DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-941D
Condition
Scheme 224
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) receives a fault message from the central electronic module (CEM), via the controller area network (CAN), indicating that the analog signal from the accelerator pedal (AP) position sensor is faulty.
The diagnostic trouble code (DTC) can be diagnosed when the engine is running.
Substitute Value
The accelerator pedal (AP) does not function when the brake pedal is pressed.
Possible Source
- Fault-trace the central electronic module (CEM).
Fault symptom[s]
- Poor accelerator pedal (AP) response
- Cruise control does not function at all.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-941D
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9430
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM), via the controller area network (CAN), receives a fault message from the central electronic module (CEM) indicating that the analog signal from the accelerator pedal (AP) position sensor is faulty or that there is a fault in the CAN communication.
The diagnostic trouble code (DTC) can be diagnosed when the engine is running.
Substitute Value
The accelerator pedal (AP) does not function when the brake pedal is pressed.
Possible Source
- Fault-trace the central electronic module (CEM).
Fault symptom[s]
- Poor accelerator pedal (AP) response
- Cruise control does not function at all.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9430
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-943B
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM), via the controller area network (CAN), receives a fault message from the central electronic module (CEM) indicating that the analog signal from the accelerator pedal (AP) position sensor is faulty or that there is a fault in the CAN communication.
The diagnostic trouble code (DTC) can be diagnosed when the engine is running.
Substitute Value
The accelerator pedal (AP) does not function when the brake pedal is pressed.
Possible Source
- Fault-trace the central electronic module (CEM).
Fault symptom[s]
- Poor accelerator pedal (AP) response
- Cruise control does not function at all.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-943B
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-943C
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM), via the controller area network (CAN), receives a fault message from the central electronic module (CEM) indicating that the analog signal from the accelerator pedal (AP) position sensor is faulty or that there is a fault in the CAN communication.
The diagnostic trouble code (DTC) can be diagnosed when the engine is running.
Substitute Value
The accelerator pedal (AP) does not function when the brake pedal is pressed.
Possible Source
- Fault-trace the central electronic module (CEM).
Fault symptom[s]
- Poor accelerator pedal (AP) response
- Cruise control does not function at all.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-943C
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-943D
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM), via the controller area network (CAN), receives a fault message from the central electronic module (CEM) indicating that the analog signal from the accelerator pedal (AP) position sensor is faulty or that there is a fault in the CAN communication.
The diagnostic trouble code (DTC) can be diagnosed when the engine is running.
Substitute Value
The accelerator pedal (AP) does not function when the brake pedal is pressed.
Possible Source
- Fault-trace the central electronic module (CEM).
Fault symptom[s]
- Poor accelerator pedal (AP) response
- Cruise control does not function at all.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-943D
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-950C
Condition
Scheme 225
If Engine Control Module (ECM) registers that the actual idle rpm (actual value) is over the limit value for a certain time, the diagnostic trouble code (DTC) is generated.
Substitute Value
- None.
Possible Source
- Air leakage in the intake system.
Fault symptom[s]
- Malfunction indicator light (MIL), on
- High idle speed
- Uneven idle
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-950C
Condition
The engine control module (ECM) checks the pulse width modulation (PWM) signal and the analog signal from the accelerator pedal (AP) position sensor.
The analog signal from the accelerator pedal (AP) position sensor is connected directly to the central electronic module (CEM). The signal is transmitted via CAN communication from the central electronic module (CEM) to the engine control module (ECM). The PWM signal is connected directly to the engine control module (ECM).
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a malfunction in the signals from the accelerator pedal (AP) position sensor.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- Filtered accelerator pedal signal when accelerating
- Acceleration is ignored when braking
- In the event of a detected malfunction in one of the signals from the accelerator pedal (AP) position sensor, the other signal is used.
Possible Source
Analogue signal too high
- Troubleshoot the central electronic module (CEM).
Analogue signal too low
- Troubleshoot the central electronic module (CEM).
Pulse width modulation (PWM) signal too high
- Short-circuit to ground in the signal cable.
- Open-circuit in the signal cable.
Pulse width modulation (PWM) signal too low
- Short-circuit to ground in the signal cable.
- Short-circuit to voltage in the signal cable
- Open circuit in the signal cable
- Open circuit in the voltage feed.
- Open circuit in the ground cable.
- Damaged accelerator pedal (AP) position sensor.
Incorrect pulse width modulation (PWM) signal
- Loose connections or contact resistance in the terminals on the pulse width modulation (PWM) signal cable
- Interference on the pulse width modulation (PWM) signal cable
- Damaged accelerator pedal (AP) position sensor.
Comparison error
- Loose connections or contact resistance in the terminals on the analog signal cable
- Malfunction of voltage feed to the analog signal.
- Malfunction in the analog signal's ground
- Malfunction in the pulse width modulated signal cable between the engine control module (ECM) and the accelerator pedal (AP) position sensor
- Damaged accelerator pedal (AP) position sensor.
Incorrect signal
- Malfunction in the control area network (CAN) communication between the engine control module (ECM) and the central electrical module (CEM)
- Troubleshoot the central electronic module (CEM).
Fault symptom[s]
- Poor accelerator pedal (AP) response
- The accelerator pedal (AP) is ignored when braking.
- Message in the display.
- Vehicle's max. speed limited.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-950C
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-950C
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-950C
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-950C
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-950D
Condition
If Engine Control Module (ECM) registers that the actual idle rpm (actual value) is under the limit value for a certain time, the diagnostic trouble code (DTC) is generated.
Substitute Value
- None.
Possible Source
- Blocked intake system.
- Blocked exhaust system.
Fault symptom[s]
- Malfunction indicator light (MIL), on
- Low idle speed
- Uneven idle
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-950D
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-951C
Condition
To warm up the catalytic converter at cold-start the Engine Control Module (ECM) controls idle so that the engine runs at a higher idle rpm until the catalytic converter has reached its operating temperature. If Engine Control Module (ECM) registers that the actual idle rpm (actual value) is over the limit value for a certain time, the diagnostic trouble code (DTC) is generated.
Substitute Value
- None.
Possible Source
- Air leakage in the intake system.
Fault symptom[s]
- Malfunction indicator light (MIL), on
- High idle speed
- Uneven idle
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-951C
Condition
Scheme 226
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the actual idle speed deviates from the predefined parameters.
Substitute Value
- None.
Possible Source
- Search the fault cause in the air supply and fuel system (air leakage, blockages, etc.).
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit
- High idling speed.
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-951D
Condition
To warm up the catalytic converter at cold-start the Engine Control Module (ECM) controls idle so that the engine runs at a higher idle rpm until the catalytic converter has reached its operating temperature. If Engine Control Module (ECM) registers that the actual idle rpm (actual value) is under the limit value for a certain time, the diagnostic trouble code (DTC) is generated.
Substitute Value
- None.
Possible Source
- Blocked intake system.
- Blocked exhaust system.
Fault symptom[s]
- Malfunction indicator light (MIL), on
- Low idle speed
- Uneven idle
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-951D
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the actual idle speed deviates from the predefined parameters.
Substitute Value
- None.
Possible Source
- Search the fault cause in the air supply and fuel system (air leakage, blockages, etc.).
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit
- Low idling speed.
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-960C
Condition
Engine control module (ECM) continuously receives information about the gear selector's position from Transmission control module (TCM) via the CAN-net.
Engine control module (ECM) checks the CAN-signal from transmission control module (TCM) compared to the signal that passes via the direct-connected cable from the gear selector.
The diagnostic trouble code (DTC) is stored if the control module detects that
- The signals deviate from an expected value.
The control module's test for the diagnostic trouble code (DTC) starts in the event of
- Ignition switch position II.
Substitute Value
- None.
Possible Source
Signal too high
- Short-circuit to supply voltage in the signal cable.
- Internal fault in the transmission control module (TCM).
Faulty signal
- Faulty CAN communication.
- Internal fault in the transmission control module (TCM).
Quality factor too low
- Faulty CAN communication.
- Internal fault in the transmission control module (TCM).
Fault symptom[s]
- Autostart; No Functionality
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-960C
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-960C
CHECKING THE DIAGNOSTIC TROUBLE CODES (DTCS)
Check whether the transmission control module (TCM) has stored any diagnostic trouble codes for improper adjustment of the gear shift position sensor. If diagnostic trouble codes (DTCs) are stored in the control module, these must be remedied and erased first.
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9700
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the basic frequency of the PWM signal from the accelerator pedal (AP) position sensor deviates from the predefined values.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- None.
Possible Source
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the accelerator pedal (AP) position sensor
- Open-circuit or short-circuit to ground or supply voltage in the signal cable
- Damaged accelerator pedal (AP) position sensor.
Fault symptom[s]
- None.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9700
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-970B
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the basic frequency of the PWM signal from the accelerator pedal (AP) position sensor deviates from the predefined values.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- None.
Possible Source
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the accelerator pedal (AP) position sensor
- Open-circuit or short-circuit to ground or supply voltage in the signal cable
- Damaged accelerator pedal (AP) position sensor.
Fault symptom[s]
- None.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-970B
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-970C
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the basic frequency of the PWM signal from the accelerator pedal (AP) position sensor deviates from the predefined values.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- None.
Possible Source
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the accelerator pedal (AP) position sensor
- Open-circuit or short-circuit to ground or supply voltage in the signal cable
- Damaged accelerator pedal (AP) position sensor.
Fault symptom[s]
- None.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-970C
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-970D
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the basic frequency of the PWM signal from the accelerator pedal (AP) position sensor deviates from the predefined values.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- None.
Possible Source
- Contact resistance or oxidation in the terminals between the engine control module (ECM) and the accelerator pedal (AP) position sensor
- Open-circuit or short-circuit to ground or supply voltage in the signal cable
- Damaged accelerator pedal (AP) position sensor.
Fault symptom[s]
- None.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-970D
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9800
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers an internal fault which indicates that the normal engine control functions are producing a higher torque than is within the maximum permitted range.
The diagnostic trouble code (DTC) is diagnosed at ignition on or with the engine running.
Substitute Value
- The engine speed (RPM) is restricted to approximately 2200 rpm by the fuel shut-off system
- Requested torque is limited to a calculated operating range.
Possible Source
- Air leakage in the intake system.
- Search for failure cause with another stored diagnostic trouble code in the control module.
- Damaged engine control module (ECM).
Fault symptom[s]
- Maximum engine speed (RPM) too low
- Cruise control does not work at all
- Uneven idle
- Malfunction indicator lamp (MIL) lit.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9800
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9810
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers an internal fault indicating that the calculated engine speed (RPM) in the internal monitoring functions differs from the normal calculated engine speed (RPM) in the engine control functions.
The diagnostic trouble code (DTC) is diagnosed with the engine running and at an engine speed (RPM) above 520 rpm.
Substitute Value
- Engine speed (RPM) and torque are limited to a calculated normal operating range.
Possible Source
- Damaged engine control module (ECM).
Fault symptom[s]
- Maximum engine speed (RPM) too low
- Cruise control does not work at all
- Uneven idle
- Malfunction indicator lamp (MIL) lit.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9810
CHECKING THE RANKING VALUES FOR OTHER DIAGNOSTIC TROUBLE CODES (DTCS)
- Ignition on or engine running.
- Activate the tool for reading off the ranking values by clicking on the VCT2000 symbol.
- Check ranking values for other diagnostic trouble codes in Engine control module (ECM). The diagnostic trouble code has been stored due to Engine control module (ECM) has registered that it has not been possible to close the throttle and thus the vehicle's brake vacuum has been affected negatively. If no additional diagnostic trouble codes are stored in Engine control module (ECM), read-out of the ranking values for the throttle module's diagnoses can be used to determine the malfunction. The ranking value is a counter that indicates how close to storing a diagnostic trouble code (DTC) the system considers itself to be for each diagnostic function, in relation to component or function. The counter counts upwards when the fault is active and downwards when the fault is not active. For certain functions the diagnostic trouble code is generated at the same time as the replacement value is activated, that is, at ranking value 128, but for other functions the counter goes on to 255 before the diagnostic trouble code is generated. If the ranking value for relevant diagnostic trouble codes is 128 or higher, then troubleshooting shall be performed on these diagnostic trouble codes as if the diagnostic trouble code was stored in Engine control module (ECM). HINT: Obtain the fault-tracing manually. The ranking value consists of two values: Worst shows highest ranking value for the diagnostic function after erasing diagnostic trouble codes (DTCs) or after the Engine control module (ECM) was rendered powerless. Latest shows present ranking value for the diagnostic function. HINT: The updating rate for Worst and Latest are different depending on diagnostic function. NOTE: The updating rate for Worst and Latest may for certain diagnostic functions be as slow as once in 10 seconds. HINT: A high value for "Worst" and a low value for "Latest" indicates an intermittent fault or that the fault is not currently active. Note the diagnostic trouble codes (DTCs) and high ranking values. Other information see «RANKING VALUES»(ref-479169-S38922818922012061200000)
- Continue Refer to «VERIFICATION»(ref-466673-S38307995162012042500000)
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9818
Condition
The diagnostic trouble code (DTC) is stored in the engine control module (ECM) if the engine control module (ECM) detects that the throttle cannot be closed but is stuck in the open position, resulting in poor brake vacuum.
The diagnostic trouble code (DTC) can be diagnosed when the engine is running.
Substitute Value
- Limited maximum speed of the car.
Possible Source
- Something is blocking the throttle position sensor (an oil film, dust, etc.)
- The power supply to the throttle unit
- Damaged throttle.
Fault symptom[s]
- Poor braking power
- Message in the display
- Maximum vehicle speed reduced.
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9820
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault indicating that the calculated load signals for the normal engine control functions are lower than calculated by the internal monitoring functions.
The diagnostic trouble code (DTC) is diagnosed with the engine running and at an engine speed (RPM) of more than 1000 rpm.
Substitute Value
- Engine speed (RPM) and torque are limited to a calculated normal operating range.
Possible Source
- Dirt or contaminants in the electronic throttle unit
- Foreign objects in the intake passages
- Damaged engine control module (ECM).
Fault symptom[s]
- Maximum engine speed (RPM) too low
- Cruise control does not work at all
- Uneven idle
- Malfunction indicator lamp (MIL) lit.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9820
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault indicating that the internal monitoring functions have registered one or more present values that do not correspond with the complement value.
The diagnostic trouble code (DTC) is diagnosed at ignition on or with the engine running.
Substitute Value
- Engine speed (RPM) and torque are limited to a calculated normal operating range.
Possible Source
- Damaged engine control module (ECM).
Fault symptom[s]
- Maximum engine speed (RPM) too low
- Cruise control does not work at all
- Uneven idle
- Malfunction indicator lamp (MIL) lit.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-983C
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault indicating that the internal monitoring functions have registered one or more present values that do not correspond with the complement value.
The diagnostic trouble code (DTC) is diagnosed at ignition on or with the engine running.
Substitute Value
- Engine speed (RPM) and torque are limited to a calculated normal operating range.
Possible Source
- Damaged engine control module (ECM).
Fault symptom[s]
- Maximum engine speed (RPM) too low
- Cruise control does not work at all
- Uneven idle
- Malfunction indicator lamp (MIL) lit.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-983C
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-983D
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault indicating that the internal monitoring functions have registered one or more present values that do not correspond with the complement value.
The diagnostic trouble code (DTC) is diagnosed at ignition on or with the engine running.
Substitute Value
- Engine speed (RPM) and torque are limited to a calculated normal operating range.
Possible Source
- Damaged engine control module (ECM).
Fault symptom[s]
- Maximum engine speed (RPM) too low
- Cruise control does not work at all
- Uneven idle
- Malfunction indicator lamp (MIL) lit.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-983D
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9840
Condition
If the engine control module (ECM) registers a fault where the input signals from the throttle unit position sensor are interpreted by the normal engine control functions as having exceeded their minimum or maximum limits. While the internal monitoring function interprets the input signals from the electronic throttle unit position sensor differently.
The diagnostic trouble code (DTC) is diagnosed at ignition on or with the engine running.
Substitute Value
- Engine speed (RPM) and torque are limited to a calculated normal operating range.
Possible Source
- Damaged engine control module (ECM).
Fault symptom[s]
- Maximum engine speed (RPM) too low
- Cruise control does not work at all
- Uneven idle
- Malfunction indicator lamp (MIL) lit.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9840
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-984B
Condition
If the engine control module (ECM) registers a fault where the input signals from the throttle unit position sensor are interpreted by the normal engine control functions as having exceeded their minimum or maximum limits. While the internal monitoring function interprets the input signals from the electronic throttle unit position sensor differently.
The diagnostic trouble code (DTC) is diagnosed at ignition on or with the engine running.
Substitute Value
- Engine speed (RPM) and torque are limited to a calculated normal operating range.
Possible Source
- Damaged engine control module (ECM).
Fault symptom[s]
- Maximum engine speed (RPM) too low
- Cruise control does not work at all
- Uneven idle
- Malfunction indicator lamp (MIL) lit.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-984B
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-985C
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers an internal fault indicating that the internal monitoring functions in the engine control module (ECM) have registered a fault in the analog / digital converter function.
The diagnostic trouble code (DTC) can be diagnosed at ignition on or with the engine running.
Substitute Value
Engine speed (RPM) and torque are limited to a calculated normal operating range.
Possible Source
- Damaged engine control module (ECM).
Fault symptom[s]
- Maximum engine speed (RPM) too low
- Cruise control does not work at all
- Uneven idle
- Malfunction indicator lamp (MIL) lit.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-985C
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9860
Condition
Scheme 227
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault indicating that the normal engine control functions have not discovered a fault in the signals from the accelerator pedal (AP) position sensor, but that the internal monitoring function has detected a difference between the two signals.
The diagnostic trouble code (DTC) is diagnosed at ignition on or with the engine running.
Substitute Value
- Engine speed (RPM) and torque are limited to a calculated normal operating range.
Possible Source
- Damaged engine control module (ECM).
Fault symptom[s]
- Maximum engine speed (RPM) too low
- Cruise control does not work at all
- Uneven idle
- Malfunction indicator lamp (MIL) lit.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9860
CHECKING OTHER DIAGNOSTIC TROUBLE CODES (DTCS)
- Ignition on. The diagnostic trouble code has been stored due to the Engine control module (ECM) having registered that true torque has exceeded requested torque and has been forced to reconfigure the system with replacement values in the form of fuel shut-off. The cause of the increase in torque can be found in another diagnostic function. It is probable that diagnostic trouble codes for failing components and/or functions also are stored in Engine control module (ECM). These diagnostic trouble codes (DTCs) must be fault-traced and any faults remedied first. Check if other diagnostic trouble codes are stored in Engine control module (ECM). Ignition on. Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).
Are other diagnostic trouble codes (DTCs) stored in the engine control module (ECM)?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «CHECKING THE RANKING VALUES FOR OTHER DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-466673-S10738381402012042500000)
- Ignition on or engine running.
- Activate the tool for reading off the ranking values by clicking on the VCT2000 symbol.
- Check ranking values for other diagnostic trouble codes in Engine control module (ECM). The diagnostic trouble code has been stored due to the Engine control module (ECM) having registered that true torque has exceeded requested torque and has been forced to reconfigure the system with replacement values in the form of fuel shut-off. The cause of the increase in torque can be found in another diagnostic function. A replacement value for a diagnostic function is activated when the ranking value for the diagnostic function exceeds a certain value, normally 128. The ranking value itself is a counter that indicates how close to storing a diagnostic trouble code the system considers itself to be for each diagnostic function, in relation to component or function. The counter counts upwards when the fault is active and downwards when the fault is not active. For certain functions the diagnostic trouble code is generated at the same time as the replacement value is activated, that is, at ranking value 128, but for other functions the counter goes on to 255 before the diagnostic trouble code is generated. If the ranking value for relevant diagnostic trouble codes is 128 or higher, then troubleshooting shall be performed on these diagnostic trouble codes as if the diagnostic trouble code was stored in Engine control module (ECM). HINT: Obtain the fault-tracing manually. The ranking value consists of two values: Worst shows highest ranking value for the diagnostic function after erasing diagnostic trouble codes (DTCs) or after the Engine control module (ECM) was rendered powerless. Latest shows present ranking value for the diagnostic function. HINT: The updating rate for Worst and Latest are different depending on diagnostic function. NOTE: The updating rate for Worst and Latest may for certain diagnostic functions be as slow as once in 10 seconds. HINT: A high value for "Worst" and a low value for "Latest" indicates an intermittent fault or that the fault is not currently active. Note the diagnostic trouble codes (DTCs) and high ranking values. Other information see «RANKING VALUES»(ref-479169-S38922818922012061200000)
- Continue Refer to «VERIFICATION»(ref-466673-S11002178132012042500000)
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-990F
Condition
The engine control module (ECM) checks the engine torque by reading off the acceleration of the flywheel. The diagnostic trouble code (DTC) is stored if the measured torque exceeds the requested torque, based on the pedal position and the engine speed (RPM).
The diagnostic trouble code (DTC) can be diagnosed when the engine is idling.
Substitute Value
- The cruise control is disengaged when the fault is active
- The engine torque is limited using fuel shut off. The maximum permitted engine torque depends on the position of the accelerator pedal (AP).
Possible Source
- Air leak downstream of the mass air flow (MAF) sensor
- Problem with the throttle unit
- Problem with the mass air flow (MAF) sensor
- Problem with the clutch pedal position sensor
- Problem with engine coolant temperature (ECT) sensor
- Problem with the engine control module (ECM)
- Problem with the flywheel sensor
- Problem with the manifold absolute pressure (MAP) sensor
- Problem with control of the variable valve timing (VVT)
- Problem with the generator (GEN)
- Problem with the air conditioning (A/C) compressor.
Fault symptom[s]
- Jerky operation.
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9918
Condition
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) switches off the supply to the damper motor in the throttle unit, causing the throttle to turn to the return position using the return spring in the throttle unit.
The diagnostic trouble code (DTC) can be diagnosed when the engine is idling.
Substitute Value
- The engine torque is limited using fuel shut-off. The maximum permitted engine torque depends on the position of the accelerator pedal (AP) and the return position of the throttle unit.
Possible Source
- Other diagnostic trouble codes (DTCs) are stored, caused by the throttle unit being deactivated.
Fault symptom[s]
- General warning lamp lit
- Message in the display
- Deterioration in performance
- Cruise control does not work at all
- Uneven idle.
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9970
Condition
The engine control module (ECM) continuously checks the internal RAM (random access memory) functionality. The diagnostic trouble code (DTC) is stored if there is a fault in the RAM.
The diagnostic trouble code (DTC) is diagnosed when the ignition is on.
Substitute Value
The engine control module (ECM) tries to reset the engine control module (ECM).
Possible Source
- Faulty software in the engine control module (ECM)
- Damaged engine control module (ECM).
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit
- The malfunction indicator lamp (MIL) flashes
- The engine cuts out
- The starter motor turns but the engine does not start.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9970
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9980
Condition
The engine control module (ECM) continuously checks the internal ROM (read only memory) functionality. The diagnostic trouble code (DTC) is stored if there is a fault in the ROM. The diagnostic trouble code (DTC) is diagnosed when the ignition is on.
Substitute Value
The engine control module (ECM) tries to reset the engine control module (ECM).
Possible Source
- Faulty software in the engine control module (ECM)
- Damaged engine control module (ECM).
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit
- The malfunction indicator lamp (MIL) flashes
- The engine cuts out
- The starter motor turns but the engine does not start.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9980
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9990
Condition
The engine control module (ECM) continuously checks the internal reset functionality in the engine control module (ECM). The diagnostic trouble code (DTC) is stored in the event of a fault in the reset function.
The diagnostic trouble code (DTC) is diagnosed when the ignition is on.
Substitute Value
The engine control module (ECM) tries to reset the engine control module (ECM).
Possible Source
- Faulty software in the engine control module (ECM)
- Damaged engine control module (ECM).
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit
- The malfunction indicator lamp (MIL) flashes
- The engine cuts out
- The starter motor turns but the engine does not start.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9990
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-999B
Condition
The engine control module (ECM) continuously checks the internal reset functionality in the engine control module (ECM). The diagnostic trouble code (DTC) is stored in the event of a fault in the reset function.
The diagnostic trouble code (DTC) is diagnosed when the ignition is on.
Substitute Value
The engine control module (ECM) tries to reset the engine control module (ECM).
Possible Source
- Faulty software in the engine control module (ECM)
- Damaged engine control module (ECM).
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit
- The malfunction indicator lamp (MIL) flashes
- The engine cuts out
- The starter motor turns but the engine does not start.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-999B
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-999D
Condition
The engine control module (ECM) continuously checks the internal reset functionality in the engine control module (ECM). The diagnostic trouble code (DTC) is stored in the event of a fault in the reset function.
The diagnostic trouble code (DTC) is diagnosed when the ignition is on.
Substitute Value
The engine control module (ECM) tries to reset the engine control module (ECM).
Possible Source
- Faulty software in the engine control module (ECM)
- Damaged engine control module (ECM).
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit
- The malfunction indicator lamp (MIL) flashes
- The engine cuts out
- The starter motor turns but the engine does not start.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-999D
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9A0A
Condition
Diagnostic functions in the engine control module (ECM) have activated substitute values that result in the driveability of the car being affected. The diagnostic trouble code (DTC) is stored if the engine control module (ECM) detects that the driveability of the car has been negatively affected.
Substitute Value
- None.
Possible Source
- Faults that are detected by another diagnostic function and whose substitute values affect driveability negatively.
Fault symptom[s]
- Autostart; No Functionality
- Engine fails to start
- The cruise control does not function at all
- Jerky operation
- Uneven idle
- Poor accelerator pedal (AP) response
- The accelerator pedal (AP) is ignored when braking.
- Ignition on. The diagnostic trouble code (DTC) is stored because the engine control module (ECM) registered discrepancies in components or functions. The engine control module (ECM) was forced to reconfigure the system using substitute values, negatively affecting the driveability of the car. It is probable that diagnostic trouble codes (DTCs) for faulty components and/or functions are also stored in the engine control module (ECM). These diagnostic trouble codes (DTCs) must be fault-traced and any faults remedied first. Check whether other diagnostic trouble codes (DTCs) are stored in the engine control module (ECM). Ignition on Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).
Are other diagnostic trouble codes (DTCs) stored in the engine control module (ECM)?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «CHECKING THE RANKING VALUES FOR OTHER DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-466673-S36634195752012042500000)
- Ignition on or engine running. Click on the VCT2000 symbol to activate the tool for reading off the ranking values. Check the ranking values for other diagnostic trouble codes (DTCs) in the engine control module (ECM). The diagnostic trouble code (DTC) is stored because the engine control module (ECM) registered discrepancies in components or functions. The engine control module (ECM) was forced to reconfigure the system using substitute values, negatively affecting the driveability of the car. A substitute value for a diagnostic function is activated when the ranking value for the diagnostic function exceeds a certain value, normally 128. The ranking value is a counter that indicates how close to storing a diagnostic trouble code (DTC) the system considers itself to be for each diagnostic function, in relation to a component or function. The counter counts upwards when the fault is active and downwards when the fault is not active. For certain functions, a diagnostic trouble code (DTC) is stored at the same time as the substitute value is activated, i. e. at ranking value 128. For other functions the counter continues to 255 before a diagnostic trouble code (DTC) is stored. If the ranking value for relevant diagnostic trouble codes (DTCs) is 128 or higher, fault-tracing must be carried out on these diagnostic trouble codes (DTCs) as though the diagnostic trouble codes (DTC) were stored in the engine control module (ECM). HINT: Obtain the fault-tracing manually. The ranking value consists of two values: "Worst" indicates the highest ranking value for the diagnostic function since diagnostic trouble codes (DTCs) were erased or the power supply to the engine control module (ECM) was cut "Latest" indicates the current ranking value for the diagnostic function. HINT: The update frequency for "Worst" and "Latest" varies depending on the diagnostic function. NOTE: For some diagnostic functions, the update frequency for "Worst" and Latest" can be as slow as once every 10 seconds. HINT: A high value for "Worst" and a low value for "Latest" indicates an intermittent fault or that the fault is not currently active. Note the diagnostic trouble codes (DTCs) and high ranking values. Other information see «RANKING VALUES»(ref-479169-S38922818922012061200000) see «DESCRIPTION OF BEHAVIORS, ECM-9A0A»(ref-466673-S41402377582012042500000)
- Continue Refer to «VERIFICATION»(ref-466673-S22540757362012042500000)
- Ignition on. The diagnostic trouble code has been stored due to the Engine control module (ECM) having registered deviations of components or functions and has been forced to reconfigure the system with replacement values which has resulted in the vehicle's driveability being affected negatively. It is probable that diagnostic trouble codes for failing components and/or functions also are stored in Engine control module (ECM). These diagnostic trouble codes (DTCs) must be fault-traced and any faults remedied first. Check if other diagnostic trouble codes are stored in Engine control module (ECM). Ignition on. Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).
Are other diagnostic trouble codes (DTCs) stored in the engine control module (ECM)?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «CHECKING THE RANKING VALUES FOR OTHER DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-466673-S04195737812012042500000)
- Ignition on or engine running. Activate the tool for reading off the ranking values by clicking on the VCT2000 symbol. Check ranking values for other diagnostic trouble codes in Engine control module (ECM). The diagnostic trouble code has been stored due to the Engine control module (ECM) having registered deviations of components or functions and has been forced to reconfigure the system with replacement values which has resulted in the vehicle's driveability being affected negatively. A replacement value for a diagnostic function is activated when the ranking value for the diagnostic function exceeds a certain value, normally 128. The ranking value itself is a counter that indicates how close to storing a diagnostic trouble code the system considers itself to be for each diagnostic function, in relation to component or function. The counter counts upwards when the fault is active and downwards when the fault is not active. For certain functions the diagnostic trouble code is generated at the same time as the replacement value is activated, that is, at ranking value 128, but for other functions the counter goes on to 255 before the diagnostic trouble code is generated. If the ranking value for relevant diagnostic trouble codes is 128 or higher, then troubleshooting shall be performed on these diagnostic trouble codes as if the diagnostic trouble code was stored in Engine control module (ECM). HINT: Obtain the fault-tracing manually. The ranking value consists of two values: Worst shows highest ranking value for the diagnostic function after erasing diagnostic trouble codes (DTCs) or after the Engine control module (ECM) was rendered powerless. Latest shows present ranking value for the diagnostic function. HINT: The updating rate for Worst and Latest are different depending on diagnostic function. NOTE: The updating rate for Worst and Latest may for certain diagnostic functions be as slow as once in 10 seconds. HINT: A high value for "Worst" and a low value for "Latest" indicates an intermittent fault or that the fault is not currently active. Note the diagnostic trouble codes (DTCs) and high ranking values. Other information see «RANKING VALUES»(ref-479169-S38922818922012061200000) see «DESCRIPTION OF BEHAVIORS, ECM-9A0A»(ref-466673-S41402377582012042500000)
- Continue Refer to «VERIFICATION»(ref-466673-S18449202022012042500000)
Condition
Diagnostic functions in the engine control module (ECM) have activated substitute values that result in the driveability of the car being affected. The diagnostic trouble code (DTC) is stored if the engine control module (ECM) detects that the driveability of the car has been negatively affected.
Substitute Value
- None.
Possible Source
- Faults that are detected by another diagnostic function and whose substitute values affect driveability negatively.
Fault symptom[s]
- The cruise control does not function at all
- Jerky operation
- Uneven idle
- Poor accelerator pedal (AP) response
- The accelerator pedal (AP) is ignored when braking.
- Ignition on. The diagnostic trouble code has been stored due to the Engine control module (ECM) having registered deviations of components or functions and has been forced to reconfigure the system with replacement values which has resulted in the vehicle's driveability being affected negatively. It is probable that diagnostic trouble codes for failing components and/or functions also are stored in Engine control module (ECM). These diagnostic trouble codes (DTCs) must be fault-traced and any faults remedied first. Check if other diagnostic trouble codes are stored in Engine control module (ECM). Ignition on. Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).
Are other diagnostic trouble codes (DTCs) stored in the engine control module (ECM)?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «CHECKING THE RANKING VALUES FOR OTHER DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-466673-S18507102912012042500000)
- Ignition on or engine running. Activate the tool for reading off the ranking values by clicking on the VCT2000 symbol. Check ranking values for other diagnostic trouble codes in Engine control module (ECM). The diagnostic trouble code has been stored due to the Engine control module (ECM) having registered deviations of components or functions and has been forced to reconfigure the system with replacement values which has resulted in the vehicle's driveability being affected negatively. A replacement value for a diagnostic function is activated when the ranking value for the diagnostic function exceeds a certain value, normally 128. The ranking value itself is a counter that indicates how close to storing a diagnostic trouble code the system considers itself to be for each diagnostic function, in relation to component or function. The counter counts upwards when the fault is active and downwards when the fault is not active. For certain functions the diagnostic trouble code is generated at the same time as the replacement value is activated, that is, at ranking value 128, but for other functions the counter goes on to 255 before the diagnostic trouble code is generated. If the ranking value for relevant diagnostic trouble codes is 128 or higher, then troubleshooting shall be performed on these diagnostic trouble codes as if the diagnostic trouble code was stored in Engine control module (ECM). HINT: Obtain the fault-tracing manually. The ranking value consists of two values: Worst shows highest ranking value for the diagnostic function after erasing diagnostic trouble codes (DTCs) or after the Engine control module (ECM) was rendered powerless. Latest shows present ranking value for the diagnostic function. HINT: The updating rate for Worst and Latest are different depending on diagnostic function. NOTE: The updating rate for Worst and Latest may for certain diagnostic functions be as slow as once in 10 seconds. HINT: A high value for "Worst" and a low value for "Latest" indicates an intermittent fault or that the fault is not currently active. Note the diagnostic trouble codes (DTCs) and high ranking values. Other information see «RANKING VALUES»(ref-479169-S38922818922012061200000) see «DESCRIPTION OF BEHAVIORS, ECM-9A0A»(ref-466673-S41402377582012042500000)
- Continue Refer to «VERIFICATION»(ref-466673-S16180335872012042500000)
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9A0A
- Ignition on. The diagnostic trouble code has been stored due to the Engine control module (ECM) having registered deviations of components or functions and has been forced to reconfigure the system with replacement values which has resulted in the vehicle's driveability being affected negatively. It is probable that diagnostic trouble codes for failing components and/or functions also are stored in Engine control module (ECM). These diagnostic trouble codes (DTCs) must be fault-traced and any faults remedied first. Check if other diagnostic trouble codes are stored in Engine control module (ECM). Ignition on. Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).
Are other diagnostic trouble codes (DTCs) stored in the engine control module (ECM)?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «CHECKING THE RANKING VALUES FOR OTHER DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-466673-S38467481332012042500000)
- Ignition on or engine running. Activate the tool for reading off the ranking values by clicking on the VCT2000 symbol. Check ranking values for other diagnostic trouble codes in Engine control module (ECM). The diagnostic trouble code has been stored due to the Engine control module (ECM) having registered deviations of components or functions and has been forced to reconfigure the system with replacement values which has resulted in the vehicle's driveability being affected negatively. A replacement value for a diagnostic function is activated when the ranking value for the diagnostic function exceeds a certain value, normally 128. The ranking value itself is a counter that indicates how close to storing a diagnostic trouble code the system considers itself to be for each diagnostic function, in relation to component or function. The counter counts upwards when the fault is active and downwards when the fault is not active. For certain functions the diagnostic trouble code is generated at the same time as the replacement value is activated, that is, at ranking value 128, but for other functions the counter goes on to 255 before the diagnostic trouble code is generated. If the ranking value for relevant diagnostic trouble codes is 128 or higher, then troubleshooting shall be performed on these diagnostic trouble codes as if the diagnostic trouble code was stored in Engine control module (ECM). HINT: Obtain the fault-tracing manually. The ranking value consists of two values: Worst shows highest ranking value for the diagnostic function after erasing diagnostic trouble codes (DTCs) or after the Engine control module (ECM) was rendered powerless. Latest shows present ranking value for the diagnostic function. HINT: The updating rate for Worst and Latest are different depending on diagnostic function. NOTE: The updating rate for Worst and Latest may for certain diagnostic functions be as slow as once in 10 seconds. HINT: A high value for "Worst" and a low value for "Latest" indicates an intermittent fault or that the fault is not currently active. Note the diagnostic trouble codes (DTCs) and high ranking values. Other information see «RANKING VALUES»(ref-479169-S38922818922012061200000) see «DESCRIPTION OF BEHAVIORS, ECM-9A0A»(ref-466673-S41402377582012042500000)
- Continue Refer to «VERIFICATION»(ref-466673-S21634467932012042500000)
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9A0A
- Ignition on. The diagnostic trouble code has been stored due to the Engine control module (ECM) having registered deviations of components or functions and has been forced to reconfigure the system with replacement values which has resulted in the vehicle's driveability being affected negatively. It is probable that diagnostic trouble codes for failing components and/or functions also are stored in Engine control module (ECM). These diagnostic trouble codes (DTCs) must be fault-traced and any faults remedied first. Check if other diagnostic trouble codes are stored in Engine control module (ECM). Ignition on. Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).
Are other diagnostic trouble codes (DTCs) stored in the engine control module (ECM)?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «CHECKING THE RANKING VALUES FOR OTHER DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-466673-S42381019352012042500000)
- Ignition on or engine running. Activate the tool for reading off the ranking values by clicking on the VCT2000 symbol. Check ranking values for other diagnostic trouble codes in Engine control module (ECM). The diagnostic trouble code has been stored due to the Engine control module (ECM) having registered deviations of components or functions and has been forced to reconfigure the system with replacement values which has resulted in the vehicle's driveability being affected negatively. A replacement value for a diagnostic function is activated when the ranking value for the diagnostic function exceeds a certain value, normally 128. The ranking value itself is a counter that indicates how close to storing a diagnostic trouble code the system considers itself to be for each diagnostic function, in relation to component or function. The counter counts upwards when the fault is active and downwards when the fault is not active. For certain functions the diagnostic trouble code is generated at the same time as the replacement value is activated, that is, at ranking value 128, but for other functions the counter goes on to 255 before the diagnostic trouble code is generated. If the ranking value for relevant diagnostic trouble codes is 128 or higher, then troubleshooting shall be performed on these diagnostic trouble codes as if the diagnostic trouble code was stored in Engine control module (ECM). HINT: Obtain the fault-tracing manually. The ranking value consists of two values: Worst shows highest ranking value for the diagnostic function after erasing diagnostic trouble codes (DTCs) or after the Engine control module (ECM) was rendered powerless. Latest shows present ranking value for the diagnostic function. HINT: The updating rate for Worst and Latest are different depending on diagnostic function. NOTE: The updating rate for Worst and Latest may for certain diagnostic functions be as slow as once in 10 seconds. HINT: A high value for "Worst" and a low value for "Latest" indicates an intermittent fault or that the fault is not currently active. Note the diagnostic trouble codes (DTCs) and high ranking values. Other information see «RANKING VALUES»(ref-479169-S38922818922012061200000) see «DESCRIPTION OF BEHAVIORS, ECM-9A0A»(ref-466673-S41402377582012042500000)
- Continue Refer to «VERIFICATION»(ref-466673-S12166144742012042500000)
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9A0A
- Ignition on. The diagnostic trouble code has been stored due to the Engine control module (ECM) having registered deviations of components or functions and has been forced to reconfigure the system with replacement values which has resulted in the vehicle's driveability being affected negatively. It is probable that diagnostic trouble codes for failing components and/or functions also are stored in Engine control module (ECM). These diagnostic trouble codes (DTCs) must be fault-traced and any faults remedied first. Check if other diagnostic trouble codes are stored in Engine control module (ECM). Ignition on. Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).
Are other diagnostic trouble codes (DTCs) stored in the engine control module (ECM)?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «CHECKING THE RANKING VALUES FOR OTHER DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-466673-S05839260252012042500000)
- Ignition on or engine running. Activate the tool for reading off the ranking values by clicking on the VCT2000 symbol. Check ranking values for other diagnostic trouble codes in Engine control module (ECM). The diagnostic trouble code has been stored due to the Engine control module (ECM) having registered deviations of components or functions and has been forced to reconfigure the system with replacement values which has resulted in the vehicle's driveability being affected negatively. A replacement value for a diagnostic function is activated when the ranking value for the diagnostic function exceeds a certain value, normally 128. The ranking value itself is a counter that indicates how close to storing a diagnostic trouble code the system considers itself to be for each diagnostic function, in relation to component or function. The counter counts upwards when the fault is active and downwards when the fault is not active. For certain functions the diagnostic trouble code is generated at the same time as the replacement value is activated, that is, at ranking value 128, but for other functions the counter goes on to 255 before the diagnostic trouble code is generated. If the ranking value for relevant diagnostic trouble codes is 128 or higher, then troubleshooting shall be performed on these diagnostic trouble codes as if the diagnostic trouble code was stored in Engine control module (ECM). HINT: Obtain the fault-tracing manually. The ranking value consists of two values: Worst shows highest ranking value for the diagnostic function after erasing diagnostic trouble codes (DTCs) or after the Engine control module (ECM) was rendered powerless. Latest shows present ranking value for the diagnostic function. HINT: The updating rate for Worst and Latest are different depending on diagnostic function. NOTE: The updating rate for Worst and Latest may for certain diagnostic functions be as slow as once in 10 seconds. HINT: A high value for "Worst" and a low value for "Latest" indicates an intermittent fault or that the fault is not currently active. Note the diagnostic trouble codes (DTCs) and high ranking values. Other information see «RANKING VALUES»(ref-479169-S38922818922012061200000) see «DESCRIPTION OF BEHAVIORS, ECM-9A0A»(ref-466673-S41402377582012042500000)
- Continue Refer to «VERIFICATION»(ref-466673-S13036284112012042500000)
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9A0A
- Ignition on. The diagnostic trouble code has been stored due to the Engine control module (ECM) having registered deviations of components or functions and has been forced to reconfigure the system with replacement values which has resulted in the vehicle's driveability being affected negatively. It is probable that diagnostic trouble codes for failing components and/or functions also are stored in Engine control module (ECM). These diagnostic trouble codes (DTCs) must be fault-traced and any faults remedied first. Check if other diagnostic trouble codes are stored in Engine control module (ECM). Ignition on. Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).
Are other diagnostic trouble codes (DTCs) stored in the engine control module (ECM)?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «CHECKING THE RANKING VALUES FOR OTHER DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-466673-S34335082032012042500000)
- Ignition on or engine running. Activate the tool for reading off the ranking values by clicking on the VCT2000 symbol. Check ranking values for other diagnostic trouble codes in Engine control module (ECM). The diagnostic trouble code has been stored due to the Engine control module (ECM) having registered deviations of components or functions and has been forced to reconfigure the system with replacement values which has resulted in the vehicle's driveability being affected negatively. A replacement value for a diagnostic function is activated when the ranking value for the diagnostic function exceeds a certain value, normally 128. The ranking value itself is a counter that indicates how close to storing a diagnostic trouble code the system considers itself to be for each diagnostic function, in relation to component or function. The counter counts upwards when the fault is active and downwards when the fault is not active. For certain functions the diagnostic trouble code is generated at the same time as the replacement value is activated, that is, at ranking value 128, but for other functions the counter goes on to 255 before the diagnostic trouble code is generated. If the ranking value for relevant diagnostic trouble codes is 128 or higher, then troubleshooting shall be performed on these diagnostic trouble codes as if the diagnostic trouble code was stored in Engine control module (ECM). HINT: Obtain the fault-tracing manually. The ranking value consists of two values: Worst shows highest ranking value for the diagnostic function after erasing diagnostic trouble codes (DTCs) or after the Engine control module (ECM) was rendered powerless. Latest shows present ranking value for the diagnostic function. HINT: The updating rate for Worst and Latest are different depending on diagnostic function. NOTE: The updating rate for Worst and Latest may for certain diagnostic functions be as slow as once in 10 seconds. HINT: A high value for "Worst" and a low value for "Latest" indicates an intermittent fault or that the fault is not currently active. Note the diagnostic trouble codes (DTCs) and high ranking values. Other information see «RANKING VALUES»(ref-479169-S38922818922012061200000) see «DESCRIPTION OF BEHAVIORS, ECM-9A0A»(ref-466673-S41402377582012042500000)
- Continue Refer to «VERIFICATION»(ref-466673-S28989811272012042500000)
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9A0A
- Ignition on. The diagnostic trouble code has been stored due to the Engine control module (ECM) having registered deviations of components or functions and has been forced to reconfigure the system with replacement values which has resulted in the vehicle's driveability being affected negatively. It is probable that diagnostic trouble codes for failing components and/or functions also are stored in Engine control module (ECM). These diagnostic trouble codes (DTCs) must be fault-traced and any faults remedied first. Check if other diagnostic trouble codes are stored in Engine control module (ECM). Ignition on. Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).
Are other diagnostic trouble codes (DTCs) stored in the engine control module (ECM)?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «CHECKING THE RANKING VALUES FOR OTHER DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-466673-S28492909292012042500000)
- Ignition on or engine running. Activate the tool for reading off the ranking values by clicking on the VCT2000 symbol. Check ranking values for other diagnostic trouble codes in Engine control module (ECM). The diagnostic trouble code has been stored due to the Engine control module (ECM) having registered deviations of components or functions and has been forced to reconfigure the system with replacement values which has resulted in the vehicle's driveability being affected negatively. A replacement value for a diagnostic function is activated when the ranking value for the diagnostic function exceeds a certain value, normally 128. The ranking value itself is a counter that indicates how close to storing a diagnostic trouble code the system considers itself to be for each diagnostic function, in relation to component or function. The counter counts upwards when the fault is active and downwards when the fault is not active. For certain functions the diagnostic trouble code is generated at the same time as the replacement value is activated, that is, at ranking value 128, but for other functions the counter goes on to 255 before the diagnostic trouble code is generated. If the ranking value for relevant diagnostic trouble codes is 128 or higher, then troubleshooting shall be performed on these diagnostic trouble codes as if the diagnostic trouble code was stored in Engine control module (ECM). HINT: Obtain the fault-tracing manually. The ranking value consists of two values: Worst shows highest ranking value for the diagnostic function after erasing diagnostic trouble codes (DTCs) or after the Engine control module (ECM) was rendered powerless. Latest shows present ranking value for the diagnostic function. HINT: The updating rate for Worst and Latest are different depending on diagnostic function. NOTE: The updating rate for Worst and Latest may for certain diagnostic functions be as slow as once in 10 seconds. HINT: A high value for "Worst" and a low value for "Latest" indicates an intermittent fault or that the fault is not currently active. Note the diagnostic trouble codes (DTCs) and high ranking values. Other information see «RANKING VALUES»(ref-479169-S38922818922012061200000) see «DESCRIPTION OF BEHAVIORS, ECM-9A0A»(ref-466673-S41402377582012042500000)
- Continue Refer to «VERIFICATION»(ref-466673-S34218851692012042500000)
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9A0A
Condition
The engine control module (ECM) has integrated control systems for detecting internal faults. The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the internal voltage references.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
None.
Possible Source
- Damaged engine control module (ECM).
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
- Ignition on. The diagnostic trouble code has been stored due to the Engine control module (ECM) having registered deviations of components or functions and has been forced to reconfigure the system with replacement values which has resulted in the vehicle's driveability being affected negatively. It is probable that diagnostic trouble codes for failing components and/or functions also are stored in Engine control module (ECM). These diagnostic trouble codes (DTCs) must be fault-traced and any faults remedied first. Check if other diagnostic trouble codes are stored in Engine control module (ECM). Ignition on. Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).
Are other diagnostic trouble codes (DTCs) stored in the engine control module (ECM)?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «CHECKING THE RANKING VALUES FOR OTHER DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-466673-S30092012502012042500000)
- Ignition on or engine running. Activate the tool for reading off the ranking values by clicking on the VCT2000 symbol. Check ranking values for other diagnostic trouble codes in Engine control module (ECM). The diagnostic trouble code has been stored due to the Engine control module (ECM) having registered deviations of components or functions and has been forced to reconfigure the system with replacement values which has resulted in the vehicle's driveability being affected negatively. A replacement value for a diagnostic function is activated when the ranking value for the diagnostic function exceeds a certain value, normally 128. The ranking value itself is a counter that indicates how close to storing a diagnostic trouble code the system considers itself to be for each diagnostic function, in relation to component or function. The counter counts upwards when the fault is active and downwards when the fault is not active. For certain functions the diagnostic trouble code is generated at the same time as the replacement value is activated, that is, at ranking value 128, but for other functions the counter goes on to 255 before the diagnostic trouble code is generated. If the ranking value for relevant diagnostic trouble codes is 128 or higher, then troubleshooting shall be performed on these diagnostic trouble codes as if the diagnostic trouble code was stored in Engine control module (ECM). HINT: Obtain the fault-tracing manually. The ranking value consists of two values: Worst shows highest ranking value for the diagnostic function after erasing diagnostic trouble codes (DTCs) or after the Engine control module (ECM) was rendered powerless. Latest shows present ranking value for the diagnostic function. HINT: The updating rate for Worst and Latest are different depending on diagnostic function. NOTE: The updating rate for Worst and Latest may for certain diagnostic functions be as slow as once in 10 seconds. HINT: A high value for "Worst" and a low value for "Latest" indicates an intermittent fault or that the fault is not currently active. Note the diagnostic trouble codes (DTCs) and high ranking values. Other information see «RANKING VALUES»(ref-479169-S38922818922012061200000) see «DESCRIPTION OF BEHAVIORS, ECM-9A0B»(ref-479169-S31656712772012061200000)
- Continue Refer to «VERIFICATION»(ref-466673-S08597882912012042500000)
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9A0B
Condition
Diagnostic functions in the engine control module (ECM) have activated substitute values that result in the driveability of the car being affected. The diagnostic trouble code (DTC) is stored if the engine control module (ECM) detects that the driveability of the car has been negatively affected.
Substitute Value
- None.
Possible Source
- Faults that are detected by another diagnostic function and whose substitute values affect driveability negatively.
Fault symptom[s]
- Message in the display
- The cruise control does not function at all
- Jerky operation
- Uneven idle
- Poor accelerator pedal (AP) response
- The accelerator pedal (AP) is ignored when braking
- Maximum vehicle speed reduced.
- Ignition on. The diagnostic trouble code has been stored due to the Engine control module (ECM) having registered deviations of components or functions and has been forced to reconfigure the system with replacement values which has resulted in the vehicle's driveability being affected negatively. It is probable that diagnostic trouble codes for failing components and/or functions also are stored in Engine control module (ECM). These diagnostic trouble codes (DTCs) must be fault-traced and any faults remedied first. Check if other diagnostic trouble codes are stored in Engine control module (ECM). Ignition on. Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).
Are other diagnostic trouble codes (DTCs) stored in the engine control module (ECM)?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «CHECKING THE RANKING VALUES FOR OTHER DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-466673-S27466192252012042500000)
- Ignition on or engine running. Activate the tool for reading off the ranking values by clicking on the VCT2000 symbol. Check ranking values for other diagnostic trouble codes in Engine control module (ECM). The diagnostic trouble code has been stored due to the Engine control module (ECM) having registered deviations of components or functions and has been forced to reconfigure the system with replacement values which has resulted in the vehicle's driveability being affected negatively. A replacement value for a diagnostic function is activated when the ranking value for the diagnostic function exceeds a certain value, normally 128. The ranking value itself is a counter that indicates how close to storing a diagnostic trouble code the system considers itself to be for each diagnostic function, in relation to component or function. The counter counts upwards when the fault is active and downwards when the fault is not active. For certain functions the diagnostic trouble code is generated at the same time as the replacement value is activated, that is, at ranking value 128, but for other functions the counter goes on to 255 before the diagnostic trouble code is generated. If the ranking value for relevant diagnostic trouble codes is 128 or higher, then troubleshooting shall be performed on these diagnostic trouble codes as if the diagnostic trouble code was stored in Engine control module (ECM). HINT: Obtain the fault-tracing manually. The ranking value consists of two values: Worst shows highest ranking value for the diagnostic function after erasing diagnostic trouble codes (DTCs) or after the Engine control module (ECM) was rendered powerless. Latest shows present ranking value for the diagnostic function. HINT: The updating rate for Worst and Latest are different depending on diagnostic function. NOTE: The updating rate for Worst and Latest may for certain diagnostic functions be as slow as once in 10 seconds. HINT: A high value for "Worst" and a low value for "Latest" indicates an intermittent fault or that the fault is not currently active. Note the diagnostic trouble codes (DTCs) and high ranking values. Other information see «RANKING VALUES»(ref-479169-S38922818922012061200000) see «DESCRIPTION OF BEHAVIORS, ECM-9A0B»(ref-479169-S31656712772012061200000)
- Continue Refer to «VERIFICATION»(ref-466673-S01738546812012042500000)
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-9A0B
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A00B
Condition
The control modules transmit and receive information via a standardized serial communication method - CAN (Control Area Network). The diagnostic trouble code (DTC) is stored in the engine control module (ECM) if it registers a communication fault with the transmission control module (TCM).
Substitute Value
- None.
Possible Source
- Open-circuit in the control area network (CAN) wiring
- Short-circuit between the control area network (CAN) wiring
- Internal fault in the engine control module (ECM)
- Internal fault in another control module in the same part of the control area network (CAN).
Fault symptom[s]
- Harsh gear shifting
- Malfunction indicator lamp (MIL) lit.
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A020
Condition
To minimize the number of software versions, the vehicle configuration taken from the central electronic module (CEM) is used to configure the engine control module (ECM). The diagnostic trouble code (DTC) is stored if the engine control module (ECM) discovers that a parameter transmitted by the central electronic module (CEM) is incorrect.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on
Substitute Value
- The default value for the incorrect parameter is set.
Possible Source
- A control module or function has been removed from or added to the vehicle without correctly updating the vehicle configuration.
Fault symptom[s]
- None.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A020
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A02B
Condition
The control modules transmit and receive information via a standardized serial communication method - CAN (Control Area Network). The diagnostic trouble code (DTC) is stored in the engine control module (ECM) if it registers a communication fault with the brake control module (BCM).
Substitute Value
- None.
Possible Source
- Open-circuit in the control area network (CAN) wiring
- Short-circuit between the control area network (CAN) wiring
- Internal fault in the engine control module (ECM)
- Internal fault in another control module in the same part of the control area network (CAN).
Fault symptom[s]
- Anti-spin does not function.
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A03B
Condition
The control modules transmit and receive information via a standardized serial communication method - CAN (Control Area Network). The diagnostic trouble code (DTC) is stored in the engine control module (ECM) if it registers a communication fault with the central electronic module (CEM).
Substitute Value
- None.
Possible Source
- Open-circuit in the control area network (CAN) wiring
- Short-circuit between the control area network (CAN) wiring
- Internal fault in another control module in the same part of the control area network (CAN).
Fault symptom[s]
- None.
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A10B
Condition
Engine control module (ECM) communicates with alternator control module (ACM) and the Premair sensor via LIN-communication. LIN is a standardized serial communication method (Local Interconnect Network).
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) detects communication interference.
The diagnostic trouble code (DTC) can be diagnosed when the engine is running.
Substitute Value
- The alternator control module (ACM) charges at a fixed voltage of 13.8 V.
Possible Source
Alternator control module (ACM), incorrect communication
- Contact resistance and oxidation in the terminals
- Open-circuit in the LIN wiring
- Short-circuit between the LIN wiring.
- Internal fault in another unit in the same part of the LIN network.
- Damaged alternator control module (ACM) (charge regulator).
- Generator with a charge regulator not intended for LIN communication installed.
Premair sensor, faulty communication
- Contact resistance or oxidation in the terminals.
- Open-circuit in the LIN wiring between the Engine control module (ECM) and Premair sensor.
- Faulty Premair sensor (wrong radiator).
Engine control module (ECM), incorrect communication
- None.
Fault symptom[s]
- The "Generator not charging" warning lamp is lit when the engine is running.
Condition
Scheme 228
The engine control module (ECM) communicates with the alternator control module (ACM) via a standardized serial communication method, Local Interconnect Network (LIN).
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) detects interference in communication with the alternator control module (ACM).
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- The alternator control module (ACM) charges at a fixed voltage of 13.8 V.
Possible Source
- Contact resistance and oxidation in the terminals
- Short-circuit between the LIN wiring
- Open-circuit in the LIN wiring
- Internal fault in another control module in the same part of the LIN network
- Damaged alternator control module (ACM)
- Generator with a charge regulator not intended for LIN communication installed.
Fault symptom[s]
- The "Generator not charging" warning lamp is lit when the engine is running.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A10B
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A10D
Condition
The engine control module (ECM) communicates with the alternator control module (ACM) via a standardized serial communication method, Local Interconnect Network (LIN).
The diagnostic trouble code (DTC) (Signal too high/Signal too low) is stored if the alternator control module (ACM) transmits information about an electrical fault to the engine control module (ECM).
The diagnostic trouble code (DTC) can be diagnosed when the engine is running.
The diagnostic trouble code (DTC) (Faulty signal) is stored if alternator control module (ACM) transmits information to the engine control module (ECM) about an mechanical fault in the generator (GEN) (the engine is running above a certain speed but the generator (GEN) is stationary.
The diagnostic trouble code (DTC) can be diagnosed when the engine is running.
The diagnostic trouble code (DTC) (Temperature too high) is stored if the alternator control module (ACM) transmits information to the engine control module (ECM) that the generator (GEN) temperature exceeds a certain value.
The diagnostic trouble code (DTC) can be diagnosed when the engine is running.
The diagnostic trouble code (DTC) (Faulty communication) is stored if the engine control module (ECM) registers interference in communication with the alternator control module (ACM).
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- The alternator control module (ACM) charges at a fixed voltage of 13.8 V.
Possible Source
Signal too high / Signal too low
- Battery charger with too high charge voltage has been connected previously
- Worn brushes (carbon)
- Damaged alternator control module (ACM)
- Damaged generator (GEN).
Faulty signal
- Defective auxiliaries belt and belt tensioner
- Damaged freewheel
- Damaged generator (GEN).
Temperature too high
- The air ducts for the generator (GEN) are blocked.
Faulty communication
- Contact resistance and oxidation in the terminals
- Short-circuit between the LIN wiring
- Open-circuit in the LIN wiring
- Internal fault in another control module in the same part of the LIN network
- Damaged alternator control module (ACM)
- Generator with a charge regulator not intended for LIN communication installed.
Fault symptom[s]
- The "Generator not charging" warning lamp is lit when the engine is running
- The battery discharges
- Low rotation speed in the starter motor
- Noise from the generator (GEN)
- Noise from the belt transmission
- The engine judders under acceleration
- The electrolyte in battery boils with the engine running
- The headlamp bulb blows.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A10D
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A10D
Scheme 229
- Start the engine
- Read off the battery voltage and the target value of the generator (GEN) charge voltage
- Load the battery by switching on high current consumers such as high beam and the blower fan etc. Check that the battery voltage is approximately 13.5-14.9 V. Check that the battery voltage is approximately the same as the target value for the generator (GEN) charge. Try different engine speeds (RPM). The fault is permanent if the function is faulty. If the voltage is correct, this is an indication that the fault was present previously but is not active at the moment, i. e. an intermittent fault. HINT: This diagnostic trouble code can be stored if a battery charger with too high charge voltage has been connected.
- Continue Refer to «CHECKING THE COMPONENT»(ref-466673-S32154823372012042500000)
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A10D
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A11A
Condition
The engine control module (ECM) monitors the car's radiator with the help of a Premair sensor. The sensor communicates with the engine control module (ECM) via LIN-communication. LIN is a standardized serial communication method (Local Interconnect Network). The sent information is encrypted.
The purpose of the sensor is to ensure that the right radiator is fitted on the vehicle.
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the signal from the Premair sensor is incorrect (Wrong signal).
The diagnostic trouble code (DTC) can be scanned 10 minutes after thermostat opening (engine temperature >90 °C) when the engine has cooled completely since the previous operating cycle.
Note. The diagnostic trouble code (DTC) can only be diagnosed while driving. Stationary vehicle with engine running stops diagnostics.
Substitute Value
- None.
Possible Source
- None.
Fault symptom[s]
- None.
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A11D
Condition
The engine control module (ECM) monitors the car's radiator with the help of a Premair sensor. The sensor communicates with the engine control module (ECM) via LIN-communication. LIN is a standardized serial communication method (Local Interconnect Network). The sent information is encrypted. The purpose of the sensor is to ensure that the right radiator is fitted on the vehicle.
The diagnostic trouble code (DTC) is stored if the engine control module (ECM) receives information from the Premair sensor that a fault has been detected.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is on.
Substitute Value
- None.
Possible Source
- None.
Fault symptom[s]
- None.
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A12B
Condition
A fault message is transmitted to the engine control module (ECM) and the diagnostic trouble code (DTC) is stored if a fault is detected in the brake control module (BCM). Diagnostic trouble codes (DTCs) for the vehicle speed sensor (VSS) signal are also stored in the brake control module (BCM).
Substitute Value
- The speed signal from the brake control module (BCM) is set at 0 km/h.
Possible Source
- Contact resistance in the control area network (CAN) terminals
- Open-circuit in one or both CAN cables
- Short-circuit to ground, voltage or each other in one or both signal cables
- Damaged brake control module (BCM)
- Damaged engine control module (ECM).
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A12B
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A12C
Condition
A fault message is transmitted to the engine control module (ECM) and the diagnostic trouble code (DTC) is stored if a fault is detected in the brake control module (BCM). Diagnostic trouble codes (DTCs) for the vehicle speed sensor (VSS) signal are also stored in the brake control module (BCM).
Substitute Value
- The speed signal from the brake control module (BCM) is set at 0 km/h.
Possible Source
- Faulty speed signal to the brake control module (BCM).
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A12C
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A130
Condition
The control modules transmit and receive information via a standardized serial communication method - CAN (Control Area Network). The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers serious interference (CAN communication blocked).
Note. In the event of system communication problems, it is not possible to communicate with the engine control module (ECM). Therefore it will only be possible to read off the diagnostic trouble code (DTC) if the fault is intermittent.
Substitute Value
- The engine control module (ECM) shuts itself off "bus-off".
HINT: The engine control module (ECM) will remain shut off until the power supply is broken (15, 30, x-supply). When the power supply is switched on, the engine control module (ECM) will make a new attempt to communicate.
Possible Source
- Contact resistance or oxidation in the terminals
- Open-circuit in the control area network (CAN) wiring
- Short-circuit between the control area network (CAN) wiring
- Internal fault in the engine control module (ECM)
- Internal fault in another control module in the same part of the control area network (CAN).
Fault symptom[s]
- General warning lamp lit
- The cruise control does not function at all
- The engine judders under acceleration
- The engine judders heavily after engine braking
- Uneven idle.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A130
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A13C
Condition
Note. This diagnostic trouble code (DTC) status is an event controlled diagnostic trouble code (DTC). An event controlled diagnostic trouble code (DTC) does not mean that there is a fault in the control module when it is active, but is designed as information.
Engine control module (ECM) registers internally if the vehicle has been involved in a collision. If the control module detects that Central electronic module (CEM) sends internal signals that a collision has occurred, the diagnostic trouble code is generated.
Note. The diagnostic trouble code must be erased like a normal diagnostic trouble code, even if fault-tracing is not carried out.
The diagnostic trouble code (DTC) can be diagnosed at key position II.
Substitute Value
- Nothing.
Possible Source
- This diagnostic trouble code (DTC) is not caused by a fault that needs to be remedied.
Fault symptom[s]
- Engine is difficult to start
- Malfunction indicator light (MIL), on
- Message in information display
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A13C
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A20B
Condition
The central electronic module (CEM) transmits a timer signal to the control modules in the car via the controller area network (CAN). This signal informs how many seconds have passed since the engine was last switched off. The signal is used for example by the engine control module (ECM) when restarting a warm engine. The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the timer signal transmitted by the central electronic module (CEM) is incorrect.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
A calculated timer signal is used by the engine control module (ECM).
Possible Source
- Fault trace the central electronic module (CEM)
- Open-circuit or short-circuit in CAN wiring between the engine control module (ECM) and the central electronic module (CEM)
- Damaged central electronic module (CEM).
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A20B
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A20C
Condition
The central electronic module (CEM) transmits a timer signal to the control modules in the car via the controller area network (CAN). This signal informs how many seconds have passed since the engine was last switched off. The signal is used for example by the engine control module (ECM) when restarting a warm engine. The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the timer signal transmitted by the central electronic module (CEM) is incorrect.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
A calculated timer signal is used by the engine control module (ECM).
Possible Source
- Fault trace the central electronic module (CEM)
- Open-circuit or short-circuit in CAN wiring between the engine control module (ECM) and the central electronic module (CEM)
- Damaged central electronic module (CEM).
Fault symptom[s]
- Malfunction indicator lamp (MIL) lit.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-A20C
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-E000
Condition
The control modules transmit and receive information via a standardized serial communication method - CAN (Control Area Network). The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers serious interference (CAN communication blocked).
Note. In the event of system communication problems, it is not possible to communicate with the engine control module (ECM). Therefore it will only be possible to read off the diagnostic trouble code (DTC) if the fault is intermittent.
Substitute Value
- The engine control module (ECM) shuts itself off ("bus-off").
HINT: The engine control module (ECM) will remain shut off until the power supply is broken (15, 30, x-supply). When the power supply is switched on, the engine control module (ECM) will make a new attempt to communicate.
Possible Source
- Contact resistance or oxidation in the terminals
- Open-circuit in the control area network (CAN) wiring
- Short-circuit between the control area network (CAN) wiring
- Internal fault in the engine control module (ECM)
- Internal fault in another control module in the same part of the control area network (CAN).
Fault symptom[s]
- General warning lamp lit
- The cruise control does not function at all
- The engine judders under acceleration
- The engine judders heavily after engine braking
- Uneven idle.
Condition
The control modules transmit and receive information via a standardized serial communication method - CAN (Control Area Network). The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers serious interference (CAN communication blocked).
Note. In the event of system communication problems, it is not possible to communicate with the engine control module (ECM). Therefore it will only be possible to read off the diagnostic trouble code (DTC) if the fault is intermittent.
Substitute Value
- The engine control module (ECM) shuts itself off "bus-off".
HINT: The engine control module (ECM) will remain shut off until the power supply is broken (15, 30, x-supply). When the power supply is switched on, the engine control module (ECM) will make a new attempt to communicate.
Possible Source
- Contact resistance or oxidation in the terminals
- Open-circuit in the control area network (CAN) wiring
- Short-circuit between the control area network (CAN) wiring
- Internal fault in the engine control module (ECM)
- Internal fault in another control module in the same part of the control area network (CAN).
Fault symptom[s]
- General warning lamp lit
- The cruise control does not function at all
- The engine judders under acceleration
- The engine judders heavily after engine braking
- Uneven idle.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-E000
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-E003
Condition
The engine control module (ECM) compares its configuration ID with the signal configuration transmitted on the control area network (CAN) by the central electronic module (CEM). If the configuration IDs do not correspond the fault code is stored. The diagnostic trouble code (DTC) is also stored if the communication between the engine control module (ECM) and the central electronic module (CEM) is interrupted.
Note. In the event of an open-circuit in both the control area network (CAN) cables, it is not possible to communicate with the engine control module (ECM). Therefore it will only be possible to read off the diagnostic trouble code (DTC) if this type of fault is intermittent. When the diagnostic trouble code (DTC) is stored, the engine control module (ECM) responds to the diagnostic commands. However normal control area network (CAN) communication does not work ("Expulsion mode").
Substitute Value
- None.
Possible Source
- Incorrect CAN configuration ID (engine control module (ECM) is not intended for this car (for example a used control module with other software/hardware)
- Open-circuit in the control area network (CAN) wiring between the engine control module (ECM) and the central electrical module (CEM).
Fault symptom[s]
- General warning lamp lit
- The cruise control does not function at all
- The engine judders under acceleration
- The engine judders heavily after engine braking
- Uneven idle.
Condition
The engine control module (ECM) compares its configuration ID with the signal configuration transmitted by the central electronic module (CEM) on the control area network (CAN). If the configuration IDs do not correspond the fault code is stored. The diagnostic trouble code (DTC) is also stored if the communication between the engine control module (ECM) and the central electronic module (CEM) is interrupted.
Note. In the event of an open-circuit in both the control area network (CAN) cables, it is not possible to communicate with the engine control module (ECM). Therefore it will only be possible to read off the diagnostic trouble code (DTC) if this type of fault is intermittent. When the diagnostic trouble code (DTC) is stored, the engine control module (ECM) responds to the diagnostic commands. However normal control area network (CAN) communication "Expulsion mode" does not work.
Substitute value
- None.
Possible Source
- Incorrect CAN configuration ID (present engine control module (ECM) is not intended for the vehicle, for example a used control module with other software/hardware)
- Open-circuit in the control area network (CAN) wiring between the engine control module (ECM) and the central electrical module (CEM).
Fault symptom[s]
- General warning lamp lit
- The cruise control does not function at all
- The engine judders under acceleration
- The engine judders heavily after engine braking
- Uneven idle.
See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-E003
READING OFF DIAGNOSTIC TROUBLE CODES (DTC)
- Ignition on. Read off the diagnostic trouble code (DTC) that is stored in the car. Make a note of the code. Report the code to VIDA customer support.
- Ignition on. Read off the diagnostic trouble code (DTC) that is stored in the vehicle. Make a note of the code. Report the code to VIDA customer support.
UNKNOWN DIAGNOSTIC TROUBLE CODE (DTC) FOR THE PRESENT CONTROL MODULE VERSION
See UNKNOWN DIAGNOSTIC TROUBLE CODE (DTC) FOR THE PRESENT CONTROL MODULE VERSION
