Replace Timing Chain Opel Agila A

Remove

1. 1. Remove timing case
2. 2. Remove timing chain tensioner • Tension timing chain tensioner. Block in pretensioned position using KM-955 (1) • Unscrew 2x bolt (2)

3. 3. Remove timing chain tension rail • Remove bolt (1)

4. 4. Remove timing chain sliding rail (2) • Unscrew 2x bolt (1)

5. 5. Loosen camshaft drive gear • Remove bolt • Counterhold on the camshaft drive gear using KM-6347 (1) and KM-956-1 (2)

6. 6. Remove timing chain (1) with camshaft drive gear and crankshaft drive gear

Install

7. 7. Insert timing chain with camshaft drive gear and crankshaft drive gear
8. 8. Tighten camshaft drive gear • Tighten bolt 150 Nm • Counterhold on the camshaft drive gear using KM-6347 and KM-956-1
9. 9. Install timing chain sliding rail • Tighten 2x bolt 9 Nm
10. 10. Install timing chain tension rail • Tighten bolt 9 Nm
11. 11. Install timing chain tensioner • Tighten 2x bolt 9 Nm • Tension timing chain tensioner. Remove KM-955
12. 12. Install timing case
