Remove
Release wiring harness plug (2) from ignition module control unit and disconnect.
Remove fastening bolts (arrows) and detach DIS ignition module (1) from spark plugs.
Remove fastening bolts (arrows) and carefully detach ignition module control unit (3) from ignition module (4).
Remove
Remove fastening bolts (arrows).
Detach ignition module cover (2) from DIS ignition module (1).
Install
Attach ignition module cover to DIS ignition module using the fastening bolts.
Position ignition module control unit on DIS ignition module and attach to DIS ignition module using the fastening bolts.
Position DIS ignition module on spark plugs and fit to cylinder head cover with fastening bolts.
Tightening torque 9 Nm
Connect wiring harness plug to ignition module control unit and lock.
