Special Service Tools Opel Agila A

DOHC Diesel Engine 41 illustrations
KM-301Measuring bridge
For measuring piston projection
KM-412-AAssembly stand
Holding dismantled engine
KM-412-32Engine adapter
Engine mounting in conjunction with KM-412-A
KM-468-BHolding wrench
For counterholding wheel hub
KM-470-BAngled tightening wrench
Tightening screwed joints with angled wrench
KM-471Adapter
For checking cooling system under pressure together with cooling system tester
KM-498-BOil pressure gauge
For checking engine oil pressure together with KM-232
KM-507-CPusher tool
Pushing tie rod joint out of steering knuckle
MKM-596-ATemperature gauge
MKM-604-DTorx bit and socket set
For removing/installing Torx bolts/nuts
MKM-610Torque wrench 1/2"
Range: 30 - 130 Nm
KM-662-CHolding wrench
For counterholding belt pulley/crankshaft
MKM-669Torque wrench 1/2"
Range: 50 - 300 Nm
KM-796-ARemover
For opening quick-fittings of fuel system
KM-807Sealing bung
For sealing fuel lines
MKM-883-1Engine bridge
To hold / lower / lift engine
MKM-883-4Hook
Holding the engine with MKM-883-1
KM-904Base frame
For removing and installing engine with transmission
KM-955Locking pins
For blocking timing chain tensioner
KM-956Holding wrench
Correspondingly KM-956-1For counterholding belt pulley/crankshaft
KM-2358Wire ropes
Suspending the engine
KM-6015Sealing bung
Sealing the fuel lines
KM-6054Holding the engine
Installation and removal of the engine with transmission using KM-904 and KM-6056
KM-6056Engine bracket
Holding the engine when removing and installing the engine with transmission using KM-6054
KM-6103-AEngine bracket
Holding the engine when removing and installing the cylinder head and working on the engine timing side
KM-6130Fixing pin
For fixing ribbed V-belt tensioner in position
KM-6182-1Precision pliers
Removing/installing compact clamps
KM-6182-2Curved pliers
Removing/installing compact clamps
KM-6347Bracket
For holding camshaft sprockets to be loosened
For tightening fastening bolts together with KM-956-1
KM-6368Sealing bung
For sealing high pressure connections to pump, rail and injectors
KM-J-37228Separation Tool
To disconnect oil pan
EN-46775For centring cover on drive side during installation
EN-46776For installing seal ring, engine timing side
EN-46777For installing rear crankshaft seal ring
EN-46778Marking tool
Flywheel to cylinder block
EN-46781Camshaft locking device
For checking timing
EN-46782Check compression
Together with EN-46783
EN-46783Adapter
For checking compression together with EN-46782
EN-46785Marking tool
For checking TDC
EN-46786Remover
For removing injectors together with KM-328-B
EN-47632Cleaner
Cleaning the injector shaft
