ECM Connector End Views Opel Agila B

Engine Control and Fuel System - K10B 1 illustration

Terminal Arrangement of Engine Control Module (ECM) Connectors

ECM Connector End Views

Note. The illustration shows end views of connector X1 (1) and connector X2 (2).

Connector: X1 (1)

Terminal	Circuit	Terminal	Circuit
1	Main power supply circuit 1	31	—
2	Back–up power supply circuit	32	—
3	CAN (high) communication circuit to ABS/ESP control module	33	—
4	Main relay drive circuit	34	—
5	—	35	—
6	Electric power steering (EPS) active (idle up) signal circuit	36	—
7	Electric load signal circuit (for heater motor)	37	—
8	Brake light switch signal circuit	38	—
9	—	39	—
10	—	40	—
11	Engine speed signal circuit (for EPS control module)	41	—
12	—	42	—
13	Clock signal circuit (for immobilizer control module)	43	—
14	Serial communication circuit (for immobilizer control module)	44	—
15	Fuel pump relay drive circuit	45	—
16	Main power supply circuit 2	46	Throttle motor control relay drive circuit
17	Throttle motor power supply circuit	47	A/C compressor relay drive circuit
18	CAN (low) communication circuit to ABS/ESP control module	48	Ignition switch signal circuit
19	—	49	A/C system temperature sensor signal circuit
20	—	50	A/C high pressure safety switch signal circuit
21	—	51	—
22	—	52	APP sensor (main) ground circuit
23	—	53	APP sensor (sub) ground circuit
24	Accelerator pedal position (APP) sensor (main) signal circuit	54	A/C high pressure safety switch ground circuit
25	APP sensor (sub) signal circuit	55	A/C system temperature sensor ground circuit
26	APP sensor (main) power supply circuit	56	—
27	APP sensor (sub) power supply circuit	57	APP sensor shield ground circuit
28	A/C high pressure safety switch power supply circuit	58	—
29	—	59	Radiator cooling fan relay No. 1 drive circuit
30	Starter motor relay ground circuit	60	Radiator cooling fan relay No. 2 and No. 3 drive circuit (Automatic transmission model only)

Connector: X2 (2)

Terminal	Circuit	Terminal	Circuit
1	Fuel injector No. 1 drive circuit	31	Mixture control oxygen sensor heater ground circuit
2	Fuel injector No. 2 drive circuit	32	Mixture control oxygen sensor heater drive circuit
3	CAN (low) communication circuit to transmission control module (TCM)	33	Mixture control oxygen sensor signal circuit (UN)
4	EGR valve drive circuit 1	34	Mixture control oxygen sensor signal circuit (VM)
5	Ignition coil No. 2 drive circuit	35	Mixture control oxygen sensor signal circuit (IP)
6	Ignition coil No. 1 drive circuit	36	Mixture control oxygen sensor signal circuit (IA)
7	—	37	—
8	—	38	Manifold absolute pressure (MAP) sensor signal circuit
9	—	39	Throttle position (TP) sensor (sub) signal circuit
10	—	40	TP sensor (main) signal circuit
11	—	41	Catalytic converter control oxygen sensor signal circuit
12	Mass air flow (MAF) meter signal circuit	42	MAP sensor power supply circuit
13	CAN (low) communication circuit to transmission control module (TCM)	43	TP sensor power supply circuit
14	CAN (high) communication circuit to TCM	44	Throttle motor drive circuit (close)
15	Engine control module (ECM) ground circuit 1	45	Throttle motor drive circuit (open)
16	Fuel injector No. 3 drive circuit	46	—
17	Fuel injector No. 4 drive circuit (K12B model only)	47	Catalytic converter control oxygen sensor heater drive circuit
18	EGR valve drive circuit 4	48	Fuel tank evaporation solenoid valve drive circuit
19	EGR valve drive circuit 3	49	—
20	Ignition coil No. 4 drive circuit (K12B model only)	50	—
21	Ignition coil No. 3 drive circuit	51	Mixture control oxygen sensor shield ground circuit
22	Camshaft (CMP) sensor signal circuit	52	Catalytic converter control oxygen sensor shield ground circuit
23	Crankshaft (CKP) sensor signal circuit	53	Knock sensor shield ground circuit
24	Engine coolant temperature (ECT) sensor signal circuit	54	TP sensor shield ground circuit
25	Intake air temperature (IAT) sensor signal circuit	55	TP sensor ground circuit
26	Knock sensor signal circuit	56	MAP sensor ground circuit
27	Knock sensor ground circuit	57	Catalytic converter control oxygen sensor ground circuit
28	MAF and IAT sensor ground circuit	58	ECT sensor ground circuit
29	Starter motor relay signal circuit	59	ECM ground circuit
30	ECM ground circuit 2	60	Throttle motor ground circuit
