Wiring diagrams Section: Fuel Injection Systems

All sections

Circuit Diagram Opel Vectra B

Fuel Injection Systems 3 illustrations ~202 words

Wiring Schematic Diagram

Wiring Schematic Diagram, X 16 Szr Vetra�b

Abbreviations

AC	= Air Conditioning
DZM	= Tachometer
EKP	= Fuel pump
ECC	= Electronic Climate Control
ID	= Info Display
INS	= Instrument panel
WEG	= Odometer signal
EMP	= Radio

FV6	Fuse 20A

K57 Control Unit - Multec (F)	("FLASH" Programmable)
K58 Relay - Pump, Fuel

L2 Ignition Coil
M66 Stepper Motor - Idle Speed

P23 Sensor - Absolute Pressure, Intake Manifold

P29 Temperature Sensor - Intake Manifold

P30 Temperature Sensor - Coolant

P33 Sensor - Oxygen, Exhaust

P34 Potentiometer - Throttle Valve

P35 Impulse Sensor - Crankshaft

P46 Sensor - Knocking Control

Y18 Solenoid Valve - Exhaust Gas Recirculation

Y32 Injection Valve - Fuel

Y34 Valve - Fuel Tank Ventilation (Evaporation Control Valve)

X7 Instrument Panel & Multec

X13 Diagnostic Link

X25 Motronic/Simtec/Multec & Automatic Transmission

X29 Multec & Valve, Injection

Wiring Schematic Diagram, X 16 Xel Vetra�b

Abbreviations

AT	= Automatic Transmission
AC	= Air Conditioning
DZM	= Tachmeter
EKP	= Fuel pump
ECC	= Electronic Climate Control
ID	= Info Display
INS	= Instrument panel
WEG	= Odometer signal
EMP	= Radio

FV6	Fuse 20A

K12 Relay - Secondary Air Injection
K57 Control Unit - Multec (F)	("FLASH" Programmable)
K58 Relay - Pump, Fuel

L2 Ignition Coil

M21 Pump - Fuel

M27 Pump - Secondary Air Injection

M66 Stepper Motor - Idle Speed

P23 Sensor - Absolute Pressure, Intake Manifold

P29 Temperature Sensor - Intake Manifold

P30 temperature Sensor - Coolant

P33 Sensor - Oxygen, Exhaust

P34 Potentiometer - Throttle Valve

P35 Impulse Sensor - Crankshaft

P46 Sensor - Knocking Control

P47 Sensor-Cramshaft

Y7 Injection Valves - Fuel

Y15 Valve - Secondary Air Injection
