SPECIFICATIONS

1. Type: Hall effect sensor HALL EFFECT SENSOR SPECIFICATION CHART Operation condition [°C (°F)] ((-) 40~150)) -40~302 Air gap (mm) in. (0.95~1.65) 0.037~0.065 Output voltage (V) High 1.18~1.68 Low 0.59~0.84

Scheme 767

Scheme 768

Scheme 769

see scheme 1) Input/Output speed sensor at low speed

see scheme 2) Input/Output speed sensor at high speed

1. Type: Hall effect sensor HALL EFFECT SENSOR SPECIFICATION CHART Operation condition [°C (°F)] ((-) 40~150)) -40~302 Air gap (mm) in. (0.55~1) 0.0217~0.0394 Output voltage High 1.18~1.68 Low 0.59~0.84

Scheme 770

Scheme 771

Scheme 772

see scheme 1) Input/Output speed sensor at low speed

see scheme 2) Input/Output speed sensor at high speed

Direct control VFS[T/CON]

1. Control type : Normal low type DIRECT CONTROL VFS SPECIFICATION CHART Control Pressure kpa (kgf/cm 2 , psi) 9.81~500.14 (0.1~5.1,1.42~72.54) Current value (mA) 50~850 Internal resistance (ohms) 5.1

Scheme 773

Direct control VFS[26/B]

1. Control type : Normal low type DIRECT CONTROL VFS SPECIFICATION CHART Control Pressure kpa (kgf/cm 2 , psi) 9.81~500.14 (0.1~5.1, 1.42~72.54) Current value (mA) 50~850 Internal resistance (ohms) 5.1

Scheme 774

Direct control VFS[LINE Pressure]

1. Control type : Normal low type DIRECT CONTROL VFS SPECIFICATION CHART Control Pressure kpa (kgf/cm 2 , psi) 500.14~9.81 (5.1~0.1,72.54~1.42) Current value (mA) 50~850 Internal resistance (ohms) 5.1

Scheme 775

Direct control VFS[35R/C]

1. Control type : Normal low type DIRECT CONTROL VFS SPECIFICATION CHART Control Pressure kpa (kgf/cm 2 , psi) 500.14~9.81 (5.1~0.1,72.54~1.42) Current value (mA) 50~850 Internal resistance (ohms) 5.1

Scheme 776

Direct control VFS[35R/C]

1. Control type : Normal low type DIRECT CONTROL VFS SPECIFICATION CHART Control Pressure kpa (kgf/cm 2 , psi) 500.14~9.81 (5.1~0.1,72.54~1.42) Current value (mA) 50~850 Internal resistance (ohms) 5.1

Scheme 777

Direct control VFS[35R/C]

1. Control type : Normal low type DIRECT CONTROL VFS SPECIFICATION CHART Control Pressure kpa (kgf/cm 2 , psi) 500.14~9.81 (5.1~0.1,72.54~1.42) Current value (mA) 50~850 Internal resistance (ohms) 5.1

Scheme 778

ON/OFF Solenoid Valve (SS-A, SS-B)

1. Control type : Normal low type ON/OFF SOLENOID VALVE SPECIFICATION CHART Control pressure kpa (kgf/cm 2 , psi) 490.33 (5.0, 71.12) Internal resistance (ohms) 10~11

Scheme 779

ON/OFF Solenoid Valve (SS-A, SS-B)

1. Control type: Normal low type ON/OFF SOLENOID VALVE SPECIFICATION CHART Control pressure kpa (kgf/cm 2 , psi) 490.33 (5.0, 71.12) Internal resistance (ohms) 10~11

Scheme 780

1. Type: Combination of output signals from 4 terminals VOLTAGE SPECIFICATION CHART Power supply (V) 12 Output type Pin to Pin
