Engine Control Module (ECM) Diagnostic Trouble Codes - 11 of 13: Other Volvo XC90 I

Testing & Diagnostics 12 illustrations ~10536 words

FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

VERIFICATION

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 384

Scheme 384: VERIFICATION

Scheme 385

Scheme 385
  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Check that the engine is firing on all cylinders and is not misfiring.

Is the engine running on all cylinders?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S03190996412012060500000)

FAULT-TRACING INFORMATION

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT TRACING

see FAULT TRACING

CHECKING AIR LEAKAGE AND COMPONENT

Check the exhaust system for air leakage.

If no air leakage is found on the exhaust system, replace the front heated oxygen sensor (bank 1).

If the above troubleshooting does not fix the problem, try with a new front catalytic converter (bank 1).

Remedy as necessary.

Other information

  1. see «EXHAUST MANIFOLD»(ref-476768-S20924415312012060500000)
  2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-476768-S18546887202012060500000)

Scheme 386

Scheme 386
  1. Continue Refer to «VERIFICATION»(ref-476782-S39009646812012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 387

Scheme 387: VERIFICATION
  1. Start the engine and let it idle until it has reached operating temperature (approx. 80 °C).
  2. Test-drive the vehicle on road. Drive in float mode (normal road load), constant speed around 70-90 km/h for approx. 30-40 seconds.
  3. Connect the VCT2000 (or appropriate scan tool) to the data link connector without turning off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and trouble status for the diagnostic trouble code. Check that the diagnosis is "Implemented" and that the trouble status is "No malfunction found". If the trouble status is "Malfunction found", this indicates defective function.

Trouble status shows "No malfunction found"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S39714022412012060500000)

see FAULT-TRACING

Check the exhaust system for air leakage.

If no air leakage is found on the exhaust system, replace the front heated oxygen sensor (bank 1).

If the above troubleshooting does not fix the problem, try with a new front catalytic converter (bank 1).

Remedy as necessary.

Other information

  1. see «AIR LEAKS IN THE INTAKE SYSTEM, CHECKING»(ref-476750-S38054557722012060500000)
  2. see «HEATED OXYGEN SENSOR (HO2S), REPLACING»(ref-476768-S40343228252012060500000)
  3. see «EXHAUST MANIFOLD/GASKET, CYLINDER 1, 3, 5 AND 7 (BANK 1), REPLACING»(ref-476768-S21666858272012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476782-S05117960632012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Start the engine and let it idle until it has reached operating temperature (approx. 80 °C).
  2. Test-drive the vehicle on road. Drive in float mode (normal road load), constant speed around 70-90 km/h for approx. 30-40 seconds.
  3. Connect the VCT2000 (or appropriate scan tool) to the data link connector without turning off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and trouble status for the diagnostic trouble code. Check that the diagnosis is "Implemented" and that the trouble status is "No malfunction found". If the trouble status is "Malfunction found", this indicates defective function.

Trouble status shows "No malfunction found"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S34921521292012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check the exhaust system for air leakage.

If no air leakage is found on the exhaust system, replace the front heated oxygen sensor (bank 2).

If the above troubleshooting does not fix the problem, try with a new front catalytic converter (bank 2).

Remedy as necessary.

Other information

  1. see «EXHAUST MANIFOLD»(ref-476768-S20924415312012060500000)
  2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-476768-S18546887202012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476782-S08043844842012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Start the engine and let it idle until it has reached operating temperature (approx. 80 °C).
  2. Test-drive the vehicle on road. Drive in float mode (normal road load), constant speed around 70-90 km/h for approx. 30-40 seconds.
  3. Connect the VCT2000 (or appropriate scan tool) to the data link connector without turning off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and trouble status for the diagnostic trouble code. Check that the diagnosis is "Implemented" and that the trouble status is "No malfunction found". If the trouble status is "Malfunction found", this indicates defective function.

Trouble status shows "No malfunction found"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S24576275652012060500000)

see FAULT-TRACING

Note. This diagnostic trouble code (DTC) can be stored if installation of the front and rear oxygen sensors is mixed up. Mixing up regards the physical installation of the heated oxygen sensors, where the front one is screwed into place where the rear one is to be located, and vice versa. The connectors and cable harness are correctly connected. These cannot be mixed.

HINT: Check the part nos. of the components visually and compare with the parts register in VIDA (Volvo scan tool). Ensure that they are installed in the correct location.

Check the exhaust system for air leakage.

If no air leakage is found on the exhaust system, replace the front heated oxygen sensor (bank 2).

If the above troubleshooting does not fix the problem, try with a new front catalytic converter (bank 2).

Remedy as necessary.

Other information

  1. see «AIR LEAKS IN THE INTAKE SYSTEM, CHECKING»(ref-476750-S38054557722012060500000)
  2. see «HEATED OXYGEN SENSOR (HO2S), REPLACING»(ref-476768-S40343228252012060500000)
  3. see «EXHAUST MANIFOLD/GASKET, CYLINDER 2, 4, 6 AND 8 (BANK 2), REPLACING»(ref-476768-S03971953522012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476782-S05413917292012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Start the engine and let it idle until it has reached operating temperature (approx. 80 °C).
  2. Test-drive the vehicle on road. Drive in float mode (normal road load), constant speed around 70-90 km/h for approx. 30-40 seconds.
  3. Connect the VCT2000 (or appropriate scan tool) to the data link connector without turning off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and trouble status for the diagnostic trouble code. Check that the diagnosis is "Implemented" and that the trouble status is "No malfunction found". If the trouble status is "Malfunction found", this indicates defective function.

Trouble status shows "No malfunction found"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S26521839882012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CHECKING SOFTWARE

Note. For vehicles of model year 2007-2008, the software in the engine control module (ECM) should be checked before fault tracing is carried out of the fault relating to the leak from the tank system.

Scheme 388

Scheme 388: CHECKING SOFTWARE

Scheme 389

Scheme 389
  1. Ignition on. Use the VCT2000 (or appropriate scan tool) to read out and check the software version in the Engine control module. NOTE: More instructions follow together with the read out.

Has the latest software been downloaded to the control module?

  1. YES Refer to «PERFORM QUICK-TEST TANK SYSTEM»(ref-476782-S11973385782012060500000)

Scheme 390

Scheme 390
  1. Activate the test using the VCT2000 (or appropriate scan tool).
  2. Read off initial parameters and check them according to start conditions for performing the test.
  3. Check that the test has started. Parameters run status shall go to "In progress" and the test phase shall go to "Reference". NOTE: If the test does not start, check that the start conditions are fulfilled. When the reference phase is finished, check of the tank system starts. The pressure in the tank starts to increase, see graph. Within 15 minutes the Engine control module makes a decision as to whether there is leakage in the tank system or not. The test is finished.
  4. Check parameters for test result and follow relevant instructions provided in this service information. NOTE: Estimated leakage shall be used to get an idea of the proximity to the diagnostic trouble code limit. If the estimated leakage is very near the diagnostic trouble code limit (greater than 0.3mm), troubleshooting should probably be performed despite the Tank system, test result shows "No leakage found", especially if a diagnostic trouble code for leakage has been stored earlier. NOTE: Use diagnostic trouble code counter to, see the frequency of the problem. Also use frozen values to get an idea if external conditions may have affected the result. Compare with current conditions in the workshop. Conditions for starting the quick test of the fuel tank system No DTCs related to EVAP purge valve or ambient air pressure sensor set. Battery voltage 11-15 V. Atmospheric pressure higher than 750 hPa, approx. 2500 m (8200 ft). Fuel level 0-85 %. Ambient air temperature 4-35 °C. NOTE: The battery voltage must be correct throughout the entire test. The test can take up to 15 minutes, depending on the quantity of fuel in the fuel tank. It is highly recommended to use the constant voltage charger, Midtronics PSC-550, during the test. For more information, see 30-04 (USA/CDN). Other information see «DESCRIPTION OF PARAMETERS, QUICK TEST OF THE FUEL TANK SYSTEM»(ref-494825-S06435322702012081600000) see «TEST PHASES, QUICK TEST FUEL TANK SYSTEM»(ref-494829-S32160542522012081600000) see «LOCATION OF COMPONENTS»(ref-476766-S34089063632012060500000) see «LEAK DIAGNOSTIC PUMP, REPLACING»(ref-476751-S30362075082012060500000) Select alternative according to relevant test results: DMTL, test result = "Problem found" Refer to «DMTL, TEST RESULT = "PROBLEM FOUND"»(ref-476782-S31853503332012060500000) Tank system, test result = "No leakage found" Refer to «TANK SYSTEM, TEST RESULT = "NO LEAKAGE FOUND"»(ref-476782-S24410991582012060500000) Tank system, test result = "Major leakage found" or "Minor leakage found" Refer to «TANK SYSTEM, TEST RESULT = "MAJOR LEAKAGE FOUND" OR "MINOR LEAKAGE FOUND"»(ref-476782-S09720887372012060500000) DMTL, test result and Tank system, test result = "Unknown" Refer to «DMTL, TEST RESULT AND TANK SYSTEM, TEST RESULT = "UNKNOWN"»(ref-476782-S34448369312012060500000) Cancel fault-tracing. FAULT NOT FOUND: Troubleshooting has been completed.

see FAULT-TRACING

Note. For vehicles of model year 2005-2007, the software in the engine control module (ECM) should be checked before fault tracing of the fault relating to the leak from the tank system is carried out.

  1. Ignition on. Use the VCT2000 (or appropriate scan tool) to read out and check the software version in the Engine control module. NOTE: More instructions follow together with the read out.

Has the latest software been downloaded to the control module?

  1. YES Refer to «PERFORM QUICK-TEST TANK SYSTEM»(ref-476782-S11822432702012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. By once again starting quick-test of EVAP-valve and checking result, one can confirm if the work has fixed the malfunction.
  4. Engine idling during the entire test. Activate quick-test EVAP-valve. The test takes a few seconds. Check that the result shows "No malfunction found". This indicates that the malfunction has been fixed and the function is OK.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S31324278772012060500000)

see FAULT-TRACING

CHECKING COMPONENT AND CONNECTIONS

  1. By activating quick-test of EVAP-valve, the valve's status can be decided. The test is based on pressure pulses through the valve and, in this way, the valve's function can be checked. If malfunction is detected on the EVAP-valve when performing the quick-test, this indicates that the malfunction is permanent.
  2. Engine idling during the entire test. Activate quick-test EVAP-valve. The test takes a few seconds. If the result shows "Malfunction found", function is poor. Check hose/hose connections between EVAP-valve and canister for damage, clogging or squeezing. The valve may need to be cleaned or replaced. If the result shows "No malfunction found", function is correct. Then check hose/hose connections between EVAP-valve and inlet pipe for damage, clogging or squeezing. Remedy as necessary. Other information see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476782-S38418225132012060500000)

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. By once again starting quick-test of EVAP-valve and checking result, one can confirm if the work has fixed the malfunction.
  4. Engine idling during the entire test. Activate quick-test EVAP-valve. The test takes a few seconds. Check that the result shows "No malfunction found". This indicates that the malfunction has been fixed and the function is OK.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S30438231372012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Note. For vehicles of model year 2007-2008, the software in the engine control module (ECM) should be checked before fault tracing is carried out of the fault relating to the leak from the tank system.

  1. Ignition on. Use the VCT2000 (or appropriate scan tool) to read out and check the software version in the Engine control module. NOTE: More instructions follow together with the read out.

Has the latest software been downloaded to the control module?

  1. YES Refer to «PERFORM QUICK-TEST TANK SYSTEM»(ref-476782-S05046955822012060500000)

see FAULT-TRACING

Note. For vehicles of model year 2005-2007, the software in the engine control module (ECM) should be checked before fault tracing of the fault relating to the leak from the tank system is carried out.

  1. Ignition on. Use the VCT2000 (or appropriate scan tool) to read out and check the software version in the Engine control module. NOTE: More instructions follow together with the read out.

Has the latest software been downloaded to the control module?

  1. YES Refer to «PERFORM QUICK-TEST TANK SYSTEM»(ref-476782-S26514976112012060500000)

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

CHECKING THE STATUS

  1. Ignition on Check if the malfunction is permanent or intermittent by activating the EVAP-valve. Listen for clicking sounds and/or feel the valve for frequent vibrations. If the valve does not vibrate, this indicates a permanent malfunction. If the valve vibrates, this indicates that the malfunction is intermittent and not active right now.
  1. Continue Refer to «CHECKING COMPONENT AND CABLES»(ref-476782-S02972922882012060500000)

CHECKING COMPONENT AND CABLES

Check the EVAP-valve's connector for contact resistance and oxidation.

Check the cable between engine control module (ECM) #A92 (#B32) and EVAP-valve #2 for short-circuit to ground and open circuit.

Remedy as necessary.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-476691-S27857399862012060500000)
  2. see «SIGNAL SPECIFICATION, ENGINE CONTROL MODULE (ECM)»(ref-476694-S30016655152012060500000)
  3. see «EVAP VALVE, REPLACING»(ref-476751-S05915412132012060500000)
  4. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)

Scheme 391

Scheme 391
  1. Continue Refer to «VERIFICATION»(ref-476782-S08013935012012060500000)

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Ignition on
  4. Start activation of the EVAP-valve. Listen for clicking sounds and/or feel the valve for frequent vibrations.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S19740936402012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

  1. Ignition on Check if the malfunction is permanent or intermittent by activating the EVAP-valve. Listen for clicking sounds and/or feel the valve for frequent vibrations. If the valve does not vibrate, this indicates a permanent malfunction. If the valve vibrates, this indicates that the malfunction is intermittent and not active right now.
  1. Continue Refer to «CHECKING COMPONENTS AND CABLES»(ref-476782-S34233571872012060500000)

CHECKING COMPONENTS AND CABLES

Check the EVAP-valve's connector for contact resistance and oxidation.

Check the cable between engine control module (ECM) #A92 (#B32) and EVAP-valve #2 for short-circuit to voltage.

Remedy as necessary.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-476691-S27857399862012060500000)
  2. see «SIGNAL SPECIFICATION, ENGINE CONTROL MODULE (ECM)»(ref-476694-S30016655152012060500000)
  3. see «EVAP VALVE, REPLACING»(ref-476751-S05915412132012060500000)
  4. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476782-S08456564612012060500000)

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Ignition on
  4. Start activation of the EVAP-valve. Listen for clicking sounds and/or feel the valve for frequent vibrations.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S05626246962012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

CHECKING CONNECTOR

Check the fuel level sensor's connector and connections for contact resistance and oxidation.

Remedy as necessary.

Other information

  1. For replacement of fuel pump: «LEVEL SENSOR, FUEL TANK, RIGHT-HAND/FUEL TANK, REPLACING»(ref-476751-S01439095012012060500000)
  2. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17655503092012060500000)

Scheme 392

Scheme 392
  1. Continue Refer to «VERIFICATION»(ref-476782-S33175107282012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on Read off the signal from the fuel level sensor (via central electronic module (CEM)). Check that the signal is reasonable, that it moves when the vehicle is rocked lightly and that it then stabilizes at a reasonable level. Reasonable signal indicates that the malfunction has been remedied. HINT: Completely full tank may mean that the level change when rocking the vehicle is not clear enough.

Is the signal reasonable?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S22897746432012060500000)

see FAULT TRACING

  1. Ignition on Check if the malfunction is permanent or intermittent by reading off the signal from the fuel level sensor (via central electronic module (CEM)) and check that it is reasonable, that it moves when the vehicle is rocked lightly and that it then stabilizes at a reasonable level. Incorrect signal indicates that the malfunction is permanent. If the signal is reasonable, this indicates that the malfunction is intermittent. HINT: Completely full tank may mean that the level change when rocking the vehicle is not clear enough.
  1. Continue Refer to «CHECKING CONNECTOR»(ref-476782-S35043725312012060500000)

Check the fuel level sensor's connector and connections for contact resistance and oxidation.

Remedy as necessary.

Other information

  1. For replacing fuel pump: «LEVEL SENSOR, FUEL TANK, RIGHT-HAND/FUEL TANK, REPLACING»(ref-476751-S01439095012012060500000)
  2. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476782-S27428116852012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on Read off the signal from the fuel level sensor (via central electronic module (CEM)). Check that the signal is reasonable, that it moves when the vehicle is rocked lightly and that it then stabilizes at a reasonable level. Reasonable signal indicates that the malfunction has been remedied. HINT: Completely full tank may mean that the level change when rocking the vehicle is not clear enough.

Is the signal reasonable?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S11581683552012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT TRACING

see FAULT TRACING

see FAULT TRACING

see FAULT TRACING

see FAULT-TRACING

see FAULT-TRACING

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on Activate the engine cooling fan using the VCT2000 (or appropriate scan tool). Check that the engine cooling fan (FC) starts when activated.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S12418984072012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

INFORMATION

No troubleshooting has been developed for this diagnostic trouble code (DTC). Diagnostic trouble code (DTC) for this malfunction is first stored in the brake control module (BCM), then in the engine control module (ECM). This diagnostic trouble code (DTC) cannot be erased before the diagnostic trouble code (DTC) in the brake control module (BCM) has been erased and remedied.

Therefore, first read off the diagnostic trouble codes in the brake control module (BCM), perform troubleshooting and take appropriate action. Then this diagnostic trouble code can be erased.

No fault-tracing has been developed for this diagnostic trouble code (DTC).

The diagnostic trouble code (DTC) for this fault is first stored in the Brake control module (BCM), then in the Engine control module (ECM). This diagnostic trouble code (DTC) can first be erased when the root fault has been remedied and the diagnostic trouble code (DTC) for the root fault has been erased.

For further information on this diagnostic trouble code, see Diagnostic trouble code (DTC) information.

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

There is no troubleshooting for this diagnostic trouble code (DTC). A diagnostic trouble code for CAN-communication can also be generated in the central electronic module (CEM). In some instances, the diagnostic trouble code is generated in other related control modules. This code should not be erased until the code in the central electronic module (CEM) and other related control modules has been remedied and erased. Thus, first read out diagnostic trouble codes (DTCs) in the central electronic module (CEM) and other related control modules, perform troubleshooting and take appropriate action. After that, this code can be erased.

Other information

  1. see «GENERAL INFORMATION ABOUT FAULT-TRACING IN THE CAN NETWORK»(ref-494734-S01796838862012081600000)

HINT: Try using the Information Manager if the desired diagnostic trouble code information cannot be found.

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Run the starter motor/start the engine.
  4. Read off the status from the ignition lock. Check that the read off status from the ignition lock corresponds to the actual position of the ignition lock.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S08082117472012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Ignition on, wait for at least 15 seconds to perform the diagnosis. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Check if the malfunction is permanent or intermittent by reading off the diagnostic trouble code's status when the diagnostic status is "Implemented". If the trouble status is "Malfunction found", this indicates that the malfunction is permanent. If the trouble status is "No malfunction found", this indicates that the malfunction is intermittent and not active right now. NOTE: Trouble status cannot go from "Malfunction found" to "No malfunction found" in the same operating cycle.
  1. Continue Refer to «REPLACING THE COMPONENT»(ref-476782-S22835225972012060500000)

REPLACING THE COMPONENT

The engine control module (ECM) has registered an internal fault.

If the fault is intermittent, it has been registered previously but no longer remains. Intermittent faults can be due to disruption when the engine control module (ECM) started or can be another type of fault that may recur at different instances. The fault is assessed on a case by case basis. If the fault recurs, replace the engine control module (ECM).

In the event of a permanent fault, replace the engine control module (ECM).

Remedy as necessary.

Other information

  1. see «ENGINE CONTROL MODULE (ECM)»(ref-476695-S30933262542012060500000)

Scheme 393

Scheme 393
  1. Continue Refer to «INFORMATION»(ref-476782-S09012874072012060500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

see FAULT TRACING

see FAULT-TRACING

see FAULT-TRACING

CHECKING COMPONENTS

HINT: Incorrect oil grade can cause malfunctions in the variable valve timing (VVT) unit. Contaminants in the engine oil can cause damage to components in the variable valve timing (VVT) unit.

Check the engine oil grade. Check especially for contaminants.

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Check the engine oil pressure.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by an internal fault in the variable valve timing (VVT) unit. If the above fault-tracing/remedies do not rectify the fault, the variable valve timing (VVT) unit may be damaged.

Remedy as necessary.

Other information

  1. see «OIL PRESSURE, CHECKING»(ref-476770-S17127498902012060500000)
  2. see «VVT UNIT, RIGHT CYLINDER HEAD»(ref-476775-S35498753212012060500000)
  3. see «VVT UNIT, LEFT CYLINDER HEAD»(ref-476775-S00445910052012060500000)
  4. see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000)

Scheme 394

Scheme 394
  1. Continue Refer to «VERIFICATION»(ref-476782-S38155989922012060500000)

VERIFICATION, PART 1

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Verification consists of 2 parts. Part 1 is carried out via a test in the workshop. Part 2 is carried out on the road. If the function is determined as incorrect in part 1, then part 2 does not need to be carried out. If the function is determined as being correct in part 1 and the vehicle can be tested on the road, part 2 must be carried out. This is because the function can be difficult the check in a workshop environment in certain cases.
  2. Ignition off
  3. Reconnect the connectors, components, etc.
  4. Start and run the engine to operating temperature.
  5. Read off the shift angle of the camshaft and the desired shift angle of the camshaft to check the function. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476782-S09813119342012060500000)
  2. NO Refer to «INFORMATION»(ref-476782-S31468708602012060500000)

VERIFICATION, PART 2

  1. Test drive the car on the road. Use acceleration and engine braking. Repeat the procedure several times so that the camshaft control works and the engine control module (ECM) can carry out diagnostics.
  2. Connect the VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  3. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S31468708602012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

HINT: Incorrect oil grade can cause malfunctions in the variable valve timing (VVT) unit. Contaminants in the engine oil can cause damage to components in the variable valve timing (VVT) unit.

Check the engine oil grade. Check especially for contaminants.

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Check the engine oil pressure.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by an internal fault in the variable valve timing (VVT) unit. If the above fault-tracing/remedies do not rectify the fault, the variable valve timing (VVT) unit may be damaged.

Remedy as necessary.

Other information

  1. see «LOCATION OF COMPONENTS»(ref-476766-S34089063632012060500000)
  2. see «VARIABLE CAMSHAFT TIMING OIL CONTROL SOLENOID»(ref-476762-S39752382502012060500000)
  3. see «VARIABLE CAMSHAFT TIMING OIL CONTROL SOLENOID»(ref-476775-S19489647692012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476782-S17423093962012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Verification consists of 2 parts. Part 1 is carried out via a test in the workshop. Part 2 is carried out on the road. If the function is determined as incorrect in part 1, then part 2 does not need to be carried out. If the function is determined as being correct in part 1 and the vehicle can be tested on the road, part 2 must be carried out. This is because in certain cases the function can be difficult the check in a workshop environment.
  2. Ignition off
  3. Reconnect the connectors, components, etc.
  4. Start and run the engine to operating temperature.
  5. Read off the shift angle of the camshaft and the desired shift angle of the camshaft to check the function. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476782-S37446438242012060500000)
  2. NO Refer to «INFORMATION»(ref-476782-S08393670242012060500000)
  1. Test drive the car on the road. Use acceleration and engine braking. Repeat the procedure several times so that the camshaft control works and the engine control module (ECM) can carry out diagnostics.
  2. Connect the VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  3. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S08393670242012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

HINT: Incorrect oil grade can cause malfunctions in the variable valve timing (VVT) unit. Contaminants in the engine oil can cause damage to components in the variable valve timing (VVT) unit.

Check the engine oil grade. Check especially for contaminants.

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Check the engine oil pressure.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by an internal fault in the variable valve timing (VVT) unit. If the above fault-tracing/remedies do not rectify the fault, the variable valve timing (VVT) unit may be damaged.

Remedy as necessary.

Other information

  1. see «OIL PRESSURE, CHECKING»(ref-476770-S17127498902012060500000)
  2. see «VVT UNIT, RIGHT CYLINDER HEAD»(ref-476775-S35498753212012060500000)
  3. see «VVT UNIT, LEFT CYLINDER HEAD»(ref-476775-S00445910052012060500000)
  4. see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476782-S03988964632012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Verification consists of 2 parts. Part 1 is carried out via a test in the workshop. Part 2 is carried out on the road. If the function is determined as incorrect in part 1, then part 2 does not need to be carried out. If the function is determined as being correct in part 1 and the vehicle can be tested on the road, part 2 must be carried out. This is because in certain cases the function can be difficult the check in a workshop environment.
  2. Ignition off
  3. Reconnect the connectors, components, etc.
  4. Start and run the engine to operating temperature.
  5. Read off the shift angle of the camshaft and the desired shift angle of the camshaft to check the function. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476782-S27895344532012060500000)
  2. NO Refer to «INFORMATION»(ref-476782-S28071381562012060500000)
  1. Test drive the car on the road. Use acceleration and engine braking. Repeat the procedure several times so that the camshaft control works and the engine control module (ECM) can carry out diagnostics.
  2. Connect the VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  3. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S28071381562012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

Engine control module (ECM) has registered that the A/C pressure sensor is damaged.

If the malfunction is intermittent, it has been registered previously but no longer remains. Intermittent malfunctions can be due to disruption when the control module started or can be another type of malfunction that may recur at different instances. If the malfunction is permanent it means that it is active right now. The malfunction is assessed on a case by case basis.

Remedy as necessary.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-476691-S30437390172012060500000)
  2. see «SIGNAL SPECIFICATION»(ref-476694-S14228516802012060500000)
  3. see «LOCATION OF COMPONENTS»(ref-476766-S34089063632012060500000)
  4. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17655503092012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476782-S15765508112012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Start the engine.
  4. A/C on.
  5. Read the diagnostic status and trouble status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Check the trouble status for the diagnostic trouble code when the diagnosis is "Implemented". When the function is correct the trouble status should be "No malfunction found" when the diagnosis is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S06928259442012060500000)

see FAULT-TRACING

  1. Start the engine.
  2. A/C on. Read the diagnostic status and trouble status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Check if the malfunction is permanent or intermittent by reading off the diagnostic trouble code's status when the diagnostic status is "Implemented". If the trouble status is "Malfunction found", this indicates that the malfunction is permanent. If the trouble status is "No malfunction found", this indicates that the malfunction is intermittent and not active right now. NOTE: Trouble status cannot go from "Malfunction found" to "No malfunction found" in the same operating cycle.
  1. Continue Refer to «REPLACING THE COMPONENT»(ref-476782-S10239832742012060500000)

Engine control module (ECM) has registered that the A/C pressure sensor is damaged.

If the malfunction is intermittent, it has been registered previously but no longer remains. Intermittent malfunctions can be due to disruption when the control module started or can be another type of malfunction that may recur at different instances. If the malfunction is permanent it means that it is active right now. The malfunction is assessed on a case by case basis.

Remedy as necessary.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-476691-S27857399862012060500000)
  2. see «SIGNAL SPECIFICATION, ENGINE CONTROL MODULE (ECM)»(ref-476694-S30016655152012060500000)
  3. see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000)
  4. see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476782-S07477537582012060500000)

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Start the engine.
  4. A/C on.
  5. Read the diagnostic status and trouble status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Check the trouble status for the diagnostic trouble code when the diagnosis is "Implemented". When the function is correct the trouble status should be "No malfunction found" when the diagnosis is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S26088102022012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

  1. Ignition on Read the diagnostic status and trouble status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Check if the malfunction is permanent or intermittent by reading off the diagnostic trouble code's status when the diagnostic status is "Implemented". If the trouble status is "Malfunction found", this indicates that the malfunction is permanent. If the trouble status is "No malfunction found", this indicates that the malfunction is intermittent and not active right now. NOTE: Trouble status cannot go from "Malfunction found" to "No malfunction found" in the same operating cycle.
  1. Continue Refer to «CHECKING COMPONENT AND CABLES»(ref-476782-S36827547632012060500000)

Scheme 395

Scheme 395
  1. Ignition off Check the signal cables for open circuit. Check between: Engine control module (ECM) #B12 (#C12) and A/C pressure sensor's connector #12, signal cable (+). Engine control module (ECM) #B19 (#C19) and A/C pressure sensor's connector #3, voltage feed. Engine control module (ECM) #B8 (#C8) and A/C pressure sensor's connector #1, ground. Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-476691-S27857399862012060500000) see «SIGNAL SPECIFICATION, ENGINE CONTROL MODULE (ECM)»(ref-476694-S30016655152012060500000) see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000) see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476782-S29195607542012060500000)

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Ignition on
  4. Read the diagnostic status and trouble status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Check the trouble status for the diagnostic trouble code when the diagnosis is "Implemented". When the function is correct the trouble status should be "No malfunction found" when the diagnosis is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S18030549442012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

  1. Ignition on Read the diagnostic status and trouble status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Check if the malfunction is permanent or intermittent by reading off the diagnostic trouble code's status when the diagnostic status is "Implemented". If the trouble status is "Malfunction found", this indicates that the malfunction is permanent. If the trouble status is "No malfunction found", this indicates that the malfunction is intermittent and not active right now. NOTE: Trouble status cannot go from "Malfunction found" to "No malfunction found" in the same operating cycle.
  1. Continue Refer to «CHECKING COMPONENT AND CABLES»(ref-476782-S08725606622012060500000)
  1. Ignition off Check the signal cables for short-circuit to voltage and open circuit. Check between: Engine control module (ECM) #B12 (#C12) and A/C pressure sensor's connector #12, signal cable (+). Engine control module (ECM) #B19 (#C19) and A/C pressure sensor's connector #3, voltage feed. Engine control module (ECM) #B8 (#C8) and A/C pressure sensor's connector #1, ground. Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-476691-S27857399862012060500000) see «SIGNAL SPECIFICATION, ENGINE CONTROL MODULE (ECM)»(ref-476694-S30016655152012060500000) see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000) see «CHECKING WIRING AND TERMINALS»(ref-476689-S17283010372012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476782-S18797515072012060500000)

HINT: After repairing, it is necessary to check that the malfunction has been fixed.

  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Ignition on
  4. Read the diagnostic status and trouble status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Check the trouble status for the diagnostic trouble code when the diagnosis is "Implemented". When the function is correct the trouble status should be "No malfunction found" when the diagnosis is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S40137680912012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

HINT: Incorrect oil grade can cause malfunctions in the variable valve timing (VVT) unit. Contaminants in the engine oil can cause damage to components in the variable valve timing (VVT) unit.

Check the engine oil grade. Check especially for contaminants.

HINT: The VVT unit for the exhaust camshaft has a spring which turns the camshaft at control. This means that if the oil pressure becomes too low for the VVT unit, the spring controls the camshaft out too much.

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Check the engine oil pressure.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by an internal fault in the variable valve timing (VVT) unit. If the above fault-tracing/remedies do not rectify the fault, the variable valve timing (VVT) unit may be damaged.

Remedy as necessary.

Other information

  1. see «OIL PRESSURE, CHECKING»(ref-476770-S17127498902012060500000)
  2. see «VVT UNIT EXHAUST CAMSHAFT, REPLACING»(ref-476775-S12438293002012060500000)
  3. see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476782-S16006511542012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Verification consists of 2 parts. Part 1 is carried out via a test in the workshop. Part 2 is carried out on the road. If the function is determined as incorrect in part 1, then part 2 does not need to be carried out. If the function is determined as being correct in part 1 and the vehicle can be tested on the road, part 2 must be carried out. This is because in certain cases the function can be difficult the check in a workshop environment.
  2. Ignition off
  3. Reconnect the connectors, components, etc.
  4. Start and run the engine to operating temperature.
  5. Read off the shift angle of the camshaft and the desired shift angle of the camshaft to check the function. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476782-S05638422672012060500000)
  2. NO Refer to «INFORMATION»(ref-476782-S33315697662012060500000)
  1. Test drive the car on the road. Use acceleration and engine braking. Repeat the procedure several times so that the camshaft control works and the engine control module (ECM) can carry out diagnostics.
  2. Connect the VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  3. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S33315697662012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

HINT: Contaminants in the engine oil can cause damage to components in the variable valve timing (VVT) unit.

Check the engine oil grade. Check especially for contaminants.

Remove the camshaft reset valve, check the reset valve and the oil ducts in the cylinder head. Check for contaminants and blockages.

Try a new camshaft reset valve if no fault is found or if the above remedies do not rectify the fault.

HINT: The fault can also be caused by an internal fault in the variable valve timing (VVT) unit. If the above fault-tracing/remedies do not rectify the fault, the variable valve timing (VVT) unit may be damaged.

Remedy as necessary.

Other information

  1. see «VVT UNIT EXHAUST CAMSHAFT, REPLACING»(ref-476775-S12438293002012060500000)
  2. see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-476766-S16137402102012060500000)
  1. Continue Refer to «VERIFICATION»(ref-476782-S16385636812012060500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Verification consists of 2 parts. Part 1 is carried out via a test in the workshop. Part 2 is carried out on the road. If the function is determined as incorrect in part 1, then part 2 does not need to be carried out. If the function is determined as being correct in part 1 and the vehicle can be tested on the road, part 2 must be carried out. This is because in certain cases the function can be difficult the check in a workshop environment.
  2. Ignition off
  3. Reconnect the connectors, components, etc.
  4. Start and run the engine to operating temperature.
  5. Read off the shift angle of the camshaft and the desired shift angle of the camshaft to check the function. Check that the camshaft shift angle corresponds to the desired value for the camshaft shift angle with an accuracy of approximately 8° CA (camshaft angle). The difference between the values can be read off in the lower digital display.

Is the function OK?

  1. YES Refer to «VERIFICATION, PART 2»(ref-476782-S21802313692012060500000)
  2. NO Refer to «INFORMATION»(ref-476782-S20908803922012060500000)
  1. Test drive the car on the road. Use acceleration and engine braking. Repeat the procedure several times so that the camshaft control works and the engine control module (ECM) can carry out diagnostics.
  2. Connect the VCT2000 (or appropriate scan tool) to the data link connector without switching off the engine.
  3. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S20908803922012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Read off the battery voltage. Check the battery voltage, battery voltage shall be 13.5 V-14 V.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S31940704822012060500000)

see FAULT-TRACING

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Read off the battery voltage. Check the battery voltage, battery voltage shall be 13.5 V-14 V.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S06472934312012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Read off the battery voltage. Check the battery voltage, battery voltage shall be 13.5 V-14 V.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S27432609242012060500000)

see FAULT-TRACING

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Read off the battery voltage. Check the battery voltage, battery voltage shall be 13.5 V-14 V.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S02879272722012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Ignition on, wait for at least 15 seconds to perform the diagnosis. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Check if the malfunction is permanent or intermittent by reading off the diagnostic trouble code's status when the diagnostic status is "Implemented". If the trouble status is "Malfunction found", this indicates that the malfunction is permanent. If the trouble status is "No malfunction found", this indicates that the malfunction is intermittent and not active right now. NOTE: Trouble status cannot go from "Malfunction found" to "No malfunction found" in the same operating cycle.
  1. Continue Refer to «REPLACING THE COMPONENT»(ref-476782-S34078471992012060500000)

The engine control module (ECM) has registered an internal fault.

If the fault is intermittent, it has been registered previously but no longer remains. Intermittent faults can be due to disruption when the engine control module (ECM) started or can be another type of fault that may recur at different instances. The fault is assessed on a case by case basis. If the fault recurs, replace the engine control module (ECM).

In the event of a permanent fault, replace the engine control module (ECM).

Remedy as necessary.

Other information

  1. see «ENGINE CONTROL MODULE (ECM), REPLACING»(ref-476695-S24530329132012060500000)
  1. Continue Refer to «INFORMATION»(ref-476782-S21276922992012060500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

see FAULT-TRACING

see FAULT-TRACING

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Read off the battery voltage. Check the battery voltage, battery voltage shall be 13.5 V-14 V.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S00900663622012060500000)

see FAULT-TRACING

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Read off the battery voltage. Check the battery voltage, battery voltage shall be 13.5 V-14 V.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S22249907392012060500000)
  1. Engine idling. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Check if the malfunction is permanent or intermittent by reading off the diagnostic trouble code's status when the diagnostic status is "Implemented". If the trouble status is "Malfunction found", this indicates that the malfunction is permanent. If the trouble status is "No malfunction found", this indicates that the malfunction is intermittent and not active right now. NOTE: Trouble status cannot go from "Malfunction found" to "No malfunction found" in the same operating cycle.
  1. Continue Refer to «CHECKING THE BATTERY AND CONNECTIONS»(ref-476782-S10224554662012060500000)

The engine control module (ECM) has registered an internal fault.

If the fault is intermittent, it has been registered previously but is no longer present. Intermittent faults may be due to interference at start or may be a different type of fault that occurs on different occasions. The fault is evaluated depending on how it occurs.

Ensure that the software in the Engine control module (ECM) is correct by downloading it again.

If the fault recurs, replace the control module.

In the event of a permanent fault, replace the engine control module (ECM).

Remedy as necessary.

Other information

  1. see «ENGINE CONTROL MODULE (ECM)»(ref-476695-S30933262542012060500000)
  1. Continue Refer to «INFORMATION»(ref-476782-S06011390202012060500000)

CHECKING THE BATTERY AND CONNECTIONS

Check the battery.

Check the battery terminals and the engine control module (ECM) connector. Check for contact resistance, play and oxidation.

  1. Continue Refer to «REPLACING THE COMPONENT»(ref-476782-S02569888502012060500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

see FAULT TRACING

  1. Ignition on, wait for at least 15 seconds to perform the diagnosis. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Check if the malfunction is permanent or intermittent by reading off the diagnostic trouble code's status when the diagnostic status is "Implemented". If the trouble status is "Malfunction found", this indicates that the malfunction is permanent. If the trouble status is "No malfunction found", this indicates that the malfunction is intermittent and not active right now. NOTE: Trouble status cannot go from "Malfunction found" to "No malfunction found" in the same operating cycle.
  1. Continue Refer to «REPLACING THE COMPONENT»(ref-476782-S05025467062012060500000)

The engine control module (ECM) has registered an internal fault.

If the fault is intermittent, it has been registered previously but no longer remains. Intermittent faults can be due to disruption when the engine control module (ECM) started or can be another type of fault that may recur at different instances. The fault is assessed on a case by case basis. If the fault recurs, replace the engine control module (ECM).

In the event of a permanent fault, replace the engine control module (ECM).

Remedy as necessary.

Other information

  1. see «ENGINE CONTROL MODULE (ECM)»(ref-476695-S30933262542012060500000)
  1. Continue Refer to «INFORMATION»(ref-476782-S28201421842012060500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

see FAULT TRACING

see FAULT TRACING

see FAULT TRACING

see FAULT-TRACING INFORMATION

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Run the starter motor/start the engine.
  4. Allow the engine to idle if it starts.
  5. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S35560854112012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Run the starter motor/start the engine.
  4. Allow the engine to idle if it starts.
  5. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S31069262222012060500000)

see FAULT-TRACING

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Run the starter motor/start the engine.
  4. Allow the engine to idle if it starts.
  5. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S12002899312012060500000)

see FAULT-TRACING

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Run the starter motor/start the engine.
  4. Allow the engine to idle if it starts.
  5. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S03246645202012060500000)

see FAULT-TRACING

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Run the starter motor/start the engine.
  4. Allow the engine to idle if it starts.
  5. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S03385761662012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Run the starter motor/start the engine.
  4. Allow the engine to idle if it starts.
  5. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S31586276582012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

The diagnostic trouble code is stored since another diagnostic function has been close to or above the malfunction limit. Likely, this diagnostic trouble code is stored together with the diagnostic trouble code for the basic problem. Therefore fault-trace for another diagnostic trouble code (DTC).

For further information on this diagnostic trouble code, see Diagnostic trouble code (DTC) information.

see FAULT-TRACING

The diagnostic trouble code is stored since another diagnostic function has been close to or above the malfunction limit. Likely, this diagnostic trouble code is stored together with the diagnostic trouble code for the basic problem. Therefore fault-trace for another diagnostic trouble code (DTC).

For further information on this diagnostic trouble code, see Diagnostic trouble code (DTC) information.

HINT

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine.
  4. Read off the battery voltage.
  5. Load the battery by switching on several power consumers with a high power consumption, for example, the blower, main beam, etc. Read off the battery voltage using the VCT2000 (or appropriate scan tool). Check that the battery voltage is correct, battery voltage shall be approx. 13-14 V. Test at different engine speeds.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S41416636982012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine.
  4. Read off the battery voltage.
  5. Load the battery by switching on several power consumers with a high power consumption, for example, the blower, main beam, etc. Read off the battery voltage using the VCT2000 (or appropriate scan tool). Check that the battery voltage is correct, battery voltage shall be approx. 13-14 V. Test at different engine speeds.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S42628378222012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Start the engine.
  4. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Increase the engine speed a few times until the scan is "Implemented". Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S35746496112012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, components, etc.
  3. Start the engine.
  4. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. Increase the engine speed a few times until the scan is "Implemented". Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-476782-S26526307362012060500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
