Sensors
Input Speed Sensor
- Type: Hall effect sensor
- Specifications HALL EFFECT SENSOR SPECIFICATION CHART Operation condition (°C)°F ((-) 40~150)) -40~302 Air gap (mm) in. (0.95~1.65) 0.037~0.065 Output voltage (V) High 1.18~1.68 Low 0.59~0.84
Output Speed Sensor
- Type: Hall effect sensor
- Specifications HALL EFFECT SENSOR SPECIFICATION CHART Operation condition (°C)°F ((-) 40~150)) -40~302 Air gap (mm) in. (0.55~1) 0.0217~0.0394 Output voltage High 1.18~1.68 Low 0.59~0.84
Oil Temperature Sensor
- Type: Negative thermal coefficient type
- Specifications TEMPERATURE RESISTANCE REFERENCE CHART Temp.[(°C)°F] Resistance (kohms) (-40)-40 48.1 (-20)-4.0 15.6 (0) 32.0 5.88 (20) 68.0 2.51 (40) 104.0 1.11 (60) 140.0 0.61 (80) 176.0 0.32 (100) 212.0 0.18 (120) 248.0 0.10 (140) 284.0 0.06 (150) 302.0 0.05
Inhibitor Switch
- Type: Combination of output signals from 4 terminals
- Specifications VOLTAGE SPECIFICATION CHART Power supply (V) 12 Output type Pin to Pin
Solenoid Valves
Direct control VFS[26/B, T/CON]
- Control type : Normal low type SOLENOID VALVES SPECIFICATION CHART Control Pressure kpa (kgf/cm 2 , psi) 9.81~500.14 (0.1~5.1,1.42~72.54) Current value (mA) 50~850 Internal resistance (ohms) 5.1
Direct control VFS[UD/B, OD/C, 35R/C]
- Control Type : Normal high type DIRECT CONTROL VFS SPECIFICATION CHART Control Pressure kpa (kgf/cm 2 , psi) 500.14~9.81 (5.1~0.1,72.54~1.42) Current value (mA) 50~850 Internal resistance (ohms) 5.1
Line Pressure Control VFS
- Control type : Normal high type LINE PRESSURE CONTROL VFS SPECIFICATION CHART Control Pressure kpa (kgf/cm 2 , psi) 500.14~9.81 (5.1~0.1,72.54~1.42) Current value (mA) 50~850 Internal resistance (ohms) 5.1
ON/OFF Solenoid Valve (SS-A, SS-B)
- Control type : Normal low type ON/OFF SOLENOID VALVE SPECIFICATION CHART Control pressure kpa (kgf/cm 2 , psi) 490.33 (5.0, 71.12) Internal resistance (ohms) 10~11
LUBRICANTS
| Item | Specified lubricant | Quantity |
|---|---|---|
| Transaxle fluid | SK ATF SP-[], MICHANG ATF SP-[], NOCA ATF SP-[], Kia Genuine ATF SP-[] | 7.1L (1.88 U.S gal., 7.50 U.S.qt., 6.24 lmp.qt.) |
LUBRICANTS SPECIFICATION CHART
Sealant
| Item | Specified sealant |
|---|---|
| Rear cover | LOCTITE FMD-546 or THREE-BOND TB1281B |
| Torque converter housing | |
| Valve body cover |
SEALANT SPECIFICATION CHART
SPECIAL SERVICE TOOLS
SPECIAL SERVICE TOOLS DESCRIPTION CHART Tools (Number and name) Illustration Use 09200-38001 Engine support fixture Removal and installation of the transaxle. 09453-3L240 Oil seal installer Installation of transaxle case oil seal. [Using with handle (SST No.:09231-H1100)] 09231-H1100 Bar Installation of transaxle case oil seal. [Using with oil seal installer (SST No.:09453-3L240)]
