Automatic Transaxle Control System - 2.4L - Except Hev: Removal & Installation Hyundai Sonata VI

Installation

1. Installation is the reverse of removal. CAUTION: Set room side lever and T/M side lever to "N" position.

Scheme 744

Replacement

Note. In the case of the vehicle equipped with immobilizer or button engine start system, perform "Key Teaching" procedure together (Refer to " IMMOBILIZER " or " BUTTON ENGINE START SYSTEM " ).

Scheme 745

1. Turn ignition switch OFF and disconnect the negative (-) battery cable.
2. Remove the air cleaner assembly (Refer to " «INTAKE AND EXHAUST SYSTEM»(ref-424737) " ).
3. Remove the TCM connector (A) after removing the TCM (B). TCM installation bolt: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)

1. Installation is the reverse of removal. CAUTION: After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. Continue to apply liquid gasket at application points at the valve body cover with Ø2.5mm (0.0984in.) thickness. Liquid gasket Part name: Threebond 1281B or LOCTITE FMD-546 Adding automatic transaxle fluid. (Refer to " «AUTOMATIC TRANSAXLE SYSTEM»(ref-424740-S22154837112011100100000) " .)

1. Installation is the reverse of removal. CAUTION: After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. Continue to apply liquid gasket at application points at the valve body cover with Ø2.5mm (0.0984in.) thickness. Liquid gasket Part name: Threebond 1281B or LOCTITE FMD-546 Adding automatic transaxle fluid. (Refer to " «AUTOMATIC TRANSAXLE SYSTEM»(ref-424740-S22154837112011100100000) " .)

1. Installation is the reverse of removal. CAUTION: After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. Continue to apply liquid gasket at application points at the valve body cover with Ø2.5mm (0.0984in.) thickness. Liquid gasket Part name: Threebond 1281B or LOCTITE FMD-546 Adding automatic transaxle fluid. (Refer to " «AUTOMATIC TRANSAXLE SYSTEM»(ref-424740-S22154837112011100100000) " .)

1. Installation is the reverse of removal.

1. Installation is the reverse of removal. NOTE: After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. Continue to apply liquid gasket at application points at the valve body cover with Ø2.5mm (0.0984in.) thickness. Liquid gasket Part name: Threebond 1281B or LOCTITE FMD-546 Adding automatic transaxle fluid. (Refer to " «HYDRAULIC SYSTEM (FLUID)»(ref-424835-S38954557072011100100000) " ) Perform TCM learning after replacing the automatic transaxle to prevent slow automatic transaxle response, jerky acceleration and jerky startup. Refer to «TCM Learning»(ref-424768-S02688448752011100100000) .
