Automatic Transaxle Hydraulic System - Hev: Specifications Hyundai Sonata VI

Automatic Trans 8 illustrations ~103 words

SPECIFICATIONS

PumpPumping capacityAbout 6.46cc per one revolution
TypeInternal gear
MotorTypeBrushless DC motor (3 phases)
TorqueRated 1.5 N.m
Speed range100~2,500 rpm

ELECTRIC OIL PUMP SPECIFICATIONS

Scheme 41

Scheme 41: Circuit Diagram
Scheme 41: Circuit Diagram

Scheme 42

Scheme 42: Component Location
Scheme 42: Component Location

Scheme 43

Scheme 43: Removal
Scheme 43: Removal

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46
  1. Remove the under cover (A). Tightening torque: 7.8 ~ 11.7 N.m (0.8 ~ 1.2 kgf.m, 5.7 ~ 8.6 lb-ft)
  2. Disconnect the Electric Oil Pump (EOP) connector (A).
  3. Disconnect the Electric Oil Pump (EOP) connector (A) and clips (B).
  4. Remove the Electric Oil Pump (EOP) (A).
  5. Installation is the reverse of removal. NOTE: Adding automatic transaxle fluid. (Refer to " «HYDRAULIC SYSTEM (FLUID)»(ref-419426-S29914393642011091200000) " .)
Operating voltage (V)12
Current15 ~ 20A (normal), 45A (Max.)

OIL PUMP UNIT SPECIFICATIONS

Scheme 47

Scheme 47: Components Location
Scheme 47: Components Location

Scheme 48

Scheme 48: OPU connector and terminal function
Scheme 48: OPU connector and terminal function
