Engine Control Module (ECM) Diagnostic Trouble Codes - 2 of 9: Diagnosis Volvo V50 I рестайлинг

Testing & Diagnostics 10 illustrations ~6352 words

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-220A

Condition

Scheme 35

Scheme 35: DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-220A
Scheme 35: DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-220A

The engine control module (ECM) measures the voltage difference between the rear heated oxygen sensor (HO2S) maximum and minimum values. The difference must be greater than 0.3 V.

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that these parameters are not reached after approximately 5 minutes and the accumulated or actual probe preheating has reached its parameter.

The diagnostic trouble code (DTC) can be diagnosed approximately 5 minutes after starting (if probe preheating is active and at least one fuel shut-off has been made).

Substitute Value

  1. Rear heated oxygen sensor (HO2S) control shut off.

Possible Source

  1. Contact resistance and/or oxidation in the terminals
  2. Damaged rear heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-220B

Condition

The engine control module (ECM) continuously detects the rear heated oxygen sensor (HO2S) voltage. The diagnostic trouble code (DTC) is stored if the engine control module (ECM) detects that the voltage exceeds or is below a certain value and it is interpreted as a fault.

The diagnostic trouble code (DTC) can be diagnosed after approximately 3-5 minutes when the engine is running.

Substitute Value

  1. Rear heated oxygen sensor (HO2S) control is disabled.

Possible Source

Signal too high

  1. Short-circuit to supply voltage in the signal cable.

Signal too low

  1. Contact resistance and oxidation in the terminals
  2. Short-circuit to ground in the signal cable
  3. Open-circuit in the signal cable
  4. Damaged rear heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

Scheme 36

Scheme 36: CHECKING THE STATUS
Scheme 36: CHECKING THE STATUS
  1. Start the engine. Allow the engine to idle for approximately 3-5 minutes to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466654-S34404894882012042500000)

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-220B

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION

Condition

Engine control module (ECM) checks the function of the rear heated oxygen sensor by monitoring how fast the sensor reacts when the system switches from rich to lean in case of a fuel shut-off.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Voltage across rear heated oxygen sensor drops too slowly.
  2. Slow voltage-drop in case of more than 10 subsequent fuel shut-offs during the same driving cycle.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Hot engine.
  2. Vehicle speed 70-90 km/h.
  3. Fuel shut-off.

Note. The control module can only detect the fault once the test has been started and the diagnostic trouble code (DTC) is stored when the conditions are met.

Substitute Value

  1. None.

Possible Source

  1. Contact resistance, oxidation or poor contact in connections.
  2. Damaged rear heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-220F

Condition

Scheme 37

Scheme 37: DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-220F
Scheme 37: DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-220F

Note. This diagnostic trouble code (DTC) is only used for development purposes and is not to be fault-traced. This diagnostic trouble code (DTC) can be ignored and erased with no additional remedial action.

The engine control module (ECM) compares the front and rear heated oxygen sensor (HO2S) adaptation values. In order to check front oxygen sensor regulation, check the engine control module (ECM) output signals from the rear oxygen sensor. If the control system for the heated oxygen sensors is working correctly, the control signals from the rear oxygen sensor must be within a predefined statistical interval.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. The measured signals from the rear oxygen sensor (bank 1) is over or under the permissible range for a long period of time. The diagnostic trouble code can be generated after 35 minutes of normal driving (not with heavy load).

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Engine running.

Note. This diagnostic trouble code (DTC) is primarily used for development purposes and has little or no information value during fault-tracing.

Substitute Value

  1. None.

Possible Source

  1. Leakage in the exhaust system.
  2. Contact resistance in the terminals.
  3. Damaged cable harness.
  4. Damaged heated oxygen sensor (HO2S).

Fault symptom[s]

  1. None

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-2210

Condition

The engine control module (ECM) checks whether there is a short-circuit to ground or supply voltage in the preheating circuit heated oxygen sensor (HO2S). It also checks for an open-circuit or whether the heating resistor is faulty. The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers any of these.

The diagnostic trouble code (DTC) can be diagnosed at ignition on and if the battery voltage is in the range 11-16 V.

Substitute Value

  1. Rear heated oxygen sensor (HO2S) preheating shut off.

Possible Source

Signal too low

  1. Damaged fuse.
  2. Open-circuit in the power cable
  3. Short-circuit to ground in the power cable
  4. Damaged rear heated oxygen sensor (HO2S).

Signal too high

  1. Short-circuit to supply voltage in the power cable
  2. Damaged rear heated oxygen sensor (HO2S).

Faulty signal

  1. Contact resistance and/or oxidation in the terminals
  2. Damaged rear heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-2210

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-2210

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-221B

Condition

Scheme 38

Scheme 38: DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-221B
Scheme 38: DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-221B

The engine control module (ECM) monitors the operation of the rear heated oxygen sensor (HO2S) by checking its signal. The engine control module (ECM) checks that the probe has registered both rich and lean fuel/air mixtures. If this is not the case, the engine control module (ECM) changes the fuel/air mixture. The diagnostic trouble code (DTC) is stored if the rear probe has still not registered a lean or rich fuel / air mixture.

Note. At fuel shut-off, the probe must show a lean fuel/air mixture. The diagnostic trouble code (DTC) is stored if the switch-over time to a lean fuel/air mixture is too long.

Substitute Value

None.

Possible Source

  1. Leakage in the exhaust system
  2. Damaged rear heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-221B

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-221C

Condition

The engine control module (ECM) monitors the operation of the rear heated oxygen sensor (HO2S) by checking its signal. The engine control module (ECM) checks that the probe has registered a rich fuel/air mixture. If this is not the case, the engine control module (ECM) changes the fuel/air mixture. The diagnostic trouble code (DTC) is stored if the rear probe has still not registered a rich fuel / air mixture.

Note. At fuel shut-off, the probe must show a lean fuel/air mixture. The diagnostic trouble code (DTC) is stored if the switch-over time to a lean fuel/air mixture is too long.

Substitute Value

None.

Possible Source

  1. Leakage in the exhaust system
  2. Damaged rear heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-221C

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-221D

Condition

The engine control module (ECM) monitors the operation of the rear heated oxygen sensor (HO2S) by checking its signal. The engine control module (ECM) checks that the probe has registered a lean fuel/air mixture. If this is not the case, the engine control module (ECM) changes the fuel/air mixture. The diagnostic trouble code (DTC) is stored if the rear probe has still not registered a lean fuel / air mixture.

Note. At fuel shut-off, the probe must show a lean fuel/air mixture. The diagnostic trouble code (DTC) is stored if the switch-over time to a lean fuel/air mixture is too long.

Substitute Value

None.

Possible Source

  1. Leakage in the exhaust system
  2. Damaged rear heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-221D

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-2220

Condition

The engine control module (ECM) monitors the operation of the rear heated oxygen sensor (HO2S) by checking its signal. The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the signal deviates from its permitted operational range or if the voltage for the heated oxygen sensor (HO2S) preheating disrupts the heated oxygen sensor (HO2S) signal.

Substitute Value

  1. Rear heated oxygen sensor (HO2S) control is disabled
  2. Three-way catalytic converter (TWC) diagnostics are disabled.

Possible Source

  1. Short-circuit in the signal cable for the pre-heating circuit
  2. Short-circuit in the ground lead for the preheating circuit
  3. Damaged rear heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-2220

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-2220

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-222B

Condition

The engine control module (ECM) monitors the operation of the rear heated oxygen sensor (HO2S) by checking its signal. The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the signal deviates from its permitted operational range or if the voltage for the heated oxygen sensor (HO2S) preheating disrupts the heated oxygen sensor (HO2S) signal.

Substitute Value

  1. Rear heated oxygen sensor (HO2S) control is disabled
  2. Three-way catalytic converter (TWC) diagnostics are disabled.

Possible Source

  1. Short-circuit to ground in the signal cable
  2. Short-circuit to ground in the ground lead
  3. Damaged rear heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-222B

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-222B

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-222C

Condition

The engine control module (ECM) monitors the operation of the rear heated oxygen sensor (HO2S) by checking its signal. The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the signal deviates from its permitted operational range or if the voltage for the heated oxygen sensor (HO2S) preheating disrupts the heated oxygen sensor (HO2S) signal.

Substitute Value

  1. Rear heated oxygen sensor (HO2S) control is disabled
  2. Three-way catalytic converter (TWC) diagnostics are disabled.

Possible Source

  1. Short-circuit to supply voltage in the signal cable
  2. Short-circuit to supply voltage in the ground lead
  3. Damaged rear heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-222C

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-222C

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-222D

Condition

The engine control module (ECM) monitors the operation of the rear heated oxygen sensor (HO2S) by checking its signal. The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the signal deviates from its permitted operational range or if the voltage for the heated oxygen sensor (HO2S) preheating disrupts the heated oxygen sensor (HO2S) signal.

Substitute Value

  1. Rear heated oxygen sensor (HO2S) control is disabled
  2. Three-way catalytic converter (TWC) diagnostics are disabled.

Possible Source

  1. Short-circuit to ground in the signal cable
  2. Short-circuit to ground in the ground lead
  3. Damaged rear heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-222D

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-222D

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-223B

Condition

The engine control module (ECM) controls preheating by pulsing the current to the positive temperature coefficient (PTC) element in the rear heated oxygen sensor (HO2S). Pulse lengths are dependent on the temperature of the heated oxygen sensor (H02S).

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the signal is lower than a certain value when preheating is deactivated.

Substitute Value

  1. The fuel trim is shut off.

Possible Source

  1. Contact resistance and oxidation in the terminals
  2. Open-circuit in the power supply from the system relay
  3. Damaged rear heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-223B

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-223C

Condition

The engine control module (ECM) controls preheating by pulsing the current to the positive temperature coefficient (PTC) element in the rear heated oxygen sensor (HO2S). Pulse lengths are dependent on the temperature of the heated oxygen sensor (H02S).

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the signal is higher than a certain value when preheating is active.

Substitute Value

  1. The fuel trim is shut off.

Possible Source

  1. Short-circuit to supply voltage in the signal cable
  2. Damaged rear heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-223C

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-223D

Condition

The engine control module (ECM) controls preheating by pulsing the current to the positive temperature coefficient (PTC) element in the rear heated oxygen sensor (HO2S). Pulse lengths are dependent on the temperature of the heated oxygen sensor (H02S).

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the signal is lower than a certain value when preheating is deactivated.

Substitute Value

  1. The fuel trim is shut off.

Possible Source

  1. Short-circuit to ground in the signal cable
  2. Damaged rear heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-223D

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-2250

Condition

Engine control module (ECM) monitors rear heated oxygen sensor by, among others, checking it electrically.

This diagnostic trouble code is a collective code for diagnoses regarding electrical malfunctions on the heated oxygen sensor and its heating.

Note. This diagnostic trouble code is stored as a result of any other diagnostic trouble code for rear heated oxygen sensor being stored in the control module. Therefore, perform troubleshooting based on the second diagnostic trouble code.

Substitute Value

  1. None.

Possible Source

  1. Search for failure cause with another stored diagnostic trouble code in the control module.

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-23X0

Condition

Scheme 39

Scheme 39: DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-23X0
Scheme 39: DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-23X0

The engine control module (ECM) checks the signal cable for the injector. The diagnostic trouble code (DTC) is stored if the engine control module (ECM) detects that the signal for the injector is too high, too low or missing.

The diagnostic trouble code (DTC) can be diagnosed at ignition on and with the engine running.

Substitute Value

Fuel trim disabled.

Possible Source

  1. Contact resistance or oxidation, injector connector
  2. Open-circuit, power supply cable
  3. Short-circuit to supply voltage in the signal cable
  4. Short-circuit to ground in the signal cable
  5. Open-circuit in the signal cable
  6. Damaged injector.

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit
  2. Engine not firing on all cylinders
  3. The starter motor turns but the engine does not start.

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-2400

Condition

Scheme 40

Scheme 40: DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-2400
Scheme 40: DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-2400

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the front heated oxygen sensor (HO2S) has not reached normal operating temperature.

Substitute Value

None.

Possible Source

  1. Contact resistance and oxidation in the terminals
  2. Damaged front heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-2400

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-240B

Condition

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that there has been no control of the heater element for the front heated oxygen sensor (HO2S) for a certain amount of time.

Substitute Value

None.

Possible Source

  1. Contact resistance and oxidation in the terminals
  2. Damaged front heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-240B

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-240C

Condition

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the resistance is too high at the front heated oxygen sensor (HO2S).

Substitute Value

None.

Possible Source

  1. Contact resistance and oxidation in the terminals
  2. Damaged front heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-240C

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-240D

Condition

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the resistance is too low at the front heated oxygen sensor (HO2S).

Substitute Value

None.

Possible Source

  1. Contact resistance and oxidation in the terminals
  2. Damaged front heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-242D

Condition

The engine control module (ECM) monitors the aging of the front heated oxygen sensor (HO2S) by checking its ability to react to changes in the exhaust gases. The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the heated oxygen sensor (HO2S) reacts too slowly to changes in the fuel/air mixture.

Substitute Value

Three-way catalytic converter (TWC) diagnostics are disabled.

Possible Source

  1. The cables for the calibration current and the pump current are short-circuited to each other
  2. Open-circuit in signal cable (-)
  3. Open-circuit in the cable for calibration current
  4. Damaged front heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-242D

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-242D

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-243B

Condition

The engine control module (ECM) monitors the operation of the front heated oxygen sensor (HO2S) by checking its signal. The diagnostic trouble code (DTC) is stored if the voltage for the heated oxygen sensor (HO2S) preheating disrupts the heated oxygen sensor (HO2S) signal.

Substitute Value

  1. The heated oxygen sensor (HO2S) control is disabled
  2. Three-way catalytic converter (TWC) diagnostics are disabled.

Possible Source

  1. One of the cables for heated oxygen sensor (HO2S) preheating is short-circuited to the probe's other signal cables
  2. Damaged front heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-243B

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-243C

Condition

Scheme 41

Scheme 41: DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-243C
Scheme 41: DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-243C

The engine control module (ECM) controls the resistance on the preheating circuit in the front lambda probe. The check is made by the control module measuring the current through the circuit and then converting the current to temperature. The diagnostic trouble code (DTC) is stored and it is interpreted as a fault if the control module detects that the resistance is unreasonably high, which results in a low temperature.

The diagnostic trouble code (DTC) can be diagnosed when driving.

Substitute Value

  1. None.

Possible Source

  1. Contact resistance and oxidation in the terminals.
  2. Damaged front heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator light (MIL), on

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-243C

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-244B

Condition

The engine control module (ECM) controls preheating by pulsing the current to the positive temperature coefficient (PTC) element in the front heated oxygen sensor (HO2S). Pulse lengths are dependent on the temperature of the heated oxygen sensor (H02S).

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the signal is lower than a certain value when preheating is deactivated.

Substitute Value

  1. The fuel trim is shut off.

Possible Source

  1. Contact resistance and oxidation in the terminals
  2. Open-circuit in the power supply from the system relay
  3. Damaged front heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-244B

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-244C

Condition

The engine control module (ECM) controls preheating by pulsing the current to the positive temperature coefficient (PTC) element in the front heated oxygen sensor (HO2S). Pulse lengths are dependent on the temperature of the heated oxygen sensor (H02S).

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the signal is higher than a certain value when preheating is active.

Substitute Value

  1. The fuel trim is shut off.

Possible Source

  1. Short-circuit to supply voltage in the signal cable
  2. Damaged front heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-244C

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-244D

Condition

The engine control module (ECM) controls preheating by pulsing the current to the positive temperature coefficient (PTC) element in the front heated oxygen sensor (HO2S). Pulse lengths are dependent on the temperature of the heated oxygen sensor (H02S).

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the signal is lower than a certain value when preheating is deactivated.

Substitute Value

  1. The fuel trim is shut off.

Possible Source

  1. Short-circuit to ground in the signal cable
  2. Damaged front heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-244D

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-2450

Condition

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers an internal fault in the control for the heated oxygen sensors (HO2S).

The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.

Substitute Value

None.

Possible Source

  1. Damaged engine control module (ECM).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-2450

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-245B

Condition

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers an internal fault in the control for the heated oxygen sensors (HO2S).

The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.

Substitute Value

None.

Possible Source

  1. Damaged engine control module (ECM).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-245B

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-245C

Condition

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers an internal fault in the control for the heated oxygen sensors (HO2S).

The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.

Substitute Value

None.

Possible Source

  1. Damaged engine control module (ECM).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-245C

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-245D

Condition

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers an internal fault in the control for the heated oxygen sensors (HO2S).

The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.

Substitute Value

None.

Possible Source

  1. Damaged engine control module (ECM).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-245D

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-246B

Condition

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the calibration current has ceased and the front heated oxygen sensor (HO2S) signal is implausibly high at fuel shut-off.

Substitute Value

None.

Possible Source

  1. Contact resistance and oxidation in the terminals
  2. Open-circuit in the cable for calibration current
  3. Damaged front heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-246B

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-246B

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-2470

Condition

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the pump current has ceased and the front heated oxygen sensor (HO2S) signal has been set to a default value.

Substitute Value

None.

Possible Source

  1. Contact resistance and oxidation in the terminals
  2. Open-circuit in the cable for pump current
  3. Damaged front heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-2470

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-2470

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-247B

Condition

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the pump current has ceased and the front heated oxygen sensor (HO2S) signal has been set to a default value.

Substitute Value

None.

Possible Source

  1. Contact resistance and oxidation in the terminals
  2. Open-circuit in the cable for pump current
  3. Damaged front heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-247B

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-247B

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-247C

Condition

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the pump current has ceased and the front heated oxygen sensor (HO2S) signal has been set to a default value.

Substitute Value

None.

Possible Source

  1. Contact resistance and oxidation in the terminals
  2. Open-circuit in the cable for pump current
  3. Damaged front heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-247C

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-247C

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-248C

Condition

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that there is a short-circuit to supply voltage or a short-circuit to ground in the signal cables for the front heated oxygen sensor (HO2S).

Substitute Value

None.

Possible Source

  1. Short-circuit in the signal cables
  2. Damaged front heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-248C

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-248D

Condition

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that there is a short-circuit to supply voltage or a short-circuit to ground in the signal cables for the front heated oxygen sensor (HO2S).

Substitute Value

None.

Possible Source

  1. Short-circuit in the signal cables
  2. Damaged front heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-248D

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-249B

Condition

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers an open-circuit in the signal cable to the component of the front heated oxygen sensor (HO2S) that detects the oxygen content of the exhaust gases.

Substitute Value

None.

Possible Source

  1. Contact resistance or oxidation on the signal cable
  2. Open-circuit in the signal cable
  3. Damaged front heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-249B

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-249B

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-24AB

Condition

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers an open-circuit in the ground lead for the front heated oxygen sensor (HO2S).

Substitute Value

None.

Possible Source

  1. Open-circuit in the ground lead
  2. Damaged front heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-24AB

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-24AB

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-24C0

Condition

The engine control module (ECM) monitors the operation of the heated oxygen sensor (HO2S) by checking its signal. The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers any of the following.

  1. The engine control module (ECM) compares the front and rear heated oxygen sensor (HO2S) adaptation values. The diagnostic trouble code (DTC) is stored when the values deviate by more than 3%. NOTE: The fault may be in the front or rear heated oxygen sensor (HO2S) circuit.
  2. The signal from the front heated oxygen sensor (HO2S) indicates a lean fuel/air mixture. The signal from the rear heated oxygen sensor (HO2S) indicates a rich fuel/air mixture
  3. The signal from the front heated oxygen sensor (HO2S) indicates a rich fuel/air mixture. The signal from the rear heated oxygen sensor (HO2S) indicates a lean fuel/air mixture
  4. The signal from the heated oxygen sensor (HO2S) indicates an incorrectly rich/lean fuel/air mixture compared to what is expected by the engine control module (ECM).

Substitute Value

  1. The heated oxygen sensor (HO2S) control is disabled
  2. Three-way catalytic converter (TWC) diagnostics are disabled.

Possible Source

  1. Leakage in the exhaust system
  2. Short-circuit to supply voltage or ground in signal cable (-)
  3. Short-circuit to supply voltage or ground in the pump supply cable
  4. Short-circuit to supply voltage or ground in calibration supply cable
  5. Open-circuit in signal cable (+)
  6. Damaged heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-24C0

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-24C0

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-24CB

Condition

The engine control module (ECM) monitors the operation of the heated oxygen sensor (HO2S) by checking its signal. The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers any of the following.

  1. The engine control module (ECM) compares the front and rear heated oxygen sensor (HO2S) adaptation values. The diagnostic trouble code (DTC) is stored when the values deviate by more than 3%. NOTE: The fault may be in the front or rear heated oxygen sensor (HO2S) circuit.
  2. The signal from the front heated oxygen sensor (HO2S) indicates a lean fuel/air mixture. The signal from the rear heated oxygen sensor (HO2S) indicates a rich fuel/air mixture
  3. The signal from the front heated oxygen sensor (HO2S) indicates a rich fuel/air mixture. The signal from the rear heated oxygen sensor (HO2S) indicates a lean fuel/air mixture
  4. The signal from the heated oxygen sensor (HO2S) indicates an incorrectly rich/lean fuel/air mixture compared to what is expected by the engine control module (ECM).

Substitute Value

  1. The heated oxygen sensor (HO2S) control is disabled
  2. Three-way catalytic converter (TWC) diagnostics are disabled.

Possible Source

  1. Leakage in the exhaust system
  2. Heated oxygen sensor (HO2S) indicates an incorrectly rich fuel/air mixture
  3. Contact resistance or oxidation in the terminals
  4. Damaged heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-24CB

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-24CC

Condition

The engine control module (ECM) monitors the operation of the heated oxygen sensor (HO2S) by checking its signal. The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers any of the following.

  1. The engine control module (ECM) compares the front and rear heated oxygen sensor (HO2S) adaptation values. The diagnostic trouble code (DTC) is stored when the values deviate by more than 3%. NOTE: The fault may be in the front or rear heated oxygen sensor (HO2S) circuit.
  2. The signal from the front heated oxygen sensor (HO2S) indicates a lean fuel/air mixture. The signal from the rear heated oxygen sensor (HO2S) indicates a rich fuel/air mixture
  3. The signal from the front heated oxygen sensor (HO2S) indicates a rich fuel/air mixture. The signal from the rear heated oxygen sensor (HO2S) indicates a lean fuel/air mixture
  4. The signal from the heated oxygen sensor (HO2S) indicates an incorrectly rich/lean fuel/air mixture compared to what is expected by the engine control module (ECM).

Substitute Value

  1. The heated oxygen sensor (HO2S) control is disabled
  2. Three-way catalytic converter (TWC) diagnostics are disabled.

Possible Source

  1. Leakage in the exhaust system
  2. Heated oxygen sensor (HO2S) indicates an incorrectly lean fuel/air mixture
  3. Damaged heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-24CC

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-24CD

Condition

The engine control module (ECM) monitors the operation of the heated oxygen sensor (HO2S) by checking its signal. The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers any of the following.

  1. The engine control module (ECM) compares the front and rear heated oxygen sensor (HO2S) adaptation values. The diagnostic trouble code (DTC) is stored when the values deviate by more than 3%. NOTE: The fault may be in the front or rear heated oxygen sensor (HO2S) circuit.
  2. The signal from the front heated oxygen sensor (HO2S) indicates a lean fuel/air mixture. The signal from the rear heated oxygen sensor (HO2S) indicates a rich fuel/air mixture
  3. The signal from the front heated oxygen sensor (HO2S) indicates a rich fuel/air mixture. The signal from the rear heated oxygen sensor (HO2S) indicates a lean fuel/air mixture
  4. The signal from the heated oxygen sensor (HO2S) indicates an incorrectly rich/lean fuel/air mixture compared to what is expected by the engine control module (ECM).

Substitute Value

  1. The heated oxygen sensor (HO2S) control is disabled
  2. Three-way catalytic converter (TWC) diagnostics are disabled.

Possible Source

  1. Leakage in the exhaust system
  2. Heated oxygen sensor (HO2S) indicates an incorrectly rich fuel/air mixture
  3. Damaged heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-24CD

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-24D0

Condition

The engine control module (ECM) monitors the operation of the front heated oxygen sensor (HO2S) by checking its signal. The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the heated oxygen sensor (HO2S) only indicates air and no fuel/air mixture.

Substitute Value

  1. The heated oxygen sensor (HO2S) control is disabled
  2. Three-way catalytic converter (TWC) diagnostics are disabled.

Possible Source

  1. Incorrectly installed heated oxygen sensor (HO2S)
  2. Damaged front heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-24D0

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-24EB

Condition

Scheme 42

Scheme 42: DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-24EB
Scheme 42: DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-24EB

The engine control module (ECM) checks the signal from the rear heated oxygen sensor (HO2S). The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the heated oxygen sensor (HO2S)reacts too slowly for changes in the fuel/air mixing and the control module interprets this as a fault.

The diagnostic trouble code can be diagnosed when driving.

Substitute Value

  1. Nothing.

Possible Source

  1. Contact resistance and oxidation in the connections.
  2. Damaged rear heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-24EB

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-24EC

Condition

The engine control module (ECM) checks the signal from the rear heated oxygen sensor (HO2S). The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers that the heated oxygen sensor (HO2S)reacts too slowly for changes in the fuel/air mixing and the control module interprets this as a fault.

The diagnostic trouble code can be diagnosed when driving.

Substitute Value

  1. Nothing.

Possible Source

  1. Contact resistance and oxidation in the connections.
  2. Damaged rear heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator lamp (MIL) lit.

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-24EC

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-250A

Condition

Engine Control Module (ECM) receives information from the heated oxygen sensor about fuel/air mixture in different load areas. If Engine Control Module (ECM) registers that fuel/air mixture deviates too much from target lambda, so that adaptations end up in any of its end-positions, the diagnostic trouble code is generated.

Substitute Value

  1. None.

Possible Source

Upper limit

  1. Incorrectly installed oil dipstick. Air leakage.
  2. Too high ethanol content in fuel.
  3. Air leakage in the intake system.
  4. Air leakage in the exhaust system.
  5. Low fuel pressure.
  6. Damaged mass air flow (MAF) sensor.
  7. Damaged, dirty oil trap.

Lower limit

  1. Oil level too high.
  2. Contaminated engine oil.
  3. Leaking injectors.
  4. Damaged evaporative emission system (EVAP) valve.
  5. High fuel pressure.
  6. Damaged mass air flow (MAF) sensor.
  7. Damaged, dirty oil trap.

Fault symptom[s]

  1. Warning lights and chimes/Malfunction Indicator Light ("Check engine" light) indication/no indication
  2. Text window and warning symbol/Yellow symbol and text message
  3. Driving/Poor performance/lacks power
  4. Fuel system/Excessive fuel consumption

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-250A

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-251A

Condition

Engine Control Module (ECM) receives information from the rear heated oxygen sensor about fuel/air mixture in different load areas. Internal functions in the control module detect faults in the lambda control.

The diagnostic trouble code (DTC) is stored if the control module detects that

  1. Large differences have been measured in fuel/air mixture between the front and rear heated oxygen sensors (HO2S). So large that the trims for the rear heated oxygen sensor are in one of their limit positions.

The control module's test for the diagnostic trouble code (DTC) starts in the event of

  1. Normal load (driving) for at least 15 minutes.

Note. The control module can only detect the fault once the test has been started and the diagnostic trouble code (DTC) is stored when the conditions are met.

Substitute Value

  1. None.

Possible Source

Upper limit

  1. Contact resistance, oxidation or poor contact in connections.
  2. Air leakage in the exhaust system.
  3. Damaged front heated oxygen sensor (HO2S).
  4. Damaged center heated oxygen sensor (HO2S).
  5. Damaged rear heated oxygen sensor (HO2S).

Lower limit

  1. Contact resistance, oxidation or poor contact in connections.
  2. Damaged front heated oxygen sensor (HO2S).
  3. Damaged center heated oxygen sensor (HO2S).
  4. Damaged rear heated oxygen sensor (HO2S).

Fault symptom[s]

  1. Malfunction indicator light (MIL), on

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-251A

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-2600

Condition

Scheme 43

Scheme 43: DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-2600
Scheme 43: DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-2600

The engine control module (ECM) checks the signal from the fuel pressure sensor.

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the signal from the fuel pressure sensor.

The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.

Substitute Value

  1. The fuel pressure is set to a constant.
  2. The control signal to the fuel pump (FP) control module is set to a calculated value.

Possible Source

Signal too high

  1. Short-circuit to supply voltage in the signal cable.
  2. Open circuit on signal cable.
  3. Damaged fuel pressure sensor.

Signal too low

  1. The signal cable is short-circuited to ground.
  2. Damaged fuel pressure sensor.

Fault symptom[s]

  1. Malfunction indicator light (MIL), on
  2. Engine misfires

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-2600

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-260A

Condition

The engine control module (ECM) checks the signal from the fuel pressure sensor.

If the Engine control module (ECM) registers that the signal from the fuel pressure sensor does not change when the fuel pump activation changes, the diagnostic trouble code is generated.

The diagnostic trouble code (DTC) can be diagnosed when starting the engine.

Substitute Value

  1. The fuel pressure is set to a constant.
  2. The control signal to the fuel pump (FP) control module is set to a calculated value.

Possible Source

  1. Contact resistance in the connectors.
  2. Damaged fuel pressure sensor.
  3. Damaged fuel pump unit.

Fault symptom[s]

  1. Malfunction indicator light (MIL), on
  2. Engine misfires
  3. Jerky running
  4. Engine stalls

See DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-260A

DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-2610

Condition

Scheme 44

Scheme 44: DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-2610
Scheme 44: DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION ECM-2610

The engine control module (ECM) checks the control signal to the fuel pump (FP) control module.

The diagnostic trouble code (DTC) is stored if the engine control module (ECM) registers a fault in the control signal to the fuel pump (FP) control module.

The diagnostic trouble code (DTC) can be diagnosed when the engine is running.

Substitute Value

  1. None.

Possible Source

Signal too high

  1. Fault registered by the central electronic module (CEM)
  2. Short-circuit to supply voltage in the signal cable
  3. Damaged fuel pump (FP) control module.

Signal too low

  1. Fault registered by the central electronic module (CEM)
  2. Short-circuit to ground in the signal cable
  3. Open-circuit in the signal cable
  4. Damaged fuel pump (FP) control module.

Fault symptom[s]

  1. The starter motor turns but the engine does not start
  2. The engine stops.

More articles — Engine Control Module (ECM) Diagnostic Trouble Codes - 2 of 9
