Special Service Tools Opel Corsa D

Fuel Injection Systems 54 illustrations
CH-47658Clamping tool
To detach the mounting nut of the tie rod ends
CH-48373Fixture, engine / transmission / front axle
Removing, installing and fixing the engine, transmission and front axle in conjunction with KM-904 and hydraulic jack
EN-48375Bonnet support rod
To support the bonnet in conjunction with the carrier frame EN-46750
KM-161-BBearing puller
Inner race and rollers of differential
KM-301Measuring bridge
Measure the piston projection
KM-313Slide Hammer
Pull left axle shaft from transmission
KM-412-AEngine Overhaul Stand
To hold the removed engine
KM-412-11-BAdapter
To hold engine in conjunction with KM-412
KM-412-34Adapter
To hold engine in conjunction with KM-412
KM-470-BAngular Torque Wrench
Tightening cylinder head bolts according to angle°
KM-471Adapter
Check pressurised cooling system in conjunction with cooling system tester
KM-498-BOil Pressure Manometer
Engine oil pressure with KM-6342
KM-596-ATemperature measuring device
To measure oil temperature
MKM-604-DTorx Bit and Socket Set
Removing and installing torx bolts
MKM-611Torque wrench 3/8" drive
Range 10 – 60 Nm
KM-652Flywheel Locking Device
Locking the flywheel
KM-655Installer
Oil nozzles, piston cooling
KM-656Installer
Oil seal ring crankshaft/camshaft
KM-657Installer
Oil pump seal ring
KM-658Installer
Installing rear crankshaft seal ring
KM-662-CHolding Wrench
Toothed belt drive gear, slackening/tightening bolt
MKM-667Pressure and vacuum pump
Check vacuum cell for leaks
MKM-669Torque wrench 1/2" drive
Range 50 to 300 Nm
KM-796-ADismantler
To open fuel system quick-release fittings
KM-812Pipe wrench
Releasing the union nuts on pressure lines
KM-845Nipples
To remove the cup tappets
KM-904Base Frame
To remove/install engine and transmission with KM-6001-A
KM-956-1Grip
Holding camshaft timing gears to slacken/tighten bolt in conjunction with KM-6347
KM-2358Wire ropes
Hitching engine
KM-6003Remover
Remove left axle shaft in conjunction with KM-313
KM-6092Locking Tool
Removing/installing exhaust camshaft
KM-6092-10Fixing rod
Fixing the two part camshaft sprocket to install the camshaft, in conjunction with KM-6092
KM-6098Removing/installing wrench
Removing/installing injection lines
MKM-6104Removing/installing wrench
Removing/installing sheathed glow plugs
KM-6182-1Pliers, straight
Removal/installation of compact clamps
KM-6182-2Pliers, curved
Removal/installation of compact clamps
KM-6282Remover
To remove drive shafts from wheel flange
KM-6327Adapter
To seal coolant expansion tank for coolant system leak test, with KM-471
KM-6332Protective sleeve
To protect the axle shaft sealing rings when installing the axle shaft
KM-6347Holder
Holding camshaft timing gears to slacken/tighten bolts in conjunction with KM-956-1
KM-6355Remover
Removing the belt pulley from the high pressure pump in conjunction with KM-6356
KM-6356Holding Wrench
Holding the belt pulley of the high pressure pump when releasing and tightening the retaining nut Removing the belt pulley in conjunction with KM-6355
KM-6390Centring Tool
Removing and installing front axle and aligning subframe to vehicle underbody in conjunction with KM-904 and hydraulic jack
MKM-6600-1Torque spanner 4-40 Nm
Small torque spanner with low torque range, for use in tight spaces, in conjunction with MKM-6600-100, MKM-6600-200 and MKM-6600-300
MKM-6600-2Torque spanner 20-120 Nm
Large torque spanner with large torque range, for use in tight spaces, in conjunction with MKM-6600-100, MKM-6600-200 and MKM-6600-300
MKM-6600-100Torx socket spanner set
Sizes: E8, E10, E11, E12, E14, E16, E18, E20, E22, E24 for use in tight spaces, in conjunction with MKM-6600-1 and MKM-6600-2
MKM-6600-200Ring socket spanner set
Sizes: 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 21, 22, 24, 27 for use in tight spaces, in conjunction with MKM-6600-1 and MKM-6600-2
MKM-6600-300Open-jawed socket spanner set
Sizes: 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 21, 22, 24, 27 for use in tight spaces, in conjunction with MKM-6600-1 and MKM-6600-2
KM-6610Holding Wrench
To counterhold the axle shaft nut. Tighten with wheel bolts on wheel hub
KM-J-37228Separation Tool
To disconnect oil pan
KM-J-45000Remover
To remove various sealing rings
EN-48560Alignment tool
Aligning the injectors
EN-48559Sealing tool
Sealing the injectors
EN-48558Remover
Removing the wiring harness plugs from the sheathed glow plugs
