR SPECIFICATIONS CHART

Scheme 721

Scheme 721: Removal

Scheme 722

Scheme 722

Scheme 723

Scheme 723

Scheme 724

Scheme 724

Scheme 725

Scheme 725

Scheme 726

Scheme 726
  1. Remove the battery and the battery tray. (Refer to " «CHARGING SYSTEM»(ref-424742) " .)
  2. Remove the under cover (A).
  3. Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. (Refer to " «AUTOMATIC TRANSAXLE SYSTEM»(ref-424740-S22154837112011100100000) " .)
  4. Remove the valve body cover (A) and eyebolt (B). Tightening torque: 12.8 ~ 14.7 N.m (1.3 ~ 1.5 kgf.m, 9.4 ~ 10.8 lb-ft) 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~ 32.6 lb-ft) CAUTION: The gasket of the eyebolt use new one. NOTE: Remove installation bolts in the engine room first and then remove others under the vehicle.
  5. Remove the plate and the defend spring (A) after removing the bolt. Tightening torque: 24.5 ~ 35.3 N.m (2.5 ~ 3.6 kgf.m, 18.1 ~ 26.0 lb-ft)
  6. Remove the bolt (3ea) after disconnecting the solenoid valve connector (A) and the oil temperature sensor connector (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: Be careful not to damage the harness lock connector.
  7. Remove the valve body assembly (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
  8. Disconnect the input & output speed sensor connector (A).
  9. Remove the input & output speed sensor (B) after removing the bolts (2ea). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
ItemSpecification
TypeNegative Thermal Coefficient Type
Operation temperature40~165°C [-40~329°F]
Resistance4.81kohms~39 ohms
FailsafeOil temperature set to default value [80°C (176°F)]

TRANSAXLE OIL TEMPERATURE SENSOR SPECIFICATIONS CHART

Scheme 727

Scheme 727: Removal

Scheme 728

Scheme 728

Scheme 729

Scheme 729

Scheme 730

Scheme 730
  1. Remove the battery and the battery tray. (Refer to " «CHARGING SYSTEM»(ref-424742) " .)
  2. Remove the under cover (A).
  3. Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. (Refer to " «AUTOMATIC TRANSAXLE SYSTEM»(ref-424740-S22154837112011100100000) " .)
  4. Remove the valve body cover (A) and eyebolt (B). Tightening torque: 12.8 ~ 14.7 N.m (1.3 ~ 1.5 kgf.m, 9.4 ~ 10.8 lb-ft) 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~ 32.6 lb-ft) CAUTION: The gasket of the eyebolt use new one. NOTE: Remove installation bolts in the engine room first and then remove others under the vehicle.
  5. Disconnect the oil temperature sensor connector (A).
  6. Remove the oil temperature sensor (A) after removing a bolt. Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: Be careful not to damage the harness lock connector.
