Automatic Transaxle Control System - 2.4L - Except Hev: Other Hyundai Sonata VI

Automatic Trans 1 illustration ~160 words

2. TCM Terminal Function

Connector [CHG-AG]

PinDescription
1[]
2Line pressure control solenoid valve (LINE_VFS)
3Torque converter control solenoid valve (T/CON_VFS)
435R clutch control solenoid valve (35R/C_VFS)
5[]
6[]
7Inhibitor switch signal "S1"
8Inhibitor switch signal "S2"
9Inhibitor switch signal "S3"
10Inhibitor switch signal "S4"
11[]
12[]
13[]
14[]
15[]
16[]
17[]
18[]
19[]
20[]
21[]
22[]
23Underdrive brake control solenoid valve (UD/B_VFS)
2426 brake control solenoid valve (26/B_VFS)
25Overdrive clutch control solenoid valve (OD/C_VFS)
26[]
27[]
28[]
29[]
30[]
31[]
32[]
33[]
34[]
35[]
36[]
37[]
38[]
39[]
40[]
41[]
42[]
43[]
44Ground (Power 1)
45Ground (Power 2)
46Shift lock solenoid
47[]
48Oil temperature sensor (-)
49[]
50[]
51[]
52Sports mode select switch
53[]
54[]
55[]
56[]
57[]
58[]
59[]
60[]
61[]
62[]
63[]
64[]
65ON/OFF solenoid valve B (SS-B)
66ON/OFF solenoid valve B (SS-A)
67Battery (B+)
68[]
69Oil temperature sensor (+)
70[]
71[]
72[]
73Output speed sensor signal
74Sports mode up switch
75[]
76[]
77[]
78[]
79[]
80[]
81[]
82[]
83[]
84[]
85[]
86Solenoid supply power 1
87Solenoid supply power 2
88Battery (B+)
89[]
90Output speed sensor power
91Input speed sensor power
92[]
93[]
94Input speed sensor signal
95Sports mode down switch
96[]
97[]
98[]
99[]
100[]
101[]
102[]
103[]
104[]
105[]

TCM TERMINAL FUNCTION REFERENCE CHART

TCM Terminal Input/Output Signal

Connector [CHG-AG]

PinDescriptionConditionInput/output value
TypeLevel
1
2Line pressure control solenoid valve (LINE_VFS)Output0V/Battery voltage level
9V < Battery voltage level < 16V
3Torque converter control solenoid valve (T/CON_VFS)Output0V/Battery voltage level
9V < Battery voltage level < 16V
435R clutch control solenoid valve (35R/C_VFS)Output0V/Battery voltage level
9V < Battery voltage level < 16V
5
6
7Inhibitor switch signal "S1"HighInput0V/Battery voltage level
Low9V < Battery voltage level < 16V
8Inhibitor switch signal "S2"HighInput0V/Battery voltage level
Low9V < Battery voltage level < 16V
9Inhibitor switch signal "S3"HighInput0V/Battery voltage level
Low9V < Battery voltage level < 16V
10Inhibitor switch signal "S4"HighInput0V/Battery voltage level
Low9V < Battery voltage level < 16V
11
12
13
14
15
16
17
18
19
20
21
22
23Underdrive brake control solenoid valve (UD/B_VFS)Output0V/Battery voltage level
9V < Battery voltage level < 16V
Power supply : V_SOL2
2426 brake control solenoid valve (26/B_VFS)Output0V/Battery voltage level
9V < Battery voltage level < 16V
Power supply : V_SOL2
25Overdrive clutch control solenoid valve (OD/C_VFS)Output0V/Battery voltage level
9V < Battery voltage level < 16V
Power supply : V_SOL1
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44Ground (Power 1)Ground0V
45Ground (Power 2)Ground0V
46Shift lock solenoidHighOutput0V/Battery voltage level
Low9V < Battery voltage level < 16V
47
48Oil temperature sensor (-)Ground0V
49
50
51
52Sports mode select switchSport modeInput0V/Battery voltage level
Other9V < Battery voltage level < 16V
53
54
55
56
57
58
59
60
61
62
63
64
65ON/OFF solenoid valve B (SS-B)HighOutput0V/Battery voltage level
Low9V < Battery voltage level < 16V
66ON/OFF solenoid valve A (SS-A)HighOutput0V/Battery voltage level
Low9V < Battery voltage level < 16V
67Battery power (B+)ONPower0V/Battery voltage level
OFF9V < Battery voltage level < 16V
68
69Oil temperature sensor (+)ONInput0V/3.3V
OFF
70
71
72
73Output speed sensor signalHighInput0.7V/1.4V
Low
74Sports mode up switchUp ONInput0V/Battery voltage level
Other9V < Battery voltage level < 16V
75
76
77
78
79
80
81
82
83
84
85
86Solenoid supply power 1ONPower0V/Battery voltage level
OFF9V < Battery voltage level < 16V
87Solenoid supply power 2ONPower0V/Battery voltage level
OFF9V < Battery voltage level < 16V
88Battery power (B+)ONPower0V/Battery voltage level
OFF9V < Battery voltage level < 16V
89
90Output speed sensor powerONPower0V/7.5V
OFF
91Input speed sensor powerONPower0V/7.5V
OFF
92
93
94Input speed sensor signalHighInput0.7V/1.4V
Low
95Sports mode down switchDown ONInput0V/Battery voltage level
Other9V < Battery voltage level < 16V
96
97
98
99
100
101
102
103
104
105

TCM TERMINAL INPUT/OUTPUT SIGNAL REFERENCE CHART

TCM Learning

When shift shock is occurred or parts related with the transaxle are replaced, TCM learning should be performed.

In the following case, TCM learning is required.

  1. Transaxle assembly replacement
  2. TCM replacement
  3. TCM upgrading

Scheme 746

Scheme 746
Scheme 746
  1. TCM learning condition ATF temperature: 60~115°C (140~239°F)
  2. TCM learning procedure Stop learning Repeat the below shift pattern four times or more with stepping on the brake. Driving learning Drive the vehicle through all gears at D range. Drive from stop to 1st to 2nd to 3rd to 4th to 5th to 6th with keeping fixed throttle open. Down shift from 6th to 5th, 5th to 4th, 4th to 3rd, 3rd to 2nd, 2nd to 1st. Repeat the above driving pattern four times or more. NOTE: Up-shift throttle open : 15~30%
