| No. | Work operations | Designation | Mounting | torque |
|---|---|---|---|---|
| Number | ||||
| 1 | L002400 | Tank vent valve | ||
| 2 | J795200 | Camshaft sensor | Bolt | 6 Nm |
| 3 | J740500 | Coolant temperature sensor | ||
| 4 | J741100 | Boost pressure sensor | Bolt | 5 Nm |
| 5 | J794400 | Crankshaft pulse pick-up | Bolt | 8 Nm |
| 6 | J471000 | Charge pressure control solenoid valve |
| No. | Work operations | Designation | Mounting | torque |
|---|---|---|---|---|
| Number | ||||
| 1 | J 741000 | Hot film mass air flow meter | ||
| 2 | J 980500 | Catalytic converter control oxygen sensor (vehicle underside) | 40 Nm | |
| 3 | J 855510 | Injectors | Fuel manifold to intake manifold | 8 Nm |
| 4 | J 715100 | Ignition module | 8 Nm | |
| 5 | J 980400 | Mixture control oxygen sensor | 40 Nm | |
| 6 | J 740810 | Ambient pressure sensor |
| No. | Work operations | Designation | Mounting | torque |
|---|---|---|---|---|
| Number | ||||
| 1 | J 986510 | Vacuum reservoir solenoid valve | ||
| 2 | J795100 | Knock sensor | 20 Nm | |
| 3 | J 815500 | Accelerator pedal module (in passenger compartment) | 12 Nm | |
| 4 | J 852510 | Throttle valve module | 8 Nm | |
| 5 | J 745500 | Engine control unit |
