Engine Control Module (ECM) Diagnostic Trouble Codes - 7 of 13: Other Volvo XC90 I

Testing & Diagnostics 13 illustrations ~13444 words

VERIFICATION

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 251

Scheme 251: VERIFICATION
Scheme 251: VERIFICATION

Scheme 252

Scheme 252
Scheme 252
  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine and let it run at idle speed
  4. Activate the malfunction indicator lamp (MIL)
  5. Check that the function is OK.

Is function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S40549661962012060500000)

FAULT-TRACING INFORMATION

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

CHECKING THE COMPONENT

HINT: The diagnostic trouble code (DTC) may due to a damaged cooling fan for the control module boxes. If diagnostic trouble code (DTC) ECM-680X is stored it must be remedied first.

Activate the cooling fan for the control module box. Check the function. There must be a buzzing noise from the cooling fan when the fan for the control module box is activated.

Check that the air ducts for the control module box are not blocked.

Remedy as necessary.

Other information

  1. For the location of components, see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S14590560332012060500000) .

Scheme 253

Scheme 253
Scheme 253
  1. Continue Refer to «INFORMATION»(ref-476771-S22452103612012060500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

FAULTY SIGNAL

see FAULTY SIGNAL

see FAULTY SIGNAL

see FAULTY SIGNAL

INFORMATION

This diagnostic trouble code (DTC) indicates that the immobilizer code does not match between the engine control module (ECM) and the central electronic module (CEM). This may be because

  1. the immobilizer code in the engine control module (ECM) is incorrect i. e. the code does not correspond to the code stored in the central electronic module (CEM)
  2. the engine control module (ECM) is not programmed and has no immobilizer code
  3. the immobilizer code in the central electronic module (CEM) is incorrect
  4. the central electronic module (CEM) is not programmed and has no immobilizer code
  5. the engine control module (ECM) is damaged
  6. the central electronic module (CEM) is damaged.

Note. A programmed engine control module (ECM) or central electronic module (CEM) cannot be moved from one vehicle to another.

HINT: Read off the diagnostic trouble codes (DTCs) for the central electronic module (CEM).

Other information

  1. To access and replace the engine control module (ECM), see «ENGINE CONTROL MODULE (ECM), REPLACING»(ref-476695-S16000409902012060500000)
  2. For -2004, see: «CENTRAL ELECTRONIC MODULE (CEM), REPLACING»(ref-476708-S16664243282012060500000)
  3. For 2005-, see: «CENTRAL ELECTRONIC MODULE (CEM), REPLACING»(ref-476708-S02617745982012060500000) .
  4. For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000)
  5. For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) .
  6. For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000)
  7. For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) .
  1. Continue Refer to «VERIFICATION»(ref-476771-S12311182032012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall connectors, components etc.
  3. Start the engine.

Did the engine start?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S22559865632012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

FAULTY SIGNAL. PERMANENT FAULT

see FAULTY SIGNAL. PERMANENT FAULT

The immobilizer function is integrated in the central electronic module (CEM).

This diagnostic trouble code (DTC) can be caused by missing CAN communication. If there is a diagnostic trouble code (DTC) stored in the central electronic module (CEM) fault trace accordingly.

If no diagnostic trouble codes (DTCs) are stored in the central electronic module (CEM), try a new central electronic module (CEM).

Other information

  1. For -2004, see: «CENTRAL ELECTRONIC MODULE (CEM), REPLACING»(ref-476708-S16664243282012060500000)
  2. For 2005-, see: «CENTRAL ELECTRONIC MODULE (CEM), REPLACING»(ref-476708-S02617745982012060500000) .
  3. To access and replace the engine control module (ECM), see «ENGINE CONTROL MODULE (ECM), REPLACING»(ref-476695-S16000409902012060500000)
  4. 2004: «SIGNAL SPECIFICATION»(ref-476705-S04532231402012060500000)
  5. 2005-: «SIGNAL SPECIFICATION»(ref-476705-S32237667672012060500000)
  6. For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000)
  7. For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) .
  8. For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000)
  9. For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) .
  1. Continue Refer to «INFORMATION»(ref-476771-S06369271192012060500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

SIGNAL MISSING. PERMANENT FAULT

see SIGNAL MISSING. PERMANENT FAULT

SIGNAL TOO HIGH/SIGNAL TOO LOW. INTERMITTENT FAULT

see SIGNAL TOO HIGH/SIGNAL TOO LOW. INTERMITTENT FAULT

SIGNAL TOO HIGH/SIGNAL TOO LOW. PERMANENT FAULT

see SIGNAL TOO HIGH/SIGNAL TOO LOW. PERMANENT FAULT

HINT: The fault may be due to a defective cooling fan for the control modules. If diagnostic trouble code (DTC) ECM-6220 is stored it must be remedied first.

Activate the cooling fan for the control modules. Check the function. There must be a buzzing noise from the cooling fan when the fan for the control modules is activated.

Check that the air ducts for the control module box are not blocked.

Remedy as necessary.

Other information

  1. For the location of components: see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S14590560332012060500000) .
  1. Continue Refer to «INFORMATION»(ref-476771-S39860898582012060500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

see FAULTY SIGNAL

see SIGNAL TOO HIGH/SIGNAL TOO LOW. INTERMITTENT FAULT

see SIGNAL TOO HIGH/SIGNAL TOO LOW. PERMANENT FAULT

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

see FAULTY SIGNAL. PERMANENT FAULT

The immobilizer function is integrated in the central electronic module (CEM).

The engine control module (ECM) has previously registered a fault in communication with the central electronic module (CEM), but detects that the fault no longer exists.

  1. Continue Refer to «INFORMATION»(ref-476771-S00045558722012060500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

see SIGNAL MISSING. PERMANENT FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

CHECKING CONNECTORS AND COMPONENTS

Check the engine control module (ECM) and the system relay connectors. Check for contact resistance. Check for oxidation.

Check the cable between system relay terminal #5 and the engine control module (ECM). Check for an open-circuit.

Remedy as necessary.

Try a new system relay if no fault is found during the above fault-tracing.

HINT: Read off the voltage from the system relay to the engine control module (ECM) using the VCT2000 (or appropriate scan tool).

Other information

  1. For information about signals for 5 cylinder engines: «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000)
  2. For information about signals for 6 cylinder engines: «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000)
  3. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)

Scheme 254

Scheme 254
Scheme 254
  1. Continue Refer to «VERIFICATION»(ref-476771-S00962057512012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 255

Scheme 255: VERIFICATION
Scheme 255: VERIFICATION
  1. Ignition on
  2. Read off the voltage from the system relay to the engine control module (ECM). Check that the voltage is correct. The voltage must be approximately 12 V.

Is the voltage correct?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S23755014302012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL TOO LOW

see SIGNAL TOO LOW

CHECKING THE CONNECTORS AND COMPONENTS

Check the battery voltage.

Check the charging function of the generator (GEN).

Check the engine control module (ECM) and system relay connectors. Check for contact resistance and oxidation.

Check the cable between system relay terminal #5 and control module terminal #A17 (#A17). Check for an open-circuit. Check for a short-circuit to ground.

Remedy as necessary.

Try a new system relay if no fault is found during the above fault-tracing.

HINT: Read off the voltage from the system relay to the engine control module (ECM) using the VCT2000 (or appropriate scan tool).

Other information

  1. To fault-trace the charging system, see «FAULT-TRACING AND TESTING THE VOLTAGE SUPPLY SYSTEM»(ref-494825-S14405429772012081600000)
  2. To connect the breakout box and access the control module, see «CONNECTING THE BREAKOUT BOX»(ref-476691-S38062545372012060500000)
  3. For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000)
  4. For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) .
  5. For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000)
  6. For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) .
  7. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000) .
  1. Continue Refer to «VERIFICATION»(ref-476771-S04182086862012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition on
  2. Read off the voltage from the system relay to the engine control module (ECM). Check that the voltage is correct. The voltage must be approximately 12 V.

Is the voltage correct?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S07388548122012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check the charging function of the generator (GEN). Check for high charging voltage.

Remedy as necessary.

Other information

  1. To fault-trace the charging system, see «FAULT-TRACING AND TESTING THE VOLTAGE SUPPLY SYSTEM»(ref-494825-S14405429772012081600000) .
  1. Continue Refer to «VERIFICATION»(ref-476771-S03607526072012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Start the engine
  2. Read off the voltage from the system relay to the engine control module (ECM). Check that the voltage is correct. The voltage must be approximately 12 V.

Is the voltage correct?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S28558314662012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check the battery voltage.

Check the charging function of the generator (GEN).

Check the engine control module (ECM) and system relay connectors. Check for contact resistance and oxidation.

Check the cable between system relay terminal #5 and control module terminal #A17 (#A17). Check for contact resistance and oxidation.

Remedy as necessary.

Try a new system relay if no fault is found during the above fault-tracing.

HINT: Read off the voltage from the system relay to the engine control module (ECM) using the VCT2000 (or appropriate scan tool).

Other information

  1. To fault-trace the charging system, see «FAULT-TRACING AND TESTING THE VOLTAGE SUPPLY SYSTEM»(ref-494825-S14405429772012081600000)
  2. To connect the breakout box / access the control module, see «CONNECTING THE BREAKOUT BOX»(ref-476691-S38062545372012060500000)
  3. For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000)
  4. For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) .
  5. For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000)
  6. For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) .
  7. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476771-S18129939412012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition on
  2. Read off the voltage from the system relay to the engine control module (ECM). Check that the voltage is correct. The voltage must be approximately 12 V.

Is the voltage correct?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S39455385672012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check the battery voltage.

Check the charging function of the generator (GEN).

Check the fuse before the circuit. If the fuse is blown, check the circuit. Check for a short-circuit to ground.

Check the cable between system relay terminal #5 and control module terminal #A17 (#A17). Check for an open-circuit.

Check the engine control module (ECM) and system relay connectors. Check for contact resistance and oxidation.

Remedy as necessary.

Try a new system relay if no fault is found during the above fault-tracing.

HINT: Read off the voltage from the system relay to the engine control module (ECM).

Other information

  1. To fault-trace the charging system, see «FAULT-TRACING AND TESTING THE VOLTAGE SUPPLY SYSTEM»(ref-494825-S14405429772012081600000)
  2. To connect the breakout box and access the control module, see «CONNECTING THE BREAKOUT BOX»(ref-476691-S38062545372012060500000)
  3. For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000)
  4. For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) .
  5. For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000)
  6. For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) .
  7. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476771-S08609654472012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition on
  2. Read off the voltage from the system relay to the engine control module (ECM). The voltage must be approximately 12 V.

Is the voltage correct?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S34260718472012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see SIGNAL TOO LOW

see SIGNAL TOO LOW

see INTERNAL FAULT

see INTERNAL FAULT

SIGNAL TOO HIGH

see SIGNAL TOO HIGH

see SIGNAL TOO HIGH

see SIGNAL TOO LOW

see SIGNAL TOO LOW

FAULTY SIGNAL OR SIGNAL MISSING

see FAULTY SIGNAL OR SIGNAL MISSING

see FAULTY SIGNAL OR SIGNAL MISSING

see FAULTY SIGNAL OR SIGNAL MISSING

see FAULTY SIGNAL OR SIGNAL MISSING

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition on.
  2. Read off the 5 volt supply. The value must be 5 V.

Is the value OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S12535715742012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition on.
  2. Read off the 5 volt supply. The value must be 5 V.

Is the value OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S29937029682012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CHECKING THE STATUS

  1. Ignition on
  2. Read off the status from the stop lamp switch. Check the function of the stop lamp switch by carefully pressing and releasing the brake pedal. Check that the status changes between "OFF" when the brake pedal is unaffected and "ON" when the brake pedal is depressed. If the status of the stop lamp switch changes as described above when the brake pedal is depressed, the fault is intermittent at the moment.
  1. Continue Refer to «CHECKING THE POWER SUPPLY»(ref-476771-S37433371722012060500000)

Scheme 256

Scheme 256
Scheme 256
  1. Ignition on. Check the power supply to the stop lamp switch. Take readings between stop lamp switch terminal #1 (cable harness side) and the ground terminal. The power supply must be approximately 12 V. If there is no power supply: Check the power supply circuit for stop lamp switch terminal #1 (cable harness side). Check for an open-circuit. Check for a short-circuit to ground. Check for a blown fuse in the circuit. Remedy as necessary. Other information: see «CONNECTING THE BREAKOUT BOX»(ref-476691-S38062545372012060500000) For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000) For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) . For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000) For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) . see «STOP LAMP SWITCH, REPLACING»(ref-476779-S00282256302012060500000) see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000) .
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S19827548302012060500000)

Scheme 257

Scheme 257: CHECKING COMPONENTS AND WIRING
Scheme 257: CHECKING COMPONENTS AND WIRING
  1. Ignition off
  2. Check that the stop lamp switch is correctly installed. Check the resistance of the stop lamp switch with the switch pressed in and with the switch released. Take readings between terminals #1 and #5 (component side) on the stop lamp switch. HINT: The stop lamp switch must be closed when the brake pedal is depressed. The resistance of the stop lamp switch must be infinite when the brake pedal is unaffected. Check the stop lamp switch and engine control module (ECM) connectors. Check for contact resistance and oxidation. Check the cable between stop lamp switch terminal #5 (cable harness side) and engine control module (ECM) terminal #B26 (#B36). Check for an open-circuit. Check for a short-circuit to ground. Check for a short-circuit to supply voltage. Check central electronic module (CEM) connector B. Check for contact resistance and oxidation. Check the cable between stop lamp switch terminal #5 (cable harness side) and central electronic module (CEM) terminal #4B. Check for an open-circuit. Check for a short-circuit to ground. Check for a short-circuit to supply voltage. Remedy as necessary. Other information: see «CONNECTING THE BREAKOUT BOX»(ref-476691-S38062545372012060500000) For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000) For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) . For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000) For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) . For resistance values: «COMPONENT SPECIFICATIONS»(ref-476694-S25701556572012060500000) For -2004, see: «CENTRAL ELECTRONIC MODULE (CEM), REPLACING»(ref-476708-S16664243282012060500000) For 2005-, see: «CENTRAL ELECTRONIC MODULE (CEM), REPLACING»(ref-476708-S02617745982012060500000) . see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000) .
  1. Continue Refer to «VERIFICATION»(ref-476771-S18660231522012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 258

Scheme 258
Scheme 258
  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Ignition on
  4. Read off the status from the stop lamp switch. Check the function of the stop lamp switch by carefully pressing and releasing the brake pedal. Check that the status changes between "OFF" when the brake pedal is unaffected and "ON" when the brake pedal is depressed. If the status of the stop lamp switch changes as described above when the brake pedal is depressed, the fault has been remedied.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S17389903792012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL MISSING OR FAULTY SIGNAL

see SIGNAL MISSING OR FAULTY SIGNAL

see SIGNAL MISSING OR FAULTY SIGNAL

see SIGNAL MISSING OR FAULTY SIGNAL

  1. Ignition on
  2. Read off the status from the stop lamp switch. Check the function of the stop lamp switch by carefully pressing and releasing the brake pedal. Check that the status changes between "OFF" when the brake pedal is unaffected and "ON" when the brake pedal is depressed. If the status of the stop lamp switch changes as described above when the brake pedal is depressed, the fault is intermittent at the moment.
  1. Continue Refer to «CHECKING THE POWER SUPPLY»(ref-476771-S06715581192012060500000)

CHECKING THE POWER SUPPLY

  1. Ignition on. Check the power supply to the stop lamp switch. Take readings between stop lamp switch terminal #1 (cable harness side) and the ground terminal. The power supply must be approximately 12 V. If there is no power supply: Check the power supply circuit for stop lamp switch terminal #1 (cable harness side). Check for an open-circuit. Check for a short-circuit to ground. Check for a blown fuse in the circuit. Remedy as necessary. Other information: see «CONNECTING THE BREAKOUT BOX»(ref-476691-S38062545372012060500000) For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000) For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) . For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000) For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) . see «STOP LAMP SWITCH, REPLACING»(ref-476779-S00282256302012060500000) see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S20739572862012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Ignition on
  4. Read off the status from the stop lamp switch. Check the function of the stop lamp switch by carefully pressing and releasing the brake pedal. Check that the status changes between "OFF" when the brake pedal is unaffected and "ON" when the brake pedal is depressed. If the status of the stop lamp switch changes as described above when the brake pedal is depressed, the fault has been remedied.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S23050259392012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL TOO HIGH

see FAULT-TRACING INFORMATION

The engine control module (ECM) previously registered a fault but has now detected that the fault is no longer present.

  1. Continue Refer to «INFORMATION»(ref-476771-S30018505492012060500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

PROGRAMMING OR REPLACING THE ENGINE CONTROL MODULE (ECM)

  1. Ignition off. The engine control module (ECM) has registered an internal fault or a fault in the software. Try downloading new software into the engine control module (ECM). To download new software or replace the engine control module (ECM), see «ENGINE CONTROL MODULE (ECM), REPLACING»(ref-476695-S16000409902012060500000) . If software cannot be downloaded or new software does not solve the problem, replace the engine control module (ECM) and download the relevant software for the new engine control module (ECM). NOTE: After downloading the software or replacing the engine control module (ECM), the throttle unit must be adapted according to vehicle communication socket: "Throttle unit adaptation". Remedy as necessary.
  1. Continue Refer to «INFORMATION»(ref-476771-S12594672122012060500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

see FAULT-TRACING INFORMATION

INTERNAL FAULT. PERMANENT FAULT

see INTERNAL FAULT. PERMANENT FAULT

see FAULT-TRACING INFORMATION

see INTERNAL FAULT. PERMANENT FAULT

  1. Ignition on
  2. Read off the clutch pedal movement by carefully pressing and releasing the clutch pedal. Check that the value changes with clutch pedal movement. The value must be between 60-70 % when the clutch pedal is unaffected and 10-20 % when the pedal is fully depressed. The fault is intermittent at the moment if the values are OK.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S38809493332012060500000)

Scheme 259

Scheme 259
Scheme 259
  1. Ignition off. Check the resistance of the clutch pedal sensor between terminals #2 and #4 (component side). Check the clutch pedal and engine control module (ECM) connectors. Check for contact resistance and oxidation. Check the signal cable between engine control module (ECM) terminal #B15 (#B25) and clutch pedal sensor terminal #2 (component side). Check for an open-circuit. Check the signal ground cable between engine control module (ECM) terminal #B4 (#B14) and clutch pedal sensor terminal #4 (cable harness side). Check for an open-circuit. Check the clutch pedal sensor installation. Search for damage and check the connections visually. HINT: With the ignition on, the power supply to the clutch pedal sensor must be approximately 5 V (measured with the clutch pedal sensor disconnected), measured between terminals #2 and #4 (cable harness side). Remedy as necessary. Other information: see «CONNECTING THE BREAKOUT BOX»(ref-476691-S38062545372012060500000) For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000) For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) . For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000) For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) . For resistance values: «COMPONENT SPECIFICATIONS»(ref-476694-S25701556572012060500000) see «PEDAL POSITION SENSOR CLUTCH, REPLACING»(ref-494835-S39096077882012081600000) see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476771-S37266542202012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Ignition on
  4. Read off the clutch pedal movement by carefully pressing and releasing the clutch pedal. Check that the value changes with clutch pedal movement. The value must be between 60-70 % when the clutch pedal is unaffected and 10-20% when the pedal is fully depressed. The fault has been remedied if the values are OK.

Are these values OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S10837848332012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL MISSING OR FAULTY SIGNAL

CAUTIONThe male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.
  1. Continue Refer to «CHECKING DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-476771-S34472868642012060500000)

Remedy any diagnostic trouble codes (DTCs) that are stored.

Remedy as necessary.

Scheme 260

Scheme 260
Scheme 260

Scheme 261

Scheme 261
Scheme 261
  1. Ignition off
  2. Check the throttle unit and engine control module (ECM) connectors. Check for contact resistance and oxidation. Check the resistance value of the damper motor winding in the throttle unit. Take readings between throttle unit terminals #1 and #4 (component side). Check for an open-circuit. Check for a short-circuit. NOTE: The resistance of the motor winding in the damper motor is very low. Replace the throttle unit if necessary. Check the cable (+) for the damper motor between engine control module (ECM) terminal #A35 (#A35) and throttle unit terminal #4 (wiring side). Check for an open-circuit. Check for a short-circuit to ground. Check for a short-circuit to supply voltage. Check the cable (-) for the damper motor between engine control module (ECM) terminal #A36 (#A36) and throttle unit terminal #1 (wiring side). Check for an open-circuit. Check for a short-circuit to ground. Check for a short-circuit to supply voltage. Also check the damper motor cables (+) and (-). Check for a short-circuit to each other. If no faults are found during the checks and the diagnostic trouble code (DTC) recurs, try replacing the throttle unit. NOTE: When replacing the throttle unit or the engine control module (ECM) the throttle unit must be adapted. See "Throttle unit adaptation" in the vehicle communication socket. Remedy as necessary. Other information: see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000) For resistance values, see «COMPONENT SPECIFICATIONS»(ref-476694-S25701556572012060500000) To connect the breakout box, see «CONNECTING THE BREAKOUT BOX»(ref-476691-S38062545372012060500000) For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000) For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) . For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000) For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) . For B5xx4T, see «THROTTLE BODY (ELECTRONIC THROTTLE MODULE), REPLACING»(ref-476768-S14571847792012060500000) . For B6xx4T, see «THROTTLE BODY (ELECTRONIC THROTTLE MODULE), REPLACING»(ref-476768-S06588082252012060500000) . To access or replace the engine control module (ECM), see «ENGINE CONTROL MODULE (ECM), REPLACING»(ref-476695-S16000409902012060500000) .
  1. Continue Refer to «VERIFICATION»(ref-476771-S15309605802012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine
  4. Read off diagnostic trouble codes (DTCs). The fault has been remedied if status of the diagnostic trouble code (DTC) is intermittent.

Is the status of the diagnostic trouble code (DTC) intermittent?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S39204354962012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL MISSING OR FAULTY SIGNAL

see SIGNAL MISSING OR FAULTY SIGNAL

  1. Ignition on
  2. Read off the clutch pedal movement by carefully pressing and releasing the clutch pedal. Check that the value changes with clutch pedal movement. The value must be between 60-70 % when the clutch pedal is unaffected and 10-20 % when the pedal is fully depressed. The fault is intermittent at the moment if the values are OK.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S32342122762012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Ignition on
  4. Read off the clutch pedal movement by carefully pressing and releasing the clutch pedal. Check that the value changes with clutch pedal movement. The value must be between 60-70 % when the clutch pedal is unaffected and 10-20% when the pedal is fully depressed. The fault has been remedied if the values are OK.

Are these values OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S22303641192012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL TOO HIGH / SIGNAL TOO LOW

see SIGNAL TOO HIGH / SIGNAL TOO LOW

see SIGNAL TOO HIGH / SIGNAL TOO LOW

see SIGNAL TOO HIGH / SIGNAL TOO LOW

CAUTIONThe male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S02463584632012060500000)

ADAPTATION OF THE THROTTLE UNIT

HINT: Faults which caused this diagnostic trouble code (DTC) may affect the adaptation values for the throttle unit. Carry out adaptation of the throttle unit to update the adaptation values.

Note. The ignition must be switched on for at least 30 seconds after the basic conditions are met in order for the adaptation to start. It takes approximately 10 seconds to run the adaptation.

  1. Ignition off
  2. Reinstall the components and connectors etc.
  3. Ignition on
  4. Read off the parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The car must be stationary (no vehicle speed signal) Engine coolant temperature (ECT) between 5-100 °C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation is completed correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO.
  1. Continue Refer to «CHECKING THE FAULT STATUS»(ref-476771-S16313731562012060500000)

CHECKING THE FAULT STATUS

  1. Ignition on
  2. Read off the diagnostic status and the fault status for diagnostic trouble code (DTC) ECM-9117. Check that the fault status is "NO FAULT FOUND" when the diagnostic status is COMPLETED. If the fault status is "FAULT FOUND" when the diagnostic status is COMPLETED there is a fault.

Is the fault status "NO FAULT FOUND"?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «REPLACING THE COMPONENT»(ref-476771-S02842581022012060500000)

REPLACING THE COMPONENT

  1. Ignition off. Try a new throttle unit. For B5xx4T, see «THROTTLE BODY (ELECTRONIC THROTTLE MODULE), REPLACING»(ref-476768-S14571847792012060500000) . For B6xx4T, see «THROTTLE BODY (ELECTRONIC THROTTLE MODULE), REPLACING»(ref-476768-S06588082252012060500000) . .
  1. Continue Refer to «VERIFICATION»(ref-476771-S36731419492012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Read off the parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The car must be stationary (no vehicle speed signal) Engine coolant temperature (ECT) between 5-100 °C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation is completed correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO.
  1. Continue Refer to «VERIFICATION, CONTINUED»(ref-476771-S12393948602012060500000)

VERIFICATION, CONTINUED

  1. Ignition on
  2. Read off the diagnostic status and the fault status for diagnostic trouble code (DTC) ECM-9117. Check that the fault status is "NO FAULT FOUND" when the diagnostic status is COMPLETED. If the fault status is "FAULT FOUND" when the diagnostic status is COMPLETED there fault is still present.

Is the fault status "NO FAULT FOUND"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S13703076052012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CAUTIONThe male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.
  1. Continue Refer to «CHECKING DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-476771-S15969565062012060500000)

Note. The ignition must be switched on for at least 30 seconds after the basic conditions are met in order for the adaptation to start. It takes approximately 10 seconds to run the adaptation.

  1. Ignition off
  2. Ignition on
  3. Read off the parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The car must be stationary (no vehicle speed signal) Engine coolant temperature (ECT) between 5-100 °C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation is completed correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO. The fault is intermittent at the moment if the adaptation has been completed correctly.
  1. Continue Refer to «CHECKING THE CONNECTORS AND COMPONENTS»(ref-476771-S21388404212012060500000)
  1. Ignition off. Check the throttle unit and engine control module (ECM) connectors. Check for contact resistance and oxidation. Check the resistance values of the potentiometers in the throttle unit. Check that the shutter in the throttle unit is not blocked or sticking. Clean as necessary. Remedy as necessary. Other information: see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000) For resistance values, see «COMPONENT SPECIFICATIONS»(ref-476694-S25701556572012060500000) For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000) For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) . For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000) For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) . For B5xx4T, see «THROTTLE BODY (ELECTRONIC THROTTLE MODULE), REPLACING»(ref-476768-S14571847792012060500000) . For B6xx4T, see «THROTTLE BODY (ELECTRONIC THROTTLE MODULE), REPLACING»(ref-476768-S06588082252012060500000) . For B5xx4T, see «THROTTLE BODY (TB), CLEANING»(ref-476750-S36382112932012060500000) . For B6xx4x, see «THROTTLE BODY (TB), CLEANING»(ref-476750-S05163330712012060500000) .
  1. Continue Refer to «VERIFICATION»(ref-476771-S02262241802012060500000)

Remedy stored diagnostic trouble code(s) (DTCs).

Remedy as necessary.

HINT: After carrying out the repair, check that the fault has been remedied.

Note. The ignition must be switched on for at least 30 seconds after the basic conditions are met in order for the adaptation to start. It takes approximately 10 seconds to run the adaptation.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Read off the parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The car must be stationary (no vehicle speed signal) Engine coolant temperature (ECT) between 5-100 °C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation is completed correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO. The fault has been remedied if the adaptation has been completed correctly.

Is the adaptation OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S34575668272012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULTY SIGNAL

see FAULTY SIGNAL

CAUTIONThe male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S38327791652012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine
  4. Read off diagnostic trouble codes (DTCs). The fault has been remedied if status of the diagnostic trouble code (DTC) is intermittent.

Is the status of the diagnostic trouble code (DTC) intermittent?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S06787022682012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CAUTIONThe male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S04291373942012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine
  4. Read off diagnostic trouble codes (DTCs). The fault has been remedied if status of the diagnostic trouble code (DTC) is intermittent.

Is the status of the diagnostic trouble code (DTC) intermittent?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S10389488052012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CAUTIONThe male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S15464893412012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine
  4. Read off diagnostic trouble codes (DTCs). The fault has been remedied if status of the diagnostic trouble code (DTC) is intermittent.

Is the status of the diagnostic trouble code (DTC) intermittent?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S06825201482012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULTY SIGNAL

CAUTIONThe male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S30362090472012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine
  4. Read off diagnostic trouble codes (DTCs). The fault has been remedied if status of the diagnostic trouble code (DTC) is intermittent.

Is the status of the diagnostic trouble code (DTC) intermittent?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S20552925502012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CAUTIONThe male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S17752683962012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine
  4. Read off diagnostic trouble codes (DTCs). The fault has been remedied if status of the diagnostic trouble code (DTC) is intermittent.

Is the status of the diagnostic trouble code (DTC) intermittent?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S20951282202012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

  1. Ignition off. The engine control module (ECM) has registered an internal fault. Replace the engine control module (ECM). See «ENGINE CONTROL MODULE (ECM), REPLACING»(ref-476695-S16000409902012060500000) . NOTE: After replacing the engine control module (ECM), the throttle unit must be adapted using the vehicle communication input: "Throttle unit adaptation". Remedy as necessary.
  1. Continue Refer to «INFORMATION»(ref-476771-S01592220212012060500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

CAUTIONThe male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.
  1. Continue Refer to «CHECKING THE FAULT STATUS»(ref-476771-S03113759252012060500000)
  1. Ignition off
  2. Start the engine
  3. Read off the diagnostic status and the fault status for diagnostic trouble code (DTC) ECM-919A. Check the fault status when the status of the diagnostic is COMPLETED. If the fault status is "NO FAULT FOUND" when the diagnostic status is COMPLETED the fault is intermittent at the moment.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S42772118842012060500000)

Note. The ignition must be switched on for at least 30 seconds after the basic conditions are met in order for the adaptation to start. It takes approximately 10 seconds to run the adaptation.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Read off the parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The car must be stationary (no vehicle speed signal) Engine coolant temperature (ECT) between 5-100 °C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation is completed correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO.
  1. Continue Refer to «VERIFICATION»(ref-476771-S04199610412012060500000)
  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine
  4. Read off the diagnostic status and the fault status for diagnostic trouble code (DTC) ECM-919A. Check that the fault status is "NO FAULT FOUND" when the diagnostic status is COMPLETED. If the fault status is "FAULT FOUND" when the diagnostic status is COMPLETED there is a fault.

Is the fault status "NO FAULT FOUND" when the status of the diagnostic is completed?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «PROGRAMMING THE ENGINE CONTROL MODULE (ECM)»(ref-476771-S00885183262012060500000)

PROGRAMMING THE ENGINE CONTROL MODULE (ECM)

HINT: This diagnostic trouble code (DTC) may be caused by faulty software.

  1. Ignition off. Try downloading new software into the engine control module (ECM). To download new software, see «ENGINE CONTROL MODULE (ECM), REPLACING»(ref-476695-S16000409902012060500000) . Remedy as necessary.
  1. Continue Refer to «ADAPTATION OF THE THROTTLE UNIT»(ref-476771-S41568015672012060500000)

Note. The ignition must be switched on for at least 30 seconds after the basic conditions are met in order for the adaptation to start. It takes approximately 10 seconds to run the adaptation.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Read off the parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The car must be stationary (no vehicle speed signal) Engine coolant temperature (ECT) between 5-100 °C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation is completed correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO.
  1. Continue Refer to «VERIFICATION»(ref-476771-S25184832882012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine
  4. Read off the diagnostic status and the fault status for diagnostic trouble code (DTC) ECM-919A. Check that the fault status is "NO FAULT FOUND" when the diagnostic status is COMPLETED. If the fault status is "FAULT FOUND" when the diagnostic status is COMPLETED there is a fault. Remedy as necessary.

Is the fault status is "NO FAULT FOUND"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S19467919462012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CAUTIONThe male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.
  1. Continue Refer to «CHECKING DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-476771-S41336676172012060500000)

Remedy stored diagnostic trouble code(s) (DTCs).

Remedy as necessary.

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

see FAULTY SIGNAL

see FAULTY SIGNAL

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULTY SIGNAL

see FAULTY SIGNAL

see SIGNAL TOO HIGH

see SIGNAL TOO HIGH

see SIGNAL TOO LOW

see SIGNAL TOO LOW

see FAULTY SIGNAL

see FAULTY SIGNAL

see SIGNAL TOO HIGH

see SIGNAL TOO HIGH

see SIGNAL TOO LOW

see SIGNAL TOO LOW

CAUTIONThe male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.
  1. Continue Refer to «CHECKING THE DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-476771-S27929928762012060500000)

Remedy any diagnostic trouble codes (DTCs) that are stored.

Remedy as necessary.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine
  4. Read off diagnostic trouble codes (DTCs). The fault has been remedied if status of the diagnostic trouble code (DTC) is intermittent.

Is the status of the diagnostic trouble code (DTC) intermittent?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S05815858432012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULTY SIGNAL

CAUTIONThe male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.
  1. Continue Refer to «CHECKING THE DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-476771-S22979458002012060500000)

Remedy stored diagnostic trouble code(s) (DTCs).

Remedy as necessary.

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

see SIGNAL TOO HIGH

CAUTIONThe male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.
  1. Continue Refer to «CHECKING THE DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-476771-S03892913162012060500000)

Remedy stored diagnostic trouble code(s) (DTCs).

Remedy as necessary.

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

see SIGNAL TOO LOW

CAUTIONThe male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.
  1. Continue Refer to «CHECKING THE DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-476771-S12766227252012060500000)

Remedy stored diagnostic trouble code(s) (DTCs).

Remedy as necessary.

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

see SIGNAL TOO HIGH

CAUTIONThe male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.
  1. Continue Refer to «CHECKING THE DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-476771-S03784396522012060500000)

Remedy stored diagnostic trouble code(s) (DTCs).

Remedy as necessary.

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

see SIGNAL TOO LOW

CAUTIONThe male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.
  1. Continue Refer to «CHECKING THE DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-476771-S37244363092012060500000)

Remedy stored diagnostic trouble code(s) (DTCs).

Remedy as necessary.

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

see FAULTY SIGNAL

CAUTIONThe male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S30455303882012060500000)

HINT: Faults which caused this diagnostic trouble code (DTC) may affect the adaptation values for the throttle unit. Carry out adaptation of the throttle unit to update the adaptation values.

Note. The ignition must be switched on for at least 30 seconds after the basic conditions are met in order for the adaptation to start. It takes approximately 10 seconds to run the adaptation.

  1. Ignition off
  2. Reinstall the components and connectors etc.
  3. Ignition on
  4. Read off the parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The vehicle must be stationary (no vehicle speed signal) Engine coolant temperature (ECT) between 5-100°C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation has been run correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO.
  1. Continue Refer to «CHECKING THE FUNCTION»(ref-476771-S31350584382012060500000)

CHECKING THE FUNCTION

  1. Ignition on. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". HINT: In some cases several functions of the component will be diagnosed. The affects the amount of time taken to run the diagnostic. The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active.
  1. Continue Refer to «REPLACING THE COMPONENT»(ref-476771-S02877196002012060500000)
  1. Ignition off. For B5xx4T, see «THROTTLE BODY (ELECTRONIC THROTTLE MODULE), REPLACING»(ref-476768-S14571847792012060500000) . For B6xx4T, see «THROTTLE BODY (ELECTRONIC THROTTLE MODULE), REPLACING»(ref-476768-S06588082252012060500000) .
  1. Continue Refer to «VERIFICATION»(ref-476771-S34581619442012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Read off the parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The vehicle must be stationary (no vehicle speed signal) Engine coolant temperature (ECT) between 5-100°C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation has been run correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO.
  1. Continue Refer to «VERIFICATION, CONTINUED»(ref-476771-S18483704052012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition on. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S07593801352012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULTY SIGNAL

see FAULT-TRACING INFORMATION

CAUTIONThe male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.
  1. Continue Refer to «CHECKING THE FAULT STATUS»(ref-476771-S25408859152012060500000)
  1. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". HINT: In some cases several functions of the component will be diagnosed. The affects the amount of time taken to run the diagnostic. The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S33457479902012060500000)

Note. The ignition must be switched on for at least 30 seconds after the basic conditions are met in order for the adaptation to start. It takes approximately 10 seconds to run the adaptation.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Read off the parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The vehicle must be stationary (no vehicle speed signal) Engine coolant temperature (ECT) between 5-100°C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation has been run correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO.
  1. Continue Refer to «VERIFICATION»(ref-476771-S08380997822012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «PROGRAMMING THE ENGINE CONTROL MODULE (ECM)»(ref-476771-S42714782022012060500000)

HINT: This diagnostic trouble code (DTC) may be caused by faulty software.

  1. Ignition off. Try downloading new software to the engine control module (ECM). To download new software, see: «ENGINE CONTROL MODULE (ECM), REPLACING»(ref-476695-S16000409902012060500000) Remedy as necessary.
  1. Continue Refer to «ADAPTATION OF THE THROTTLE UNIT»(ref-476771-S03733148542012060500000)

Note. The ignition must be switched on for at least 30 seconds after the basic conditions are met in order for the adaptation to start. It takes approximately 10 seconds to run the adaptation.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Read off the parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The vehicle must be stationary (no vehicle speed signal) Engine coolant temperature (ECT) between 5-100°C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation has been run correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO.
  1. Continue Refer to «VERIFICATION»(ref-476771-S20609269382012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S07411066972012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULTY SIGNAL

CAUTIONThe male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.
  1. Continue Refer to «CHECKING THE FAULT STATUS»(ref-476771-S41953998042012060500000)
  1. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". HINT: In some cases several functions of the component will be diagnosed. The affects the amount of time taken to run the diagnostic. The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S27425526692012060500000)

Note. The ignition must be switched on for at least 30 seconds after the basic conditions are met in order for the adaptation to start. It takes approximately 10 seconds to run the adaptation.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Read off the parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The vehicle must be stationary (no vehicle speed signal) Engine coolant temperature (ECT) between 5-100°C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation has been run correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO.
  1. Continue Refer to «VERIFICATION»(ref-476771-S30992431022012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «PROGRAMMING THE ENGINE CONTROL MODULE (ECM)»(ref-476771-S41531910752012060500000)

HINT: This diagnostic trouble code (DTC) may be caused by faulty software.

  1. Ignition off. Try downloading new software to the engine control module (ECM). To download new software, see: «ENGINE CONTROL MODULE (ECM), REPLACING»(ref-476695-S16000409902012060500000) Remedy as necessary.
  1. Continue Refer to «ADAPTATION OF THE THROTTLE UNIT»(ref-476771-S11767481892012060500000)

Note. The ignition must be switched on for at least 30 seconds after the basic conditions are met in order for the adaptation to start. It takes approximately 10 seconds to run the adaptation.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Read off the parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The vehicle must be stationary (no vehicle speed signal) Engine coolant temperature (ECT) between 5-100°C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation has been run correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO.
  1. Continue Refer to «VERIFICATION»(ref-476771-S08964636072012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S34750292232012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL TOO HIGH

CAUTIONThe male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.
  1. Continue Refer to «CHECKING THE FAULT STATUS»(ref-476771-S15220733492012060500000)
  1. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". HINT: In some cases several functions of the component will be diagnosed. The affects the amount of time taken to run the diagnostic. The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S42883175842012060500000)

Note. The ignition must be switched on for at least 30 seconds after the basic conditions are met in order for the adaptation to start. It takes approximately 10 seconds to run the adaptation.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Read off the parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The vehicle must be stationary (no vehicle speed signal) Engine coolant temperature (ECT) between 5-100°C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation has been run correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO.
  1. Continue Refer to «VERIFICATION»(ref-476771-S13503892222012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «PROGRAMMING THE ENGINE CONTROL MODULE (ECM)»(ref-476771-S21245676202012060500000)

HINT: This diagnostic trouble code (DTC) may be caused by faulty software.

  1. Ignition off. Try downloading new software to the engine control module (ECM). To download new software, see: «ENGINE CONTROL MODULE (ECM), REPLACING»(ref-476695-S16000409902012060500000) Remedy as necessary.
  1. Continue Refer to «ADAPTATION OF THE THROTTLE UNIT»(ref-476771-S35015712622012060500000)

Note. The ignition must be switched on for at least 30 seconds after the basic conditions are met in order for the adaptation to start. It takes approximately 10 seconds to run the adaptation.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Read off the parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The vehicle must be stationary (no vehicle speed signal) Engine coolant temperature (ECT) between 5-100°C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation has been run correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO.
  1. Continue Refer to «VERIFICATION»(ref-476771-S00123279292012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S19406944242012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL TOO LOW

see FAULTY SIGNAL

see FAULTY SIGNAL

CAUTIONThe male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.
  1. Continue Refer to «CHECKING THE DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-476771-S02607856702012060500000)

Note. The ignition must be switched on for at least 30 seconds after the basic conditions are met in order for the adaptation to start. It takes approximately 10 seconds to run the adaptation.

  1. Ignition off
  2. Ignition on
  3. Read off the parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The vehicle must be stationary (no vehicle speed signal) Engine coolant temperature (ECT) between 5-100°C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation has been run correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO. The fault is intermittent at the moment if the adaptation has been completed correctly.
  1. Continue Refer to «CHECKING CONNECTORS AND COMPONENTS»(ref-476771-S15278747012012060500000)
  1. Ignition off. Check the throttle unit and engine control module (ECM) connectors. Check for contact resistance and oxidation. Check the resistance values of the potentiometers in the throttle unit. Check that the shutter in the throttle unit is not blocked or sticking. Clean as necessary. Remedy as necessary. Other information: For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000) For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) . For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000) For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) . For resistance values: «COMPONENT SPECIFICATIONS»(ref-476694-S25701556572012060500000) For B5xx4T, see «THROTTLE BODY (ELECTRONIC THROTTLE MODULE), REPLACING»(ref-476768-S14571847792012060500000) . For B6xx4T, see «THROTTLE BODY (ELECTRONIC THROTTLE MODULE), REPLACING»(ref-476768-S06588082252012060500000) . For B5xx4T, see «THROTTLE BODY (TB), CLEANING»(ref-476750-S36382112932012060500000) . For B6xx4x, see «THROTTLE BODY (TB), CLEANING»(ref-476750-S05163330712012060500000) . see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476771-S36182573812012060500000)

Remedy stored diagnostic trouble code(s) (DTCs).

Remedy as necessary.

HINT: After carrying out the repair, check that the fault has been remedied.

Note. The ignition must be switched on for at least 30 seconds after the basic conditions are met in order for the adaptation to start. It takes approximately 10 seconds to run the adaptation.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Read off the parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The car must be stationary (no vehicle speed signal) Engine coolant temperature (ECT) between 5-100 °C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation is completed correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO. The fault has been remedied if the adaptation has been completed correctly.

Is the adaptation OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S41764990182012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL TOO HIGH / SIGNAL TOO LOW

see SIGNAL TOO HIGH / SIGNAL TOO LOW

see SIGNAL TOO HIGH / SIGNAL TOO LOW

see FAULTY SIGNAL

see FAULTY SIGNAL

see INTERNAL FAULT

see INTERNAL FAULT

  1. Ignition on
  2. Read off the clutch pedal movement by carefully pressing and releasing the clutch pedal. Check that the value changes with clutch pedal movement. The value must be between 60-70 % when the clutch pedal is unaffected and 10-20 % when the pedal is fully depressed. The fault is intermittent at the moment if the values are OK.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S09188785932012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Ignition on
  4. Read off the clutch pedal movement by carefully pressing and releasing the clutch pedal. Check that the value changes with clutch pedal movement. The value must be between 60-70 % when the clutch pedal is unaffected and 10-20% when the pedal is fully depressed. The fault has been remedied if the values are OK.

Are these values OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S21291677722012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Ignition on
  2. Read off the clutch pedal movement by carefully pressing and releasing the clutch pedal. Check that the value changes with clutch pedal movement. The value must be between 60-70% when the clutch pedal is unaffected and 10-20% when the pedal is fully depressed. The fault is intermittent at the moment if the values are OK.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S14621853662012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Ignition on
  4. Read off the clutch pedal movement by carefully pressing and releasing the clutch pedal. Check that the value changes with clutch pedal movement. The value must be between 60-70 % when the clutch pedal is unaffected and 10-20% when the pedal is fully depressed. The fault has been remedied if the values are OK.

Are these values OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S04781054192012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Ignition on
  2. Read off the clutch pedal movement by carefully pressing and releasing the clutch pedal. Check that the value changes with clutch pedal movement. The value must be between 60-70 % when the clutch pedal is unaffected and 10-20 % when the pedal is fully depressed. The fault is intermittent at the moment if the values are OK.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S31369836732012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Ignition on
  4. Read off the clutch pedal movement by carefully pressing and releasing the clutch pedal. Check that the value changes with clutch pedal movement. The value must be between 60-70 % when the clutch pedal is unaffected and 10-20% when the pedal is fully depressed. The fault has been remedied if the values are OK.

Are these values OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S27255087762012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

  1. Ignition on
  2. Read off the movement of the accelerator pedal by carefully depressing and releasing the accelerator pedal (AP). Check that the value changes with accelerator pedal movement. The value must be approximately 0.4 V when the accelerator pedal (AP) is unaffected and approximately 4 V when the accelerator pedal (AP) is fully depressed. The fault is intermittent at the moment if the values are OK.
  1. Continue Refer to «CHECKING THE POWER SUPPLY»(ref-476771-S31532416992012060500000)

Scheme 262

Scheme 262
Scheme 262
  1. Ignition on. Check the connectors and terminals for water penetration. Check the power supply (12 V) to the accelerator pedal (AP) position sensor between accelerator pedal (AP) position sensor terminals #1 (wiring side) and #3 (wiring side). Check that the power supply is approximately 12 V with the ignition on. Remedy as necessary. Other information: see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000) To connect the breakout box, see «CONNECTING THE BREAKOUT BOX»(ref-476691-S38062545372012060500000) For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000) For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) . For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000) For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) . To access and replace the accelerator pedal (AP) position sensor, see «ACCELERATOR PEDAL (AP), REPLACING»(ref-476780-S18973143032012060500000) .

Is the power supply OK?

  1. YES Refer to «REPLACING THE COMPONENT»(ref-476771-S34560520602012060500000)
  2. NO Refer to «CHECKING THE CONNECTORS AND CABLES»(ref-476771-S11651333872012060500000)
  1. Ignition off. Try a new accelerator pedal (AP) position sensor if no fault is found and the fault is permanent. See «ACCELERATOR PEDAL (AP), REPLACING»(ref-476780-S18973143032012060500000) .
  1. Continue Refer to «VERIFICATION»(ref-476771-S29962269602012060500000)

CHECKING THE CONNECTORS AND CABLES

  1. Ignition off
  2. Check the accelerator pedal (AP) position sensor connector. Check for contact resistance and oxidation. Check the power supply cable (12 V) between accelerator pedal (AP) position sensor terminal #1 (wiring side) and the relevant fuse for the circuit. Check for a short-circuit to ground. Check for an open-circuit. Check that the fuse for the circuit has not blown. Check the ground lead for power supply (12 V) between accelerator pedal (AP) position sensor terminal #3 (wiring side) and the relevant ground terminal. Check for contact resistance and oxidation. Check for an open-circuit. HINT: With the ignition on, the power supply to the accelerator pedal (AP) position sensor must be approximately 12 V measured between accelerator pedal (AP) position sensor terminals #1 (wiring side) and #3 (wiring side). HINT: With the ignition on, the power supply from the engine control module (ECM) must be approximately 5 V measured between accelerator pedal (AP) position sensor terminals #6 (wiring side) and #4 (wiring side). Remedy as necessary. Other information: see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000) To connect the breakout box, see «CONNECTING THE BREAKOUT BOX»(ref-476691-S38062545372012060500000) For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000) For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) . For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000) For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) . To access and replace the accelerator pedal (AP) position sensor, see «ACCELERATOR PEDAL (AP), REPLACING»(ref-476780-S18973143032012060500000) .
  1. Continue Refer to «REPLACING THE COMPONENT»(ref-476771-S34560520602012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Ignition on
  4. Read off the movement of the accelerator pedal by carefully depressing and releasing the accelerator pedal (AP). Check that the value changes with accelerator pedal movement. The value must be approximately 0.4 V when the accelerator pedal (AP) is unaffected and approximately 4 V when the accelerator pedal (AP) is fully depressed. The fault has been remedied if the values are OK.

Are these values OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S13379530212012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULTY SIGNAL

  1. Ignition on
  2. Read off the status from the brake light switch. Check the function of the brake light switch by slowly pressing down and letting up the brake pedal. Check that the status changes between "OFF" when brake pedal is not pressed and "ON" when brake pedal is pressed. If the status from the brake light switch changes according to the above when pressing on the brake pedal, this indicates that the malfunction is intermittent at this time.
  1. Continue Refer to «CHECKING VOLTAGE FEED»(ref-476771-S39681602492012060500000)

CHECKING VOLTAGE FEED

  1. Ignition on Check voltage feed to the brake light switch. Measure between the brake light switch #1 (against cable harness) and ground (frame grounding point). Voltage feed shall be approx. 12 V. If voltage feed is missing: Check the circuit for voltage feed to the brake light switch #1 (against cable harness) for open circuit, short-circuit to ground and damaged fuse for the circuit. Remedy as necessary. Other information: see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000) . To connect the breakout box, see «CONNECTING THE BREAKOUT BOX»(ref-476691-S38062545372012060500000) . For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000) For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) . For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000) For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) . To access/replace brake light switch, see «STOP LAMP SWITCH, REPLACING»(ref-476779-S00282256302012060500000) .
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S35930439712012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Ignition on
  4. Read off the status from the stop lamp switch. Check the function of the stop lamp switch by carefully pressing and releasing the brake pedal. Check that the status changes between "OFF" when the brake pedal is unaffected and "ON" when the brake pedal is depressed. If the status of the stop lamp switch changes as described above when the brake pedal is depressed, the fault has been remedied.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S27810257592012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING INFORMATION

  1. Ignition on
  2. Read off the movement of the accelerator pedal by carefully depressing and releasing the accelerator pedal (AP). Check that the value changes with accelerator pedal movement. The value must be approximately 0.4 V when the accelerator pedal (AP) is unaffected and approximately 4 V when the accelerator pedal (AP) is fully depressed. The fault is intermittent at the moment if the values are OK.
  1. Continue Refer to «CHECKING THE POWER SUPPLY»(ref-476771-S01811323702012060500000)
  1. Ignition on. Check the power supply (12 V) to the accelerator pedal (AP) position sensor between accelerator pedal (AP) position sensor terminals #1 (cable harness side) and #3 (cable harness side). Check that the power supply is approximately 12 V with the ignition on. Remedy as necessary. Other information: see «CONNECTING THE BREAKOUT BOX»(ref-476691-S38062545372012060500000) For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000) For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) . For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000) For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) . see «ACCELERATOR PEDAL (AP), REPLACING»(ref-476780-S18973143032012060500000) see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000) .

Is the power supply OK?

  1. YES Refer to «REPLACING THE COMPONENT»(ref-476771-S37280586742012060500000)
  2. NO Refer to «CHECKING THE CONNECTORS AND CABLES»(ref-476771-S29996945272012060500000)
  1. Ignition off. Try a new accelerator pedal (AP) position sensor if no fault is found and the fault is permanent. See: «ACCELERATOR PEDAL (AP), REPLACING»(ref-476780-S18973143032012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476771-S26989706112012060500000)
  1. Ignition off
  2. Check the accelerator pedal (AP) position sensor connector. Check for contact resistance and oxidation. Check the power supply cable (12 V) between accelerator pedal (AP) position sensor terminal #1 (cable harness side) and the relevant fuse for the circuit. Check for a short-circuit to ground. Check for an open-circuit. Check that the fuse for the circuit is not damaged. Check the ground lead for power supply (12 V) between accelerator pedal (AP) position sensor terminal #3 (cable harness side) and the relevant ground terminal. Check for contact resistance and oxidation. Check for an open-circuit. HINT: With the ignition on, the power supply to the accelerator pedal (AP) position sensor measured between accelerator pedal (AP) position sensor terminals #1 (cable harness side) and #3 (cable harness side) must be approximately 12 V. HINT: With the ignition on, the power supply from the engine control module (ECM) must be approximately 5 V measured between accelerator pedal (AP) position sensor terminals #6 (cable harness side) and #4 (cable harness side). Remedy as necessary. Other information: see «CONNECTING THE BREAKOUT BOX»(ref-476691-S38062545372012060500000) For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000) For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) . For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000) For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) . see «ACCELERATOR PEDAL (AP), REPLACING»(ref-476780-S18973143032012060500000) see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)
  1. Continue Refer to «REPLACING THE COMPONENT»(ref-476771-S37280586742012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Ignition on
  4. Read off the movement of the accelerator pedal by carefully depressing and releasing the accelerator pedal (AP). Check that the value changes with accelerator pedal movement. The value must be approximately 0.4 V when the accelerator pedal (AP) is unaffected and approximately 4 V when the accelerator pedal (AP) is fully depressed. The fault has been remedied if the values are OK.

Are these values OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S12927599542012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL TOO HIGH / SIGNAL TOO LOW

see SIGNAL TOO HIGH / SIGNAL TOO LOW

see SIGNAL TOO HIGH / SIGNAL TOO LOW

  1. Start the engine
  2. Ignition off
  3. Ignition on
  4. Read off the movement of the accelerator pedal by carefully depressing and releasing the accelerator pedal (AP). Check that the value changes with accelerator pedal movement. The value must be between approximately 0.4 V when the accelerator pedal (AP) is unaffected and approximately 4 V when the accelerator pedal (AP) is fully depressed. The fault is intermittent at the moment if the values are OK.
  1. Continue Refer to «CHECKING THE POWER SUPPLY»(ref-476771-S15795106162012060500000)

Scheme 263

Scheme 263
Scheme 263
  1. Ignition on. Check the power supply (12 V) to the accelerator pedal (AP) position sensor between accelerator pedal (AP) position sensor terminals #1 (wiring side) and #3 (wiring side). Check that the power supply is approximately 12 V with the ignition on Other information: see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000) To connect the breakout box, see «CONNECTING THE BREAKOUT BOX»(ref-476691-S38062545372012060500000) For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000) For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) . For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000) For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) . To access and replace the accelerator pedal (AP) position sensor, see «ACCELERATOR PEDAL (AP), REPLACING»(ref-476780-S18973143032012060500000) .

Is the power supply OK?

  1. YES Refer to «CHECKING THE CONNECTORS AND CABLES»(ref-476771-S22785693232012060500000)
  2. NO Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S06106535872012060500000)
  1. Ignition off. Check the signal cable between engine control module (ECM) terminal #B25 (#B35) and accelerator pedal (AP) position sensor terminal #2. Check for a short-circuit to supply voltage. Try a new accelerator pedal (AP) position sensor if no fault is found and the fault is permanent. Remedy as necessary. Other information: see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000) To connect the breakout box, see «CONNECTING THE BREAKOUT BOX»(ref-476691-S38062545372012060500000) For 5 cylinder turbocharged engines -2004, see «SIGNAL DESCRIPTION»(ref-476694-S26303328522012060500000) For 5 cylinder turbocharged engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S29505181092012060500000) . For 6 cylinder engines -2004, see «SIGNAL SPECIFICATION»(ref-476694-S39196199822012060500000) For 6 cylinder engines 2005-, see «SIGNAL SPECIFICATION»(ref-476694-S31890965202012060500000) . To access and replace the accelerator pedal (AP) position sensor, see «ACCELERATOR PEDAL (AP), REPLACING»(ref-476780-S18973143032012060500000) .
  1. Continue Refer to «VERIFICATION»(ref-476771-S00014553662012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine
  4. Ignition off
  5. Ignition on
  6. Read off the movement of the accelerator pedal by carefully depressing and releasing the accelerator pedal (AP). Check that the value changes with accelerator pedal movement. The value must be between approximately 0.4 V when the accelerator pedal (AP) is unaffected and approximately 4 V when the accelerator pedal (AP) is fully depressed. The fault has been remedied if the values are OK.

Are these values OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476771-S02251460532012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

More articles — Engine Control Module (ECM) Diagnostic Trouble Codes - 7 of 13
