Parts Location
Components Overview
| PART | RHD | LHD | Location |
|---|
| K12 Relay - Secondary Air Injection | B2H | B2H | Relay box near battery |
| K57 Control Unit - Multec | E2J | E2J | Below cover rain channel |
| K58 Relay - Pump, Fuel | B2H | B2H | Relay box near battery |
| K85 Control Unit - Automatic Transmission | F3H | A3H | A�pillar |
| K117 Control Unit - Immobiliser | B3H | E3H | Fuse box |
| | | |
| X7 Instrument Panel & Multec | B2J | A2H | Cable channel firewall |
| X13 Diagnostic Link | C4H | C4H | Centre console |
| X25 Motronic/Simtec Multec & Automatic Transmission | E2J | B2J | Cable channel firewall |
| X29 Multec Valve, Injection | D2H | D2H | Engine, intake manifold |
| | | |
Overview Relay
Relays above control unit ABS
| Relay | Pos. | Colour |
|---|
| K12 Relay - Secondary Air Injection | 19 | brown |
| K58 Relay - Pump, Fuel | 13 | violete |
| K97 Relay - Time Delay, Washerpump, Headlamp | 18 | black |
