Engine Management System GMPT-E15, Multec Block Diagram Opel Vectra B

Fuel Injection Systems 2 illustrations

Block Diagram, Multec

A4Engine control unit
ABSAnti–lock brake system
ACAir conditioning
B117Oxygen sensor for catalytic converter control
B118Oxygen sensor for exhaust emissions control
B12Coolant temperature sensor
B13Intake air temperature sensor
B19Accelerator pedal module
B21Intake pipe pressure sensor
B30Knock sensor
B34Crankshaft pulse pick–up
IDInformation display
IMOImmobiliser
INSInstruments
K16Fuel pump relay
K18Engine timing relay

1.12.4.7 Block Diagram, Multec

1.12.4.7 Block Diagram, Multec

FPFuel pump
ECEngine cooling
CMCUCooling module control unit
S1Starter switch
S28Clutch switch
S43Brake lamp switch
T1DIS ignition module
X2Instrument panel
X22Body wiring harness plug
X77Multec wiring harness plug
X78Control unit
Y29Throttle valve servo motor
Y4Exhaust gas recirculation valve
Y5Tank vent valve
Y9.1Injector, 1st cylinder
Y9.2Injector, 2nd cylinder
Y9.3Injector, 3rd cylinder
Y9.4Injector, 4th cylinder
