Engine Control Module (ECM) Diagnostic Trouble Codes - 7 of 9: Other Volvo V50 I рестайлинг

VERIFICATION

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 176

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Activate the engine cooling fan (FC). Check that the engine cooling fan (FC) starts when activated.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S02630383192012042500000)

FAULT-TRACING INFORMATION

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CHECKING THE STATUS

1. Ignition on. Activate the engine cooling fan (FC). Check that the engine cooling fan (FC) starts when activated. The fault is permanent if the engine cooling fan (FC) does not start when activated. The fault is intermittent if the engine cooling fan (FC) starts.

1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466669-S03536799382012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Activate the engine cooling fan (FC). Check that the engine cooling fan (FC) starts when activated.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S04421011462012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition on. Activate the engine cooling fan (FC). Check that the engine cooling fan (FC) starts when activated. The fault is permanent if the engine cooling fan (FC) does not start when activated. The fault is intermittent if the engine cooling fan (FC) starts.

1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466669-S03359727892012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Activate the engine cooling fan (FC). Check that the engine cooling fan (FC) starts when activated.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S25347801492012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition on. Activate the engine cooling fan (FC). Check that the engine cooling fan (FC) starts when activated. The fault is permanent if the engine cooling fan (FC) does not start when activated. The fault is intermittent if the engine cooling fan (FC) starts.

1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466669-S17698887892012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Activate the engine cooling fan (FC). Check that the engine cooling fan (FC) starts when activated.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S35793345282012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: Diagnostic trouble code (DTC) may be caused by a damaged fuse. Check the fuse for the power supply to the camshaft reset valve.

Scheme 177

1. Start the engine
2. Read off the value for the camshaft closing angle and the desired value for the camshaft closing angle
3. Active the quick test of camshaft control by clicking the start button
4. Increase the engine speed (RPM) to approximately 2500 RPM and keep the engine running at this speed. When the engine speed (RPM) increases, the control module will start the quick test to guide the camshaft to the different target values. During the quick test, check that the closing angle of the camshaft (actual value) corresponds to the desired camshaft closing angle (target value) to an accuracy of ±10°. If the values do not correspond to an accuracy of ±10°, the function is faulty. Deviation between the values can be read off in the lower display. Carry out the check for approximately 15 seconds at an engine speed (RPM) of 2500 RPM. When the desired value is stable once again, the test has been completed. To restart the test, let the engine return to idle speed, then increase the engine speed to approximately 2500 RPM again. The fault is intermittent if the function is OK. NOTE: The test is active until the ignition is switched off. Switch off the ignition before the vehicle is delivered to the customer.

1. Continue Refer to «CHECKING COMPONENTS»(ref-466669-S01404158672012042500000)

CHECKING COMPONENTS

Check the engine oil level and quality. Check for contaminants in particular.

Check the engine oil pressure.

Remove the camshaft reset valve. Check the oil ducts for the cylinder head for the camshaft reset valve (intake) for blockages and dirt.

HINT: Faults may result from dirt in the camshaft reset valve. Try cleaning the valve.

Remedy as necessary.

Try a new intake camshaft reset valve if the above remedy does not solve the fault.

HINT: The fault may also have been caused by an internal fault in the variable valve timing unit. The variable valve timing unit may be damaged if the above fault-tracing and corrective action do not remedy the fault.

Other information

1. see «OIL PRESSURE TEST»(ref-466670-S14378446332012042500000)
2. see «VVT SOLENOID»(ref-466659-S08868277172012042500000)
3. see «VVT UNIT»(ref-466659-S10981923982012042500000)

1. Continue Refer to «VERIFICATION»(ref-466669-S05896414982012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine
2. Read off the value for the camshaft closing angle and the desired value for the camshaft closing angle
3. Active the quick test of camshaft control by clicking the start button
4. Increase the engine speed (RPM) to approximately 2500 RPM and keep the engine running at this speed. When the engine speed (RPM) increases, the control module will start the quick test to guide the camshaft to the different target values. During the quick test, check that the closing angle of the camshaft (actual value) corresponds to the desired camshaft closing angle (target value) to an accuracy of ±10°. If the values do not correspond to an accuracy of ±10°, the function is faulty. Deviation between the values can be read off in the lower display. Carry out the check for approximately 15 seconds at an engine speed (RPM) of 2500 RPM. When the desired value is stable once again, the test has been completed. To restart the test, let the engine return to idle speed, then increase the engine speed to approximately 2500 RPM again. NOTE: The test is active until the ignition is switched off. Switch off the ignition before the vehicle is delivered to the customer.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S05651817322012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SLOW/FAULTY

See SLOW/FAULTY

See SLOW/FAULTY

See SLOW/FAULTY

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine
2. Read off the value for the camshaft closing angle and the desired value for the camshaft closing angle
3. Active the quick test of camshaft control by clicking the start button
4. Increase the engine speed (RPM) to approximately 2500 RPM and keep the engine running at this speed. When the engine speed (RPM) increases, the control module will start the quick test to guide the camshaft to the different target values. During the quick test, check that the closing angle of the camshaft (actual value) corresponds to the desired camshaft closing angle (target value) to an accuracy of ±10°. If the values do not correspond to an accuracy of ±10°, the function is faulty. Deviation between the values can be read off in the lower display. Carry out the check for approximately 15 seconds at an engine speed (RPM) of 2500 RPM. When the desired value is stable once again, the test has been completed. To restart the test, let the engine return to idle speed, then increase the engine speed to approximately 2500 RPM again. NOTE: The test is active until the ignition is switched off. Switch off the ignition before the vehicle is delivered to the customer.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S01474435132012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL MISSING

See SIGNAL MISSING

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine
2. Read off the value for the camshaft closing angle and the desired value for the camshaft closing angle
3. Active the quick test of camshaft control by clicking the start button
4. Increase the engine speed (RPM) to approximately 2500 RPM and keep the engine running at this speed. When the engine speed (RPM) increases, the control module will start the quick test to guide the camshaft to the different target values. During the quick test, check that the closing angle of the camshaft (actual value) corresponds to the desired camshaft closing angle (target value) to an accuracy of ±10°. If the values do not correspond to an accuracy of ±10°, the function is faulty. Deviation between the values can be read off in the lower display. Carry out the check for approximately 15 seconds at an engine speed (RPM) of 2500 RPM. When the desired value is stable once again, the test has been completed. To restart the test, let the engine return to idle speed, then increase the engine speed to approximately 2500 RPM again. NOTE: The test is active until the ignition is switched off. Switch off the ignition before the vehicle is delivered to the customer.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S01635288502012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL TOO HIGH

See SIGNAL TOO HIGH

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine
2. Read off the value for the camshaft closing angle and the desired value for the camshaft closing angle
3. Active the quick test of camshaft control by clicking the start button
4. Increase the engine speed (RPM) to approximately 2500 RPM and keep the engine running at this speed. When the engine speed (RPM) increases, the control module will start the quick test to guide the camshaft to the different target values. During the quick test, check that the closing angle of the camshaft (actual value) corresponds to the desired camshaft closing angle (target value) to an accuracy of ±10°. If the values do not correspond to an accuracy of ±10°, the function is faulty. Deviation between the values can be read off in the lower display. Carry out the check for approximately 15 seconds at an engine speed (RPM) of 2500 RPM. When the desired value is stable once again, the test has been completed. To restart the test, let the engine return to idle speed, then increase the engine speed to approximately 2500 RPM again. NOTE: The test is active until the ignition is switched off. Switch off the ignition before the vehicle is delivered to the customer.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S10249126362012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL TOO LOW

See SIGNAL TOO LOW

HINT: Diagnostic trouble code (DTC) may be caused by a damaged fuse. Check the fuse for the power supply to the camshaft reset valve.

1. Start the engine
2. Read off the camshaft opening angle and the camshaft opening angle, desired value
3. Active the quick test of camshaft control by clicking the start button
4. Increase the engine speed (RPM) to approximately 2500 RPM and keep the engine running at this speed. When the engine speed (RPM) increases, the control module will start the quick test to guide the camshaft to the different target values. During the quick test, check that the closing angle of the camshaft (actual value) corresponds to the desired camshaft closing angle (target value) to an accuracy of ±10°. If the values do not correspond to an accuracy of ±10°, the function is faulty. Deviation between the values can be read off in the lower display. Carry out the check for approximately 15 seconds at an engine speed (RPM) of 2500 RPM. When the desired value is stable once again, the test has been completed. To restart the test, let the engine return to idle speed, then increase the engine speed to approximately 2500 RPM again. The fault is intermittent if the function is OK. NOTE: The test is active until the ignition is switched off. Switch off the ignition before the vehicle is delivered to the customer.

1. Continue Refer to «CHECKING COMPONENTS»(ref-466669-S13089407022012042500000)

Check the engine oil level and quality. Check for contaminants in particular.

Check the engine oil pressure.

Remove the camshaft reset valve. Check the oil ducts for the cylinder head for the camshaft reset valve (exhaust) for blockages and dirt.

HINT: Faults may result from dirt in the camshaft reset valve. Try cleaning the valve.

Remedy as necessary.

Try a new camshaft reset valve (exhaust) if the above remedy does not solve the fault.

HINT: The fault may also have been caused by an internal fault in the variable valve timing unit. The variable valve timing unit may be damaged if the above fault-tracing and corrective action do not remedy the fault.

Other information

1. see «OIL PRESSURE TEST (2005-2007)»(ref-466670-S14378446332012042500000) , or «OIL PRESSURE TEST (2008-2010)»(ref-466670-S03046006662012042500000)
2. see «VVT SOLENOID»(ref-466659-S08868277172012042500000)
3. see «VVT UNIT»(ref-466659-S10981923982012042500000)

1. Continue Refer to «VERIFICATION»(ref-466669-S31946701162012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine
2. Read off the camshaft opening angle and the camshaft opening angle, desired value
3. Active the quick test of camshaft control by clicking the start button
4. Increase the engine speed (RPM) to approximately 2500 RPM and keep the engine running at this speed. When the engine speed (RPM) increases, the control module will start the quick test to guide the camshaft to the different target values. During the quick test, check that the opening angle of the camshaft (actual value) corresponds to the desired camshaft opening angle (target value) to an accuracy of ±10°. If the values do not correspond to an accuracy of ±10°, the function is faulty. Deviation between the values can be read off in the lower display. Carry out the check for approximately 15 seconds at an engine speed (RPM) of 2500 RPM. When the desired value is stable once again, the test has been completed. To restart the test, let the engine return to idle speed, then increase the engine speed to approximately 2500 RPM again. NOTE: The test is active until the ignition is switched off. Switch off the ignition before the car is delivered to the customer.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S35047472322012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SLOW/FAULTY

See SLOW/FAULTY

See SLOW/FAULTY

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine
2. Read off the camshaft opening angle and the camshaft opening angle, desired value
3. Active the quick test of camshaft control by clicking the start button
4. Increase the engine speed (RPM) to approximately 2500 RPM and keep the engine running at this speed. When the engine speed (RPM) increases, the control module will start the quick test to guide the camshaft to the different target values. During the quick test, check that the opening angle of the camshaft (actual value) corresponds to the desired camshaft opening angle (target value) to an accuracy of ±10°. If the values do not correspond to an accuracy of ±10°, the function is faulty. Deviation between the values can be read off in the lower display. Carry out the check for approximately 15 seconds at an engine speed (RPM) of 2500 RPM. When the desired value is stable once again, the test has been completed. To restart the test, let the engine return to idle speed, then increase the engine speed to approximately 2500 RPM again. NOTE: The test is active until the ignition is switched off. Switch off the ignition before the car is delivered to the customer.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S35637773712012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL MISSING

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine
2. Read off the camshaft opening angle and the camshaft opening angle, desired value
3. Active the quick test of camshaft control by clicking the start button
4. Increase the engine speed (RPM) to approximately 2500 RPM and keep the engine running at this speed. When the engine speed (RPM) increases, the control module will start the quick test to guide the camshaft to the different target values. During the quick test, check that the opening angle of the camshaft (actual value) corresponds to the desired camshaft opening angle (target value) to an accuracy of ±10°. If the values do not correspond to an accuracy of ±10°, the function is faulty. Deviation between the values can be read off in the lower display. Carry out the check for approximately 15 seconds at an engine speed (RPM) of 2500 RPM. When the desired value is stable once again, the test has been completed. To restart the test, let the engine return to idle speed, then increase the engine speed to approximately 2500 RPM again. NOTE: The test is active until the ignition is switched off. Switch off the ignition before the car is delivered to the customer.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S26118685502012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO HIGH

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine
2. Read off the camshaft opening angle and the camshaft opening angle, desired value
3. Active the quick test of camshaft control by clicking the start button
4. Increase the engine speed (RPM) to approximately 2500 RPM and keep the engine running at this speed. When the engine speed (RPM) increases, the control module will start the quick test to guide the camshaft to the different target values. During the quick test, check that the opening angle of the camshaft (actual value) corresponds to the desired camshaft opening angle (target value) to an accuracy of ±10°. If the values do not correspond to an accuracy of ±10°, the function is faulty. Deviation between the values can be read off in the lower display. Carry out the check for approximately 15 seconds at an engine speed (RPM) of 2500 RPM. When the desired value is stable once again, the test has been completed. To restart the test, let the engine return to idle speed, then increase the engine speed to approximately 2500 RPM again. NOTE: The test is active until the ignition is switched off. Switch off the ignition before the car is delivered to the customer.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S08120964052012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO LOW

See SLOW/FAULTY

See SLOW/FAULTY

see FAULT-TRACING INFORMATION

CHECKING THE COMPONENT

Check that the fan blade rotates easily and that nothing is obstructing it.

Remedy as necessary.

1. Continue Refer to «VERIFICATION»(ref-466669-S27916963962012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Activate the engine cooling fan (FC). Check that the engine cooling fan (FC) starts.

Does the engine cooling fan (FC) start?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S08339164432012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL TOO HIGH / SIGNAL MISSING

See SIGNAL TOO HIGH / SIGNAL MISSING

See SIGNAL TOO HIGH / SIGNAL MISSING

See SIGNAL TOO HIGH / SIGNAL MISSING

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Activate the engine cooling fan (FC). Check that the engine cooling fan (FC) starts.

Does the engine cooling fan (FC) start?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S03498533812012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Activate the engine cooling fan (FC). Check that the engine cooling fan (FC) starts.

Does the engine cooling fan (FC) start?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S05589621372012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

FAULT-TRACING

See FAULT-TRACING

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Activate the engine cooling fan (FC). Check that the engine cooling fan (FC) starts.

Does the engine cooling fan (FC) start?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S21313184772012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Activate the engine cooling fan (FC). Check that the engine cooling fan (FC) starts.

Does the engine cooling fan (FC) start?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S24697447572012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO HIGH

See FAULT-TRACING

See FAULT-TRACING

SIGNAL TOO LOW OR SIGNAL MISSING

See SIGNAL TOO LOW OR SIGNAL MISSING

INFORMATION

The diagnostic trouble code (DTC) may for example be stored when

1. Insufficient coolant in cooling system.
2. Clogged radiator.

These should therefore be checked and rectified first.

Scheme 178

1. Continue Refer to «CHECKING THE FUNCTION»(ref-466669-S36251216922012042500000)

Scheme 179

1. Ignition on. Activate the engine cooling fan (FC). Check that it starts and runs normally. Try by activating different speeds on the electric cooling fan. Remedy as necessary. Other information see «ENGINE COOLING FAN (FC)»(ref-479166-S33734270582012061200000)

1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466669-S32496963732012042500000)

Scheme 180

Scheme 181

Scheme 182

1. Ignition off.
2. Unplug the engine temperature sensor connectors. Check the connectors. Check for loose connections. Check for contact resistance. Check for oxidation. Check the resistance of the sensor between #1 and #2 (to the sensor). Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000) see «SIGNAL SPECIFICATION»(ref-466592-S15491428272012042500000) see «COMPONENT SPECIFICATIONS»(ref-466592-S02390340522012042500000) see «ENGINE COOLANT TEMPERATURE SENSOR (ECT)»(ref-466594-S40429581352012042500000) see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)

1. Continue Refer to «VERIFICATION»(ref-466669-S23110747712012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Verification should begin with a cold engine (+20 °C) so that the engine coolant temperature (ECT) sensor can be tested over as wide a temperature range as possible
2. Ignition off
3. Reconnect the connectors, reinstall components etc.
4. Start the engine. Read off the engine coolant temperature (ECT) sensor signal. Check that the engine coolant temperature (ECT) is within its permitted range and corresponds with the engine warming up.

Is the temperature within its permitted range?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S32950817882012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

FAULTY SIGNAL

See FAULTY SIGNAL

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Activate the air conditioning (A/C) relay. A "clicking sound" should be heard from the air conditioning (A/C) relay and the air conditioning (A/C) compressor when the relay is activated.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S03072130072012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL MISSING

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Activate the air conditioning (A/C) relay. A "clicking sound" should be heard from the air conditioning (A/C) relay and the air conditioning (A/C) compressor when the relay is activated.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S12995708482012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO HIGH

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Activate the air conditioning (A/C) relay. A "clicking sound" should be heard from the air conditioning (A/C) relay and the air conditioning (A/C) compressor when the relay is activated.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S31586106702012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO LOW

1. Start the engine and run it to normal operating temperature. Check whether the fault is permanent or intermittent. Read off the signal from the intake camshaft reset valve. Check that the signal is within its permitted range. The normal value with an idling engine at operating temperature is 400 - 900 mA. The fault is permanent if the signal is incorrect. The fault is intermittent if the signal is correct.

1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466669-S20042004452012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine and run it to normal operating temperature. Read off the signal from the (intake) camshaft reset valve. Check that the signal is within its permitted range. The normal value with an idling engine at operating temperature is 400 - 900 mA.

Is the signal within its permitted range?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S32245093682012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine and run it to normal operating temperature. Check whether the fault is permanent or intermittent. Read off the signal from the intake camshaft reset valve. Check that the signal is within its permitted range. The normal value with an idling engine at operating temperature is 400 - 900 mA. The fault is permanent if the signal is incorrect. The fault is intermittent if the signal is correct.

1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466669-S36160604922012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine and run it to normal operating temperature. Read off the signal from the (intake) camshaft reset valve. Check that the signal is within its permitted range. The normal value with an idling engine at operating temperature is 400 - 900 mA.

Is the signal within its permitted range?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S05494481672012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine and run it to normal operating temperature. Check whether the fault is permanent or intermittent. Read off the signal from the intake camshaft reset valve. Check that the signal is within its permitted range. The normal value with an idling engine at operating temperature is 400 - 900 mA. The fault is permanent if the signal is incorrect. The fault is intermittent if the signal is correct.

1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466669-S21989722402012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine and run it to normal operating temperature. Read off the signal from the (intake) camshaft reset valve. Check that the signal is within its permitted range. The normal value with an idling engine at operating temperature is 400 - 900 mA.

Is the signal within its permitted range?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S11680674412012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine and run it to normal operating temperature. Check whether the fault is permanent or intermittent. Read off the signal from the intake camshaft reset valve. Check that the signal is within its permitted range. The normal value with an idling engine at operating temperature is 400 - 900 mA. The fault is permanent if the signal is incorrect. The fault is intermittent if the signal is correct.

1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466669-S05935106162012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine and run it to normal operating temperature. Read off the signal from the (intake) camshaft reset valve. Check that the signal is within its permitted range. The normal value with an idling engine at operating temperature is 400 - 900 mA.

Is the signal within its permitted range?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S14041677692012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine and run it to normal operating temperature. Check whether the fault is permanent or intermittent. Read off the signal from the intake camshaft reset valve. Check that the signal is within its permitted range. The normal value with an idling engine at operating temperature is 400 - 900 mA. The fault is permanent if the signal is incorrect. The fault is intermittent if the signal is correct.

1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466669-S10777495622012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine and run it to normal operating temperature. Read off the signal from the (intake) camshaft reset valve. Check that the signal is within its permitted range. The normal value with an idling engine at operating temperature is 400 - 900 mA.

Is the signal within its permitted range?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S39362694572012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine and run it to normal operating temperature. Check whether the fault is permanent or intermittent. Read off the signal from the intake camshaft reset valve. Check that the signal is within its permitted range. The normal value with an idling engine at operating temperature is 400 - 900 mA. The fault is permanent if the signal is incorrect. The fault is intermittent if the signal is correct.

1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466669-S35484770672012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine and run it to normal operating temperature. Read off the signal from the (intake) camshaft reset valve. Check that the signal is within its permitted range. The normal value with an idling engine at operating temperature is 400 - 900 mA.

Is the signal within its permitted range?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S00971089262012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine and run it to normal operating temperature. Read off the camshaft shift angle and the camshaft shift angle, desired value. Check that the camshaft's gear angle and reference value for the camshaft's gear angle correspond with an accuracy of about 20 degrees CA when idling and when the engine is warm. Rev the engine a few times and check again at idle speed that the values correspond. The difference between the values can be read off in the lower digital display. The fault is permanent if the values do not correspond. The fault is intermittent if the values correspond.

1. Continue Refer to «CHECKING COMPONENTS»(ref-466669-S01466572582012042500000)

Check the engine oil level and quality. Check for contaminants in particular.

Remove the camshaft reset valve. Check the oil ducts for the cylinder head for the camshaft reset valve. Check for blockages and dirt.

HINT: Faults may result from dirt in the camshaft reset valve. Try cleaning the valve.

Try a new camshaft reset valve if the above remedy does not solve the fault.

HINT: The fault may also have been caused by an internal fault in the variable valve timing unit. The variable valve timing unit may be damaged if the above fault-tracing and corrective action do not remedy the fault.

Remedy as necessary.

Other information

1. see «CRANKSHAFT POSITION SENSOR (CKP)»(ref-466594-S40916949102012042500000)
2. see «VVT SOLENOID»(ref-466659-S08868277172012042500000)

1. Continue Refer to «VERIFICATION»(ref-466669-S06424217522012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine and run it to normal operating temperature. Read off the camshaft shift angle and the camshaft shift angle, desired value. At idle speed with the engine at operating temperature, check that the camshaft shift angle and the desired value for the camshaft shift angle correspond with an accuracy of approximately 8° CA. Rev the engine a few times and check again at idle speed that the values correspond. The difference between the values can be read off in the lower digital display.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S23025841582012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine and run it to normal operating temperature. Read off the camshaft shift angle and the camshaft shift angle, desired value. Check that the camshaft's gear angle and reference value for the camshaft's gear angle correspond with an accuracy of about 20 degrees CA when idling and when the engine is warm. Rev the engine a few times and check again at idle speed that the values correspond. The difference between the values can be read off in the lower digital display. The fault is permanent if the values do not correspond. The fault is intermittent if the values correspond.

1. Continue Refer to «CHECKING COMPONENTS»(ref-466669-S05927438382012042500000)

Check the engine oil level and quality. Check for contaminants in particular.

Remove the camshaft reset valve. Check the oil ducts for the cylinder head for the camshaft reset valve. Check for blockages and dirt.

HINT: Faults may result from dirt in the camshaft reset valve. Try cleaning the valve.

Try a new camshaft reset valve if the above remedy does not solve the fault.

HINT: The fault may also have been caused by an internal fault in the variable valve timing unit. The variable valve timing unit may be damaged if the above fault-tracing and corrective action do not remedy the fault.

Remedy as necessary.

Other information

1. see «CRANKSHAFT POSITION SENSOR (CKP)»(ref-466594-S40916949102012042500000)
2. see «VVT SOLENOID»(ref-466659-S08868277172012042500000)

1. Continue Refer to «VERIFICATION»(ref-466669-S39294852762012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine and run it to normal operating temperature. Read off the camshaft shift angle and the camshaft shift angle, desired value. At idle speed with the engine at operating temperature, check that the camshaft shift angle and the desired value for the camshaft shift angle correspond with an accuracy of approximately 8° CA. Rev the engine a few times and check again at idle speed that the values correspond. The difference between the values can be read off in the lower digital display.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S28067827932012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO HIGH

See SIGNAL TOO LOW

1. Start the engine and run it to normal operating temperature. Read off the camshaft shift angle and the camshaft shift angle, desired value. Check that the camshaft's gear angle and reference value for the camshaft's gear angle correspond with an accuracy of about 5 degrees CA when idling and when the engine is warm. Rev the engine a few times and check again at idle speed that the values correspond. The difference between the values can be read off in the lower digital display. The fault is permanent if the values do not correspond. The fault is intermittent if the values correspond.

1. Continue Refer to «CHECKING COMPONENTS»(ref-466669-S08966398462012042500000)

Check the engine oil level and quality. Check for contaminants in particular.

Remove the camshaft reset valve. Check the oil ducts for the cylinder head for the camshaft reset valve. Check for blockages and dirt.

HINT: Faults may result from dirt in the camshaft reset valve. Try cleaning the valve.

Try a new camshaft reset valve if the above remedy does not solve the fault.

HINT: The fault may also have been caused by an internal fault in the variable valve timing unit. The variable valve timing unit may be damaged if the above fault-tracing and corrective action do not remedy the fault.

Remedy as necessary.

Other information

1. see «CRANKSHAFT POSITION SENSOR (CKP)»(ref-466594-S40916949102012042500000)
2. see «VVT SOLENOID»(ref-466659-S08868277172012042500000)

1. Continue Refer to «VERIFICATION»(ref-466669-S09317163582012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine and run it to normal operating temperature. Read off the camshaft shift angle and the camshaft shift angle, desired value. At idle speed with the engine at operating temperature, check that the camshaft shift angle and the desired value for the camshaft shift angle correspond with an accuracy of approximately 8° CA. Rev the engine a few times and check again at idle speed that the values correspond. The difference between the values can be read off in the lower digital display.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S12154837352012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine and run it to normal operating temperature. Read off the camshaft shift angle and the camshaft shift angle, desired value. Check that the camshaft's gear angle and reference value for the camshaft's gear angle correspond with an accuracy of about 5 degrees CA when idling and when the engine is warm. Rev the engine a few times and check again at idle speed that the values correspond. The difference between the values can be read off in the lower digital display. The fault is permanent if the values do not correspond. The fault is intermittent if the values correspond.

1. Continue Refer to «CHECKING COMPONENTS»(ref-466669-S13020363222012042500000)

Check the engine oil level and quality. Check for contaminants in particular.

Remove the camshaft reset valve. Check the oil ducts for the cylinder head for the camshaft reset valve. Check for blockages and dirt.

HINT: Faults may result from dirt in the camshaft reset valve. Try cleaning the valve.

Try a new camshaft reset valve if the above remedy does not solve the fault.

HINT: The fault may also have been caused by an internal fault in the variable valve timing unit. The variable valve timing unit may be damaged if the above fault-tracing and corrective action do not remedy the fault.

Remedy as necessary.

Other information

1. see «CRANKSHAFT POSITION SENSOR (CKP)»(ref-466594-S40916949102012042500000)
2. see «VVT SOLENOID»(ref-466659-S08868277172012042500000)

1. Continue Refer to «VERIFICATION»(ref-466669-S15240923782012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine and run it to normal operating temperature. Read off the camshaft shift angle and the camshaft shift angle, desired value. At idle speed with the engine at operating temperature, check that the camshaft shift angle and the desired value for the camshaft shift angle correspond with an accuracy of approximately 8° CA. Rev the engine a few times and check again at idle speed that the values correspond. The difference between the values can be read off in the lower digital display.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S24692106942012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CHECKING INTAKE SYSTEM

Check the intake system between the turbocharger (TC) and the throttle unit. Check for air leakage.

Check particularly that the boost pressure sensor is correctly installed and has not come loose.

Check that the non-return valve to the crankcase ventilation is positioned correctly and is not damaged.

Try a new boost pressure sensor if no fault is found during the above fault-tracing.

Other information

1. see «AIR LEAKS IN THE INTAKE SYSTEM, CHECKING»(ref-479169-S42610968362012061200000)
2. see «TEMPERATURE AND MANIFOLD ABSOLUTE PRESSURE SENSOR (MAPT)»(ref-466594-S34563894352012042500000)
3. see «NON-RETURN VALVE, CRANKCASE VENTILATION»(ref-466651-S08385276522012042500000)

1. Continue Refer to «VERIFICATION»(ref-466669-S36908862552012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Test drive the vehicle on the road. Ensure that high boost pressure is reached (high load) so that the engine control module (ECM) can run the diagnostic.
4. Connect VCT2000 (or appropriate scan tool) to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the diagnostic is not complete after the test drive, further test driving is required. If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S31282741862012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL TOO HIGH / SIGNAL TOO LOW

See SIGNAL TOO HIGH / SIGNAL TOO LOW

See SIGNAL TOO HIGH / SIGNAL TOO LOW

See SIGNAL TOO HIGH / SIGNAL TOO LOW

ADJUSTING THE CAMSHAFT SETTING

Adjust the camshaft settings.

Check to, see if any symptoms reported by the customer are still present.

Other information

1. see «TIMING BELT»(ref-466659-S40084495992012042500000)

For variable valve timing control to operate correctly the engine oil must be at the correct level, of the correct quality and not contaminated.

Check the engine oil level and quality. Check for contaminants in particular.

The normal value for adaption is 27°CA (+/-8°CA). If the value is too high when the engine is at operating temperature, the cause of the fault is probably one of the following

1. Camshaft belt incorrectly seated
2. Incorrect basic setting for the timing belt
3. Faulty camshaft reset valve (the slide in the valve has stuck).

HINT: First try adjusting the basic setting of the camshaft. Test drive the car. Then read off the camshaft discrepancy at idle speed with the engine at operating temperature. The value must be between -8° and +8°. If the value is incorrect when the basic setting of the camshaft is correct, try cleaning the camshaft reset valve.

Note. The camshafts must be adjusted using the adjustment tool for the camshafts and crankshaft in the prescribed manner.

Try a new camshaft reset valve if the above fault-tracing does not remedy the fault.

Remedy as necessary.

HINT: The fault can also be caused by a damaged variable valve timing unit. The variable valve timing unit may be damaged if the above fault-tracing and corrective action do not remedy the fault.

Other information

1. see «SIGNAL SPECIFICATION»(ref-466592-S15475582172012042500000)
2. see «CRANKSHAFT POSITION SENSOR (CKP)»(ref-466594-S40916949102012042500000)

1. Continue Refer to «VERIFICATION»(ref-466669-S39587449872012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

HINT: In order to verify this diagnostic trouble code (DTC), adaptation of the camshaft must be completed. Adaptation of the camshaft is carried out by the engine control module (ECM) when the catalytic converter is warmed up, during engine braking (fuel shut-off) above 1300 RPM for at least 10 seconds.

1. Start and run the engine for at least 30 seconds
2. Drive the car on the road. Ensure that the conditions for adaptation are met: engine braking (fuel shut-off) above 1300 RPM for at least 10 sec. The conditions can be satisfied for example by driving the car with a high engine load up to approximately 90 km/h and then releasing the accelerator pedal for 10 seconds. Repeat the schedule to ensure that the adaptation is carried out. NOTE: In order for the adaptation to be carried out, the accelerator pedal must not be touched during engine braking.
3. Read off the camshaft adaptation after driving. Check that the value for the camshaft adaptation is correct. The normal value is 27°CA (+/-8°CA).

Is the adaptation correct?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S12138312482012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

For variable valve timing control to operate correctly the engine oil must be at the correct level, of the correct quality and not contaminated.

Check the engine oil level and quality. Check for contaminants in particular.

The normal value for adaption is 27°CA (+/-8°CA). If the value is too high when the engine is at operating temperature, the cause of the fault is probably one of the following

1. Camshaft belt incorrectly seated
2. Incorrect basic setting for the timing belt
3. Faulty camshaft reset valve (the slide in the valve has stuck).

HINT: First try adjusting the basic setting of the camshaft. Test drive the car. Then read off the camshaft discrepancy at idle speed with the engine at operating temperature. The value must be between -8° and +8°. If the value is incorrect when the basic setting of the camshaft is correct, try cleaning the camshaft reset valve.

Note. The camshafts must be adjusted using the adjustment tool for the camshafts and crankshaft in the prescribed manner.

Try a new camshaft reset valve if the above fault-tracing does not remedy the fault.

Remedy as necessary.

HINT: The fault can also be caused by a damaged variable valve timing unit. The variable valve timing unit may be damaged if the above fault-tracing and corrective action do not remedy the fault.

Other information

1. see «SIGNAL SPECIFICATION»(ref-466592-S26583508152012042500000)
2. see «CRANKSHAFT POSITION SENSOR (CKP)»(ref-466594-S40916949102012042500000)

1. Continue Refer to «VERIFICATION»(ref-466669-S18061189072012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

HINT: In order to verify this diagnostic trouble code (DTC), adaptation of the camshaft must be completed. Adaptation of the camshaft is carried out by the engine control module (ECM) when the catalytic converter is warmed up, during engine braking (fuel shut-off) above 1300 RPM for at least 10 seconds.

1. Start and run the engine for at least 30 seconds
2. Drive the car on the road. Ensure that the conditions for adaptation are met: engine braking (fuel shut-off) above 1300 RPM for at least 10 sec. The conditions can be satisfied for example by driving the car with a high engine load up to approximately 90 km/h and then releasing the accelerator pedal for 10 seconds. Repeat the schedule to ensure that the adaptation is carried out. NOTE: In order for the adaptation to be carried out, the accelerator pedal must not be touched during engine braking.
3. Read off the camshaft adaptation after driving. Check that the value for the camshaft adaptation is correct. The normal value is 27°CA (+/-8°CA).

Is the adaptation correct?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S04710543122012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

For variable valve timing control to operate correctly the engine oil must be at the correct level, of the correct quality and not contaminated.

Check the engine oil level and quality. Check for contaminants in particular.

Adjust the camshaft settings.

Note. The camshafts must be adjusted using the adjustment tool for the camshafts and crankshaft in the prescribed manner.

Other information

1. see «SIGNAL SPECIFICATION»(ref-466592-S15475582172012042500000)

1. Continue Refer to «VERIFICATION»(ref-466669-S13107221012012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

HINT: In order to verify this diagnostic trouble code (DTC), adaptation of the camshaft must be completed. Adaptation of the camshaft is carried out by the engine control module (ECM) when the catalytic converter is warmed up, during engine braking (fuel shut-off) above 1300 RPM for at least 10 seconds.

1. Start and run the engine for at least 30 seconds
2. Drive the car on the road. Ensure that the conditions for adaptation are met: engine braking (fuel shut-off) above 1300 RPM for at least 10 sec. The conditions can be satisfied for example by driving the car with a high engine load up to approximately 90 km/h and then releasing the accelerator pedal for 10 seconds. Repeat the schedule to ensure that the adaptation is carried out. NOTE: In order for the adaptation to be carried out, the accelerator pedal must not be touched during engine braking.
3. Read off the camshaft adaptation after driving. Check that the value for the camshaft adaptation is correct. The normal value is 27°CA (+/-8°CA).

Is the adaptation correct?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S06020142642012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

For variable valve timing control to operate correctly the engine oil must be at the correct level, of the correct quality and not contaminated.

Check the engine oil level and quality. Check for contaminants in particular.

Adjust the camshaft settings.

Note. The camshafts must be adjusted using the adjustment tool for the camshafts and crankshaft in the prescribed manner.

Other information

1. see «SIGNAL SPECIFICATION»(ref-466592-S26583508152012042500000)

1. Continue Refer to «VERIFICATION»(ref-466669-S31216432462012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

HINT: In order to verify this diagnostic trouble code (DTC), adaptation of the camshaft must be completed. Adaptation of the camshaft is carried out by the engine control module (ECM) when the catalytic converter is warmed up, during engine braking (fuel shut-off) above 1300 RPM for at least 10 seconds.

1. Start and run the engine for at least 30 seconds
2. Drive the car on the road. Ensure that the conditions for adaptation are met: engine braking (fuel shut-off) above 1300 RPM for at least 10 sec. The conditions can be satisfied for example by driving the car with a high engine load up to approximately 90 km/h and then releasing the accelerator pedal for 10 seconds. Repeat the schedule to ensure that the adaptation is carried out. NOTE: In order for the adaptation to be carried out, the accelerator pedal must not be touched during engine braking.
3. Read off the camshaft adaptation after driving. Check that the value for the camshaft adaptation is correct. The normal value is 27°CA (+/-8°CA).

Is the adaptation correct?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S01282353072012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 183

1. Ignition off
2. Reinstall the connectors, components etc. Check that the engine can be started.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S34829574412012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc. Check that the engine can be started.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S38218199972012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc. Check that the starter motor is not running when the ignition switch is in position 2 (ignition position). Check that the starter motor is running when the ignition switch is in position 3 (starting position).

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S18254562682012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc. Check that the starter motor is not running when the ignition switch is in position 2 (ignition position). Check that the starter motor is running when the ignition switch is in position 3 (starting position).

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S16088935162012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc. Check that the starter motor is not running when the ignition switch is in position 2 (ignition position). Check that the starter motor is running when the ignition switch is in position 3 (starting position).

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S39905619242012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc. Check that the starter motor is not running when the ignition switch is in position 2 (ignition position). Check that the starter motor is running when the ignition switch is in position 3 (starting position).

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S19307747072012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine
2. Read off the engine coolant temperature (ECT)
3. Start the quick test for adaptation of the camshaft when the engine coolant temperature is between 60 °C and 100 °C
4. Increase the engine speed to at least 2000 RPM
5. Check that the quick test starts. The quick test has started when "Adaptation camshaft" changes status from "Not in operation" to "In operation". HINT: In some cases the quick test can be carried out extremely quickly. Check the status in the graphic display if in doubt.
6. The quick test has been carried out when "Adaptation camshaft" is back in "Not in operation".
7. The engine must be at idle speed when the quick test is carried out. Check the value of the camshaft discrepancy (adaptation camshaft) when the quick test has been carried out. The value must be between -8° and +8°. If the value is correct (between -8° and +8°) the fault is intermittent. If the value is incorrect (lower than -8° or higher than +8°), the fault is permanent.

Is the value correct?

1. YES Refer to «INTERMITTENT FAULT»(ref-466669-S37784974502012042500000)
2. NO Refer to «CHECKING COMPONENTS»(ref-466669-S06783341122012042500000)

For variable valve timing control to operate correctly the engine oil must be at the correct level, of the correct quality and not contaminated.

Check the engine oil level and quality. Check for contaminants in particular.

If the value is too high (higher than +8°) when the engine is at operating temperature, the cause of the fault is probably one of the following

1. Camshaft belt incorrectly seated
2. Incorrect basic setting for the timing belt
3. Faulty camshaft reset valve (the slide in the valve has stuck).

HINT: First try adjusting the basic setting of the camshaft. Then read off the camshaft discrepancy at idle speed after carrying out the quick test. The value must be between -8° and +8°. If the value is incorrect when the basic setting of the camshaft is correct, try cleaning the camshaft reset valve.

Try a new camshaft reset valve if the above fault-tracing does not solve the fault.

Remedy as necessary.

HINT: The fault can also be caused by a damaged variable valve timing unit. The variable valve timing unit may be damaged if the above fault-tracing and corrective action do not remedy the fault.

Other information

1. To adjust the camshaft position (CMP), see «VVT UNIT»(ref-466659-S10981923982012042500000)
2. see «VVT SOLENOID»(ref-466659-S08868277172012042500000)

1. Continue Refer to «VERIFICATION»(ref-466669-S30583513772012042500000)

INTERMITTENT FAULT

If the diagnostic trouble code (DTC) for this fault is stored but the value is correct, the fault is intermittent. The cause of the intermittent fault is probably a damaged camshaft reset valve.

see VVT SOLENOID

1. Continue Refer to «VERIFICATION»(ref-466669-S30583513772012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine
2. Read off the engine coolant temperature (ECT)
3. Start the quick test for adaptation of the camshaft when the engine coolant temperature is between 60 °C and 100 °C.
4. Increase the engine speed to at least 2000 RPM
5. Check that the quick test starts. The quick test has started when "Adaptation camshaft" changes status from "Not in operation" to "In operation". HINT: In some cases the quick test can be carried out extremely quickly. Check the status in the graphic display if in doubt.
6. The quick test has been carried out when "Adaptation camshaft" is back in "Not in operation".
7. The engine must be at idle speed when the quick test is carried out. Check the value of the camshaft discrepancy (adaptation camshaft) when the quick test has been carried out. The value must be between -8° and +8°.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S07690126702012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO HIGH

1. Start the engine
2. Read off the engine coolant temperature (ECT)
3. Start the quick test for adaptation of the camshaft when the engine coolant temperature is between 60 °C and 100 °C
4. Increase the engine speed to at least 2000 RPM
5. Check that the quick test starts. The quick test has started when "Adaptation camshaft" changes status from "Not in operation" to "In operation". HINT: In some cases the quick test can be carried out extremely quickly. Check the status in the graphic display if in doubt.
6. The quick test has been carried out when "Adaptation camshaft" is back in "Not in operation".
7. The engine must be at idle speed when the quick test is carried out. Check the value of the camshaft discrepancy (adaptation camshaft) when the quick test has been carried out. The value must be between -8° and +8°. If the value is correct (between -8° and +8°) the fault is intermittent. If the value is incorrect (lower than -8° or higher than +8°), the fault is permanent.

1. Continue Refer to «CHECKING COMPONENTS»(ref-466669-S32776644572012042500000)

For variable valve timing control to operate correctly the engine oil must be at the correct level, of the correct quality and not contaminated.

Check the engine oil level and quality. Check for contaminants in particular.

Adjust the camshaft settings. See: VVT UNIT .

Scheme 184

1. Continue Refer to «VERIFICATION»(ref-466669-S32741350082012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine
2. Read off the engine coolant temperature (ECT)
3. Start the quick test for adaptation of the camshaft when the engine coolant temperature is between 60 °C and 100 °C.
4. Increase the engine speed to at least 2000 RPM
5. Check that the quick test starts. The quick test has started when "Adaptation camshaft" changes status from "Not in operation" to "In operation". HINT: In some cases the quick test can be carried out extremely quickly. Check the status in the graphic display if in doubt.
6. The quick test has been carried out when "Adaptation camshaft" is back in "Not in operation".
7. The engine must be at idle speed when the quick test is carried out. Check the value of the camshaft discrepancy (adaptation camshaft) when the quick test has been carried out. The value must be between -8° and +8°.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S08945965772012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO LOW

1. Start the engine
2. Read off the engine coolant temperature (ECT)
3. Start the quick test for adaptation of the camshaft when the engine coolant temperature is between 60 °C and 100 °C
4. Increase the engine speed to at least 2000 RPM
5. Check that the quick test starts. The quick test has started when "Adaptation camshaft" changes status from "Not in operation" to "In operation". HINT: In some cases the quick test can be carried out extremely quickly. Check the status in the graphic display if in doubt.
6. The quick test has been carried out when "Adaptation camshaft" is back in "Not in operation".
7. The engine must be at idle speed when the quick test is carried out. Check the value of the camshaft discrepancy (adaptation camshaft) when the quick test has been carried out. The value must be between -8° and +8°. If the value is correct (between -8° and +8°) the fault is intermittent. If the value is incorrect (lower than -8° or higher than +8°), the fault is permanent.

Is the value correct?

1. YES Refer to «INTERMITTENT FAULT»(ref-466669-S24990873602012042500000)
2. NO Refer to «CHECKING COMPONENTS»(ref-466669-S25093521532012042500000)

For variable valve timing control to operate correctly the engine oil must be at the correct level, of the correct quality and not contaminated.

Check the engine oil level and quality. Check for contaminants in particular.

If the value is too high (higher than +8°) when the engine is at operating temperature, the cause of the fault is probably one of the following

1. Camshaft belt incorrectly seated
2. Incorrect basic setting for the timing belt
3. Faulty camshaft reset valve (the slide in the valve has stuck).

HINT: First try adjusting the basic setting of the camshaft. Then read off the camshaft discrepancy at idle speed after carrying out the quick test. The value must be between -8° and +8°. If the value is incorrect when the basic setting of the camshaft is correct, try cleaning the camshaft reset valve.

Try a new camshaft reset valve if the above fault-tracing does not solve the fault.

Remedy as necessary.

HINT: The fault can also be caused by a damaged variable valve timing unit. The variable valve timing unit may be damaged if the above fault-tracing and corrective action do not remedy the fault.

Other information

1. To adjust the camshaft position (CMP), see «VVT UNIT»(ref-466659-S10981923982012042500000)
2. see «VVT SOLENOID»(ref-466659-S08868277172012042500000)

1. Continue Refer to «VERIFICATION»(ref-466669-S29001482122012042500000)

If the diagnostic trouble code (DTC) for this fault is stored but the value is correct, the fault is intermittent. The cause of the intermittent fault is probably a damaged camshaft reset valve.

see VVT SOLENOID

1. Continue Refer to «VERIFICATION»(ref-466669-S29001482122012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine
2. Read off the engine coolant temperature (ECT)
3. Start the quick test for adaptation of the camshaft when the engine coolant temperature is between 60 °C and 100 °C
4. Increase the engine speed to at least 2000 RPM
5. Check that the quick test starts. The quick test has started when "Adaptation camshaft" changes status from "Not in operation" to "In operation". HINT: In some cases the quick test can be carried out extremely quickly. Check the status in the graphic display if in doubt.
6. The quick test has been carried out when "Adaptation camshaft" is back in "Not in operation".
7. The engine must be at idle speed when the quick test is carried out. Check the value of the camshaft discrepancy (adaptation camshaft) when the quick test has been carried out. The value must be between -8° and +8°.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S12226812822012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO HIGH

1. Start the engine
2. Read off the engine coolant temperature (ECT)
3. Start the quick test for adaptation of the camshaft when the engine coolant temperature is between 60 °C and 100 °C
4. Increase the engine speed to at least 2000 RPM
5. Check that the quick test starts. The quick test has started when "Adaptation camshaft" changes status from "Not in operation" to "In operation". HINT: In some cases the quick test can be carried out extremely quickly. Check the status in the graphic display if in doubt.
6. The quick test has been carried out when "Adaptation camshaft" is back in "Not in operation".
7. The engine must be at idle speed when the quick test is carried out. Check the value of the camshaft discrepancy (adaptation camshaft) when the quick test has been carried out. The value must be between -8° and +8°. If the value is correct (between -8° and +8°) the fault is intermittent. If the value is incorrect (lower than -8° or higher than +8°), the fault is permanent.

1. Continue Refer to «CHECKING COMPONENTS»(ref-466669-S30592241902012042500000)

For variable valve timing control to operate correctly the engine oil must be at the correct level, of the correct quality and not contaminated.

Check the engine oil level and quality. Check for contaminants in particular.

Adjust the camshaft settings.

Other information

1. To adjust the camshaft position (CMP), see «VVT UNIT»(ref-466659-S10981923982012042500000) .

1. Continue Refer to «VERIFICATION»(ref-466669-S02628902152012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine
2. Read off the engine coolant temperature (ECT)
3. Start the quick test for adaptation of the camshaft when the engine coolant temperature is between 60 °C and 100 °C
4. Increase the engine speed to at least 2000 RPM
5. Check that the quick test starts. The quick test has started when "Adaptation camshaft" changes status from "Not in operation" to "In operation". HINT: In some cases the quick test can be carried out extremely quickly. Check the status in the graphic display if in doubt.
6. The quick test has been carried out when "Adaptation camshaft" is back in "Not in operation".
7. The engine must be at idle speed when the quick test is carried out. Check the value of the camshaft discrepancy (adaptation camshaft) when the quick test has been carried out. The value must be between -8° and +8°.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S17884190942012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO LOW

Remove the camshaft reset valve. Check the oil ducts for the cylinder head for the camshaft reset valve (exhaust) for blockages and dirt.

Remedy as necessary.

Try a new camshaft reset valve (exhaust) if the above remedy does not solve the fault.

HINT: The fault can also be caused by a damaged variable valve timing unit. The variable valve timing unit may be damaged if the above fault-tracing and corrective action do not remedy the fault.

Other information

1. see «VVT SOLENOID»(ref-466659-S08868277172012042500000)
2. see «VVT UNIT»(ref-466659-S10981923982012042500000)

1. Continue Refer to «VERIFICATION»(ref-466669-S21260461972012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Start the engine and let it idle for at least 10 seconds
4. Switch off the engine
5. Start the engine again and let it idle for at least 10 seconds. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S23437597242012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Remove the camshaft reset valve. Check the oil ducts for the cylinder head for the camshaft reset valve (intake) for blockages and dirt.

Remedy as necessary.

Try a new camshaft reset valve (intake) if the above remedy does not solve the fault.

HINT: The fault can also be caused by a damaged variable valve timing unit. The variable valve timing unit may be damaged if the above fault-tracing and corrective action do not remedy the fault.

Other information

1. see «VVT SOLENOID»(ref-466659-S08868277172012042500000)
2. see «VVT UNIT»(ref-466659-S10981923982012042500000)

1. Continue Refer to «VERIFICATION»(ref-466669-S05858218662012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Start the engine and let it idle for at least 10 seconds
4. Switch off the engine
5. Start the engine again and let it idle for at least 10 seconds. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S30945757822012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

The immobilizer function is integrated in the central electronic module (CEM).

This diagnostic trouble code (DTC) indicates that the immobilizer code does not match between the engine control module (ECM) and the central electronic module (CEM). This may be because

1. The immobilizer code in the engine control module (ECM) is incorrect i. e. the code does not match that stored in the central electronic module (CEM)
2. The immobilizer code in the central electronic module (CEM) is incorrect.
3. The engine control module (ECM) is damaged.

Note. A programmed engine control module (ECM) or central electronic module (CEM) cannot be moved from one vehicle to another.

HINT: Reading diagnostic trouble codes (DTCs) in the central electronic module (CEM)

Other information

1. see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000) (2005), or «SIGNAL SPECIFICATION»(ref-466592-S15491428272012042500000) (2006-2007)
2. see «ENGINE CONTROL MODULE (ECM)»(ref-466594-S40317974462012042500000)

1. Continue Refer to «VERIFICATION»(ref-466669-S09437005722012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall connectors, components etc.
3. Start the engine.

Did the engine start?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S15193970782012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See FAULTY SIGNAL

see FAULT-TRACING INFORMATION

The immobilizer function is integrated in the central electronic module (CEM).

This diagnostic trouble code (DTC) may be due to missing CAN communication. If there is a diagnostic trouble code (DTC) stored in the central electronic module (CEM) fault trace accordingly.

Note. An unprogrammed central electronic module (CEM) does not have a code for the immobilizer, which can result in this diagnostic trouble code (DTC) being stored.

If no diagnostic trouble codes (DTCs) are stored in the central electronic module (CEM), try a new central electronic module (CEM).

Other information

1. see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000) (2005), or «SIGNAL SPECIFICATION»(ref-466592-S15491428272012042500000) (2006-2007)
2. see «ENGINE CONTROL MODULE (ECM)»(ref-466594-S40317974462012042500000)
3. see «CONTROL MODULE RELAY BOX PASSENGER COMPARTMENT»(ref-466606-S26379830782012042500000)

1. Continue Refer to «INFORMATION»(ref-466669-S18454856782012042500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

See SIGNAL MISSING

The immobilizer function is integrated in the central electronic module (CEM).

The diagnostic trouble code (DTC) indicates that the code for the immobilizer is missing in the engine control module (ECM). This may be because

1. The engine control module (ECM) is not programmed and has no immobilizer code
2. The engine control module (ECM) is damaged.

HINT: Try programming the engine control module (ECM).

Other information

1. see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000) (2005), or «SIGNAL SPECIFICATION»(ref-466592-S15491428272012042500000) (2006-2007)
2. see «ENGINE CONTROL MODULE (ECM)»(ref-466594-S40317974462012042500000)

1. Continue Refer to «VERIFICATION»(ref-466669-S38273075522012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall connectors, components etc.
3. Start the engine.

Did the engine start?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S32403551172012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO HIGH

The immobilizer function is integrated in the central electronic module (CEM).

The diagnostic trouble code (DTC) indicates that there is an internal fault in the engine control module (ECM) that is preventing the immobilizer function from working This can be caused by a damaged engine control module (ECM).

HINT: Try replacing the engine control module (ECM).

Other information

1. see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000) (2005), or «SIGNAL SPECIFICATION»(ref-466592-S15491428272012042500000) (2006-2007)
2. see «ENGINE CONTROL MODULE (ECM)»(ref-466594-S40317974462012042500000)

1. Continue Refer to «VERIFICATION»(ref-466669-S38693837982012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall connectors, components etc.
3. Start the engine.

Did the engine start?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S19959531012012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO LOW

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

1. Ignition on, wait at least 15 seconds to carry out the diagnostic. Read off the diagnostic trouble code (DTC) status. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".

1. Continue Refer to «REPLACING THE COMPONENT»(ref-466669-S21163711592012042500000)

REPLACING THE COMPONENT

The engine control module (ECM) has registered an internal fault.

If the fault is intermittent, it has been registered previously but is no longer present. Intermittent faults can be caused by interference at start up of the engine control module (ECM) or may be a different type of fault which occurs on different occasions. The fault is evaluated depending on how it occurs. Replace the engine control module (ECM) if the fault recurs.

Replace the engine control module (ECM) in the event of a permanent fault.

Remedy as necessary.

Other information

1. see «ENGINE CONTROL MODULE (ECM)»(ref-466594-S40317974462012042500000)

1. Continue Refer to «INFORMATION»(ref-466669-S20505097692012042500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

This diagnostic trouble code (DTC) indicates that the immobilizer code does not match between the engine control module (ECM) and the central electronic module (CEM). Or that there is a fault in the control area network (CAN) communication between the engine control module (ECM) and the central electrical module (CEM).

This may be because

1. The engine control module (ECM) is not programmed or the immobilizer code in the engine control module (ECM) is incorrect i. e. the code does not match the code stored in the central electronic module (CEM)
2. The central electronic module (CEM) is not programmed or the immobilizer code in the engine control module (ECM) is incorrect i. e. the code does not match the code stored in the engine control module (ECM)
3. Open-circuit in the CAN communication between the central electronic module (CEM) and the engine control module (ECM)
4. Programmed engine control module (ECM) or central electronic module (CEM) has been moved from one car to another.

HINT: Reading diagnostic trouble codes (DTCs) in the central electronic module (CEM).

1. Continue Refer to «VERIFICATION»(ref-466669-S31233041742012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall connectors, components etc.
3. Start the engine.

Did the engine start?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S37283659642012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

The diagnostic trouble code (DTC) indicates that the programmed hardware series number in the engine control module (ECM) does not correspond to the relevant hardware series number in the brake control module (BCM).

This may be because

1. The engine control module (ECM) or brake control module (BCM) has been replaced, resulting in the hardware series numbers not corresponding.

HINT: Read off diagnostic trouble codes (DTCs) in the brake control module (BCM).

1. Continue Refer to «VERIFICATION»(ref-466669-S14694905802012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall connectors, components etc.
3. Start the engine.

Did the engine start?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S08811728762012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

No fault-tracing has been developed for this diagnostic trouble code (DTC). The diagnostic trouble code (DTC) for this fault is stored first in the brake control module (BCM), then in the engine control module (ECM). This diagnostic trouble code (DTC) can not be erased before the diagnostic trouble code (DTC) in the brake control module (BCM) has been remedied and erased.

First read off the diagnostic trouble codes (DTCs) in the brake control module (BCM). Fault-trace and remedy as necessary. This diagnostic trouble code (DTC) can then be erased.

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Gear selector in position P or N
4. Ignition on. Read off the values for the gear selector position. Directly connected signals and signals via CAN communication must correspond to each other and to the selected gear position when the gear selector is in P or N.

Are the values correct?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S16095711032012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL MISSING

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine
4. Read off the battery voltage. Check that the battery voltage is not too high or too low.

Is the battery voltage correct?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S32832485542012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine
4. Read off the battery voltage. Check that the battery voltage is not too high or too low.

Is the battery voltage correct?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S31630300472012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

See SIGNAL TOO HIGH

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

See SIGNAL TOO LOW

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine
4. Read off the battery voltage. Check that the battery voltage is not too high or too low.

Is the battery voltage correct?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S22103013742012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine
4. Read off the battery voltage. Check that the battery voltage is not too high or too low.

Is the battery voltage correct?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S32417130012012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

See FAULT-TRACING

SIGNAL TOO HIGH/SIGNAL TOO LOW/SIGNAL MISSING

See SIGNAL TOO HIGH/SIGNAL TOO LOW/SIGNAL MISSING

See FAULT-TRACING

See FAULT-TRACING

See SIGNAL TOO HIGH/SIGNAL TOO LOW/SIGNAL MISSING

See FAULT-TRACING

See FAULT-TRACING

see INTERNAL FAULT

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc. Check that the starter motor is running when the ignition switch is in position 3 (starting position). Leave the ignition switched off for at least 10 minutes. Then check that the diagnostic trouble code (DTC) has not recurred.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S04361057482012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc. Check that the starter motor is running when the ignition switch is in position 3 (starting position). Leave the ignition switched off for at least 10 minutes. Then check that the diagnostic trouble code (DTC) has not recurred.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S11145001702012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CHECKING BATTERY VOLTAGE

1. Start the engine
2. Read off the battery voltage and the target value of the generator (GEN) charge voltage
3. Load the battery by switching on high current consumers such as high beam and the blower fan etc. Check that the battery voltage is approximately 13.5 -14.9 V. Check that the battery voltage is approximately the same as the target value for the generator (GEN) voltage. Try different engine speeds (RPM). The fault is permanent if the function is incorrect. If the voltage is correct, this is an indication that the fault was present previously but is not active at the moment, i. e. an intermittent fault. HINT: This diagnostic trouble code can be stored if a battery charger with too high charge voltage has been connected.

1. Continue Refer to «CHECKING THE COMPONENT»(ref-466669-S34514953572012042500000)

Scheme 185

Scheme 186

1. Ignition off. Check the generator (GEN) brushes (carbon). If the brushes are worn, replace the alternator control module (ACM). Check that the brushes can move in the regulator housing. The brushes are lightly sprung. At the same time, check the slip rings. Replace the generator (GEN) if they are worn out. If the carbon brushes and slip rings appear to be OK, try a new alternator control module (ACM) (charge regulator). If this does not help, try a new generator (GEN). HINT: Another test to check the alternator's function is to perform Quicktest of alternator function using VIDA or appropriate scan tool. Remedy as necessary. Other information: see «CHECKING WIRING AND TERMINALS»(ref-466589-S05251896242012042500000)

1. Continue Refer to «VERIFICATION»(ref-466669-S15098109842012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Start the engine
4. Read off the battery voltage and the target value of the generator (GEN) charge voltage
5. Load the battery by switching on high current consumers such as high beam and the blower fan etc. Check that the battery voltage is approximately 13.5-14.9 V. Check that the battery voltage is approximately the same as the target value for the generator (GEN) charge. Try different engine speeds (RPM).

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S10284900262012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL TOO HIGH/FAULTY SIGNAL

See SIGNAL TOO HIGH/FAULTY SIGNAL

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine. Read off the battery voltage from the system relay. Check whether the battery voltage is too high or too low.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S19194053382012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO LOW

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Read off the battery voltage. Check that the battery voltage is correct.

Is the value correct?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S39538604212012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Read off the battery voltage. Check that the battery voltage is correct.

Is the value correct?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466669-S32036042232012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See FAULT-TRACING

FAULTY SIGNAL OR SIGNAL MISSING

See FAULTY SIGNAL OR SIGNAL MISSING

See FAULT-TRACING

1. Ignition off. Check the auxiliaries belt and belt tensioner. Check for damage. Check the function of the generator (GEN) freewheel. In an undamaged freewheel, the generator rotor shaft can only rotate freely in one direction but not the other. Check that the air ducts for the generator (GEN) are not blocked. HINT: Another test to check the alternator's function is to perform Quicktest of alternator function using VIDA or appropriate scan tool. HINT: If the diagnostic trouble code is stored again after driving, replace the generator (GEN). Remedy as necessary.

Was a fault detected?

1. YES Refer to «INFORMATION»(ref-466669-S38038448832012042500000)
2. NO FAULT NOT FOUND: Troubleshooting has been completed.

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

FAULTY

See FAULTY

REPLACING THE CONTROL MODULE

Try a new alternator control module (ACM).

Remedy as necessary.

1. Continue Refer to «INFORMATION»(ref-466669-S02653120982012042500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.
