Replace Oil Level Sensor Opel Corsa D

Remove

1. 1. Open bonnet
2. 2. Raise vehicle by its full height
3. 3. Place collecting basin underneath.
4. 4. Drain engine oil • Unscrew oil drain bolt (1) • Replace seal • Tighten oil drain screw 20 Nm

5. 5. Remove lower part of oil pan (1) • Unscrew 15x bolts • Detach lower part of oil pan with KM-J-37228

6. 6. Remove oil level sensor • Disconnect wiring harness plug (4) • Release retaining clamp (3) • Unscrew 3 bolts (1 and 2)

7. 7. Detach oil level sensor from retaining plate • Unscrew 2x nuts

Install

8. 8. Attach oil level sensor to retaining plate • Tighten 2x nut 8 Nm
9. 9. Install oil level sensor • Fix wiring harness plug • Latch retaining clamp • Tighten 3x bolt 24 Nm
10. 10. Clean sealing surfaces. • Lower part of oil pan • Upper part of oil pan
11. 11. Install lower part of oil pan • Apply a bead of silicone sealant to the sealing surfaces of the lower part of the oil pan • Tighten 15 bolts 10 Nm

Note. Select suitable sealing compound from the spare parts catalogue

12. 12. Lower vehicle by its full height
13. 13. Top up engine oil
14. 14. Close bonnet
