DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
Condition
Scheme 241
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) detects a fault in the circuit for the internal temperature sensor in the control module. The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- None.
Possible Source
- Damaged engine control module (ECM).
Fault symptom[s]
- None.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-7010
Condition
The diagnostic trouble code (DTC) is stored if the temperature in the engine control module (ECM) exceeds 95 °C.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- The engine cooling fan (FC) runs at low-speed.
Possible Source
- Air supply is blocked.
Fault symptom[s]
- None.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-7010
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-7020
Condition
The diagnostic trouble code (DTC) is stored if the temperature in the engine control module (ECM) exceeds 105 °C.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- The engine cooling fan (FC) runs at low-speed.
Possible Source
- Air supply is blocked.
Fault symptom[s]
- None.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-7020
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-7100
Condition
The engine control module (ECM) contains a code for the immobilizer which is unique to each car. Before the engine can be started, the immobilizer code is checked to ensure that it corresponds to both the central electronic module (CEM) and the engine control module (ECM). The diagnostic trouble code (DTC) is stored if the immobilizer code does not correspond.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
None
Possible Source
- The engine control module (ECM) is not programmed and has no immobilizer code
- The immobilizer code in the engine control module (ECM) is incorrect
- The immobilizer code in the central electronic module (CEM) is incorrect
- The central electronic module (CEM) is not programmed and has no immobilizer code
- Damaged central electronic module (CEM)
- Damaged engine control module (ECM).
Fault symptom[s]
- The engine does not start.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-7100
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-710B
Condition
The engine control module (ECM) contains a code for the immobilizer which is unique to each car. Before the engine can be started, the immobilizer code is checked to ensure that it corresponds to both the central electronic module (CEM) and the engine control module (ECM).
The diagnostic trouble code (DTC) will be stored if there is no communication between the central electronic module (CEM) and the engine control module (ECM) so that the immobilizer code cannot be checked.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
None
Possible Source
- Open-circuit in the communication between the central electronic module (CEM) and the engine control module (ECM).
Fault symptom[s]
- The engine does not start.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-710B
Condition
Diagnostic trouble code (DTC) ECM-711A is stored if the engine control module (ECM) registers a fault in the internal circuit for the timer in the control module.
Substitute Value
- None.
Possible Source
Faulty signal
- Defective control module.
Fault symptom[s]
- The malfunction indicator lamp (MIL) lights.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
Condition
Diagnostic trouble code (DTC) ECM-715D is stored if the temperature in the control module exceeds 95°C.
Substitute Value
The cooling fan runs at low-speed.
Possible Source
- The air supply is blocked
- Defective control module cooling fan.
Fault symptom[s]
- None.
Condition
Diagnostic trouble code (DTC) ECM-715D is stored if the temperature in the control module exceeds 105°C.
Substitute Value
The cooling fan runs at low-speed
Possible Source
- The air supply is blocked
- Defective cooling fan for the control module.
Fault symptom[s]
- None.
Condition
Diagnostic trouble code (DTC) ECM-7180 is stored if the control module detects a fault in the circuit for control module internal temperature sensor.
Substitute Value
engine cooling fan (FC) runs at low-speed
Possible Source
- fault in the control module temperature sensor circuit
Fault symptom[s]
- malfunction indicator lamp (MIL) lit
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
Condition
The engine control module (ECM) contains a code for the immobilizer which is unique to each car. Before the engine can be started, the immobilizer code is checked to ensure that it corresponds to the central electronic module (CEM) and the engine control module (ECM). Diagnostic trouble code (DTC) ECM-720A, faulty signal, will be stored if the code for the immobilizer does not match.
Diagnostic trouble code (DTC) ECM-720A, signal missing, will be stored if there is no communication between the central electronic module (CEM) and the engine control module (ECM) so that the immobilizer code cannot be checked.
The fault is diagnosed by the engine control module (ECM) when the ignition is switched on.
Substitute Value
none
Possible Source
Faulty signal
- the engine control module (ECM) is not programmed and has no immobilizer code
- the immobilizer code in the engine control module (ECM) is incorrect
- the immobilizer code in the central electronic module (CEM) is incorrect
- the central electronic module (CEM) is not programmed and has no immobilizer code
- the central electronic module (CEM) is defective
- the engine control module (ECM) is defective.
Signal missing
- open-circuit in the communication between the central electronic module (CEM) and the engine control module (ECM).
Fault symptom[s]
- the engine does not start.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-720B
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the circuit for the timer functions.
Substitute Value
- None.
Possible Source
- Damaged engine control module (ECM).
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-720B
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-7300
Condition
The engine control module (ECM) checks the signal from the gear-shift position sensor via CAN communication.
Diagnostic trouble code (DTC) is stored if the engine control module (ECM) detects that the information about the selected gear position from the transmission control module (TCM) is outside its permitted range compared with the speed of the vehicle.
The diagnostic trouble code (DTC) can be diagnosed when the engine is running.
Substitute Value
- None.
Possible Source
- Fault-trace the transmission control module (TCM)
- Fault-trace the brake control module (BCM).
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-7300
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-800B
Condition
Scheme 242
The engine control module (ECM) checks the function of the system relay. The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the voltage from the system relay is too low when the relay is activated.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- None.
Possible Source
- Contact resistance in the terminals
- Open-circuit in the signal cable for the system relay
- Damaged system relay.
Fault symptom[s]
- The engine does not start.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-800B
Condition
The diagnostic trouble code (DTC) ECM-8010 is stored if the voltage from the system relay exceeds 16.5 V (high signal) under 9 V (low signal) or is less than 2.5 V (faulty signal) and that 3 minutes has passed since the engine was started and that the car has a speed.
Substitute Value
13.4 V for a faulty signal, other fault none
Possible Source
Signal too high
- faulty charging system
Signal too low
- faulty charging system
- poor battery
- contact resistance in terminals
Faulty signal
- faulty system relay
- open-circuit in power cable from system relay
- system relay power cable short-circuited to ground
Fault symptom[s]
- engine cuts out
- engine does not start
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
Condition
Diagnostic trouble code (DTC) ECM-801A is stored if the voltage from the system relay to the control module is greater than 2.5 V but lower than 3 V (signal missing) or if the power supply for the control module to the electronic throttle module is lower than 8 V (faulty signal). The fault is diagnosed when the ignition is on.
Substitute Value
None.
Possible Source
Signal missing
- Faulty charging system
- Contact resistance in the terminals
- Open-circuit in the signal cable for the system relay
- Faulty system relay.
Faulty signal
- Faulty charging system
- Contact resistance in the terminals
- Faulty system relay.
Fault symptom[s]
- The engine fails to start
- The engine runs poorly.
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-810C
Condition
The engine control module (ECM) checks the 5 volt cable which supplies components with power. The diagnostic trouble code (DTC) is stored if the voltage at the 5 volt cable is higher than a certain value.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- None.
Possible Source
- short-circuit to battery voltage in the 5 volt supply cable
- Damaged sensor connected to the 5 volt supply cable.
Fault symptom[s]
- Poor performance.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-810C
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-810D
Condition
The engine control module (ECM) checks the 5 volt cable which supplies components with power. If the voltage at the 5 volt cable is lower than a certain value, the engine control module (ECM) interprets this as a fault and a diagnostic trouble code (DTC) is stored.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- None.
Possible Source
- Short-circuit to ground in 5-volt supply cable
- Damaged sensor connected to the 5 volt supply cable.
Fault symptom[s]
- Poor performance.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-810D
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-8200
Condition
The engine control module (ECM) checks the power supply from the system relay.
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) detects that the voltage from the system relay is below 2.5 V.
The diagnostic trouble code (DTC) can be diagnosed at ignition on or when the engine is running.
Substitute Value
- The engine control module (ECM) assumes a voltage of 13.4 V.
Possible Source
- Damaged engine control module (ECM).
Fault symptom[s]
- The engine cuts out
- The engine does not start.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-8200
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-820C
Condition
The engine control module (ECM) checks the power supply from the system relay.
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) detects that the voltage from the system relay is higher than a certain value.
The diagnostic trouble code (DTC) can be diagnosed at ignition on or when the engine is running.
Substitute Value
- None.
Possible Source
- Defective charging system.
Fault symptom[s]
- Starting/Engine does not start/Unsure when/at all times
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-820C
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-820D
Condition
The engine control module (ECM) checks the power supply from the system relay.
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) detects that the voltage from the system relay is lower than a certain value.
The diagnostic trouble code (DTC) can be diagnosed at ignition on or when the engine is running.
Substitute Value
- None.
Possible Source
- Faulty charging system
- Damaged battery.
Fault symptom[s]
- Starting/Engine does not start/Unsure when/at all times
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-820D
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-8210
Condition
The engine control module (ECM) checks the power supply from the system relay.
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) detects that the power supply from the engine control module (ECM) to the throttle unit is lower than 8 V.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- The injectors are shut off.
Possible Source
- Faulty charging system
- Contact resistance in the terminals
- Damaged system relay.
Fault symptom[s]
- The starter motor turns but the engine does not start.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-8210
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-821B
Condition
The engine control module (ECM) checks the power supply from the system relay.
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) detects that the power supply from the system relay is lower than a certain value.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- None.
Possible Source
- Faulty charging system
- Contact resistance in the terminals
- Open-circuit in the signal cable for the system relay
- Damaged system relay.
Fault symptom[s]
- The starter motor turns but the engine does not start.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-821B
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-8410
Condition
If the 5 volt supply circuit for the mass air flow (MAF) sensor, boost pressure sensor, air conditioning (A/C) pressure sensor and fuel tank pressure sensor has a voltage higher than 6 V (high signal) or lower than 4 V (low signal) the control module interprets it as a fault and ECM-8410 is stored.
Substitute Value
- None.
Possible Source
Signal too high
- short-circuit to battery voltage in the 5 volt supply cable
- Defective mass air flow (MAF) sensor
- Defective boost pressure sensor
- Defective air conditioning (A/C) pressure sensor.
Signal too low
- short-circuit to ground in the 5 volt supply cable
- Defective mass air flow (MAF) sensor
- Defective boost pressure sensor
- Defective air conditioning (A/C) pressure sensor.
Fault symptom[s]
- Driving/Poor performance/lacks power
- Driving/Engine stalls/Unsure when/at all times
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-8410
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9000
Condition
Scheme 243
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the circuit for the brake pedal position sensor, the circuit for the stop lamp switch or in the CAN communication between the brake control module (BCM) and the engine control module (ECM).
The diagnostic trouble code (DTC) can be diagnosed when the engine is running.
Substitute Value
Cruise control switched off.
Possible Source
- Fault in the brake control module (BCM) or the central electronic module (CEM)
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the stop lamp switch
- Open-circuit in the power supply to the stop lamp switch
- Open-circuit or short-circuit to ground or supply voltage in the cable for the stop lamp switch
- Incorrectly installed stop lamp switch
- Damaged stop lamp switch.
Fault symptom[s]
- Cruise control/Does not engage
- Text window and warning symbol/Text message
CHECKING THE DIAGNOSTIC TROUBLE CODES (DTCS)
Check whether any diagnostic trouble codes (DTCs) are stored in the brake control module (BCM) or in the central electronic module (CEM).
Any diagnostic trouble codes (DTCs) stored in the brake control module (BCM) or central electronic module (CEM) must be remedied first.
Have fault causes been traced or remedied in the brake control module (BCM) and the central electronic module (CEM)?
- YES Refer to «CHECKING THE STATUS»(ref-476771-S04527417082012060500000)
- NO OKAY: Troubleshooting has been completed.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9000
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-900B
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the circuit for the brake pedal position sensor, the circuit for the stop lamp switch or in the CAN communication between the brake control module (BCM) and the engine control module (ECM).
The diagnostic trouble code (DTC) can be diagnosed when the engine is running.
Substitute Value
Cruise control switched off.
Possible Source
- Fault trace the brake control module (BCM) and the central electronic module (CEM).
Fault symptom[s]
- Cruise control does not function at all.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-900B
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-900C
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the circuit for the brake pedal position sensor, the circuit for the stop lamp switch or in the CAN communication between the brake control module (BCM) and the engine control module (ECM).
The diagnostic trouble code (DTC) can be diagnosed when the engine is running.
Substitute Value
Cruise control switched off.
Possible Source
- Fault trace the brake control module (BCM) and the central electronic module (CEM).
Fault symptom[s]
- Cruise control/Does not engage
- Text window and warning symbol/Text message
Check whether any diagnostic trouble codes (DTCs) are stored in the brake control module (BCM) in the central electronic module (CEM).
Any diagnostic trouble codes (DTCs) stored in the brake control module (BCM) or central electronic module (CEM) must be remedied first.
Have fault causes been traced or remedied in the brake control module (BCM) and central electronic module (CEM)?
- YES Refer to «CHECKING THE STATUS»(ref-476771-S21187307832012060500000)
- NO OKAY: Troubleshooting has been completed.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-900C
Condition
Scheme 244
This diagnostic trouble code (DTC) is never stored on its own.
Diagnostic trouble code (DTC) ECM-903C will also be stored if the engine control module (ECM) registers, when the ignition is switched on, that diagnostic trouble code (DTC) ECM-9150 and/or ECM-9160 is stored (fault in the throttle position (TP) sensor for the throttle unit).
Substitute Value
None.
Possible Source
Faulty signal
- Fault in the throttle position (TP) sensor circuit for the throttle unit.
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit.
Condition
The engine control module (ECM) continuously checks the internal RAM (random access memory). Diagnostic trouble code (DTC) ECM-9050 is stored in the engine control module (ECM) in the event of a fault. If this diagnostic trouble code (DTC) is stored the engine control module (ECM) will try to restart (reset) itself.
Substitute Value
None.
Possible Source
- Faulty software in the engine control module (ECM)
- Defective engine control module (ECM).
Fault symptom[s]
- The malfunction indicator lamp (MIL) flashes
- The engine cuts out
- The engine does not start.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
Condition
The engine control module (ECM) continuously checks the internal ROM (read-only memory). Diagnostic trouble code (DTC) ECM-9060 is stored in the engine control module (ECM) in the event of a fault. If this diagnostic trouble code (DTC) is stored the engine control module (ECM) will try to restart (reset) itself.
Substitute Value
None.
Possible Source
- Faulty software in the engine control module (ECM)
- Defective engine control module (ECM).
Fault symptom[s]
- The malfunction indicator lamp (MIL) flashes
- The engine cuts out
- The engine does not start.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
Condition
The engine control module (ECM) continuously checks the internal reset function. Diagnostic trouble code (DTC) ECM-9070 is stored in the engine control module (ECM) in the event of a fault. If this diagnostic trouble code (DTC) is stored the engine control module (ECM) will try to restart (reset) itself.
Substitute Value
None.
Possible Source
- Faulty software in the engine control module (ECM)
- Defective engine control module (ECM).
Fault symptom[s]
- The malfunction indicator lamp (MIL) flashes
- The engine cuts out
- The engine does not start.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9100
Condition
Scheme 245
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the signal from the clutch pedal position sensor.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
Cruise control switched off.
Possible Source
- Open-circuit in the signal cable
- Incorrectly installed clutch pedal sensor
- Damaged clutch pedal sensor.
Fault symptom[s]
- Cruise control does not function at all.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9100
Condition
Diagnostic trouble code (DTC) ECM-9100 is stored if the engine control module (ECM) registers an internal fault or a fault in the circuit for the damper motor in the throttle unit when the ignition is switched on.
Substitute Value
The engine control module (ECM) shuts down the supply to the throttle unit damper motor. The throttle will set itself to the return position.
Possible Source
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the throttle unit
- Open-circuit, short-circuit to ground or short-circuit to supply voltage in the wiring for the damper motor in the throttle unit
- Short-circuit to each other in the wiring for the damper motor in the throttle unit
- Defective throttle unit
- Defective engine control module (ECM).
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit
- Poor performance.
CHECKING DIAGNOSTIC TROUBLE CODES (DTCS)
- Ignition on
- Read off diagnostic trouble codes (DTCs). Check whether any of diagnostic trouble codes (DTCs) ECM-903C, ECM-9150, ECM-9160 or ECM-9170 are stored in the engine control module (ECM). If any of these diagnostic trouble codes (DTCs) are stored, these must be remedied first.
Are any of the above diagnostic trouble codes (DTCs) stored?
- YES Refer to «FAULT-TRACING INFORMATION»(ref-476771-S36411313812012060500000)
- NO Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S04679408652012060500000)
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-910B
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the signal from the clutch pedal position sensor.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
Cruise control switched off.
Possible Source
- Open-circuit in the signal cable
- Incorrectly installed clutch pedal sensor
- Damaged clutch pedal sensor.
Fault symptom[s]
- Cruise control does not function at all.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-910B
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-910C
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the signal from the clutch pedal position sensor.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
Cruise control switched off.
Possible Source
- Short-circuit to supply voltage in the signal cable
- Damaged clutch pedal sensor.
Fault symptom[s]
- Cruise control does not function at all.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-910C
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-910D
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the signal from the clutch pedal position sensor.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
Cruise control switched off.
Possible Source
- Short-circuit to ground in the signal cable
- Damaged clutch pedal sensor.
Fault symptom[s]
- Cruise control does not function at all.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-910D
Condition
Diagnostic trouble code (DTC) ECM-9117 is stored if the engine control module (ECM) registers that the throttle angle at the return limit position is outside the programmed parameter when trying to adapt the throttle unit.
Substitute Value
None.
Possible Source
Faulty signal
- The throttle is sticking or is blocked (oil film, dust etc.)
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the throttle unit
- Defective throttle unit.
Fault symptom[s]
- Driving/Poor performance/lacks power
- Idling/Uneven idle
Condition
Diagnostic trouble code (DTC) ECM-913C is stored if the engine control module (ECM) detects that the basic conditions for adaptation are not met when trying to adapt the throttle unit. If other diagnostic trouble codes (DTCs) are stored, these must be remedied first. These may have caused the adaptation to fail.
Substitute Value
- The adaptation is cancelled
- The engine control module (ECM) shuts down the supply to the throttle unit damper motor. The throttle will set itself to the return position.
Possible Source
- The throttle is sticking or is blocked (oil film, dust etc.)
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the throttle unit
- Defective throttle unit.
Fault symptom[s]
- Poor performance.
- Ignition on
- Read off diagnostic trouble codes (DTCs). Check to, see if any other diagnostic trouble codes (DTCs) are stored. If other diagnostic trouble codes (DTCs) are stored, they may mean that it is not possible to run the adaptation of the engine control module (ECM).
Are any other diagnostic trouble codes (DTCs) stored?
- YES Refer to «FAULT-TRACING INFORMATION»(ref-476771-S35934629442012060500000)
- NO Refer to «CHECKING THE STATUS»(ref-476771-S29544231252012060500000)
Condition
Diagnostic trouble code (DTC) ECM-913F is stored if the engine control module (ECM) is unable to run its first adaptation of the throttle unit. This is because the programmed parameter for the stop position in the throttle position (TP) sensor has been exceeded. This adaptation is normally run during manufacture of the car. However the throttle unit must be adapted again if software, the engine control module (ECM) or the throttle unit is replaced. If other diagnostic trouble codes (DTCs) are stored, these must be remedied first. These may have caused the adaptation to fail.
Substitute Value
- The engine control module (ECM) uses the nominal values for the throttle unit parameters
- The engine control module (ECM) shuts down the supply to the throttle unit damper motor. The throttle will set itself to the return position.
Possible Source
Faulty signal
- The throttle is sticking or is blocked (oil film, dust etc.)
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the throttle unit
- Defective throttle unit.
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit
- Poor performance.
Condition
Diagnostic trouble code (DTC) ECM-914F is stored if the ignition has been left on for 30 seconds and the engine control module (ECM) has been unable to adapt the throttle unit. This is because the programmed parameter for the stop position in the throttle position (TP) sensor has been exceeded. Adaptation is usually carried out to ensure that the throttle unit parameters are within the programmed values that are stored in the engine control module (ECM). If other diagnostic trouble codes (DTCs) are stored, these must be remedied first. These may have caused the adaptation to fail.
Substitute Value
- The engine control module (ECM) uses parameters from previous successful adaptations
- The engine control module (ECM) shuts down the supply to the throttle unit damper motor. The throttle will set itself to the return position.
Possible Source
Faulty signal
- The throttle is sticking or is blocked (oil film, dust etc.)
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the throttle unit
- Defective throttle unit.
Fault symptom[s]
- Poor performance.
Condition
Diagnostic trouble code (DTC) ECM-9150 is stored if the engine control module (ECM) registers a fault in the signal from the throttle position sensor (TP) for the throttle unit, potentiometer 1 (circuit 1) when the ignition is switched on
Substitute Value
The throttle angle is calculated using potentiometer 2 (circuit 2) in the throttle position (TP) sensor for the throttle unit. If diagnostic trouble codes (DTCs) ECM-9150 and ECM-9160 are stored at the same time, the supply to the damper motor in the throttle unit will be cut. The throttle will set itself to the return position.
Possible Source
Signal too high
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the throttle unit
- Open-circuit or short-circuit to supply voltage in the signal cable
- Open-circuit in the signal ground cable for potentiometers 1 and 2
- Defective throttle unit.
Signal too low
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the throttle unit
- Short-circuit to ground in the signal cable
- Open-circuit or short-circuit to ground in the power supply to potentiometers 1 and 2
- Defective throttle unit.
Faulty signal
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the throttle unit
- The signal cables are short-circuited to each other
- Defective throttle unit.
Fault symptom[s]
- Poor performance.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
Condition
Diagnostic trouble code (DTC) ECM-9160 is stored if the engine control module (ECM) registers a fault in the signal from the throttle position sensor (TP) for the throttle unit, potentiometer 2 (circuit 2) when the ignition is switched on
Substitute Value
The throttle angle is calculated using potentiometer 1 (circuit 1) in the throttle position (TP) sensor for the throttle unit. Diagnostic trouble code (DTC) ECM-9150 is also stored if the fault is also detected in potentiometer 1 (circuit 1). If both ECM-9160 and ECM-9150 are stored, the supply to the damper motor in the throttle unit will be shut off. The throttle will set itself to the return position.
Possible Source
Signal too high
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the throttle unit
- Short-circuit to supply voltage in the signal cable
- Open-circuit in the signal ground cable for potentiometers 1 and 2
- Defective throttle unit.
Signal too low
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the throttle unit
- Open-circuit or short-circuit to ground in the signal cable
- Open-circuit or short-circuit to ground in the power supply to potentiometers 1 and 2
- Defective throttle unit.
Faulty signal
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the throttle unit
- The signal cables are short-circuited to each other
- Defective throttle unit.
Fault symptom[s]
- Poor performance.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
Condition
This diagnostic trouble code (DTC) is never stored on its own. Diagnostic trouble code (DTC) ECM-9170 is also stored if the engine control module (ECM) registers that diagnostic trouble codes (DTC) ECM-9150 and ECM-9160 (fault in the throttle position (TP) sensor in the throttle unit, potentiometer 1 and 2) are stored.
Substitute Value
The supply to the throttle unit damper motor is shut off. The throttle will set itself to the return position.
Possible Source
Faulty signal
- Fault in the throttle position (TP) sensor circuit for the throttle unit.
Fault symptom[s]
- Driving/Poor performance/lacks power
- Idling/Uneven idle
Condition
Diagnostic trouble code (DTC) ECM-918A is stored if the engine control module (ECM), when attempting to adapt the throttle unit, registers an internal fault in the integrated amplifier for the signal from potentiometer 1 in the throttle unit throttle position sensor (circuit 1).
Substitute Value
The engine control module (ECM) does not use the signal from potentiometer 1 for the throttle unit throttle position (TP) sensor (circuit 1).
Possible Source
- Defective engine control module (ECM).
Fault symptom[s]
- None.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
Condition
Diagnostic trouble code (DTC) ECM-919A is stored if the engine control module (ECM), when the engine is running, registers that the internal governor for control of the throttle angle in the throttle unit is defective or that the control signal for the governor is too low when controlling the throttle.
Substitute Value
The engine control module (ECM) shuts down the supply to the throttle unit damper motor. The throttle will set itself to the return position.
Possible Source
Faulty signal
- The throttle is sticking or is blocked (oil film, dust etc.)
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the throttle unit
- Open-circuit, short-circuit to ground or short-circuit to supply voltage in the wiring for the damper motor in the throttle unit
- Short-circuit to each other in the wiring for the damper motor in the throttle unit
- Defective throttle unit
- Faulty software in the engine control module (ECM).
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit
- Poor performance.
Condition
Diagnostic trouble code (DTC) ECM-91A7 is stored if the engine control module (ECM) registers, when the engine is running, that the required throttle angle (desired value) does not correspond with the actual throttle angle (actual value) in the throttle unit
Substitute Value
The engine control module (ECM) shuts down the supply to the throttle unit damper motor. The throttle will set itself to the return position
Possible Source
Faulty signal
- The throttle is sticking or is blocked (oil film, dust etc.)
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the throttle unit
- Open-circuit, short-circuit to ground or short-circuit to supply voltage in the wiring for the damper motor in the throttle unit
- Short-circuit to each other in the wiring for the damper motor in the throttle unit
- Defective throttle unit.
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit
- Poor performance.
- Ignition on
- Read off diagnostic trouble codes (DTCs). Check whether one or more of the following codes are stored: ECM-9150, ECM-9160, ECM-9170, ECM-903C or ECM-9100
Are any of the above diagnostic trouble codes (DTCs) stored?
- YES Refer to «FAULT-TRACING INFORMATION»(ref-476771-S41254960132012060500000)
- NO Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S22534192532012060500000)
Condition
Diagnostic trouble code (DTC) ECM-91B7 is stored if the engine control module (ECM), when attempting to adapt the throttle unit, registers that the movements of the throttle is impeded or that the return spring in the throttle unit is not functioning correctly.
Substitute Value
Depending on the fault, the engine control module (ECM) can cut off the supply to the damper motor in the throttle unit. The throttle will then attempt to set itself to the return position.
Possible Source
Faulty signal
- The throttle is sticking or is blocked (oil film, dust etc.)
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the throttle unit
- Open-circuit, short-circuit to ground or short-circuit to supply voltage in the wiring for the damper motor in the throttle unit
- Short-circuit to each other in the wiring for the damper motor in the throttle unit
- Defective throttle unit.
Fault symptom[s]
- Driving/Hesitates/surges/Unsure when/at all times
- Driving/Engine stalls/During acceleration
- Driving/Engine stalls/During deceleration
- Starting/Engine does not start/Unsure when/at all times
- Driving/Engine stalls/At steady speed
- Warning lights and chimes/Malfunction Indicator Light ("Check engine" light) indication/no indication
Condition
Diagnostic trouble code (DTC) ECM-91C7 is stored if the engine control module (ECM), when attempting to adapt the throttle unit, registers that the movements of the throttle is impeded or that the opening spring in the throttle unit is not functioning correctly.
Substitute Value
Depending on the fault, the engine control module (ECM) can cut off the supply to the damper motor in the throttle unit. The throttle will then attempt to set itself to the return position.
Possible Source
Faulty signal
- The throttle is sticking or is blocked (oil film, dust etc.)
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the throttle unit
- Open-circuit, short-circuit to ground or short-circuit to supply voltage in the wiring for the damper motor in the throttle unit
- Short-circuit to each other in the wiring for the damper motor in the throttle unit
- Defective throttle unit.
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit
- Poor performance.
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9200
Condition
This diagnostic trouble code (DTC) is never stored on its own. This diagnostic trouble code (DTC) will also be stored if the engine control module (ECM) registers that one of the diagnostic trouble codes (DTCs) for the throttle position sensor circuit is stored.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
None.
Possible Source
- Fault in the throttle position (TP) sensor circuit for the electronic throttle unit.
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9200
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9210
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the signal from the throttle position (TP) sensor, potentiometer 1 (circuit 1) in the electronic throttle unit.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
The throttle angle is calculated using potentiometer 2 (circuit 2) in the throttle position (TP) sensor for the throttle unit. If the diagnostic trouble codes (DTCs) for both potentiometers 1 and 2 are stored at the same time, the supply to the damper motor in the throttle unit will be disabled. The throttle will set itself to the return position.
Possible Source
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the electronic throttle unit
- The signal cables are short-circuited to each other
- Damaged throttle unit.
Fault symptom[s]
- Poor performance.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9210
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-921C
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the signal from the throttle position (TP) sensor, potentiometer 1 (circuit 1) in the electronic throttle unit.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
The throttle angle is calculated using potentiometer 2 (circuit 2) in the throttle position (TP) sensor for the throttle unit. If the diagnostic trouble codes (DTCs) for both potentiometers 1 and 2 are stored at the same time, the supply to the damper motor in the throttle unit will be disabled. The throttle will set itself to the return position.
Possible Source
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the electronic throttle unit
- Open-circuit or short-circuit to supply voltage in the signal cable
- Open-circuit in the signal ground cable for potentiometers 1 and 2
- Damaged throttle unit.
Fault symptom[s]
- Poor performance.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-921C
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-921D
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the signal from the throttle position (TP) sensor, potentiometer 1 (circuit 1) in the electronic throttle unit.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
The throttle angle is calculated using potentiometer 2 (circuit 2) in the throttle position (TP) sensor for the throttle unit. If the diagnostic trouble codes (DTCs) for both potentiometers 1 and 2 are stored at the same time, the supply to the damper motor in the throttle unit will be disabled. The throttle will set itself to the return position.
Possible Source
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the electronic throttle unit
- Short-circuit to ground in the signal cable
- Open-circuit or short-circuit to ground in the power supply to potentiometers 1 and 2
- Damaged throttle unit.
Fault symptom[s]
- Poor performance.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-921D
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9220
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the signal from the throttle position (TP) sensor, potentiometer 2 (circuit 2) in the electronic throttle unit.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
The throttle angle is calculated using potentiometer 1 (circuit 1) in the throttle position (TP) sensor for the throttle unit. If the diagnostic trouble codes (DTCs) for both potentiometers 1 and 2 are stored at the same time, the supply to the damper motor in the throttle unit will be disabled. The throttle will set itself to the return position.
Possible Source
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the electronic throttle unit
- The signal cables are short-circuited to each other
- Damaged throttle unit.
Fault symptom[s]
- Poor performance.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9220
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-922C
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the signal from the throttle position (TP) sensor, potentiometer 2 (circuit 2) in the electronic throttle unit.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
The throttle angle is calculated using potentiometer 1 (circuit 1) in the throttle position (TP) sensor for the throttle unit. If the diagnostic trouble codes (DTCs) for both potentiometers 1 and 2 are stored at the same time, the supply to the damper motor in the throttle unit will be disabled. The throttle will set itself to the return position.
Possible Source
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the electronic throttle unit
- Short-circuit to supply voltage in the signal cable
- Open-circuit in the signal ground cable for potentiometers 1 and 2
- Damaged throttle unit.
Fault symptom[s]
- Poor performance.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-922C
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-922D
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the signal from the throttle position (TP) sensor, potentiometer 2 (circuit 2) in the electronic throttle unit.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
The throttle angle is calculated using potentiometer 1 (circuit 1) in the throttle position (TP) sensor for the throttle unit. If a fault is also detected in potentiometer 1 (circuit 1) a diagnostic trouble code (DTC) will also be stored for this. If diagnostic trouble codes (DTCs) have been stored for both potentiometers, the supply to the damper motor for the electronic throttle unit will be disabled. The throttle will set itself to the return position.
Possible Source
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the electronic throttle unit
- Open-circuit or short-circuit to ground in the signal cable
- Open-circuit or short-circuit to ground in the power supply to potentiometers 1 and 2
- Damaged throttle unit.
Fault symptom[s]
- Poor performance.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-922D
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9240
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers an internal fault or a fault in the circuit for the throttle unit damper motor.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
The engine control module (ECM) shuts down the supply to the damper motor for the electronic throttle unit. The throttle will set itself to the return position.
Possible Source
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the electronic throttle unit
- Open-circuit, short-circuit to ground or short-circuit to supply voltage in the wiring for the damper motor in the throttle unit
- Short-circuit to each other in the wiring for the damper motor in the throttle unit
- Damaged throttle unit
- Damaged engine control module (ECM).
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit
- Poor performance.
- Ignition on
- Read off diagnostic trouble codes (DTCs). Check if any diagnostic trouble codes (DTCs) are stored for the electronic throttle unit or the throttle position (TP) sensor. If any of these diagnostic trouble codes (DTCs) are stored, these must be remedied first.
Are any of the above diagnostic trouble codes (DTCs) stored?
- YES Refer to «FAULT-TRACING INFORMATION»(ref-476771-S40769509312012060500000)
- NO Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S21970491032012060500000)
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9240
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-925C
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the movement of the throttle is impeded, or that the return spring in the throttle unit is not functioning correctly, when attempting to adapt the electronic throttle unit.
Substitute Value
Depending on the fault, the engine control module (ECM) can cut off the supply to the damper motor in the electronic throttle unit. The throttle will then attempt to set itself to the return position.
Possible Source
- The throttle is sticking or is blocked (e. g. oil film, dust)
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the electronic throttle unit
- Open-circuit, short-circuit to ground or short-circuit to supply voltage in the wiring for the damper motor in the throttle unit
- Short-circuit to each other in the wiring for the damper motor in the electronic throttle unit
- Damaged throttle unit.
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit
- Poor performance.
- Ignition on
- Read off diagnostic trouble codes (DTCs). Check if any diagnostic trouble codes (DTCs) are stored for the electronic throttle unit, throttle position (TP) sensor or engine control module (ECM). If any of these diagnostic trouble codes (DTCs) are stored, these must be remedied first.
Are any of the above diagnostic trouble codes (DTCs) stored?
- YES Refer to «FAULT-TRACING INFORMATION»(ref-476771-S39684475252012060500000)
- NO Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S32893657152012060500000)
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-925C
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-925D
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the movement of the throttle is impeded, or that the return spring in the throttle unit is not functioning correctly, when attempting to adapt the electronic throttle unit.
Substitute Value
Depending on the fault, the engine control module (ECM) can cut off the supply to the damper motor in the electronic throttle unit. The throttle will then attempt to set itself to the return position.
Possible Source
- The throttle is sticking or is blocked (e. g. oil film, dust)
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the electronic throttle unit
- Open-circuit, short-circuit to ground or short-circuit to supply voltage in the wiring for the damper motor in the throttle unit
- Short-circuit to each other in the wiring for the damper motor in the throttle unit
- Damaged throttle unit.
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit
- Poor performance.
- Ignition on
- Read off diagnostic trouble codes (DTCs). Check if any diagnostic trouble codes (DTCs) are stored for the electronic throttle unit, throttle position (TP) sensor or engine control module (ECM). If any of these diagnostic trouble codes (DTCs) are stored, these must be remedied first.
Are any of the above diagnostic trouble codes (DTCs) stored?
- YES Refer to «FAULT-TRACING INFORMATION»(ref-476771-S37466839752012060500000)
- NO Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S17095555672012060500000)
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-925D
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-926C
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM), when attempting to adapt the throttle unit, registers that the movements of the throttle is impeded or that the opening spring in the electronic throttle unit is not functioning correctly.
Substitute Value
Depending on the fault, the engine control module (ECM) can cut off the supply to the damper motor in the electronic throttle unit. The throttle will then attempt to set itself to the return position.
Possible Source
- The throttle is sticking or is blocked (e. g. oil film, dust)
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the electronic throttle unit
- Open-circuit, short-circuit to ground or short-circuit to supply voltage in the wiring for the damper motor in the throttle unit
- Short-circuit to each other in the wiring for the damper motor in the electronic throttle unit
- Damaged throttle unit.
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit
- Poor performance.
- Ignition on
- Read off diagnostic trouble codes (DTCs). Check if any diagnostic trouble codes (DTCs) are stored for the electronic throttle unit, throttle position (TP) sensor or engine control module (ECM). If any of these diagnostic trouble codes (DTCs) are stored, these must be remedied first.
Are any of the above diagnostic trouble codes (DTCs) stored?
- YES Refer to «FAULT-TRACING INFORMATION»(ref-476771-S37336819152012060500000)
- NO Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S35890710572012060500000)
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-926C
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-926D
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM), when attempting to adapt the throttle unit, registers that the movements of the throttle is impeded or that the opening spring in the electronic throttle unit is not functioning correctly.
Substitute Value
Depending on the fault, the engine control module (ECM) can cut off the supply to the damper motor in the electronic throttle unit. The throttle will then attempt to set itself to the return position.
Possible Source
- The throttle is sticking or is blocked (e. g. oil film, dust)
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the electronic throttle unit
- Open-circuit, short-circuit to ground or short-circuit to supply voltage in the wiring for the damper motor in the throttle unit
- Short-circuit to each other in the wiring for the damper motor in the throttle unit
- Damaged throttle unit.
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit
- Poor performance.
- Ignition on
- Read off diagnostic trouble codes (DTCs). Check if any diagnostic trouble codes (DTCs) are stored for the electronic throttle unit, throttle position (TP) sensor or engine control module (ECM). If any of these diagnostic trouble codes (DTCs) are stored, these must be remedied first.
Are any of the above diagnostic trouble codes (DTCs) stored?
- YES Refer to «FAULT-TRACING INFORMATION»(ref-476771-S21494329142012060500000)
- NO Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S34698491132012060500000)
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-926D
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9270
Condition
The diagnostic trouble code (DTC) is stored if, when the engine is running, the engine control module (ECM) registers that the desired throttle angle (desired value) does not correspond to the actual throttle angle (actual value) in the electronic throttle unit.
Substitute Value
The engine control module (ECM) shuts down the supply to the damper motor for the electronic throttle unit. The throttle will set itself to the return position.
Possible Source
- The throttle is sticking or is blocked (e. g. oil film, dust)
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the electronic throttle unit
- Open-circuit, short-circuit to ground or short-circuit to supply voltage in the wiring for the damper motor in the throttle unit
- Short-circuit to each other in the wiring for the damper motor in the throttle unit
- Damaged throttle unit.
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit
- Poor performance.
- Ignition on
- Read off diagnostic trouble codes (DTCs). Check if any diagnostic trouble codes (DTCs) are stored for the electronic throttle unit, throttle position (TP) sensor or engine control module (ECM). If any of these diagnostic trouble codes (DTCs) are stored, these must be remedied first.
Are any of the above diagnostic trouble codes (DTCs) stored?
- YES Refer to «FAULT-TRACING INFORMATION»(ref-476771-S16807784172012060500000)
- NO Refer to «CHECKING COMPONENTS AND WIRING»(ref-476771-S10305627822012060500000)
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9270
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9280
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the throttle angle at the return limit position is outside the programmed parameter when trying to adapt the throttle unit.
Substitute Value
None.
Possible Source
- The throttle is sticking or is blocked (e. g. oil film, dust)
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the electronic throttle unit
- Damaged throttle unit.
Fault symptom[s]
- Driving/Poor performance/lacks power
- Idling/Uneven idle
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9280
Condition
Scheme 246
Diagnostic trouble code (DTC) ECM-928C is stored if the engine control module (ECM), when the ignition is switched on, registers a fault in the steering wheel module or in its Control area network (CAN) communication.
Substitute Value
Cruise control switched off.
Possible Source
Faulty signal
- Fault trace the steering wheel module
- Fault trace the central electronic module.
Fault symptom[s]
- Cruise control does not function at all.
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9290
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the internal governor for control of the throttle angle in the throttle unit is damaged or that the control signal for the governor is too low when controlling the throttle.
The diagnostic trouble code (DTC) can be diagnosed when the engine is running.
Substitute Value
The engine control module (ECM) shuts down the supply to the damper motor for the electronic throttle unit. The throttle will set itself to the return position.
Possible Source
- The throttle is sticking or is blocked (e. g. oil film, dust)
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the electronic throttle unit
- Open-circuit, short-circuit to ground or short-circuit to supply voltage in the wiring for the damper motor in the throttle unit
- Short-circuit to each other in the wiring for the damper motor in the throttle unit
- Damaged throttle unit
- Faulty software in the engine control module (ECM).
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit
- Poor performance.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9290
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-929C
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the internal governor for control of the throttle angle in the throttle unit is damaged or that the control signal for the governor is too low when controlling the throttle.
The diagnostic trouble code (DTC) can be diagnosed when the engine is running.
Substitute Value
The engine control module (ECM) shuts down the supply to the damper motor for the electronic throttle unit. The throttle will set itself to the return position.
Possible Source
- The throttle is sticking or is blocked (e. g. oil film, dust)
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the electronic throttle unit
- Open-circuit, short-circuit to ground or short-circuit to supply voltage in the wiring for the damper motor in the throttle unit
- Short-circuit to each other in the wiring for the damper motor in the throttle unit
- Damaged throttle unit
- Faulty software in the engine control module (ECM).
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit
- Poor performance.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-929C
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-929D
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the internal governor for control of the throttle angle in the throttle unit is damaged or that the control signal for the governor is too low when controlling the throttle.
The diagnostic trouble code (DTC) can be diagnosed when the engine is running.
Substitute Value
The engine control module (ECM) shuts down the supply to the damper motor for the electronic throttle unit. The throttle will set itself to the return position.
Possible Source
- The throttle is sticking or is blocked (e. g. oil film, dust)
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the electronic throttle unit
- Open-circuit, short-circuit to ground or short-circuit to supply voltage in the wiring for the damper motor in the throttle unit
- Short-circuit to each other in the wiring for the damper motor in the throttle unit
- Damaged throttle unit
- Faulty software in the engine control module (ECM).
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit
- Poor performance.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-929D
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-92B0
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) fails to carry out its first adaptation of the electronic throttle unit. This is because the programmed parameter for the stop position in the throttle position (TP) sensor has been exceeded. This adaptation is normally run during manufacture of the vehicle. However the electronic throttle unit must be adapted again if the software, the engine control module (ECM) or the throttle unit is replaced. If other diagnostic trouble codes (DTCs) are stored, these must be remedied first. These may have caused the adaptation to fail.
Substitute Value
- The engine control module (ECM) uses nominal values for the throttle unit parameters
- The engine control module (ECM) shuts down the supply to the damper motor for the electronic throttle unit. The throttle will set itself to the return position.
Possible Source
- The throttle is sticking or is blocked (e. g. oil film, dust)
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the electronic throttle unit
- Damaged throttle unit.
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit
- Poor performance.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-92B0
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-92CC
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) detects that the basic conditions for adaptation are not met when trying to adapt the electronic throttle unit. If other diagnostic trouble codes (DTCs) are stored, these must be remedied first. These may have caused the adaptation to fail.
Substitute Value
- The adaptation is cancelled
- The engine control module (ECM) shuts down the supply to the damper motor for the electronic throttle unit. The throttle will set itself to the return position.
Possible Source
Adaptation of the throttle unit is cancelled because one of the following basic requirements has not been met
- Ignition on / engine off
- The battery voltage must be over 10 V
- Accelerator pedal (AP) unaffected
- The vehicle must be stationary (no vehicle speed signal)
- Engine coolant temperature (ECT) between 5-100°C
- Intake air temperature (IAT) above 5 °C.
- The throttle is sticking or is blocked (e. g. oil film, dust)
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the electronic throttle unit
- Damaged throttle unit.
Fault symptom[s]
- Poor performance.
- Ignition on
- Read off diagnostic trouble codes (DTCs). Check to, see if any other diagnostic trouble codes (DTCs) are stored. If other diagnostic trouble codes (DTCs) are stored, the engine control module (ECM) may not be able to run the adaptation.
Are any other diagnostic trouble codes (DTCs) stored?
- YES Refer to «FAULT-TRACING INFORMATION»(ref-476771-S16658091292012060500000)
- NO Refer to «CHECKING THE STATUS»(ref-476771-S05527759322012060500000)
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-92CC
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-92CD
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) detects that the basic conditions for adaptation are not met when trying to adapt the electronic throttle unit. If other diagnostic trouble codes (DTCs) are stored, these must be remedied first. These may have caused the adaptation to fail.
Substitute Value
- The adaptation is cancelled
- The engine control module (ECM) shuts down the supply to the damper motor for the electronic throttle unit. The throttle will set itself to the return position.
Possible Source
Adaptation of the throttle unit is cancelled because one of the following basic requirements has not been met
- Ignition on / engine off
- The battery voltage must be over 10 V
- Accelerator pedal (AP) unaffected
- The vehicle must be stationary (no vehicle speed signal)
- Engine coolant temperature (ECT) between 5-100°C
- Intake air temperature (IAT) above 5 °C.
- The throttle is sticking or is blocked (e. g. oil film, dust)
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the electronic throttle unit
- Damaged throttle unit.
Fault symptom[s]
- Poor performance.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-92CD
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-92D0
Condition
The diagnostic trouble code (DTC) is stored if the ignition has been left on for 30 seconds and the engine control module (ECM) has been unable to adapt the electronic throttle unit. This is because the programmed parameter for the stop position in the throttle position (TP) sensor has been exceeded. Adaptation is usually carried out to ensure that the throttle unit parameters are within the programmed values that are stored in the engine control module (ECM). If other diagnostic trouble codes (DTCs) are stored, these must be remedied first. These may have caused the adaptation to fail.
Substitute Value
- The engine control module (ECM) uses parameters from previous successful adaptations
- The engine control module (ECM) shuts down the supply to the damper motor for the electronic throttle unit. The throttle will set itself to the return position.
Possible Source
- The throttle is sticking or is blocked (e. g. oil film, dust)
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the electronic throttle unit
- Damaged throttle unit.
Fault symptom[s]
- Poor performance.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-92D0
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-92E0
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM), when attempting to adapt the electronic throttle unit, registers an internal fault in the integrated amplifier for the signal from potentiometer 1 in throttle position sensor (circuit 1) in the electronic throttle unit.
Substitute Value
The engine control module (ECM) does not use the signal from potentiometer 1 for the throttle position (TP) sensor (circuit 1) in the electronic throttle unit.
Possible Source
- Damaged engine control module (ECM).
Fault symptom[s]
- None.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-92E0
Condition
Diagnostic trouble code (DTC) ECM-9300 is stored if the engine control module (ECM) registers a fault in the PWM signal from the clutch pedal position sensor when the ignition is switched on.
Substitute Value
Cruise control switched off.
Possible Source
Signal too high
- Short-circuit to supply voltage in the signal cable
- Defective clutch pedal sensor.
Signal too low
- Short-circuit to ground in the signal cable
- Defective clutch pedal sensor.
Faulty signal
- Open-circuit in the signal cable
- Incorrectly installed clutch pedal sensor
- Defective clutch pedal sensor.
Fault symptom[s]
- Cruise control does not function at all.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9300
Condition
Scheme 247
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the steering wheel module (SWM) or in its CAN communication.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- Cruise control switched off.
Possible Source
- Fault trace the steering wheel module (SWM)
- Fault trace the central electronic module (CEM).
Fault symptom[s]
- Cruise control does not function at all.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9300
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-930B
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the steering wheel module (SWM) or in its CAN communication.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- Cruise control switched off.
Possible Source
- Fault trace the steering wheel module (SWM)
- Fault trace the central electronic module (CEM).
Fault symptom[s]
- Cruise control does not function at all.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-930B
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-930C
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the steering wheel module (SWM) or in its CAN communication.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- Cruise control switched off.
Possible Source
- Fault trace the steering wheel module (SWM)
- Fault trace the central electronic module (CEM).
Fault symptom[s]
- Cruise control does not function at all.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-930C
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-930D
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the steering wheel module (SWM) or in its CAN communication.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- Cruise control switched off.
Possible Source
- Fault trace the steering wheel module (SWM)
- Fault trace the central electronic module (CEM).
Fault symptom[s]
- Cruise control does not function at all.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-930D
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9400
Condition
Scheme 248
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the analog signal from the accelerator pedal (AP) position sensor.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- The accelerator pedal (AP) is disabled at the same time as the brake pedal is pressed.
Possible Source
- Open-circuit in the power supply (12 V) for the accelerator pedal (AP) position sensor
- Water in the connectors.
- Damaged accelerator pedal (AP) position sensor.
Fault symptom[s]
- Poor accelerator pedal (AP) response.
- Message in information display
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9400
Condition
If the engine control module (ECM), with engine running, registers a malfunction on the brake pedal sensor's circuit, the brake light switch circuit, or on the CAN-communication between the brake control module (BCM) and the engine control module (ECM), the diagnostic trouble code is generated.
Substitute Value
Cruise control switched off.
Possible Source
Signal too high
- Look for the cause of the malfunction in the brake control module (BCM) and in the central electronic module (CEM).
Incorrect signal
- Malfunction in brake control module (BCM) or in central electronic module (CEM).
- Contact resistance or oxidation in the connections between the engine control module (ECM) and the brake light switch.
- Open circuit in the voltage feed to the brake light switch.
- Open circuit or short-circuit to ground or voltage in the cable for the brake light switch.
- Incorrectly installed brake light switch.
- Incorrectly adjusted brake light switch.
- Water in the connectors.
- Damaged brake light switch.
Signal missing
- Look for the cause of the malfunction in the brake control module (BCM) and in the central electronic module (CEM).
Fault symptom[s]
- Cruise control does not function at all.
- Brake light constantly on.
- Message in information display
Check if any diagnostic trouble codes are stored in the brake control module (BCM) or in the central electronic module (CEM).
If diagnostic trouble codes are stored in the brake control module (BCM) or in the central electronic module (CEM), these shall be taken care of first.
Have fault causes been searched for or remedied in the above control modules?
- YES Refer to «CHECKING THE STATUS»(ref-476771-S28068548972012060500000)
- NO OKAY: Troubleshooting has been completed.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-940C
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the analog signal from the accelerator pedal (AP) position sensor.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- The accelerator pedal (AP) is disabled at the same time as the brake pedal is pressed.
Possible Source
- Short-circuit to supply voltage in the signal cable
- Damaged accelerator pedal (AP) position sensor.
Fault symptom[s]
- Poor accelerator pedal (AP) response.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-940C
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-940D
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the analog signal from the accelerator pedal (AP) position sensor.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- The accelerator pedal (AP) is disabled at the same time as the brake pedal is pressed.
Possible Source
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the accelerator pedal (AP) position sensor
- Open-circuit in the power supply (12 V) for the accelerator pedal (AP) position sensor
- Open-circuit in the power supply (5 V) for the analog signal
- Open-circuit in the signal ground cable for the analog signal
- Open-circuit or short-circuit to ground in the signal cable
- Damaged accelerator pedal (AP) position sensor.
Fault symptom[s]
- Poor accelerator pedal (AP) response.
see DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-940D
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-941C
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the PWM-signal from the accelerator pedal (AP) position sensor.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- The accelerator pedal (AP) is disabled at the same time as the brake pedal is pressed.
Possible Source
- Short-circuit to supply voltage in the signal cable
- Damaged accelerator pedal (AP) position sensor.
Fault symptom[s]
- Poor accelerator pedal (AP) response.
