Replacing Atmospheric Pressure Sensor Opel Meriva A

Remove

1. 1. Open bonnet
2. 2. Disconnect battery • Detach ground clamp from ground terminal – Unscrew nut
3. 3. Raise vehicle all the way
4. 4. Remove atmospheric pressure sensor (1) • Disconnect wiring harness connector. • Unclip atmospheric pressure sensor from bracket in direction of arrow

Install

5. 5. Install atmospheric pressure sensor • Clip sensor into bracket • Connect wiring harness plug
6. 6. Lower vehicle all the way
7. 7. Connect battery • Attach ground clamp to ground terminal – Tighten nut
8. 8. Program volatile memory

Note. For vehicles with ESP - the steering angle sensor must be recalibrated each time the battery is disconnected. With the ignition on, rotate the steering wheel one time from its right-hand to its left-hand stop.

9. 9. Close bonnet
