Engine Control Module (ECM) Diagnostic Trouble Codes - 8 of 13: Other Volvo XC90 I

Testing & Diagnostics 8 illustrations ~21246 words

SIGNAL TOO HIGH

see SIGNAL TOO HIGH

VERIFICATION

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 279

Scheme 279
Scheme 279
  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine
  4. Ignition off
  5. Ignition on
  6. Read off the movement of the accelerator pedal by carefully depressing and releasing the accelerator pedal (AP). Check that the value changes with accelerator pedal movement. The value must be between approximately 0.4 V when the accelerator pedal (AP) is unaffected and approximately 4 V when the accelerator pedal (AP) is fully depressed. The fault has been remedied if the values are OK.

Are these values OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S31026588202012060500000)

FAULT-TRACING INFORMATION

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL TOO LOW

see SIGNAL TOO LOW

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

FAULTY SIGNAL

see FAULTY SIGNAL

CHECKING THE STATUS

  1. Ignition on
  2. Read off the movement of the accelerator pedal by carefully depressing and releasing the accelerator pedal (AP). Check that the value changes with accelerator pedal movement. The value must be approximately 0.4 V when the accelerator pedal (AP) is unaffected and approximately 4 V when the accelerator pedal (AP) is fully depressed. The fault is intermittent at the moment if the values are OK.
  1. Continue Refer to «CHECKING THE POWER SUPPLY»(ref-476773-S32557038412012060500000)

CHECKING THE POWER SUPPLY

  1. Ignition on. Check the power supply (12 V) to the accelerator pedal (AP) position sensor between accelerator pedal (AP) position sensor terminals #1 (wiring side) and #3 (wiring side). Check that the power supply is approximately 12 V with the ignition on Other information: see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000) To connect the breakout box, see «CONNECTING THE BREAKOUT BOX»(ref-476691-S38062545372012060500000) For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000) For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) . For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000) For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) . To access and replace the accelerator pedal (AP) position sensor, see «ACCELERATOR PEDAL (AP), REPLACING»(ref-476780-S18973143032012060500000) .

Is the power supply OK?

  1. YES Refer to «CHECKING THE WIRING»(ref-476773-S19316402072012060500000)
  2. NO Refer to «CHECKING THE CONNECTORS AND CABLES»(ref-476773-S36532175392012060500000)

CHECKING THE CONNECTORS AND CABLES

  1. Ignition off
  2. Check the accelerator pedal (AP) position sensor connector. Check for contact resistance and oxidation. Check the power supply cable (12 V) between accelerator pedal (AP) position sensor terminal #1 (wiring side) and the relevant fuse for the circuit. Check for a short-circuit to ground. Check for an open-circuit. Check that the fuse for the circuit has not blown. Check the ground lead for power supply (12 V) between accelerator pedal (AP) position sensor terminal #3 (wiring side) and the relevant ground terminal. Check for contact resistance and oxidation. Check for an open-circuit. HINT: With the ignition on, the power supply to the accelerator pedal (AP) position sensor must be approximately 12 V measured between accelerator pedal (AP) position sensor terminals #1 (wiring side) and #3 (wiring side). Remedy as necessary. Other information: see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000) To connect the breakout box, see «CONNECTING THE BREAKOUT BOX»(ref-476691-S38062545372012060500000) For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000) For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) . For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000) For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) . To access and replace the accelerator pedal (AP) position sensor, see «ACCELERATOR PEDAL (AP), REPLACING»(ref-476780-S18973143032012060500000) .
  1. Continue Refer to «CHECKING THE WIRING»(ref-476773-S19316402072012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Ignition on
  4. Read off the movement of the accelerator pedal by carefully depressing and releasing the accelerator pedal (AP). Check that the value changes with accelerator pedal movement. The value must be approximately 0.4 V when the accelerator pedal (AP) is unaffected and approximately 4 V when the accelerator pedal (AP) is fully depressed. The fault has been remedied if the values are OK.

Are these values OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S11511487932012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Ignition on
  2. Read off the movement of the accelerator pedal by carefully depressing and releasing the accelerator pedal (AP). Check that the value changes with accelerator pedal movement. The value must be approximately 0.4 V when the accelerator pedal (AP) is unaffected and approximately 4 V when the accelerator pedal (AP) is fully depressed. The fault is intermittent at the moment if the values are OK.
  1. Continue Refer to «CHECKING THE POWER SUPPLY»(ref-476773-S39658870952012060500000)
  1. Ignition on. Check the power supply (12 V) to the accelerator pedal (AP) position sensor between accelerator pedal (AP) position sensor terminals #1 (wiring side) and #3 (wiring side). Check that the power supply is approximately 12 V with the ignition on. Remedy as necessary. Other information: see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000) To connect the breakout box, see «CONNECTING THE BREAKOUT BOX»(ref-476691-S38062545372012060500000) For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000) For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) . For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000) For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) . To access and replace the accelerator pedal (AP) position sensor, see «ACCELERATOR PEDAL (AP), REPLACING»(ref-476780-S18973143032012060500000) .

Is the power supply OK?

  1. YES Refer to «CHECKING COMPONENTS AND WIRING»(ref-476773-S28170958892012060500000)
  2. NO Refer to «CHECKING THE CONNECTORS AND CABLES»(ref-476773-S03040299552012060500000)
  1. Ignition off
  2. Check the accelerator pedal (AP) position sensor connector. Check for contact resistance and oxidation. Check the power supply cable (12 V) between accelerator pedal (AP) position sensor terminal #1 (wiring side) and the relevant fuse for the circuit. Check for a short-circuit to ground. Check for an open-circuit. Check that the fuse for the circuit has not blown. Check the ground lead for power supply (12 V) between accelerator pedal (AP) position sensor terminal #3 (wiring side) and the relevant ground terminal. Check for contact resistance and oxidation. Check for an open-circuit. HINT: With the ignition on, the power supply to the accelerator pedal (AP) position sensor must be approximately 12 V measured between accelerator pedal (AP) position sensor terminals #1 (wiring side) and #3 (wiring side). Remedy as necessary. Other information: see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000) To connect the breakout box, see «CONNECTING THE BREAKOUT BOX»(ref-476691-S38062545372012060500000) For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000) For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) . For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000) For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) . To access and replace the accelerator pedal (AP) position sensor, see «ACCELERATOR PEDAL (AP), REPLACING»(ref-476780-S18973143032012060500000) .
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476773-S28170958892012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Ignition on
  4. Read off the movement of the accelerator pedal by carefully depressing and releasing the accelerator pedal (AP). Check that the value changes with accelerator pedal movement. The value must be approximately 0.4 V when the accelerator pedal (AP) is unaffected and approximately 4 V when the accelerator pedal (AP) is fully depressed. The fault has been remedied if the values are OK.

Are these values OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S12832129722012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL TOO HIGH

see SIGNAL TOO LOW

  1. Ignition off
  2. Check the accelerator pedal position sensor and engine control module (ECM) connectors. Check for contact resistance and oxidation. Check the signal cable between engine control module (ECM) terminal #B25 (#B35) and accelerator pedal (AP) position sensor terminal #2 (wiring side). Check for an open-circuit. Check for a short-circuit to supply voltage. Check for a short-circuit to ground. HINT: With the ignition on, the power supply to the accelerator pedal (AP) position sensor must be approximately 12 V measured between accelerator pedal (AP) position sensor terminals #1 and #3 (wiring side). Try a new accelerator pedal (AP) position sensor if no fault is found and the fault is permanent. Remedy as necessary. Other information: see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000) To connect the breakout box, see «CONNECTING THE BREAKOUT BOX»(ref-476691-S38062545372012060500000) For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000) For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) . For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000) For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) . To access and replace the accelerator pedal (AP) position sensor, see «ACCELERATOR PEDAL (AP), REPLACING»(ref-476780-S18973143032012060500000) .
  1. Continue Refer to «VERIFICATION»(ref-476773-S03754924242012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 280

Scheme 280: VERIFICATION
Scheme 280: VERIFICATION
  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine
  4. Read off diagnostic trouble codes (DTCs). The fault has been remedied if status of the diagnostic trouble code (DTC) is intermittent.

Is the status of the diagnostic trouble code (DTC) intermittent?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S41113226082012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see FAULTY SIGNAL

see FAULTY SIGNAL

  1. Ignition off
  2. Check the accelerator pedal position sensor and engine control module (ECM) connectors. Check for contact resistance and oxidation. Check the signal cable between engine control module (ECM) terminal #B25 (#B35) and accelerator pedal (AP) position sensor terminal #2 (cable harness side). Check for an open-circuit. Check for a short-circuit to supply voltage. Check for a short-circuit to ground. HINT: With the ignition on, the power supply to the accelerator pedal (AP) position sensor must be approximately 12 V measured between accelerator pedal (AP) position sensor terminals #1 and #3 (cable harness side). Try a new accelerator pedal (AP) position sensor if no fault is found and the fault is permanent. Remedy as necessary. Other information: see «CONNECTING THE BREAKOUT BOX»(ref-476691-S38062545372012060500000) For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000) For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) . For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000) For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) . see «ACCELERATOR PEDAL (AP), REPLACING»(ref-476780-S18973143032012060500000) see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S04466163492012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine
  4. Read off diagnostic trouble codes (DTCs). The fault has been remedied if status of the diagnostic trouble code (DTC) is intermittent.

Is the status of the diagnostic trouble code (DTC) intermittent?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S25145931352012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL MISSING

see SIGNAL MISSING

REPLACING THE COMPONENT

Note. The diagnostic trouble code (DTC) may be stored as a consequence of other faults. Check therefore if any other diagnostic trouble codes (DTCs) are stored for the engine control module (ECM). Remedy these first.

The engine control module (ECM) has registered an internal fault.

If the fault is intermittent, it has been registered previously but is no longer present. Intermittent faults can be caused by interference at start up of the engine control module (ECM) or may be a different type of fault which occurs on different occasions. The fault is evaluated depending on how it occurs.

see ENGINE CONTROL MODULE (ECM), REPLACING

Remedy as necessary.

  1. Continue Refer to «INFORMATION»(ref-476773-S05661965782012060500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

see INTERNAL FAULT

see FAULT-TRACING INFORMATION

INTERNAL FAULT. PERMANENT FAULT

see INTERNAL FAULT. PERMANENT FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see FAULT-TRACING INFORMATION

see INTERNAL FAULT. PERMANENT FAULT

Note. The diagnostic trouble code (DTC) may be stored as a result of foreign objects in the intake passages or contaminants in the electronic throttle unit. Check and remedy these first.

The engine control module (ECM) has registered an internal fault.

If the fault is intermittent, it has been registered previously but is no longer present. Intermittent faults can be caused by interference at start up of the engine control module (ECM) or may be a different type of fault which occurs on different occasions. The fault is evaluated depending on how it occurs.

see ENGINE CONTROL MODULE (ECM), REPLACING

Remedy as necessary.

  1. Continue Refer to «INFORMATION»(ref-476773-S37586863392012060500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

see INTERNAL FAULT

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

Remedy any diagnostic trouble codes (DTCs) that are stored.

Remedy as necessary.

PROGRAMMING OR REPLACING THE ENGINE CONTROL MODULE (ECM)

  1. Ignition off. The engine control module (ECM) has registered an internal fault. Replace the engine control module (ECM). See «ENGINE CONTROL MODULE (ECM), REPLACING»(ref-476695-S16000409902012060500000) . NOTE: After replacing the engine control module (ECM), the throttle unit must be adapted using the vehicle communication input: "Throttle unit adaptation". Remedy as necessary.
  1. Continue Refer to «INFORMATION»(ref-476773-S40718401022012060500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

see INTERNAL FAULT. PERMANENT FAULT

The engine control module (ECM) has registered an internal fault.

If the fault is intermittent, it has been registered previously but is no longer present. Intermittent faults can be caused by interference at start up of the engine control module (ECM) or may be a different type of fault which occurs on different occasions. The fault is evaluated depending on how it occurs. Replace the engine control module (ECM) if the fault recurs.

Replace the engine control module (ECM) in the event of a permanent fault.

Remedy as necessary.

Other information

  1. see «ENGINE CONTROL MODULE (ECM), REPLACING»(ref-476695-S16000409902012060500000)
  1. Continue Refer to «INFORMATION»(ref-476773-S18793497562012060500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

see FAULT-TRACING INFORMATION

see INTERNAL FAULT. PERMANENT FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see FAULT-TRACING INFORMATION

CHECKING THE INTAKE AND EXHAUST SYSTEM

Check the intake and exhaust system. Check for blockages.

Check the intake system for leakage.

Check the inside of the throttle body (TB). Check for contamination. When the throttle body (TB) is contaminated, the air flow to the engine is impaired and diagnostic trouble code (DTCs) or fault symptoms can occur.

Remedy as necessary.

Was a fault detected?

  1. YES Refer to «INFORMATION»(ref-476773-S11537159342012060500000)
  2. NO Refer to «PROGRAMMING OR REPLACING THE ENGINE CONTROL MODULE (ECM)»(ref-476773-S14104790182012060500000)
  1. Ignition off. The diagnostic trouble code may be stored because the Engine control module (ECM) is damaged. Remedy as necessary. Other information see «ENGINE CONTROL MODULE (ECM), REPLACING»(ref-476695-S16000409902012060500000)
  1. Continue Refer to «INFORMATION»(ref-476773-S11537159342012060500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see FAULT-TRACING INFORMATION

see INTERNAL FAULT. PERMANENT FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see FAULT-TRACING INFORMATION

see INTERNAL FAULT. PERMANENT FAULT

see FAULT-TRACING INFORMATION

see INTERNAL FAULT. PERMANENT FAULT

When this trouble code is stored, it indicates that Engine control module (ECM) has failed to control the idle RPM. Normally there are also trouble codes related to the air and fuel system stored together with this trouble code. Any diagnostic trouble codes that are stored should be fault traced first. If the cause is found with this troubleshooting, you can ignore this trouble code.

HINT: Incorrectly adapted throttle module may cause this trouble code to be stored alone. Carry out adaptation of the throttle unit to update the adaptation values using VIDA (Volvo scan tool)

see FAULTY SIGNAL

see FAULTY SIGNAL

see FAULTY SIGNAL

see FAULTY SIGNAL

see FAULTY SIGNAL

see FAULTY SIGNAL

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

CHECKING A SHORT-CIRCUIT IN CAN CABLES

Connect an ohmmeter between the relevant CAN cable (CAN-L and CAN-H) and the power supply, and between the CAN cable and ground. Twist the connectors and turn the cable harness to different positions at each reading to determine any intermittent short-circuits.

Take the following readings

  1. The resistance between CAN-L and ground
  2. The resistance between CAN-L and voltage
  3. The resistance between CAN-H and ground
  4. The resistance between CAN-H and voltage.

The resistance must be infinite or very high in all cases (greater than 1 Mohms).

HINT: The reading can be taken from the same connector if the CAN cables, power supply and ground are exposed. If possible, take readings on the rear of the connector to prevent damage to the terminals in the connector. If this is not possible, use the adapter wiring or loose terminal pins to obtain a good contact.

Was a fault detected?

  1. YES Refer to «IDENTIFYING FAULT CAUSES IN THE CAN NETWORK»(ref-476773-S17838683002012060500000)
  2. NO Refer to «CHECKING THE TRAFFIC LOAD ON THE CAN CABLES»(ref-476773-S30866593022012060500000)

CHECKING THE TRAFFIC LOAD ON THE CAN CABLES

  1. Connect the battery
  2. Ignition on Also read: «BATTERY, DISCONNECTING»(ref-476746-S00156360512012060500000) Faults in the CAN network may be due to a control module sending faulty messages that disrupt "normal" communication. When messages are sent incorrectly, this results in a considerable increase in the amount of traffic on the CAN network. Check the load by measuring the average voltage value on the CAN cables in relation to ground. Connect a voltmeter between CAN-L and ground. The voltage must be approximately 2.3 V. Then connect a voltmeter between CAN-H and ground. The voltage must be approximately 2.8 V. HINT: If possible measure from the rear of the affected connectors so that they are not damaged.

Is the value OK?

  1. YES Refer to «INFORMATION»(ref-476773-S19597597512012060500000)
  2. NO Refer to «IDENTIFYING A CONTROL MODULE IN THE CAN NETWORK»(ref-476773-S32742804032012060500000)

IDENTIFYING FAULT CAUSES IN THE CAN NETWORK

  1. Disconnect a control module that disconnects the CAN network (a control module that has four terminals to the CAN network). HINT: For the low speed network, suitable places for disconnecting the network are at the steering wheel module (SWM), the driver information module (DIM) or the climate control module (CCM). In the event of a short-circuit between one of the CAN cables and voltage or ground, the fault can be located by disconnecting a control module that disconnects the CAN network. Readings can then be taken to determine on which side of the disconnected control module the fault is located. Connect an ohmmeter between the CAN cable and supply voltage or ground. Take readings at both ends of the CAN network where the network is disconnected. Twist and bend the cable harness to locate any intermittent short-circuits. The resistance must be infinite or very high (greater than 1Mohms). If a fault can be localized in one direction, disconnect the network at a point further down on the CAN network in the direction in which the fault was discovered and repeat the reading. In this way, try to identify where in the network the fault might be located. HINT: A short-circuit between the CAN cables and supply voltage or ground may be in either the wiring or in a control module. Rectify the wiring as necessary. Replace the control module if the fault has been localized to a control module.
  1. Continue Refer to «VERIFICATION»(ref-476773-S10391567762012060500000)

IDENTIFYING A CONTROL MODULE IN THE CAN NETWORK

  1. Connect the battery Also read: «BATTERY, DISCONNECTING»(ref-476746-S00156360512012060500000)
  2. Ignition on If the load on the CAN network is too high, this may be due to a control module sending faulty messages on the CAN network (known as a disruptive control module). The fault may also be due to an intermittent short-circuit to supply voltage or ground in one of the CAN cables. This results in the control modules on the CAN network starting to send faulty messages. The faults can occur without a diagnostic trouble code (DTC) being stored by the control modules. The voltage can be measured between the CAN cables in order to check the load on the CAN network. Connect a voltmeter between the CAN cables. If the communication on the network is correct, the average voltage value should be approximately 0.5 V (0.4 V to 0.6 V). If there is a fault in the communication, the voltage reading will be approximately 0.7 V or higher. In order to identify from which control module the faulty communication is being transmitted, cut the supply voltage to one control module at a time and check the voltage in the CAN cables again. The easiest way to cut the supply voltage is to remove a fuse. Repeat until the voltage between the CAN cables drops to approximately 0.5 V. HINT: When the probable faulty control module has been identified, connect and disconnect the supply voltage to the control module a number of times to verify that the fault appears and disappears. NOTE: Do not cut the power to the central electronic module (CEM) unless it is the last control module left to check. The control module that is communicating incorrectly must be replaced. Remedy as necessary. NOTE: Following a fault involving "disruptive" control modules, other modules may remain in "Limp-Home mode" even after switching the ignition off and on a number of times. To remedy this, disconnect and reconnect the battery negative terminal to restore the control modules to normal function.
  1. Continue Refer to «VERIFICATION»(ref-476773-S10391567762012060500000)
  1. Disconnect a control module that disconnects the CAN network (a control module that has four terminals to the CAN network). HINT: For the low speed network, suitable places for disconnecting the network are at the steering wheel module (SWM), the driver information module (DIM) or the climate control module (CCM). In the event of an open-circuit or a short-circuit between the CAN cables, the fault can be localized by disconnecting a control module that disconnects the CAN network. Readings can then be taken to determine on which side of the disconnected control module the fault is located. Connect an ohmmeter between the CAN cables. Take readings at both ends of the CAN network where the network is disconnected. Twist and bend the cable harness to locate any intermittent short-circuits. The resistance must be 120 ohm. If a fault can be localized in one direction, disconnect the network at a point further down on the CAN network in the direction in which the fault was discovered and repeat the reading. In this way, try to identify where in the network the fault might be located. Remedy the cables as necessary.
  1. Continue Refer to «VERIFICATION»(ref-476773-S10391567762012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Reinstall the connectors, components, etc.
  2. Ignition on
  3. Erase diagnostic trouble codes using the VCT2000 (or appropriate scan tool)
  4. Start the car. Allow the car to run for 10 minutes.
  5. Read off diagnostic trouble codes (DTCs). Check if a diagnostic trouble codes (DTCs) for communication fault recurs in the central electronic module (CEM).

Does the diagnostic trouble code (DTC) recur?

  1. YES Refer to «INFORMATION»(ref-476773-S12061758672012060500000)
  2. NO OKAY: Troubleshooting has been completed.

Verification shows that the fault is no longer present. The diagnostic trouble code (DTC) was probably caused by an intermittent fault.

Fault-tracing for this diagnostic trouble code (DTC) is not followed by a verification.

You can view the information again or exit fault-tracing for this diagnostic trouble code (DTC).

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

FAULTY COMMUNICATION

see FAULTY COMMUNICATION

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Run the starter motor/start the engine.
  4. Read off the status from the ignition lock. Check that the read off status from the ignition lock corresponds to the actual position of the ignition lock.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S31665863302012060500000)

FAULT-TRACING

see FAULT-TRACING

TAKING READING ON CABLE IN THE CAN NETWORK (HS-CAN)

  1. Disconnect the battery negative lead.
  2. Connect the breakout box with the engine control module (ECM) connected. HINT: Where a breakout box cannot be used, take readings from the rear of the affected connectors if possible. This prevents terminal pins and socket housings being damaged. Take resistance readings across the following terminals. Various readings will be obtained due to the structure of the network. Twist the cable harness and work the connectors at accessible points along the cable harness in order to check whether the resistance changes during each measurement. This method can be used to detect intermittent short-circuits or open-circuits. NOTE: The following resistance readings only measure the main arteries in the high speed network, not the junctions that exist for some control modules. If an open-circuit is suspected in a cable, or a short-circuit is suspected in one of its junctions, the connector at the control module for this junction must be disconnected and the reading taken from there. Take the following readings Measure the resistance between the terminals for HS CAN on the Engine control module (ECM). Resistance must be approximately 60 ohms. Permitted values are approximately 55 - 65 ohms. NOTE: If there is a short-circuit somewhere in the CAN-net the resistance will be 0 ohms. Also measure the resistance between each terminal and supply voltage and ground. The resistance shall be very high. HINT: Any short-circuit detected on the CAN-net may be on the main circuit or on any branching running out to some control modules. If a fault is found, try to disconnect the junction with the fault at a point further forward. Try to locate the fault in this way. Remedy as necessary. Other information see «BATTERY, DISCONNECTING»(ref-476746-S00156360512012060500000) see «CONNECTING THE BREAKOUT BOX»(ref-476691-S30437390172012060500000) see «SIGNAL SPECIFICATION»(ref-476694-S14228516802012060500000) see «CHECKING WIRING AND TERMINALS»(ref-476689-S17655503092012060500000)

Was a fault detected?

  1. YES Refer to «VERIFICATION»(ref-476773-S19096031812012060500000)
  2. NO Refer to «CHECKING THE TRAFFIC LOAD ON THE CAN CABLES»(ref-476773-S39925148452012060500000)
  1. Connect the battery.
  2. Ignition on. Faults in the CAN network may be due to a control module sending faulty messages that disrupt normal communication. When messages are sent incorrectly, this results in a considerable increase in the amount of traffic on the CAN network. Check the load by measuring the average voltage value on the CAN cables in relation to ground. Check as follows: Connect a voltmeter between CAN-L and ground. The voltage should be approx: V Connect a voltmeter between CAN-H and ground. The voltage should be approx: V Other information see «BATTERY, DISCONNECTING»(ref-476746-S00156360512012060500000)

Is the value OK?

  1. YES Refer to «INFORMATION»(ref-476773-S37452092532012060500000)
  2. NO Refer to «IDENTIFYING A CONTROL MODULE IN THE CAN NETWORK»(ref-476773-S13115260232012060500000)

If the load on the CAN network is too high, this may be due to a control module sending faulty messages on the CAN network (known as a disruptive control module). The fault may also be due to an intermittent short-circuit to supply voltage or ground in one of the CAN cables. This results in the control modules on the CAN network starting to send faulty messages. The faults can occur without a diagnostic trouble code (DTC) being stored by the control modules. The voltage can be measured between the CAN cables in order to check the load on the CAN network.

Take the following readings

  1. Connect a voltmeter between the CAN cables. The average value of the voltage must be approximately 0.6-1.4 V. In case of a problem with communication the voltage is considerably higher.
  2. In order to identify which control module has faulty communication, cut the power supply to one control module at a time. Check the voltage in the CAN cables again. The easiest way to cut the power supply is to remove the fuse(s) for the relevant control module. Repeat until the voltage between the CAN wiring drops to the normal level.

Note. When connecting and disconnecting certain control modules, diagnostic trouble codes (DTCs) may be stored in other control modules.

HINT: When the suspected control module has been identified, connect and disconnect the supply voltage to the control module a number of times to verify that the fault appears and disappears. Ignition off between each check.

Note. Do not cut the power to the central electronic module (CEM) unless it is the last control module left to check.

A control module that is communicating incorrectly must be replaced. Remedy as necessary.

Note. Following a fault involving control modules that disrupt communication, other control modules may operate in Limp-Home mode (i. e. they work but with limited functionality) even after switching the ignition off and on a number of times. To remedy this, disconnect and reconnect the battery negative terminal to restore the control modules to normal function.

  1. Continue Refer to «VERIFICATION»(ref-476773-S19096031812012060500000)

HINT: Once a fault has been repaired, conduct a verification to check that the fault has been remedied.

  1. Reinstall the connectors, components etc.
  2. Ignition on
  3. Erase diagnostic trouble codes (DTCs) in all control modules
  4. Start the vehicle. Allow the vehicle to run for 10 minutes. Read out the diagnostic trouble codes in the vehicle via the DIAGNOSTICS tab.

Does the diagnostic trouble code (DTC) for faulty communication return?

  1. YES Refer to «INFORMATION»(ref-476773-S30255331172012060500000)
  2. NO OKAY: Troubleshooting has been completed.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Verification shows that the fault is no longer present. The diagnostic trouble code (DTC) was probably caused by an intermittent fault.

Fault-tracing for this diagnostic trouble code (DTC) is not followed by a verification.

You can view the information again or exit fault-tracing for this diagnostic trouble code (DTC).

see FAULT-TRACING

INFORMATION

No fault-tracing has been developed for this diagnostic trouble code (DTC).

The diagnostic trouble code (DTC) for this fault is first stored in the Central electronic module (CEM), then in the Engine control module (ECM). This diagnostic trouble code (DTC) can first be erased when the root fault has been remedied and the diagnostic trouble code (DTC) for the root fault has been erased.

For further information on this diagnostic trouble code, see Diagnostic trouble code (DTC) information.

see FAULT-TRACING

There is no fault-tracing for this diagnostic fault code (DTC).

For further information on this diagnostic trouble code, see Diagnostic trouble code (DTC) information.

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING

see FAULT-TRACING

see FAULTY COMMUNICATION

CHECKING COMPONENTS

Note. If the diagnostic trouble code (DTC) for correlation between the crankshaft position and camshaft position is stored, it must be fault-traced first.

HINT: Contaminants in the engine oil can damage components in the variable valve timing (VVT) unit which can cause function faults. In most cases the solenoid does not have to be replaced, cleaning is enough.

Check the engine oil grade. Check especially for contaminants.

Activate automatic cleaning function using the VCT2000 (or appropriate scan tool).

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by an internal fault in the variable valve timing (VVT) unit. If the above fault-tracing/remedies do not rectify the fault, the variable valve timing (VVT) unit may be damaged.

Remedy as necessary.

Other information

  1. Cleaning: «VARIABLE CAMSHAFT TIMING OIL CONTROL SOLENOID»(ref-476762-S39752382502012060500000)
  2. Removing, replacing, and installing: «VARIABLE CAMSHAFT TIMING OIL CONTROL SOLENOID»(ref-476775-S19489647692012060500000)
  3. see «LOCATION OF COMPONENTS»(ref-476766-S34089063632012060500000)

Scheme 281

Scheme 281
Scheme 281

Scheme 282

Scheme 282
Scheme 282
  1. Continue Refer to «VERIFICATION»(ref-476773-S16830476922012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

VERIFICATION, PART 1

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Verification consists of 2 parts. Part 1 is carried out via a test in the workshop. Part 2 is carried out on the road. If the function is determined as incorrect in part 1, then part 2 does not need to be carried out. If the function is determined as being correct in part 1 and the vehicle can be tested on the road, part 2 must be carried out. This is because in certain cases the function can be difficult the check in a workshop environment.
  2. Ignition off
  3. Reconnect the connectors, components, etc.
  4. Start and run the engine to operating temperature.
  5. Read off the shift angle of the camshaft and the desired shift angle of the camshaft to check the function. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476773-S40715028522012060500000)
  2. NO Refer to «INFORMATION»(ref-476773-S31467872932012060500000)

VERIFICATION, PART 2

  1. Test drive the car on the road. Use acceleration and engine braking. Repeat the procedure several times so that the camshaft control works and the engine control module (ECM) can carry out diagnostics.
  2. Connect VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  3. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S31467872932012060500000)

see FAULT-TRACING

Note. If the diagnostic trouble code (DTC) for correlation between the crankshaft position and camshaft position is stored, it must be fault-traced first.

HINT: Contaminants in the engine oil can damage components in the variable valve timing (VVT) unit which can cause function faults.

Check the engine oil grade. Check especially for contaminants.

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by an internal fault in the variable valve timing (VVT) unit. If the above fault-tracing/remedies do not rectify the fault, the variable valve timing (VVT) unit may be damaged.

Remedy as necessary.

Other information

  1. see «VVT UNIT, RIGHT CYLINDER HEAD»(ref-476775-S35498753212012060500000)
  2. see «VVT UNIT, LEFT CYLINDER HEAD»(ref-476775-S00445910052012060500000)
  3. see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S13455490712012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Verification consists of 2 parts. Part 1 is carried out via a test in the workshop. Part 2 is carried out on the road. If the function is determined as incorrect in part 1, then part 2 does not need to be carried out. If the function is determined as being correct in part 1 and the vehicle can be tested on the road, part 2 must be carried out. This is because in certain cases the function can be difficult the check in a workshop environment.
  2. Ignition off
  3. Reconnect the connectors, components, etc.
  4. Start and run the engine to operating temperature.
  5. Read off the shift angle of the camshaft and the desired shift angle of the camshaft to check the function. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476773-S20961617592012060500000)
  2. NO Refer to «INFORMATION»(ref-476773-S21145277512012060500000)
  1. Test drive the car on the road. Use acceleration and engine braking. Repeat the procedure several times so that the camshaft control works and the engine control module (ECM) can carry out diagnostics.
  2. Connect VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  3. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S21145277512012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Note. If the diagnostic trouble code (DTC) for correlation between the crankshaft position and camshaft position is stored, it must be fault-traced first.

HINT: Incorrect oil grade can cause malfunctions in the variable valve timing (VVT) unit. Contaminants in the engine oil can cause damage to components in the variable valve timing (VVT) unit. In most cases the solenoid does not have to be replaced, cleaning is enough.

Check the engine oil grade. Check especially for contaminants.

Activate automatic cleaning function using the VCT2000 (or appropriate scan tool).

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Check the engine oil pressure.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by an internal fault in the variable valve timing (VVT) unit. If the above fault-tracing/remedies do not rectify the fault, the variable valve timing (VVT) unit may be damaged.

Remedy as necessary.

Other information

  1. Cleaning: «VARIABLE CAMSHAFT TIMING OIL CONTROL SOLENOID»(ref-476762-S39752382502012060500000)
  2. Removing, replacing, and installing: «VARIABLE CAMSHAFT TIMING OIL CONTROL SOLENOID»(ref-476775-S19489647692012060500000)
  3. see «LOCATION OF COMPONENTS»(ref-476766-S34089063632012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S28320069562012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Verification consists of 2 parts. Part 1 is carried out via a test in the workshop. Part 2 is carried out on the road. If the function is determined as incorrect in part 1, then part 2 does not need to be carried out. If the function is determined as being correct in part 1 and the vehicle can be tested on the road, part 2 must be carried out. This is because in certain cases the function can be difficult the check in a workshop environment.
  2. Ignition off
  3. Reconnect the connectors, components, etc.
  4. Start and run the engine to operating temperature.
  5. Read off the shift angle of the camshaft and the desired shift angle of the camshaft to check the function. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476773-S08275179002012060500000)
  2. NO Refer to «INFORMATION»(ref-476773-S18486641642012060500000)
  1. Test drive the car on the road. Use acceleration and engine braking. Repeat the procedure several times so that the camshaft control works and the engine control module (ECM) can carry out diagnostics.
  2. Connect VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  3. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S18486641642012060500000)

see FAULT-TRACING

Note. If the diagnostic trouble code (DTC) for correlation between the crankshaft position and camshaft position is stored, it must be fault-traced first.

HINT: Incorrect oil grade can cause malfunctions in the variable valve timing (VVT) unit. Contaminants in the engine oil can cause damage to components in the variable valve timing (VVT) unit.

Check the engine oil grade. Check especially for contaminants.

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Check the engine oil pressure.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by an internal fault in the variable valve timing (VVT) unit. If the above fault-tracing/remedies do not rectify the fault, the variable valve timing (VVT) unit may be damaged.

Remedy as necessary.

Other information

  1. see «OIL PRESSURE, CHECKING»(ref-476770-S17127498902012060500000)
  2. see «VVT UNIT, RIGHT CYLINDER HEAD»(ref-476775-S35498753212012060500000)
  3. see «VVT UNIT, LEFT CYLINDER HEAD»(ref-476775-S00445910052012060500000)
  4. see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S01321135742012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Verification consists of 2 parts. Part 1 is carried out via a test in the workshop. Part 2 is carried out on the road. If the function is determined as incorrect in part 1, then part 2 does not need to be carried out. If the function is determined as being correct in part 1 and the vehicle can be tested on the road, part 2 must be carried out. This is because in certain cases the function can be difficult the check in a workshop environment.
  2. Ignition off
  3. Reconnect the connectors, components, etc.
  4. Start and run the engine to operating temperature.
  5. Read off the shift angle of the camshaft and the desired shift angle of the camshaft to check the function. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476773-S12085408552012060500000)
  2. NO Refer to «INFORMATION»(ref-476773-S04979923482012060500000)
  1. Test drive the car on the road. Use acceleration and engine braking. Repeat the procedure several times so that the camshaft control works and the engine control module (ECM) can carry out diagnostics.
  2. Connect VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  3. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S04979923482012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

Note. If the diagnostic trouble code (DTC) for correlation between the crankshaft position and camshaft position is stored, it must be fault-traced first.

HINT: Incorrect oil grade can cause malfunctions in the variable valve timing (VVT) unit. Contaminants in the engine oil can cause damage to components in the variable valve timing (VVT) unit.

Check the engine oil grade. Check especially for contaminants.

HINT: The variable valve timing (VVT) unit for the exhaust camshaft has a spring which turns the camshaft at control. This means that if the oil pressure becomes too low for the continuous variable valve timing unit, the spring controls the camshaft out too much.

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Check the engine oil pressure.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by an internal fault in the variable valve timing (VVT) unit. If the above fault-tracing/remedies do not rectify the fault, the variable valve timing (VVT) unit may be damaged.

Remedy as necessary.

Other information

  1. see «OIL PRESSURE, CHECKING»(ref-476770-S17127498902012060500000)
  2. see «VVT UNIT EXHAUST CAMSHAFT, REPLACING»(ref-476775-S12438293002012060500000)
  3. see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S31914006222012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Verification consists of 2 parts. Part 1 is carried out via a test in the workshop. Part 2 is carried out on the road. If the function is determined as incorrect in part 1, then part 2 does not need to be carried out. If the function is determined as being correct in part 1 and the vehicle can be tested on the road, part 2 must be carried out. This is because in certain cases the function can be difficult the check in a workshop environment.
  2. Ignition off
  3. Reconnect the connectors, components, etc.
  4. Start and run the engine to operating temperature.
  5. Read off the shift angle of the camshaft and the desired shift angle of the camshaft to check the function. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476773-S35469439582012060500000)
  2. NO Refer to «INFORMATION»(ref-476773-S06224734342012060500000)
  1. Test drive the car on the road. Use acceleration and engine braking. Repeat the procedure several times so that the camshaft control works and the engine control module (ECM) can carry out diagnostics.
  2. Connect VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  3. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S06224734342012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Note. If the diagnostic trouble code (DTC) for correlation between the crankshaft position and camshaft position is stored, it must be fault-traced first.

HINT: Contaminants in the engine oil can cause damage to components in the variable valve timing (VVT) unit.

Check the engine oil grade. Check especially for contaminants.

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by an internal fault in the variable valve timing (VVT) unit. If the above fault-tracing/remedies do not rectify the fault, the variable valve timing (VVT) unit may be damaged.

Remedy as necessary.

Other information

  1. see «VVT UNIT EXHAUST CAMSHAFT, REPLACING»(ref-476775-S12438293002012060500000)
  2. see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S09338993992012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Verification consists of 2 parts. Part 1 is carried out via a test in the workshop. Part 2 is carried out on the road. If the function is determined as incorrect in part 1, then part 2 does not need to be carried out. If the function is determined as being correct in part 1 and the vehicle can be tested on the road, part 2 must be carried out. This is because in certain cases the function can be difficult the check in a workshop environment.
  2. Ignition off
  3. Reconnect the connectors, components, etc.
  4. Start and run the engine to operating temperature.
  5. Read off the shift angle of the camshaft and the desired shift angle of the camshaft to check the function. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476773-S33528590742012060500000)
  2. NO Refer to «INFORMATION»(ref-476773-S35747949522012060500000)
  1. Test drive the car on the road. Use acceleration and engine braking. Repeat the procedure several times so that the camshaft control works and the engine control module (ECM) can carry out diagnostics.
  2. Connect VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  3. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S35747949522012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Read off the adaption for the camshaft, the camshaft shift angle and desired value for the camshaft shift angle. Check that the read off values correspond to the guide values below. The difference between the camshaft shift angle and the desired value for camshaft shift angle can be read off from the lower digital display. Note the read off values as a basis for continuing fault-tracing. Adaption camshaft Intake camshaft: 75 degrees CA (camshaft angle) (+/-8 degrees CA) Camshaft shift angle The difference from the desired value of the camshaft shift angle (intake): approximately 8 degrees CA The fault is permanent if the values are not correct. If the values are correct, this indicates that the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS»(ref-476773-S23971118192012060500000)

HINT: Incorrect function on the camshaft reset valve is probably the cause of this diagnostic trouble code (DTC) if

  1. The adaption value and camshaft shift angle are correct in the previous check (intermittent fault).
  2. The adaption value is correct but the camshaft shift angle is incorrect in the previous check.

HINT: Contaminants in the engine oil can damage components in the camshaft control which can cause function faults.

Check the engine oil grade. Check especially for contaminants.

Check the default settings of the camshafts.

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by a damaged variable valve timing (VVT) unit.

Remedy as necessary.

Other information

  1. To check the camshaft settings: see «VVT UNIT»(ref-476775-S09676422072012060500000)
  2. Cleaning: «VARIABLE CAMSHAFT TIMING OIL CONTROL SOLENOID»(ref-476762-S39752382502012060500000)
  3. see «LOCATION OF COMPONENTS»(ref-476766-S34089063632012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S22694305242012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

HINT: In order to verify this diagnostic trouble code (DTC), adaptation of the camshaft must be completed. Adaptation of the camshaft is carried out by the engine control module (ECM) when the engine is at operating temperature, during engine braking (fuel shut-off) above 1500 RPM for at least 10 seconds.

CAUTIONTest driving on the road must be carried out on a road with minimal traffic. Follow the highway code.
  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Start and run the engine to operating temperature.
  4. Drive the vehicle on the road. Ensure that the conditions for camshaft adaptation are met: engine braking (fuel shut-off) above 1500 RPM for at least 10 seconds. The conditions can be satisfied for example by driving the vehicle with a high engine load (accelerating) up to approximately 90 km/h and then releasing the accelerator pedal for 10 seconds. NOTE: In order for the adaptation to be carried out, the accelerator pedal must not be touched during engine braking.
  5. Repeat the schedule to ensure that the diagnosis and adaptation are carried out.
  6. Connect VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  7. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check that the diagnostic status for the diagnostic trouble code (DTC) is "Completed". When the diagnostic status for the diagnostic trouble code (DTC) is "Completed", the engine control module (ECM) has carried out camshaft adaption. If the status is "Not completed" the test drive must be carried out again. If the function is correct, the fault status must be "No fault found" when the diagnostic is complete. Check that the value for camshaft adaption is correct when the diagnostic status for the diagnostic trouble code (DTC) is "Completed". Inlet camshaft: 75° CA (camshaft angle) (+/-8° CA)

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476773-S09521137242012060500000)
  2. NO Refer to «INFORMATION»(ref-476773-S41050859812012060500000)
  1. Engine running.
  2. Check the function. Read off the shift angle of the camshaft and the desired shift angle of the camshaft. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S41050859812012060500000)

see FAULT-TRACING

HINT: The diagnostic trouble code (DTC) specifies the relevant camshaft.

  1. ECM-P001600: Camshaft inlet, bank 1. Bank 1 (cylinder row nearest the front): cylinders 1, 3, 5 and 7. Bank 2 (cylinder row furthest to the rear, nearest the passenger compartment): cylinders 2, 4, 6, and 8.
  2. ECM-P001700: Camshaft exhaust, bank 1. Bank 1 (cylinder row nearest the front): cylinders 1, 3, 5 and 7. Bank 2 (cylinder row furthest to the rear, nearest the passenger compartment): cylinders 2, 4, 6, and 8.
  3. ECM-P001800: Camshaft inlet, bank 2. Bank 1 (cylinder row nearest the front): cylinders 1, 3, 5 and 7. Bank 2 (cylinder row furthest to the rear, nearest the passenger compartment): cylinders 2, 4, 6, and 8.
  4. ECM-P001900: Camshaft exhaust, bank 2. Bank 1 (cylinder row nearest the front): cylinders 1, 3, 5 and 7. Bank 2 (cylinder row furthest to the rear, nearest the passenger compartment): cylinders 2, 4, 6, and 8.
  1. Start the engine.
  2. Read off the adaption for the camshaft, the camshaft shift angle and desired value for the camshaft shift angle. Check that the read off values correspond to the guide values below. The difference between the camshaft shift angle and the desired value for camshaft shift angle can be read off from the lower digital display. Note the read off values as a basis for continuing fault-tracing. Adaption camshaft Inlet camshaft: 75° CA (camshaft angle) (+/-8° CA) Exhaust camshaft: 120° CA (+/-8° CA) Camshaft shift angle The difference from the desired value of the camshaft shift angle (inlet and exhaust): approximately 8° CA The fault is permanent if the values are not correct. If the values are correct, this indicates that the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS»(ref-476773-S22539972832012060500000)

HINT: Incorrect function on the camshaft reset valve is probably the cause of this diagnostic trouble code (DTC) if

  1. The adaption value and camshaft shift angle are correct in the previous check (intermittent fault).
  2. The adaption value is correct but the camshaft shift angle is incorrect in the previous check.

HINT: Contaminants in the engine oil can damage components in the camshaft control which can cause function faults.

Check the engine oil grade. Check especially for contaminants.

Check the default settings of the camshafts.

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by a damaged variable valve timing (VVT) unit.

Remedy as necessary.

Other information

  1. see «VVT UNIT, RIGHT CYLINDER HEAD»(ref-476775-S35498753212012060500000)
  2. see «VVT UNIT, LEFT CYLINDER HEAD»(ref-476775-S00445910052012060500000)
  3. see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S38422049822012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

HINT: In order to verify this diagnostic trouble code (DTC), adaptation of the camshaft must be completed. Adaptation of the camshaft is carried out by the engine control module (ECM) when the engine is at operating temperature, during engine braking (fuel shut-off) above 1500 RPM for at least 10 seconds.

CAUTIONTest driving on the road must be carried out on a road with minimal traffic. Follow the highway code.
  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Start and run the engine to operating temperature.
  4. Drive the vehicle on the road. Ensure that the conditions for camshaft adaptation are met: engine braking (fuel shut-off) above 1500 RPM for at least 10 seconds. The conditions can be satisfied for example by driving the vehicle with a high engine load (accelerating) up to approximately 90 km/h and then releasing the accelerator pedal for 10 seconds. NOTE: In order for the adaptation to be carried out, the accelerator pedal must not be touched during engine braking.
  5. Repeat the schedule to ensure that the diagnosis and adaptation are carried out.
  6. Connect VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  7. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check that the diagnostic status for the diagnostic trouble code (DTC) is "Completed". When the diagnostic status for the diagnostic trouble code (DTC) is "Completed", the engine control module (ECM) has carried out camshaft adaption. If the status is "Not completed" the test drive must be carried out again. If the function is correct, the fault status must be "No fault found" when the diagnostic is complete. Check that the value for camshaft adaption is correct when the diagnostic status for the diagnostic trouble code (DTC) is "Completed". Inlet camshaft: 75° CA (camshaft angle) (+/-8° CA) Exhaust camshaft: 120° CA (+/-8° CA)

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476773-S14225633692012060500000)
  2. NO Refer to «INFORMATION»(ref-476773-S20240691712012060500000)
  1. Engine running.
  2. Check the function. Read off the shift angle of the camshaft and the desired shift angle of the camshaft. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S20240691712012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: Sensor A covers the intake camshaft. Sensor B covers the exhaust camshaft.

  1. Start the engine.
  2. Read off the adaption for the camshaft, the camshaft shift angle and desired value for the camshaft shift angle. Check that the read off values correspond to the guide values below. The difference between the camshaft shift angle and the desired value for camshaft shift angle can be read off from the lower digital display. Note the read off values as a basis for continuing fault-tracing. Adaption camshaft Inlet camshaft: 75° CA (camshaft angle) (+/-8° CA) Exhaust camshaft: 120° CA (+/-8° CA) Camshaft shift angle The difference from the desired value of the camshaft shift angle (inlet and exhaust): approximately 8° CA The fault is permanent if the values are not correct. If the values are correct, this indicates that the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS»(ref-476773-S01181785102012060500000)

HINT: Incorrect function on the camshaft reset valve is probably the cause of this diagnostic trouble code (DTC) if

  1. The adaption value and camshaft shift angle are correct in the previous check (intermittent fault).
  2. The adaption value is correct but the camshaft shift angle is incorrect in the previous check.

HINT: Contaminants in the engine oil can damage components in the camshaft control which can cause function faults.

Check the engine oil grade. Check especially for contaminants.

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by a damaged variable valve timing (VVT) unit.

Remedy as necessary.

Other information

  1. see «VVT UNIT, RIGHT CYLINDER HEAD»(ref-476775-S35498753212012060500000)
  2. see «VVT UNIT, LEFT CYLINDER HEAD»(ref-476775-S00445910052012060500000)
  3. see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S38686021262012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

HINT: In order to verify this diagnostic trouble code (DTC), adaptation of the camshaft must be completed. Adaptation of the camshaft is carried out by the engine control module (ECM) when the engine is at operating temperature, during engine braking (fuel shut-off) above 1500 RPM for at least 10 seconds.

CAUTIONTest driving on the road must be carried out on a road with minimal traffic. Follow the highway code.
  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Start and run the engine to operating temperature.
  4. Drive the vehicle on the road. Ensure that the conditions for camshaft adaptation are met: engine braking (fuel shut-off) above 1500 RPM for at least 10 seconds. The conditions can be satisfied for example by driving the vehicle with a high engine load (accelerating) up to approximately 90 km/h and then releasing the accelerator pedal for 10 seconds. NOTE: In order for the adaptation to be carried out, the accelerator pedal must not be touched during engine braking.
  5. Repeat the schedule to ensure that the diagnosis and adaptation are carried out.
  6. Connect VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  7. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check that the diagnostic status for the diagnostic trouble code (DTC) is "Completed". When the diagnostic status for the diagnostic trouble code (DTC) is "Completed", the engine control module (ECM) has carried out camshaft adaption. If the status is "Not completed" the test drive must be carried out again. If the function is correct, the fault status must be "No fault found" when the diagnostic is complete. Check that the value for camshaft adaption is correct when the diagnostic status for the diagnostic trouble code (DTC) is "Completed". Inlet camshaft: 75° CA (camshaft angle) (+/-8° CA) Exhaust camshaft: 120° CA (+/-8° CA)

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476773-S24973449072012060500000)
  2. NO Refer to «INFORMATION»(ref-476773-S23953473402012060500000)
  1. Engine running.
  2. Check the function. Read off the shift angle of the camshaft and the desired shift angle of the camshaft. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S23953473402012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

HINT: Sensor A covers the intake camshaft. Sensor B covers the exhaust camshaft.

  1. Start the engine.
  2. Read off the adaption for the camshaft, the camshaft shift angle and desired value for the camshaft shift angle. Check that the read off values correspond to the guide values below. The difference between the camshaft shift angle and the desired value for camshaft shift angle can be read off from the lower digital display. Note the read off values as a basis for continuing fault-tracing. Adaption camshaft Inlet camshaft: 75° CA (camshaft angle) (+/-8° CA) Exhaust camshaft: 120° CA (+/-8° CA) Camshaft shift angle The difference from the desired value of the camshaft shift angle (inlet and exhaust): approximately 8° CA The fault is permanent if the values are not correct. If the values are correct, this indicates that the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS»(ref-476773-S35330773082012060500000)

HINT: Incorrect function on the camshaft reset valve is probably the cause of this diagnostic trouble code (DTC) if

  1. The adaption value and camshaft shift angle are correct in the previous check (intermittent fault).
  2. The adaption value is correct but the camshaft shift angle is incorrect in the previous check.

HINT: Contaminants in the engine oil can damage components in the camshaft control which can cause function faults.

Check the engine oil grade. Check especially for contaminants.

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by a damaged variable valve timing (VVT) unit.

Remedy as necessary.

Other information

  1. see «VVT UNIT, RIGHT CYLINDER HEAD»(ref-476775-S35498753212012060500000)
  2. see «VVT UNIT, LEFT CYLINDER HEAD»(ref-476775-S00445910052012060500000)
  3. see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S09864458782012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

HINT: In order to verify this diagnostic trouble code (DTC), adaptation of the camshaft must be completed. Adaptation of the camshaft is carried out by the engine control module (ECM) when the engine is at operating temperature, during engine braking (fuel shut-off) above 1500 RPM for at least 10 seconds.

CAUTIONTest driving on the road must be carried out on a road with minimal traffic. Follow the highway code.
  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Start and run the engine to operating temperature.
  4. Drive the vehicle on the road. Ensure that the conditions for camshaft adaptation are met: engine braking (fuel shut-off) above 1500 RPM for at least 10 seconds. The conditions can be satisfied for example by driving the vehicle with a high engine load (accelerating) up to approximately 90 km/h and then releasing the accelerator pedal for 10 seconds. NOTE: In order for the adaptation to be carried out, the accelerator pedal must not be touched during engine braking.
  5. Repeat the schedule to ensure that the diagnosis and adaptation are carried out.
  6. Connect VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  7. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check that the diagnostic status for the diagnostic trouble code (DTC) is "Completed". When the diagnostic status for the diagnostic trouble code (DTC) is "Completed", the engine control module (ECM) has carried out camshaft adaption. If the status is "Not completed" the test drive must be carried out again. If the function is correct, the fault status must be "No fault found" when the diagnostic is complete. Check that the value for camshaft adaption is correct when the diagnostic status for the diagnostic trouble code (DTC) is "Completed". Inlet camshaft: 75° CA (camshaft angle) (+/-8° CA) Exhaust camshaft: 120° CA (+/-8° CA)

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476773-S16600952102012060500000)
  2. NO Refer to «INFORMATION»(ref-476773-S25464744362012060500000)
  1. Engine running.
  2. Check the function. Read off the shift angle of the camshaft and the desired shift angle of the camshaft. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S25464744362012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: The diagnostic trouble code (DTC) specifies the relevant camshaft.

  1. ECM-P001600: Camshaft inlet, bank 1. Bank 1 (cylinder row nearest the front): cylinders 1, 3, 5 and 7. Bank 2 (cylinder row furthest to the rear, nearest the passenger compartment): cylinders 2, 4, 6, and 8.
  2. ECM-P001700: Camshaft exhaust, bank 1. Bank 1 (cylinder row nearest the front): cylinders 1, 3, 5 and 7. Bank 2 (cylinder row furthest to the rear, nearest the passenger compartment): cylinders 2, 4, 6, and 8.
  3. ECM-P001800: Camshaft inlet, bank 2. Bank 1 (cylinder row nearest the front): cylinders 1, 3, 5 and 7. Bank 2 (cylinder row furthest to the rear, nearest the passenger compartment): cylinders 2, 4, 6, and 8.
  4. ECM-P001900: Camshaft exhaust, bank 2. Bank 1 (cylinder row nearest the front): cylinders 1, 3, 5 and 7. Bank 2 (cylinder row furthest to the rear, nearest the passenger compartment): cylinders 2, 4, 6, and 8.
  1. Start the engine.
  2. Read off the adaption for the camshaft, the camshaft shift angle and desired value for the camshaft shift angle. Check that the read off values correspond to the guide values below. The difference between the camshaft shift angle and the desired value for camshaft shift angle can be read off from the lower digital display. Note the read off values as a basis for continuing fault-tracing. Adaption camshaft Inlet camshaft: 75° CA (camshaft angle) (+/-8° CA) Exhaust camshaft: 120° CA (+/-8° CA) Camshaft shift angle The difference from the desired value of the camshaft shift angle (inlet and exhaust): approximately 8° CA The fault is permanent if the values are not correct. If the values are correct, this indicates that the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS»(ref-476773-S39765794782012060500000)

HINT: Incorrect function on the camshaft reset valve is probably the cause of this diagnostic trouble code (DTC) if

  1. The adaption value and camshaft shift angle are correct in the previous check (intermittent fault).
  2. The adaption value is correct but the camshaft shift angle is incorrect in the previous check.

HINT: Contaminants in the engine oil can damage components in the camshaft control which can cause function faults.

Check the engine oil grade. Check especially for contaminants.

Check the default settings of the camshafts.

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by a damaged variable valve timing (VVT) unit.

Remedy as necessary.

Other information

  1. see «VVT UNIT, RIGHT CYLINDER HEAD»(ref-476775-S35498753212012060500000)
  2. see «VVT UNIT, LEFT CYLINDER HEAD»(ref-476775-S00445910052012060500000)
  3. see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S17239405672012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

HINT: In order to verify this diagnostic trouble code (DTC), adaptation of the camshaft must be completed. Adaptation of the camshaft is carried out by the engine control module (ECM) when the engine is at operating temperature, during engine braking (fuel shut-off) above 1500 RPM for at least 10 seconds.

CAUTIONTest driving on the road must be carried out on a road with minimal traffic. Follow the highway code.
  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Start and run the engine to operating temperature.
  4. Drive the vehicle on the road. Ensure that the conditions for camshaft adaptation are met: engine braking (fuel shut-off) above 1500 RPM for at least 10 seconds. The conditions can be satisfied for example by driving the vehicle with a high engine load (accelerating) up to approximately 90 km/h and then releasing the accelerator pedal for 10 seconds. NOTE: In order for the adaptation to be carried out, the accelerator pedal must not be touched during engine braking.
  5. Repeat the schedule to ensure that the diagnosis and adaptation are carried out.
  6. Connect VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  7. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check that the diagnostic status for the diagnostic trouble code (DTC) is "Completed". When the diagnostic status for the diagnostic trouble code (DTC) is "Completed", the engine control module (ECM) has carried out camshaft adaption. If the status is "Not completed" the test drive must be carried out again. If the function is correct, the fault status must be "No fault found" when the diagnostic is complete. Check that the value for camshaft adaption is correct when the diagnostic status for the diagnostic trouble code (DTC) is "Completed". Inlet camshaft: 75° CA (camshaft angle) (+/-8° CA) Exhaust camshaft: 120° CA (+/-8° CA)

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476773-S02890328532012060500000)
  2. NO Refer to «INFORMATION»(ref-476773-S12293168642012060500000)
  1. Engine running.
  2. Check the function. Read off the shift angle of the camshaft and the desired shift angle of the camshaft. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S12293168642012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine.
  2. Read off the adaption for the camshaft, the camshaft shift angle and desired value for the camshaft shift angle. Check that the read off values correspond to the guide values below. The difference between the camshaft shift angle and the desired value for camshaft shift angle can be read off from the lower digital display. Note the read off values as a basis for continuing fault-tracing. Adaption camshaft Intake camshaft: 75 degrees CA (camshaft angle) (+/-8 degrees CA) Camshaft shift angle The difference from the desired value of the camshaft shift angle (intake): approximately 8 degrees CA The fault is permanent if the values are not correct. If the values are correct, this indicates that the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS»(ref-476773-S17450602102012060500000)

HINT: Incorrect function on the camshaft reset valve is probably the cause of this diagnostic trouble code (DTC) if

  1. The adaption value and camshaft shift angle are correct in the previous check (intermittent fault).
  2. The adaption value is correct but the camshaft shift angle is incorrect in the previous check.

HINT: Contaminants in the engine oil can damage components in the camshaft control which can cause function faults.

Check the engine oil grade. Check especially for contaminants.

Check the default settings of the camshafts.

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault could be caused by a damaged VVT unit or over meshing of the camshaft transmission.

Remedy as necessary.

Other information

  1. To check the camshaft settings: see «VVT UNIT»(ref-476775-S09676422072012060500000)
  2. Cleaning: «VARIABLE CAMSHAFT TIMING OIL CONTROL SOLENOID»(ref-476762-S39752382502012060500000)
  3. see «LOCATION OF COMPONENTS»(ref-476766-S34089063632012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S27280211472012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

HINT: In order to verify this diagnostic trouble code (DTC), adaptation of the camshaft must be completed. Adaptation of the camshaft is carried out by the engine control module (ECM) when the engine is at operating temperature, during engine braking (fuel shut-off) above 1500 RPM for at least 10 seconds.

CAUTIONTest driving on the road must be carried out on a road with minimal traffic. Follow the highway code.
  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Start and run the engine to operating temperature.
  4. Drive the vehicle on the road. Ensure that the conditions for camshaft adaptation are met: engine braking (fuel shut-off) above 1500 RPM for at least 10 seconds. The conditions can be satisfied for example by driving the vehicle with a high engine load (accelerating) up to approximately 90 km/h and then releasing the accelerator pedal for 10 seconds. NOTE: In order for the adaptation to be carried out, the accelerator pedal must not be touched during engine braking.
  5. Repeat the schedule to ensure that the diagnosis and adaptation are carried out.
  6. Connect VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  7. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check that the diagnostic status for the diagnostic trouble code (DTC) is "Completed". When the diagnostic status for the diagnostic trouble code (DTC) is "Completed", the engine control module (ECM) has carried out camshaft adaption. If the status is "Not completed" the test drive must be carried out again. If the function is correct, the fault status must be "No fault found" when the diagnostic is complete. Check that the value for camshaft adaption is correct when the diagnostic status for the diagnostic trouble code (DTC) is "Completed". Inlet camshaft: 75° CA (camshaft angle) (+/-8° CA)

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476773-S23521364742012060500000)
  2. NO Refer to «INFORMATION»(ref-476773-S14308121682012060500000)
  1. Engine running.
  2. Check the function. Read off the shift angle of the camshaft and the desired shift angle of the camshaft. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S14308121682012060500000)

see FAULT-TRACING

HINT: Sensor A covers the intake camshaft. Sensor B covers the exhaust camshaft.

  1. Start the engine.
  2. Read off the adaption for the camshaft, the camshaft shift angle and desired value for the camshaft shift angle. Check that the read off values correspond to the guide values below. The difference between the camshaft shift angle and desired value for camshaft shift angle can be read off from the lower digital display. Note the read off values as a basis for continuing fault-tracing. Adaption camshaft Inlet camshaft: 75° CA (camshaft angle) (+/-8° CA) Exhaust camshaft: 120° CA (+/-8° CA) Camshaft shift angle The difference from the desired value of the camshaft shift angle (inlet and exhaust): approximately 8° CA The fault is permanent if the values are not correct. If the values are correct, this indicates that the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS»(ref-476773-S29987437602012060500000)

HINT: Incorrect function on the camshaft reset valve is probably the cause of this diagnostic trouble code (DTC) if

  1. The adaption value and camshaft shift angle are correct in the previous check (intermittent fault).
  2. The adaption value is correct but the camshaft shift angle is incorrect in the previous check.

HINT: Contaminants in the engine oil can damage components in the camshaft control which can cause function faults.

Check the engine oil grade. Check especially for contaminants.

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by a damaged variable valve timing (VVT) unit.

Remedy as necessary.

Other information

  1. see «VVT UNIT, RIGHT CYLINDER HEAD»(ref-476775-S35498753212012060500000)
  2. see «VVT UNIT, LEFT CYLINDER HEAD»(ref-476775-S00445910052012060500000)
  3. see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S26915042152012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

HINT: In order to verify this diagnostic trouble code (DTC), adaptation of the camshaft must be completed. Adaptation of the camshaft is carried out by the engine control module (ECM) when the engine is at operating temperature, during engine braking (fuel shut-off) above 1500 RPM for at least 10 seconds.

CAUTIONTest driving on the road must be carried out on a road with minimal traffic. Follow the highway code.
  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Start and run the engine to operating temperature.
  4. Drive the vehicle on the road. Ensure that the conditions for camshaft adaptation are met: engine braking (fuel shut-off) above 1500 RPM for at least 10 seconds. The conditions can be satisfied for example by driving the vehicle with a high engine load (accelerating) up to approximately 90 km/h and then releasing the accelerator pedal for 10 seconds. NOTE: In order for the adaptation to be carried out, the accelerator pedal must not be touched during engine braking.
  5. Repeat the schedule to ensure that the diagnosis and adaptation are carried out.
  6. Connect VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  7. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check that the diagnostic status for the diagnostic trouble code (DTC) is "Completed". When the diagnostic status for the diagnostic trouble code (DTC) is "Completed", the engine control module (ECM) has carried out camshaft adaption. If the status is "Not completed" the test drive must be carried out again. If the function is correct, the fault status must be "No fault found" when the diagnostic is complete. Check that the value for camshaft adaption is correct when the diagnostic status for the diagnostic trouble code (DTC) is "Completed". Inlet camshaft: 75° CA (camshaft angle) (+/-8° CA) Exhaust camshaft: 120° CA (+/-8° CA)

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476773-S39511884142012060500000)
  2. NO Refer to «INFORMATION»(ref-476773-S34350831392012060500000)
  1. Engine running.
  2. Check the function. Read off the shift angle of the camshaft and the desired shift angle of the camshaft. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S34350831392012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: The diagnostic trouble code (DTC) specifies the relevant camshaft.

  1. ECM-P001600: Camshaft inlet, bank 1. Bank 1 (cylinder row nearest the front): cylinders 1, 3, 5 and 7. Bank 2 (cylinder row furthest to the rear, nearest the passenger compartment): cylinders 2, 4, 6, and 8.
  2. ECM-P001700: Camshaft exhaust, bank 1. Bank 1 (cylinder row nearest the front): cylinders 1, 3, 5 and 7. Bank 2 (cylinder row furthest to the rear, nearest the passenger compartment): cylinders 2, 4, 6, and 8.
  3. ECM-P001800: Camshaft inlet, bank 2. Bank 1 (cylinder row nearest the front): cylinders 1, 3, 5 and 7. Bank 2 (cylinder row furthest to the rear, nearest the passenger compartment): cylinders 2, 4, 6, and 8.
  4. ECM-P001900: Camshaft exhaust, bank 2. Bank 1 (cylinder row nearest the front): cylinders 1, 3, 5 and 7. Bank 2 (cylinder row furthest to the rear, nearest the passenger compartment): cylinders 2, 4, 6, and 8.
  1. Start the engine.
  2. Read off the adaption for the camshaft, the camshaft shift angle and desired value for the camshaft shift angle. Check that the read off values correspond to the guide values below. The difference between the camshaft shift angle and desired value for camshaft shift angle can be read off from the lower digital display. Note the read off values as a basis for continuing fault-tracing. Adaption camshaft Inlet camshaft: 75° CA (camshaft angle) (+/-8° CA) Exhaust camshaft: 120° CA (+/-8° CA) Camshaft shift angle The difference from the desired value of the camshaft shift angle (inlet and exhaust): approximately 8° CA The fault is permanent if the values are not correct. If the values are correct, this indicates that the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS»(ref-476773-S07484997652012060500000)

HINT: Incorrect function on the camshaft reset valve is probably the cause of this diagnostic trouble code (DTC) if

  1. The adaption value and camshaft shift angle are correct in the previous check (intermittent fault).
  2. The adaption value is correct but the camshaft shift angle is incorrect in the previous check.

HINT: Contaminants in the engine oil can damage components in the camshaft control which can cause function faults.

Check the engine oil grade. Check especially for contaminants.

Check the default settings of the camshafts.

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by a damaged variable valve timing (VVT) unit.

Remedy as necessary.

Other information

  1. see «VVT UNIT, RIGHT CYLINDER HEAD»(ref-476775-S35498753212012060500000)
  2. see «VVT UNIT, LEFT CYLINDER HEAD»(ref-476775-S00445910052012060500000)
  3. see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S34478263532012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

HINT: In order to verify this diagnostic trouble code (DTC), adaptation of the camshaft must be completed. Adaptation of the camshaft is carried out by the engine control module (ECM) when the engine is at operating temperature, during engine braking (fuel shut-off) above 1500 RPM for at least 10 seconds.

CAUTIONTest driving on the road must be carried out on a road with minimal traffic. Follow the highway code.
  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Start and run the engine to operating temperature.
  4. Drive the vehicle on the road. Ensure that the conditions for camshaft adaptation are met: engine braking (fuel shut-off) above 1500 RPM for at least 10 seconds. The conditions can be satisfied for example by driving the vehicle with a high engine load (accelerating) up to approximately 90 km/h and then releasing the accelerator pedal for 10 seconds. NOTE: In order for the adaptation to be carried out, the accelerator pedal must not be touched during engine braking.
  5. Repeat the schedule to ensure that the diagnosis and adaptation are carried out.
  6. Connect VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  7. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check that the diagnostic status for the diagnostic trouble code (DTC) is "Completed". When the diagnostic status for the diagnostic trouble code (DTC) is "Completed", the engine control module (ECM) has carried out camshaft adaption. If the status is "Not completed" the test drive must be carried out again. If the function is correct, the fault status must be "No fault found" when the diagnostic is complete. Check that the value for camshaft adaption is correct when the diagnostic status for the diagnostic trouble code (DTC) is "Completed". Inlet camshaft: 75° CA (camshaft angle) (+/-8° CA) Exhaust camshaft: 120° CA (+/-8° CA)

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476773-S18665844742012060500000)
  2. NO Refer to «INFORMATION»(ref-476773-S17163665012012060500000)
  1. Engine running.
  2. Check the function. Read off the shift angle of the camshaft and the desired shift angle of the camshaft. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S17163665012012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: Sensor A covers the intake camshaft. Sensor B covers the exhaust camshaft.

  1. Start the engine.
  2. Read off the adaption for the camshaft, the camshaft shift angle and desired value for the camshaft shift angle. Check that the read off values correspond to the guide values below. The difference between the camshaft shift angle and desired value for camshaft shift angle can be read off from the lower digital display. Note the read off values as a basis for continuing fault-tracing. Adaption camshaft Inlet camshaft: 75° CA (camshaft angle) (+/-8° CA) Exhaust camshaft: 120° CA (+/-8° CA) Camshaft shift angle The difference from the desired value of the camshaft shift angle (inlet and exhaust): approximately 8° CA The fault is permanent if the values are not correct. If the values are correct, this indicates that the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS»(ref-476773-S31873187892012060500000)

HINT: Incorrect function on the camshaft reset valve is probably the cause of this diagnostic trouble code (DTC) if

  1. The adaption value and camshaft shift angle are correct in the previous check (intermittent fault).
  2. The adaption value is correct but the camshaft shift angle is incorrect in the previous check.

HINT: Contaminants in the engine oil can damage components in the camshaft control which can cause function faults.

Check the engine oil grade. Check especially for contaminants.

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by a damaged variable valve timing (VVT) unit.

Remedy as necessary.

Other information

  1. see «VVT UNIT, RIGHT CYLINDER HEAD»(ref-476775-S35498753212012060500000)
  2. see «VVT UNIT, LEFT CYLINDER HEAD»(ref-476775-S00445910052012060500000)
  3. see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S34018468202012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

HINT: In order to verify this diagnostic trouble code (DTC), adaptation of the camshaft must be completed. Adaptation of the camshaft is carried out by the engine control module (ECM) when the engine is at operating temperature, during engine braking (fuel shut-off) above 1500 RPM for at least 10 seconds.

CAUTIONTest driving on the road must be carried out on a road with minimal traffic. Follow the highway code.
  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Start and run the engine to operating temperature.
  4. Drive the vehicle on the road. Ensure that the conditions for camshaft adaptation are met: engine braking (fuel shut-off) above 1500 RPM for at least 10 seconds. The conditions can be satisfied for example by driving the vehicle with a high engine load (accelerating) up to approximately 90 km/h and then releasing the accelerator pedal for 10 seconds. NOTE: In order for the adaptation to be carried out, the accelerator pedal must not be touched during engine braking.
  5. Repeat the schedule to ensure that the diagnosis and adaptation are carried out.
  6. Connect VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  7. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check that the diagnostic status for the diagnostic trouble code (DTC) is "Completed". When the diagnostic status for the diagnostic trouble code (DTC) is "Completed", the engine control module (ECM) has carried out camshaft adaption. If the status is "Not completed" the test drive must be carried out again. If the function is correct, the fault status must be "No fault found" when the diagnostic is complete. Check that the value for camshaft adaption is correct when the diagnostic status for the diagnostic trouble code (DTC) is "Completed". Inlet camshaft: 75° CA (camshaft angle) (+/-8° CA) Exhaust camshaft: 120° CA (+/-8° CA)

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476773-S00269828132012060500000)
  2. NO Refer to «INFORMATION»(ref-476773-S01710154892012060500000)
  1. Engine running.
  2. Check the function. Read off the shift angle of the camshaft and the desired shift angle of the camshaft. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S01710154892012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: The diagnostic trouble code (DTC) specifies the relevant camshaft.

  1. ECM-P001600: Camshaft inlet, bank 1. Bank 1 (cylinder row nearest the front): cylinders 1, 3, 5 and 7. Bank 2 (cylinder row furthest to the rear, nearest the passenger compartment): cylinders 2, 4, 6, and 8.
  2. ECM-P001700: Camshaft exhaust, bank 1. Bank 1 (cylinder row nearest the front): cylinders 1, 3, 5 and 7. Bank 2 (cylinder row furthest to the rear, nearest the passenger compartment): cylinders 2, 4, 6, and 8.
  3. ECM-P001800: Camshaft inlet, bank 2. Bank 1 (cylinder row nearest the front): cylinders 1, 3, 5 and 7. Bank 2 (cylinder row furthest to the rear, nearest the passenger compartment): cylinders 2, 4, 6, and 8.
  4. ECM-P001900: Camshaft exhaust, bank 2. Bank 1 (cylinder row nearest the front): cylinders 1, 3, 5 and 7. Bank 2 (cylinder row furthest to the rear, nearest the passenger compartment): cylinders 2, 4, 6, and 8.
  1. Start the engine.
  2. Read off the adaption for the camshaft, the camshaft shift angle and desired value for the camshaft shift angle. Check that the read off values correspond to the guide values below. The difference between the camshaft shift angle and desired value for camshaft shift angle can be read off from the lower digital display. Note the read off values as a basis for continuing fault-tracing. Adaption camshaft Inlet camshaft: 75° CA (camshaft angle) (+/-8° CA) Exhaust camshaft: 120° CA (+/-8° CA) Camshaft shift angle The difference from the desired value of the camshaft shift angle (inlet and exhaust): approximately 8° CA The fault is permanent if the values are not correct. If the values are correct, this indicates that the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS»(ref-476773-S14712299242012060500000)

HINT: Incorrect function on the camshaft reset valve is probably the cause of this diagnostic trouble code (DTC) if

  1. The adaption value and camshaft shift angle are correct in the previous check (intermittent fault).
  2. The adaption value is correct but the camshaft shift angle is incorrect in the previous check.

HINT: Contaminants in the engine oil can damage components in the camshaft control which can cause function faults.

Check the engine oil grade. Check especially for contaminants.

Check the default settings of the camshafts.

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by a damaged variable valve timing (VVT) unit.

Remedy as necessary.

Other information

  1. see «VVT UNIT, RIGHT CYLINDER HEAD»(ref-476775-S35498753212012060500000)
  2. see «VVT UNIT, LEFT CYLINDER HEAD»(ref-476775-S00445910052012060500000)
  3. see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S16698149322012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

HINT: In order to verify this diagnostic trouble code (DTC), adaptation of the camshaft must be completed. Adaptation of the camshaft is carried out by the engine control module (ECM) when the engine is at operating temperature, during engine braking (fuel shut-off) above 1500 RPM for at least 10 seconds.

CAUTIONTest driving on the road must be carried out on a road with minimal traffic. Follow the highway code.
  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Start and run the engine to operating temperature.
  4. Drive the vehicle on the road. Ensure that the conditions for camshaft adaptation are met: engine braking (fuel shut-off) above 1500 RPM for at least 10 seconds. The conditions can be satisfied for example by driving the vehicle with a high engine load (accelerating) up to approximately 90 km/h and then releasing the accelerator pedal for 10 seconds. NOTE: In order for the adaptation to be carried out, the accelerator pedal must not be touched during engine braking.
  5. Repeat the schedule to ensure that the diagnosis and adaptation are carried out.
  6. Connect VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  7. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check that the diagnostic status for the diagnostic trouble code (DTC) is "Completed". When the diagnostic status for the diagnostic trouble code (DTC) is "Completed", the engine control module (ECM) has carried out camshaft adaption. If the status is "Not completed" the test drive must be carried out again. If the function is correct, the fault status must be "No fault found" when the diagnostic is complete. Check that the value for camshaft adaption is correct when the diagnostic status for the diagnostic trouble code (DTC) is "Completed". Inlet camshaft: 75° CA (camshaft angle) (+/-8° CA) Exhaust camshaft: 120° CA (+/-8° CA)

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476773-S40653559782012060500000)
  2. NO Refer to «INFORMATION»(ref-476773-S21347821912012060500000)
  1. Engine running.
  2. Check the function. Read off the shift angle of the camshaft and the desired shift angle of the camshaft. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S21347821912012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Use the following information and general checks during fault-tracing.

Note. Check that the fuses are intact. For locations, see the owner's manual or the cover for fuse box.

  1. Check, if possible, relevant functions in the vehicle using buttons/controls/test drives to determine the status of the fault. NOTE: If the vehicle does not show any of the given symptoms in the diagnostic trouble code information (DTC), this may mean that the fault is intermittent or that the control module is not detecting the fault at this moment.
  2. Use the diagnostic trouble code's frozen values , status identifiers and counter to determine the operating conditions when the fault was detected, the fault's current status and any degree of intermittence of the fault.
  3. Check and fault-trace according to the fault causes that are specified in the diagnostic trouble code (DTC) information .
  4. Use VIDA (Volvo scan tool) . Read off the parameters, activate components and functions, carry out quick tests and checking routines for the diagnostic trouble codes to identify the fault.
  5. Check relevant components according to Component specifications .
  6. Check relevant signals using the appropriate signal specification and breakout box service information.

Note. Impurities in the oil, such as cast material and cast burrs, may cause the cam profile solenoid (CPS) to jam. In most cases the solenoid does not have to be replaced, cleaning is enough. Replace the solenoid if it still has malfunctions after two cleanings.

Remedy as necessary.

Other information

  1. Cleaning: «CPS SOLENOID»(ref-476762-S39500530942012060500000)
  2. Removing, replacing, and installing: «CPS SOLENOID»(ref-476775-S28738583472012060500000)
  3. see «DESCRIPTION OF FROZEN VALUES»(ref-494825-S34808481252012081600000)
  4. see «DESCRIPTION OF STATUS IDENTIFIER»(ref-494840-S18263369932012081600000)
  5. see «DESCRIPTION OF COUNTER»(ref-494840-S28429254232012081600000)
  6. see «DESCRIPTION OF PARAMETERS»(ref-476777-S08197823022012060500000)
  7. see «DESCRIPTION OF ACTIVATIONS»(ref-476777-S10652960132012060500000)
  8. see «LOCATION OF COMPONENTS»(ref-476766-S34089063632012060500000)
  9. see «COMPONENT SPECIFICATIONS»(ref-476694-S39749312632012060500000)
  10. see «CONNECTING THE BREAKOUT BOX»(ref-476691-S30437390172012060500000)
  11. see «SIGNAL SPECIFICATION»(ref-476694-S14228516802012060500000)
  12. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)

Scheme 283

Scheme 283
Scheme 283

Scheme 284

Scheme 284
Scheme 284

Scheme 285

Scheme 285
Scheme 285
  1. Continue Refer to «VERIFICATION»(ref-476773-S00252905492012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC).
  2. Check that the diagnosis is Performed. HINT: To enable performing diagnostic status, special conditions must be fulfilled. These conditions are described in diagnostic trouble code (DTC) information for each diagnostic trouble code (DTC). If the function is correct, the fault status must be No fault found when the diagnostic is complete.

Is the function OK?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S16597343092012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

Note. If the diagnostic trouble code (DTC) for correlation between the crankshaft position and camshaft position is stored, it must be fault-traced first.

HINT: Contaminants in the engine oil can damage components in the variable valve timing (VVT) unit which can cause function faults.

Check the engine oil grade. Check especially for contaminants.

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by an internal fault in the variable valve timing (VVT) unit. If the above fault-tracing/remedies do not rectify the fault, the variable valve timing (VVT) unit may be damaged.

Remedy as necessary.

Other information

  1. see «VVT UNIT, RIGHT CYLINDER HEAD»(ref-476775-S35498753212012060500000)
  2. see «VVT UNIT, LEFT CYLINDER HEAD»(ref-476775-S00445910052012060500000)
  3. see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S35032297552012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Verification consists of 2 parts. Part 1 is carried out via a test in the workshop. Part 2 is carried out on the road. If the function is determined as incorrect in part 1, then part 2 does not need to be carried out. If the function is determined as being correct in part 1 and the vehicle can be tested on the road, part 2 must be carried out. This is because the function can be difficult the check in a workshop environment in certain cases.
  2. Ignition off
  3. Reconnect the connectors, components, etc.
  4. Start and run the engine to operating temperature.
  5. Read off the shift angle of the camshaft and the desired shift angle of the camshaft to check the function. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476773-S40113277222012060500000)
  2. NO Refer to «INFORMATION»(ref-476773-S03464515052012060500000)
  1. Test drive the car on the road. Use acceleration and engine braking. Repeat the procedure several times so that the camshaft control works and the engine control module (ECM) can carry out diagnostics.
  2. Connect VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  3. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S03464515052012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Note. If the diagnostic trouble code (DTC) for correlation between the crankshaft position and camshaft position is stored, it must be fault-traced first.

HINT: Incorrect oil grade can cause malfunctions in the variable valve timing (VVT) unit. Contaminants in the engine oil can cause damage to components in the variable valve timing (VVT) unit.

Check the engine oil grade. Check especially for contaminants.

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Check the engine oil pressure.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by an internal fault in the variable valve timing (VVT) unit. If the above fault-tracing/remedies do not rectify the fault, the variable valve timing (VVT) unit may be damaged.

Remedy as necessary.

Other information

  1. see «OIL PRESSURE, CHECKING»(ref-476770-S17127498902012060500000)
  2. see «VVT UNIT, RIGHT CYLINDER HEAD»(ref-476775-S35498753212012060500000)
  3. see «VVT UNIT, LEFT CYLINDER HEAD»(ref-476775-S00445910052012060500000)
  4. see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S30514086592012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Verification consists of 2 parts. Part 1 is carried out via a test in the workshop. Part 2 is carried out on the road. If the function is determined as incorrect in part 1, then part 2 does not need to be carried out. If the function is determined as being correct in part 1 and the vehicle can be tested on the road, part 2 must be carried out. This is because the function can be difficult the check in a workshop environment in certain cases.
  2. Ignition off
  3. Reconnect the connectors, components, etc.
  4. Start and run the engine to operating temperature.
  5. Read off the shift angle of the camshaft and the desired shift angle of the camshaft to check the function. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476773-S28299295062012060500000)
  2. NO Refer to «INFORMATION»(ref-476773-S36018779962012060500000)
  1. Test drive the car on the road. Use acceleration and engine braking. Repeat the procedure several times so that the camshaft control works and the engine control module (ECM) can carry out diagnostics.
  2. Connect VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  3. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S36018779962012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Note. If the diagnostic trouble code (DTC) for correlation between the crankshaft position and camshaft position is stored, it must be fault-traced first.

HINT: Incorrect oil grade can cause malfunctions in the variable valve timing (VVT) unit. Contaminants in the engine oil can cause damage to components in the variable valve timing (VVT) unit.

Check the engine oil grade. Check especially for contaminants.

HINT: The VVT unit for the exhaust camshaft has a spring which turns the camshaft at control. This means that if the oil pressure becomes too low for the VVT unit, the spring controls the camshaft out too much.

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Check the engine oil pressure.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by an internal fault in the variable valve timing (VVT) unit. If the above fault-tracing/remedies do not rectify the fault, the variable valve timing (VVT) unit may be damaged.

Remedy as necessary.

Other information

  1. see «OIL PRESSURE, CHECKING»(ref-476770-S17127498902012060500000)
  2. see «VVT UNIT EXHAUST CAMSHAFT, REPLACING»(ref-476775-S12438293002012060500000)
  3. see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S04590819162012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Verification consists of 2 parts. Part 1 is carried out via a test in the workshop. Part 2 is carried out on the road. If the function is determined as incorrect in part 1, then part 2 does not need to be carried out. If the function is determined as being correct in part 1 and the vehicle can be tested on the road, part 2 must be carried out. This is because in certain cases the function can be difficult the check in a workshop environment.
  2. Ignition off
  3. Reconnect the connectors, components, etc.
  4. Start and run the engine to operating temperature.
  5. Read off the shift angle of the camshaft and the desired shift angle of the camshaft to check the function. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476773-S26736718392012060500000)
  2. NO Refer to «INFORMATION»(ref-476773-S13709419172012060500000)
  1. Test drive the car on the road. Use acceleration and engine braking. Repeat the procedure several times so that the camshaft control works and the engine control module (ECM) can carry out diagnostics.
  2. Connect VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  3. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S13709419172012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Note. If the diagnostic trouble code (DTC) for correlation between the crankshaft position and camshaft position is stored, it must be fault-traced first.

HINT: Contaminants in the engine oil can cause damage to components in the variable valve timing (VVT) unit.

Check the engine oil grade. Check especially for contaminants.

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by an internal fault in the variable valve timing (VVT) unit. If the above fault-tracing/remedies do not rectify the fault, the variable valve timing (VVT) unit may be damaged.

Remedy as necessary.

Other information

  1. see «VVT UNIT EXHAUST CAMSHAFT, REPLACING»(ref-476775-S12438293002012060500000)
  2. see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S34572968772012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Verification consists of 2 parts. Part 1 is carried out via a test in the workshop. Part 2 is carried out on the road. If the function is determined as incorrect in part 1, then part 2 does not need to be carried out. If the function is determined as being correct in part 1 and the vehicle can be tested on the road, part 2 must be carried out. This is because in certain cases the function can be difficult the check in a workshop environment.
  2. Ignition off
  3. Reconnect the connectors, components, etc.
  4. Start and run the engine to operating temperature.
  5. Read off the shift angle of the camshaft and the desired shift angle of the camshaft to check the function. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476773-S21064734232012060500000)
  2. NO Refer to «INFORMATION»(ref-476773-S22720198152012060500000)
  1. Test drive the car on the road. Use acceleration and engine braking. Repeat the procedure several times so that the camshaft control works and the engine control module (ECM) can carry out diagnostics.
  2. Connect VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  3. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S22720198152012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Use the following information and general checks during fault-tracing.

Note. Check that the fuses are intact. For locations, see the owner's manual or the cover for fuse box.

  1. Check, if possible, relevant functions in the vehicle using buttons/controls/test drives to determine the status of the fault. NOTE: If the vehicle does not show any of the given symptoms in the diagnostic trouble code information (DTC), this may mean that the fault is intermittent or that the control module is not detecting the fault at this moment.
  2. Use the diagnostic trouble code's frozen values , status identifiers and counter to determine the operating conditions when the fault was detected, the fault's current status and any degree of intermittence of the fault.
  3. Check and fault-trace according to the fault causes that are specified in the diagnostic trouble code (DTC) information .
  4. Use VIDA (Volvo scan tool) . Read off the parameters, activate components and functions, carry out quick tests and checking routines for the diagnostic trouble codes to identify the fault.
  5. Check relevant components according to Component specifications .
  6. Check relevant signals using the appropriate signal specification and breakout box service information.

Remedy as necessary.

Other information

  1. see «DESCRIPTION OF FROZEN VALUES»(ref-494825-S34808481252012081600000)
  2. see «DESCRIPTION OF STATUS IDENTIFIER»(ref-494840-S18263369932012081600000)
  3. see «DESCRIPTION OF COUNTER»(ref-494840-S28429254232012081600000)
  4. see «DESCRIPTION OF PARAMETERS»(ref-476777-S08197823022012060500000)
  5. see «DESCRIPTION OF ACTIVATIONS»(ref-476777-S10652960132012060500000)
  6. see «LOCATION OF COMPONENTS»(ref-476766-S34089063632012060500000)
  7. see «COMPONENT SPECIFICATIONS»(ref-476694-S39749312632012060500000)
  8. see «CONNECTING THE BREAKOUT BOX»(ref-476691-S30437390172012060500000)
  9. see «SIGNAL SPECIFICATION»(ref-476694-S14228516802012060500000)
  10. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S29567336852012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC).
  2. Check that the diagnosis is Performed. HINT: To enable performing diagnostic status, special conditions must be fulfilled. These conditions are described in diagnostic trouble code (DTC) information for each diagnostic trouble code (DTC). If the function is correct, the fault status must be No fault found when the diagnostic is complete.

Is the function OK?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S37884466822012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

  1. The ignition must be on to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault found".
  1. Continue Refer to «CHECKING COMPONENTS»(ref-476773-S31328112702012060500000)
CAUTIONDo not apply rust solvent spray or grease to the heated oxygen sensor (HO2S) connector.

Check the cable between front heated oxygen sensor (HO2S) terminal #1 (bank 1) and voltage supply from the system relay. Check for an open-circuit. Check for a short-circuit to ground.

Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.

Remedy as necessary.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-476691-S27857399862012060500000)
  2. see «SIGNAL SPECIFICATION, ENGINE CONTROL MODULE (ECM)»(ref-476694-S30016655152012060500000)
  3. see «HEATED OXYGEN SENSOR (HO2S), REPLACING»(ref-476768-S40343228252012060500000)
  4. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)

Scheme 286

Scheme 286
Scheme 286
  1. Continue Refer to «VERIFICATION»(ref-476773-S36010413362012060500000)

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on to perform the diagnosis. Read off the diagnostic status and trouble status for the diagnostic trouble code. Check that the diagnosis is "Implemented" and that the trouble status is "No malfunction found". If the trouble status is "Malfunction found", this indicates defective function.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S30504193772012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

  1. The ignition must be on to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault found".
  1. Continue Refer to «CHECKING COMPONENTS»(ref-476773-S06131611252012060500000)
CAUTIONDo not apply rust solvent spray or grease to the heated oxygen sensor (HO2S) connector.

Check the cable between front heated oxygen sensor (HO2S) terminal #1 (bank 1) and voltage supply from the system relay. Check for a short-circuit to supply voltage.

Try a new rear heated oxygen sensor if the above measure does not remedy the fault.

Remedy as necessary.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-476691-S27857399862012060500000)
  2. see «SIGNAL SPECIFICATION, ENGINE CONTROL MODULE (ECM)»(ref-476694-S30016655152012060500000)
  3. see «HEATED OXYGEN SENSOR (HO2S), REPLACING»(ref-476768-S40343228252012060500000)
  4. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S12864843262012060500000)

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on to perform the diagnosis. Read off the diagnostic status and trouble status for the diagnostic trouble code. Check that the diagnosis is "Implemented" and that the trouble status is "No malfunction found". If the trouble status is "Malfunction found", this indicates defective function.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S05617890792012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

Use the following information and general checks during fault-tracing.

Note. Check that the fuses are intact. For locations, see the owner's manual or the cover for fuse box.

  1. Check, if possible, relevant functions in the vehicle using buttons/controls/test drives to determine the status of the fault. NOTE: If the vehicle does not show any of the given symptoms in the diagnostic trouble code information (DTC), this may mean that the fault is intermittent or that the control module is not detecting the fault at this moment.
  2. Use the diagnostic trouble code's frozen values , status identifiers and counter to determine the operating conditions when the fault was detected, the fault's current status and any degree of intermittence of the fault.
  3. Check and fault-trace according to the fault causes that are specified in the diagnostic trouble code (DTC) information .
  4. Use VIDA (Volvo scan tool) . Read off the parameters, activate components and functions, carry out quick tests and checking routines for the diagnostic trouble codes to identify the fault.
  5. Check relevant components according to Component specifications .
  6. Check relevant signals using the appropriate signal specification and breakout box service information.

Remedy as necessary.

Other information

  1. see «DESCRIPTION OF FROZEN VALUES»(ref-494825-S03382316792012081600000)
  2. see «DESCRIPTION OF STATUS IDENTIFIER»(ref-494840-S18263369932012081600000)
  3. see «DESCRIPTION OF COUNTER»(ref-494840-S28429254232012081600000)
  4. see «DESCRIPTION OF PARAMETERS»(ref-476777-S06835365852012060500000)
  5. see «DESCRIPTION OF ACTIVATIONS»(ref-476777-S42383744922012060500000)
  6. see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000)
  7. see «COMPONENT SPECIFICATIONS»(ref-476694-S25047767552012060500000)
  8. see «CONNECTING THE BREAKOUT BOX»(ref-476691-S27857399862012060500000)
  9. see «SIGNAL SPECIFICATION, ENGINE CONTROL MODULE (ECM)»(ref-476694-S30016655152012060500000)
  10. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S24287806272012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC).
  2. Check that the diagnosis is Performed. HINT: To enable performing diagnostic status, special conditions must be fulfilled. These conditions are described in diagnostic trouble code (DTC) information for each diagnostic trouble code (DTC). If the function is correct, the fault status must be No fault found when the diagnostic is complete.

Is the function OK?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S31928153182012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

  1. The ignition must be on to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault found".
  1. Continue Refer to «CHECKING COMPONENTS»(ref-476773-S28297737632012060500000)
CAUTIONDo not apply rust solvent spray or grease to the heated oxygen sensor (HO2S) connector.

Check the rear heated oxygen sensor connector (bank 1). Check for contact resistance and oxidation.

Check the cable between rear heated oxygen sensor (HO2S) terminal #1 and voltage supply from the system relay. Check for an open-circuit. Check for a short-circuit to ground

Try a new rear heated oxygen sensor if the above measure does not remedy the fault.

Remedy as necessary.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-476691-S27857399862012060500000)
  2. see «SIGNAL SPECIFICATION, ENGINE CONTROL MODULE (ECM)»(ref-476694-S30016655152012060500000)
  3. see «HEATED OXYGEN SENSOR (HO2S), REPLACING»(ref-476768-S40343228252012060500000)
  4. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S11764588162012060500000)

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on to perform the diagnosis. Read off the diagnostic status and trouble status for the diagnostic trouble code. Check that the diagnosis is "Implemented" and that the trouble status is "No malfunction found". If the trouble status is "Malfunction found", this indicates defective function.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S06217514322012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

  1. The ignition must be on to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault found".
  1. Continue Refer to «CHECKING COMPONENTS»(ref-476773-S16171276522012060500000)
CAUTIONDo not apply rust solvent spray or grease to the heated oxygen sensor (HO2S) connector.

Check the cable between rear heated oxygen sensor terminal #1 (bank 1) and voltage supply from the system relay. Check for a short-circuit to supply voltage.

Try a new rear heated oxygen sensor if the above measure does not remedy the fault.

Remedy as necessary.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-476691-S27857399862012060500000)
  2. see «SIGNAL SPECIFICATION, ENGINE CONTROL MODULE (ECM)»(ref-476694-S30016655152012060500000)
  3. see «HEATED OXYGEN SENSOR (HO2S), REPLACING»(ref-476768-S40343228252012060500000)
  4. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S33387162682012060500000)

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on to perform the diagnosis. Read off the diagnostic status and trouble status for the diagnostic trouble code. Check that the diagnosis is "Implemented" and that the trouble status is "No malfunction found". If the trouble status is "Malfunction found", this indicates defective function.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S20911340882012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CHECK OF DIRTY OR DAMAGED CAM PROFILE SOLENOID (CPS)

Impurities in the oil, such as cast material and cast burrs, may cause the cam profile solenoid (CPS) to jam. In most cases the solenoid does not have to be replaced, cleaning is enough.

Replace the solenoid if it still has malfunctions after two cleanings.

Other information

  1. Cleaning: «CPS SOLENOID»(ref-476762-S39500530942012060500000)
  2. Removing, replacing, and installing: «CPS SOLENOID»(ref-476775-S28738583472012060500000)
  1. Continue Refer to «INFORMATION»(ref-476773-S02058351472012060500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

DIRTY OR DAMAGED CAM PROFILE SOLENOID (CPS).

see DIRTY OR DAMAGED CAM PROFILE SOLENOID (CPS).

see DIRTY OR DAMAGED CAM PROFILE SOLENOID (CPS).

see DIRTY OR DAMAGED CAM PROFILE SOLENOID (CPS).

see FAULT-TRACING

see FAULT-TRACING

  1. The ignition must be on to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault found".
  1. Continue Refer to «CHECKING COMPONENTS»(ref-476773-S09300855452012060500000)
CAUTIONDo not apply rust solvent spray or grease to the heated oxygen sensor (HO2S) connector.

Check the cable between front heated oxygen sensor (HO2S) terminal #1 (bank 2) and voltage supply from the system relay. Check for an open-circuit. Check for a short-circuit to ground.

Try a new rear heated oxygen sensor if the above measure does not remedy the fault.

Remedy as necessary.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-476691-S27857399862012060500000)
  2. see «SIGNAL SPECIFICATION, ENGINE CONTROL MODULE (ECM)»(ref-476694-S30016655152012060500000)
  3. see «HEATED OXYGEN SENSOR (HO2S), REPLACING»(ref-476768-S40343228252012060500000)
  4. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476773-S16581127102012060500000)

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on to perform the diagnosis. Read off the diagnostic status and trouble status for the diagnostic trouble code. Check that the diagnosis is "Implemented" and that the trouble status is "No malfunction found". If the trouble status is "Malfunction found", this indicates defective function.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476773-S07514304052012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

More articles — Engine Control Module (ECM) Diagnostic Trouble Codes - 8 of 13
