Engine Control Module (ECM) Diagnostic Trouble Codes - 8 of 9: Other — Volvo V50 I рестайлинг (2007-2012)

REPLACING THE CONTROL MODULE

Try a new alternator control module (ACM).

Remedy as necessary.

Continue Refer to «INFORMATION»(ref-466671-S39824465432012042500000)

FAULT-TRACING INFORMATION

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

FAULTY COMMUNICATION

see FAULTY COMMUNICATION

VERIFICATION

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 208

Ignition off
Reconnect the connectors, reinstall components etc.
Start the engine
Read off the battery voltage and the target value of the generator (GEN) charge voltage
Load the battery by switching on high current consumers such as high beam and the blower fan etc. Check that the battery voltage is approximately 13.5-14.9 V. Check that the battery voltage is approximately the same as the target value for the generator (GEN) charge. Try different engine speeds (RPM).

Is the function OK?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S09388811992012052300000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL TOO HIGH/FAULTY SIGNAL

see SIGNAL TOO HIGH/FAULTY SIGNAL

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Ignition on. Read off the power supply 5 volt from the engine control module (ECM). The value must be higher than 4 volts and lower than 6 volts.

Is the value correct?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S42796079222012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CHECKING THE STATUS

Ignition on. Check whether the fault is permanent or intermittent. Read off the 5 volt power supply from the engine control module (ECM). The value must be higher than 4 volts and lower than 6 volts. The fault is permanent if the value is incorrect. The fault is intermittent if the value is correct.

Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466671-S37531904372012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Ignition on. Read off the power supply 5 volt from the engine control module (ECM). The value must be higher than 4 volts and lower than 6 volts.

Is the value correct?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S10459246882012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Ignition on. Check whether the fault is permanent or intermittent. Read off the 5 volt power supply from the engine control module (ECM). The value must be higher than 4 volts and lower than 6 volts. The fault is permanent if the value is incorrect. The fault is intermittent if the value is correct.

Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466671-S42858946832012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Ignition on. Read off the power supply 5 volt from the engine control module (ECM). The value must be higher than 4 volts and lower than 6 volts.

Is the value correct?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S18287080632012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Ignition on. Check whether the fault is permanent or intermittent. Read off the 5 volt power supply from the engine control module (ECM). The value must be higher than 4 volts and lower than 6 volts. The fault is permanent if the value is incorrect. The fault is intermittent if the value is correct.

Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466671-S25053876472012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Ignition on. Read off the power supply 5 volt from the engine control module (ECM). The value must be higher than 4 volts and lower than 6 volts.

Is the value correct?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S03847780202012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

INFORMATION

Note. The diagnostic trouble code may be caused by a physical object blocking the engine, which results in the crankshaft not being able to turn. Check the engine for visible objects that may cause the blockage.

Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466671-S35496203952012042500000)

Scheme 209

Scheme 209: CHECKING THE COMPONENT AND WIRING

Check the engine speed (RPM) sensor connector. Check for contact resistance and oxidation. HINT: The components and its cables are sensitive to interference from nearby cables, such as the starter motor cable or a similar cable with a high current rating. Interference may cause difficult engine start, the engine does not start at all or intermittent function of the tachometer, etc. Check whether any cables with high power consumption are incorrectly installed, i. e. too close to the engine speed (RPM) sensor or its wiring. Check that the engine speed (RPM) sensor is correctly installed. Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000) see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000) see «COMPONENT SPECIFICATIONS»(ref-466592-S02390340522012042500000) see «CONTENTS»(ref-466589-S05251896242012042500000)

Continue Refer to «VERIFICATION»(ref-466671-S31654878352012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reconnect the connectors, reinstall components etc.
Start the engine. The fault has not been remedied if the engine does not start. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S27677826122012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL TOO LOW

See SIGNAL TOO LOW

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reconnect the connectors, reinstall components etc.
Start the engine. The fault has not been remedied if the engine does not start. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S05270840342012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO LOW

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

SIGNAL TOO HIGH

See SIGNAL TOO HIGH

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

See SIGNAL TOO LOW

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

FAULT-TRACING

See FAULT-TRACING

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

See SIGNAL TOO HIGH

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

See SIGNAL TOO LOW

INTERNAL FAULT

see INTERNAL FAULT

REPLACING THE COMPONENT

Note. If the diagnostic trouble code (DTC) for sensors connected to 5 volt supply is stored, the diagnostic trouble code (DTC) must be fault-traced before this diagnostic trouble code (DTC).

The engine control module (ECM) has registered an internal fault.

If the fault is intermittent, it has been registered previously but is no longer present. Intermittent faults can be caused by interference at start up of the engine control module (ECM) or may be a different type of fault which occurs on different occasions. The fault is evaluated depending on how it occurs. Replace the engine control module (ECM) if the fault recurs.

Replace the engine control module (ECM) in the event of a permanent fault.

see ENGINE CONTROL MODULE (ECM)

Remedy as necessary.

Continue Refer to «INFORMATION»(ref-466671-S25421500772012042500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

See INTERNAL FAULT

Ignition on. Read off the status from the stop lamp switch. Check the function of the stop lamp switch by carefully pressing and releasing the brake pedal. Check that the status changes between "OFF" when the brake pedal is unaffected and "ON" when the brake pedal is depressed. If the status of the stop lamp switch changes as described above when the brake pedal is depressed, the fault is intermittent at the moment.

Continue Refer to «CHECKING THE POWER SUPPLY»(ref-466671-S29389901822012042500000)

Scheme 210

Scheme 211

Ignition on. Check the power supply to the stop lamp switch. Take readings between stop lamp switch terminal #2 (cable harness side) and the ground terminal. The power supply must be approximately 12 V. If there is no power supply: Check the power supply circuit for stop lamp switch terminal #2 (cable harness side). Check for an open-circuit. Check for a short-circuit to ground. Check for a blown fuse in the circuit. Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000) see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000) see «STOPLAMP SWITCH»(ref-479181-S37066927572012061200000) see «CONTENTS»(ref-466589-S05251896242012042500000)

Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466671-S31111264642012042500000)

Scheme 212

Ignition off
Check that the stop lamp switch is correctly installed. Check the resistance of the stop lamp switch with the switch pressed in and with the switch released. Take readings between terminals #1 and #2 (component side) on the stop lamp switch. HINT: The stop lamp switch must be closed when the brake pedal is depressed. The resistance of the stop lamp switch must be infinite when the brake pedal is unaffected. Check the stop lamp switch and engine control module (ECM) connectors. Check for contact resistance. Check for oxidation. Check the cable between stop lamp switch terminal #1 (cable harness side) and engine control module (ECM) terminal #B41 (#C41). Check for loose connections. Check for an open-circuit. Check for a short-circuit to ground. Check for a short-circuit to supply voltage. Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000) see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000) see «CONTENTS»(ref-466589-S05251896242012042500000)

Continue Refer to «VERIFICATION»(ref-466671-S10708514282012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reconnect the connectors, reinstall components etc.
Ignition on. Read off the status from the stop lamp switch. Check the function of the stop lamp switch by carefully pressing and releasing the brake pedal. Check that the status changes between "OFF" when the brake pedal is unaffected and "ON" when the brake pedal is depressed. If the status of the stop lamp switch changes as described above when the brake pedal is depressed, the fault has been remedied.

Is the function OK?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S22606122972012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Ignition on. Read off the status from the stop lamp switch. Check the function of the stop lamp switch by carefully pressing and releasing the brake pedal. Check that the status changes between "OFF" when the brake pedal is unaffected and "ON" when the brake pedal is depressed. If the status of the stop lamp switch changes as described above when the brake pedal is depressed, the fault is intermittent at the moment.

Continue Refer to «CHECKING THE POWER SUPPLY»(ref-466671-S38788085722012042500000)

Scheme 213

Ignition on. Check the power supply to the stop lamp switch. Take readings between stop lamp switch terminal #2 (cable harness side) and the ground terminal. The power supply must be approximately 12 V. If there is no power supply: Check the power supply circuit for stop lamp switch terminal #2 (cable harness side). Check for an open-circuit. Check for a short-circuit to ground. Check for a blown fuse in the circuit. Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000) see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000) see «STOPLAMP SWITCH»(ref-479181-S37066927572012061200000) see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)

Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466671-S41371806072012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reconnect the connectors, reinstall components etc.
Ignition on. Read off the status from the stop lamp switch. Check the function of the stop lamp switch by carefully pressing and releasing the brake pedal. Check that the status changes between "OFF" when the brake pedal is unaffected and "ON" when the brake pedal is depressed. If the status of the stop lamp switch changes as described above when the brake pedal is depressed, the fault has been remedied.

Is the function OK?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S34005008732012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

FAULTY SIGNAL

See FAULTY SIGNAL

No fault-tracing has been developed for this diagnostic trouble code (DTC). The diagnostic trouble code (DTC) for this fault is stored first in the brake control module (BCM), then in the engine control module (ECM). This diagnostic trouble code (DTC) can not be erased before the diagnostic trouble code (DTC) in the brake control module (BCM) has been remedied and erased.

First read off the diagnostic trouble codes (DTCs) in the brake control module (BCM). Fault-trace and remedy as necessary. This diagnostic trouble code (DTC) can then be erased.

For further information about this diagnostic trouble code (DTC), select Information, then DTC information.

See FAULT-TRACING INFORMATION

Ignition on. Read off the diagnostic trouble code (DTC) status. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".

Continue Refer to «REPLACING THE COMPONENT»(ref-466671-S13130695382012042500000)

The engine control module (ECM) has registered an internal fault.

Replace the engine control module (ECM) in the event of a permanent fault.

Remedy as necessary.

Other information

see «ENGINE CONTROL MODULE (ECM)»(ref-466594-S40317974462012042500000)

Continue Refer to «INFORMATION»(ref-466671-S18619410462012042500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

See FAULT-TRACING INFORMATION

Ignition on. Read off the diagnostic trouble code (DTC) status. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".

Continue Refer to «REPLACING THE COMPONENT»(ref-466671-S00934617402012042500000)

The engine control module (ECM) has registered an internal fault.

Note. This diagnostic trouble code may have been stored incorrectly due to the Engine control module (ECM) considering that the battery voltage has been lower than normal. Newer software for Engine control module (ECM) has been made more durable and thus this problem cause is eliminated. Make sure that the Engine control module (ECM) has the latest software. Troubleshooting shall only continue if the control module already has the latest software.

Replace the engine control module (ECM) in the event of a permanent fault.

Remedy as necessary.

Other information

see «ENGINE CONTROL MODULE (ECM)»(ref-466594-S40317974462012042500000)

Continue Refer to «INFORMATION»(ref-466671-S40885810122012042500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

See FAULT-TRACING INFORMATION

Ignition on. Read off the diagnostic trouble code (DTC) status. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".

Continue Refer to «REPLACING THE COMPONENT»(ref-466671-S34993819402012042500000)

The engine control module (ECM) has registered an internal fault.

Replace the engine control module (ECM) in the event of a permanent fault.

Remedy as necessary.

Other information

see «ENGINE CONTROL MODULE (ECM)»(ref-466594-S40317974462012042500000)

Continue Refer to «INFORMATION»(ref-466671-S10776029702012042500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

Turn off the ignition.
Reinstall the connectors, components etc. Check whether the fault has been remedied by switching on the ignition and attempting to start the engine. Release the ignition key/start knob from position III as soon as the starter motor has started to crank. The autostart function should drive the starter motor until the engine starts.

Has the fault been remedied?

YES OKAY: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S11058441982012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See FAULT-TRACING

see FAULT-TRACING INFORMATION

See FAULT-TRACING

see FAULT-TRACING INFORMATION

See FAULT-TRACING

see FAULT-TRACING INFORMATION

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Ignition on. Activate reading off the position of the throttle. Check that both sensors indicate values within the permitted range at different deployments.

Are these values within their permitted ranges?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S28921193432012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Ignition on. Activate reading off the position of the throttle. Check that both sensors indicate values within the permitted range at different deployments.

Are these values within their permitted ranges?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S34386678902012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Ignition on. Activate reading off the position of the throttle. Check that both sensors indicate values within the permitted range at different deployments.

Are these values within their permitted ranges?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S32744965892012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Ignition on. Activate reading off the position of the throttle. Check that both sensors indicate values within the permitted range at different deployments.

Are these values within their permitted ranges?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S05382691122012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Ignition on. Activate reading off the position of the throttle. Check that both sensors indicate values within the permitted range at different deployments.

Are these values within their permitted ranges?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S05150274182012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Ignition on. Activate reading off the position of the throttle. Check that both sensors indicate values within the permitted range at different deployments.

Are these values within their permitted ranges?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S05411895732012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Ignition on. Activate reading off the position of the throttle. Check that both sensors indicate values within the permitted range at different deployments.

Are these values within their permitted ranges?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S06746364062012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Ignition on. Activate reading off the position of the throttle. Check that both sensors indicate values within the permitted range at different deployments.

Are these values within their permitted ranges?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S21702048332012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CHECKING THE THROTTLE UNIT

Ignition on
Activate reading off the position of the throttle
Check that both sensors indicate values within the permitted range at different deployments. NOTE: Dirt, ice build-up or objects can cause the throttle disc to jam momentarily. This may cause the diagnostic trouble code (DTC) to be stored. Check that the shutter in the throttle unit is not dirty, blocked or sticking. Clean as necessary. HINT: A film of oil covering the throttle may mean that the flame trap is not functioning correctly. If the diagnostic trouble code (DTC) recurs and no faults can be found as above, try replacing the throttle unit. Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000) see «SIGNAL SPECIFICATION»(ref-466592-S15475582172012042500000) see «THROTTLE BODY, CLEANING»(ref-466667-S27857021572012042500000) see «THROTTLE BODY»(ref-466651-S01198376532012042500000) see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)

Continue Refer to «VERIFICATION»(ref-466671-S41753147802012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Ignition on. Activate reading off the position of the throttle. Check that both sensors indicate values within the permitted range at different deployments.

Are these values within their permitted ranges?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S01191588832012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Ignition on
Activate reading off the position of the throttle
Check that both sensors indicate values within the permitted range at different deployments. NOTE: Dirt, ice build-up or objects can cause the throttle disc to jam momentarily. This may cause the diagnostic trouble code (DTC) to be stored. Check that the shutter in the throttle unit is not dirty, blocked or sticking. Clean as necessary. HINT: A film of oil covering the throttle may mean that the flame trap is not functioning correctly. If the diagnostic trouble code (DTC) recurs and no faults can be found as above, try replacing the throttle unit. Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000) see «SIGNAL SPECIFICATION»(ref-466592-S26583508152012042500000) see «THROTTLE BODY, CLEANING»(ref-466667-S27857021572012042500000) see «THROTTLE BODY»(ref-466651-S01198376532012042500000) see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)

Continue Refer to «VERIFICATION»(ref-466671-S15400632642012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Ignition on. Activate reading off the position of the throttle. Check that both sensors indicate values within the permitted range at different deployments.

Are these values within their permitted ranges?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S41525746872012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Ignition on
Activate reading off the position of the throttle
Check that both sensors indicate values within the permitted range at different deployments. NOTE: Dirt, ice build-up or objects can cause the throttle disc to jam momentarily. This may cause the diagnostic trouble code (DTC) to be stored. Check that the shutter in the throttle unit is not dirty, blocked or sticking. Clean as necessary. HINT: A film of oil covering the throttle may mean that the flame trap is not functioning correctly. If the diagnostic trouble code (DTC) recurs and no faults can be found as above, try replacing the throttle unit. Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000) see «SIGNAL SPECIFICATION»(ref-466592-S15475582172012042500000) see «THROTTLE BODY, CLEANING»(ref-466667-S27857021572012042500000) see «THROTTLE BODY»(ref-466651-S01198376532012042500000) see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)

Continue Refer to «VERIFICATION»(ref-466671-S20497370092012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Ignition on. Activate reading off the position of the throttle. Check that both sensors indicate values within the permitted range at different deployments.

Are these values within their permitted ranges?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S31861845242012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Ignition on
Activate reading off the position of the throttle
Check that both sensors indicate values within the permitted range at different deployments. NOTE: Dirt, ice build-up or objects can cause the throttle disc to jam momentarily. This may cause the diagnostic trouble code (DTC) to be stored. Check that the shutter in the throttle unit is not dirty, blocked or sticking. Clean as necessary. HINT: A film of oil covering the throttle may mean that the flame trap is not functioning correctly. If the diagnostic trouble code (DTC) recurs and no faults can be found as above, try replacing the throttle unit. Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000) see «SIGNAL SPECIFICATION»(ref-466592-S26583508152012042500000) see «THROTTLE BODY, CLEANING»(ref-466667-S27857021572012042500000) see «THROTTLE BODY»(ref-466651-S01198376532012042500000) see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)

Continue Refer to «VERIFICATION»(ref-466671-S07922045492012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Ignition on. Activate reading off the position of the throttle. Check that both sensors indicate values within the permitted range at different deployments.

Are these values within their permitted ranges?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S16309698512012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

No fault-tracing has been developed for this diagnostic trouble code (DTC). The diagnostic trouble code (DTC) for this fault is stored first in the steering wheel module (SWM), then in the engine control module (ECM). This diagnostic trouble code (DTC) can not be erased before the diagnostic trouble code (DTC) in the steering wheel module (SWM) has been remedied and erased.

First read off the diagnostic trouble codes (DTCs) in the steering wheel module (SWM). Fault-trace and remedy as necessary. This diagnostic trouble code (DTC) can then be erased. For further information about this diagnostic trouble code (DTC), select Information, then DTC information.

There is no fault-tracing for this diagnostic fault code (DTC).

see FAULT-TRACING INFORMATION

CAUTION

The male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.

Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466671-S31139302772012042500000)

Scheme 214

Scheme 215

Ignition off
Check the throttle unit and engine control module (ECM) connectors. Check for contact resistance and oxidation. Check the resistance values of the potentiometers in the throttle unit. Check the signal cable (potentiometer 1) between engine control module (ECM) terminal #A65 (#B5) and throttle unit terminal #6 (cable harness side). Check for an open-circuit. Check the signal cable (potentiometer 2) between engine control module (ECM) terminal #A88 (#B28) and throttle unit terminal #5 (cable harness side). Check for an open-circuit. Check the signal cables (potentiometer 1) terminal #A65 (#B5) and (potentiometer 2) terminal #A88 (#B28). Check for a short-circuit to each other. HINT: With the ignition on, the power supply to the throttle unit potentiometers must be approximately 5 V measured between throttle unit connector terminals #2 and #3 (cable harness side). If no faults are found during the checks and the diagnostic trouble code (DTC) recurs, try replacing the throttle unit. NOTE: When replacing the throttle unit, the throttle unit must be adapted. See VIDA vehicle communication (Throttle unit adaptation). Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000) see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000) see «COMPONENT SPECIFICATIONS»(ref-466592-S02390340522012042500000) see «THROTTLE BODY»(ref-466651-S01520166752012042500000) see «CONTENTS»(ref-466589-S05251896242012042500000)

Continue Refer to «VERIFICATION»(ref-466671-S31601084492012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Start the engine. Read off diagnostic trouble codes (DTCs). If the status of the diagnostic trouble code (DTC) is intermittent the fault has been remedied.

Is the status of the diagnostic trouble code (DTC) intermittent?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S08974189122012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See FAULTY SIGNAL

CAUTION

The male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.

Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466671-S15821393072012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Start the engine. Read off diagnostic trouble codes (DTCs). If the status of the diagnostic trouble code (DTC) is intermittent the fault has been remedied.

Is the status of the diagnostic trouble code (DTC) intermittent?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S03177039582012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CAUTION

The male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.

Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466671-S06158685512012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Start the engine. Read off diagnostic trouble codes (DTCs). If the status of the diagnostic trouble code (DTC) is intermittent the fault has been remedied.

Is the status of the diagnostic trouble code (DTC) intermittent?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S31969375942012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO HIGH

CAUTION

The male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.

Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466671-S01048377632012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Start the engine. Read off diagnostic trouble codes (DTCs). If the status of the diagnostic trouble code (DTC) is intermittent the fault has been remedied.

Is the status of the diagnostic trouble code (DTC) intermittent?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S24630348442012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO LOW

See FAULTY SIGNAL

No fault-tracing has been developed for this diagnostic trouble code (DTC). A diagnostic trouble code for CAN communication can also be generated in the Central Electronic Module (CEM). This diagnostic trouble code shall not be cleared until the trouble code in the central electronic module (CEM) and in other affected control modules has been remedied and cleared. Therefore, first read the diagnostic trouble codes in the Central Electronic Module (CEM) and other affected control modules, perform fault tracing and remedy as necessary. This diagnostic trouble code (DTC) can then be erased. For further information on this diagnostic trouble code, see Diagnostic trouble code (DTC) information.

Other information

S40 (04-)/V50: «GENERAL INFORMATION ABOUT FAULT-TRACING IN THE CAN NETWORK»(ref-466603-S14975733402012042500000)

CAUTION

The male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.

Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466671-S26545218872012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Start the engine. Read off diagnostic trouble codes (DTCs). If the status of the diagnostic trouble code (DTC) is intermittent the fault has been remedied.

Is the status of the diagnostic trouble code (DTC) intermittent?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S42442866972012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CAUTION

The male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.

Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466671-S19453416872012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Start the engine. Read off diagnostic trouble codes (DTCs). If the status of the diagnostic trouble code (DTC) is intermittent the fault has been remedied.

Is the status of the diagnostic trouble code (DTC) intermittent?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S29803821652012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO HIGH

CAUTION

The male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.

Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466671-S35467912052012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Start the engine. Read off diagnostic trouble codes (DTCs). If the status of the diagnostic trouble code (DTC) is intermittent the fault has been remedied.

Is the status of the diagnostic trouble code (DTC) intermittent?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S19178045742012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO LOW

CAUTION

The male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.

Continue Refer to «CHECKING THE DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-466671-S06736723992012042500000)

Remedy any diagnostic trouble codes (DTCs) that are stored.

Remedy as necessary.

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Start the engine. Read off diagnostic trouble codes (DTCs). If the status of the diagnostic trouble code (DTC) is intermittent the fault has been remedied.

Is the status of the diagnostic trouble code (DTC) intermittent?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S37085779752012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See FAULTY SIGNAL

CAUTION

The male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.

Continue Refer to «CHECKING THE DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-466671-S20623753122012042500000)

Remedy stored diagnostic trouble code(s) (DTCs).

Remedy as necessary.

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

SIGNAL TOO HIGH / SIGNAL TOO LOW

See SIGNAL TOO HIGH / SIGNAL TOO LOW

CAUTION

The male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.

Continue Refer to «CHECKING THE DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-466671-S37177057122012042500000)

Remedy stored diagnostic trouble code(s) (DTCs).

Remedy as necessary.

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

See FAULTY SIGNAL

CAUTION

The male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.

Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-466671-S05704732762012042500000)

ADAPTATION OF THE THROTTLE UNIT

HINT: Faults which cause this diagnostic trouble code (DTC) may affect the adaptation values for the throttle unit. Carry out adaptation of the throttle unit to update the adaptation values.

Note. The ignition must be switched on for at least 30 seconds after the basic conditions are met in order for the adaptation to start. It takes approximately 10 seconds to run the adaptation.

Ignition off
Reinstall the components and connectors etc.
Ignition on. Read off parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The vehicle must be stationary (no vehicle speed signal) Engine coolant temperature (ECT) between 5-100 °C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation is completed correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO.

Select Continue without switching off the ignition when the adaptation is OK.

Continue Refer to «CHECKING THE FUNCTION»(ref-466671-S01429807672012042500000)

CHECKING THE FUNCTION

Ignition on. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". HINT: In some cases several functions of the component will be diagnosed. The affects the amount of time taken to run the diagnostic. The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active.

Continue Refer to «REPLACING THE COMPONENT»(ref-466671-S42786373272012042500000)

Ignition off. Try a new throttle unit. See «THROTTLE BODY»(ref-466651-S01520166752012042500000)

Continue Refer to «VERIFICATION»(ref-466671-S36893193872012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reinstall the connectors, components etc.
Ignition on
Read off parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The vehicle must be stationary (no vehicle speed signal) Engine coolant temperature (ECT) between 5-100 °C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation is completed correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO.

Select Continue without switching off the ignition when the adaptation is OK.

Continue Refer to «VERIFICATION, CONTINUED»(ref-466671-S14239576612012042500000)

VERIFICATION, CONTINUED

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reconnect the connectors, reinstall components etc. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S11323434302012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See FAULTY SIGNAL

CAUTION

The male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.

Continue Refer to «CHECKING THE FAULT STATUS»(ref-466671-S05943890222012042500000)

CHECKING THE FAULT STATUS

Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". HINT: In some cases several functions of the component will be diagnosed. The affects the amount of time taken to run the diagnostic. The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active.

Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-466671-S21953727782012042500000)

Note. The ignition must be switched on for at least 30 seconds after the basic conditions are met in order for the adaptation to start. It takes approximately 10 seconds to run the adaptation.

Ignition off
Reinstall the connectors, components etc.
Ignition on. Read off parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The car must be stationary (no vehicle speed signal) Engine coolant temperature (ECT) between 5-100 °C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation is completed correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO.

Then select Continue when the adaptation has been completed correctly.

Continue Refer to «VERIFICATION»(ref-466671-S24798863142012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reconnect the connectors, reinstall components etc.
Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

YES OKAY: Troubleshooting has been completed.
NO Refer to «PROGRAMMING THE ENGINE CONTROL MODULE (ECM)»(ref-466671-S36785818632012042500000)

PROGRAMMING THE ENGINE CONTROL MODULE (ECM)

HINT: This diagnostic trouble code (DTC) may be caused by faulty software.

Ignition off. Try downloading new software to the engine control module (ECM). To download new software, see «ENGINE CONTROL MODULE (ECM)»(ref-466594-S40317974462012042500000) Remedy as necessary.

Continue Refer to «ADAPTATION OF THE THROTTLE UNIT»(ref-466671-S13382414462012042500000)

Note. The ignition must be switched on for at least 30 seconds after the basic conditions are met in order for the adaptation to start. It takes approximately 10 seconds to run the adaptation.

Ignition off
Reinstall the connectors, components etc.
Ignition on
Read off parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The car must be stationary (no vehicle speed signal) Engine coolant temperature (ECT) between 5-100 °C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation is completed correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO.

Continue Refer to «VERIFICATION»(ref-466671-S37191113342012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reconnect the connectors, reinstall components etc.
Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S33853250982012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO HIGH / SIGNAL TOO LOW

CAUTION

The male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.

Continue Refer to «CHECKING THE DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-466671-S04873951332012042500000)

Note. The ignition must be switched on for at least 30 seconds after the basic conditions are met in order for the adaptation to start. It takes approximately 10 seconds to run the adaptation.

Ignition off
Ignition on. Read off parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The vehicle must be stationary (no vehicle speed signal). Engine coolant temperature (ECT) between 5-100 °C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation is completed correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO. The fault is intermittent at the moment if the adaptation has been completed correctly.

Continue Refer to «CHECKING CONNECTORS AND COMPONENTS»(ref-466671-S21407527462012042500000)

CHECKING CONNECTORS AND COMPONENTS

Ignition off. Check the throttle unit and engine control module (ECM) connectors. Check for contact resistance and oxidation. Check the resistance values of the potentiometers in the throttle unit. Check that the shutter in the throttle unit is not blocked or sticking. Clean as necessary. Remedy as necessary. Other information see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000) see «COMPONENT SPECIFICATIONS»(ref-466592-S02390340522012042500000) see «THROTTLE BODY»(ref-466651-S01520166752012042500000) see «THROTTLE BODY, CLEANING»(ref-466667-S27857021572012042500000) see «CONTENTS»(ref-466589-S05251896242012042500000)

Continue Refer to «VERIFICATION»(ref-466671-S39813518072012042500000)

Remedy stored diagnostic trouble code(s) (DTCs).

Remedy as necessary.

HINT: After carrying out the repair, check that the fault has been remedied.

Note. The ignition must be switched on for at least 30 seconds after the basic conditions are met in order for the adaptation to start. It takes approximately 10 seconds to run the adaptation.

Ignition off
Reinstall the connectors, components etc.
Ignition on. Read off parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The vehicle must be stationary (no vehicle speed signal). Engine coolant temperature (ECT) between 5-100 °C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation is completed correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO. The fault has been remedied if the adaptation has been completed correctly.

Is the adaptation OK?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S29162738692012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See FAULTY SIGNAL

CAUTION

The male and female pins on the electronic throttle unit connectors are gold plated. Great care must be taken when measuring. Damage to the gold plating can result in operating difficulties.

Continue Refer to «CHECKING THE DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-466671-S07055970282012042500000)

Note. The ignition must be switched on for at least 30 seconds after the basic conditions are met in order for the adaptation to start. It takes approximately 10 seconds to run the adaptation.

Ignition off
Ignition on. Read off parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The vehicle must be stationary (no vehicle speed signal) Engine coolant temperature (ECT) between 5-100 °C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation is completed correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO. The fault is intermittent at the moment if the adaptation has been completed correctly.

Continue Refer to «CHECKING CONNECTORS AND COMPONENTS»(ref-466671-S34438286902012042500000)

Ignition off. Check the throttle unit and engine control module (ECM) connectors. Check for contact resistance and oxidation. Check the resistance values of the potentiometers in the throttle unit. Check that the shutter in the throttle unit is not blocked or sticking. Clean as necessary. Remedy as necessary. Other information see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000) see «COMPONENT SPECIFICATIONS»(ref-466592-S02390340522012042500000) see «THROTTLE BODY»(ref-466651-S01520166752012042500000) see «THROTTLE BODY, CLEANING»(ref-466667-S27857021572012042500000) see «CONTENTS»(ref-466589-S05251896242012042500000)

Continue Refer to «VERIFICATION»(ref-466671-S03235203272012042500000)

Remedy stored diagnostic trouble code(s) (DTCs).

Remedy as necessary.

HINT: After carrying out the repair, check that the fault has been remedied.

Note. The ignition must be switched on for at least 30 seconds after the basic conditions are met in order for the adaptation to start. It takes approximately 10 seconds to run the adaptation.

Ignition off
Reinstall the connectors, components etc.
Ignition on. Read off parameters. Check that the following basic conditions for adaptation of the throttle unit are met. Ignition on / engine off Battery voltage above 10 V Accelerator pedal (AP) unaffected The vehicle must be stationary (no vehicle speed signal). Engine coolant temperature (ECT) between 5-100 °C Intake air temperature (IAT) above 5 °C. Remedy as necessary. Check that the adaptation is correctly run after the "Adaptation of the throttle unit running" parameter changes status from "YES" to "NO". When all basic conditions are met, the adaptation must be completed after approximately 40 seconds. When the adaptation is completed correctly, the following information will be displayed: Adaptation of the throttle unit: OK Adaptation of the throttle unit running: NO. The fault has been remedied if the adaptation has been completed correctly.

Is the adaptation OK?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S39947043002012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO HIGH / SIGNAL TOO LOW

See FAULTY SIGNAL

see INTERNAL FAULT

Other information

S40 (04-)/V50: «GENERAL INFORMATION ABOUT FAULT-TRACING IN THE CAN NETWORK»(ref-466603-S14975733402012042500000)

see FAULT-TRACING INFORMATION

No fault-tracing has been developed for this diagnostic trouble code (DTC). The diagnostic trouble code (DTC) for this fault is first stored in the Central electronic module (CEM), then in the Engine control module (ECM). This diagnostic trouble code (DTC) can not be erased before the diagnostic trouble codes (DTC) in the central electronic module (CEM) has been remedied and erased.

Therefore, first read off diagnostic trouble codes in Central electronic module (CEM), perform troubleshooting and perform actions as needed. This diagnostic trouble code (DTC) can then be erased.

see FAULT-TRACING INFORMATION

Turn off the ignition.
Reinstall the connectors, components etc. Check whether the fault has been remedied by switching on the ignition and attempting to start the engine. Release the ignition key/start knob from position III as soon as the starter motor has started to crank. The autostart function should drive the starter motor until the engine starts.

Has the fault been remedied?

YES OKAY: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S26584923432012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Turn off the ignition.
Reinstall the connectors, components etc. Check whether the fault has been remedied by switching on the ignition and attempting to start the engine. Release the ignition key/start knob from position III as soon as the starter motor has started to crank. The autostart function should drive the starter motor until the engine starts.

Has the fault been remedied?

YES OKAY: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S11974398052012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Start the engine.
Ignition off
Ignition on. Read off the movement of the accelerator pedal by carefully depressing and releasing the accelerator pedal (AP). Check that the value changes with accelerator pedal movement. The value must be between 5 % (released pedal) and a maximum of 90 % (fully depressed pedal). The function is OK if the value is within this range and follows the pedal movement. The fault is intermittent at the moment if the values are OK.

Continue Refer to «CHECKING THE POWER SUPPLY»(ref-466671-S21379445892012042500000)

Scheme 216

Ignition on. Check the power supply (12 V) to the accelerator pedal (AP) position sensor between accelerator pedal (AP) position sensor terminals #4 (cable harness side) and #6 (cable harness side). Check that the power supply is approximately 12 V with the ignition on. Other information see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000) see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000) see «ACCELERATOR PEDAL»(ref-466672-S34630835312012042500000) see «CONTENTS»(ref-466589-S05251896242012042500000)

Is the power supply OK?

YES Refer to «CHECKING THE CONNECTORS AND CABLES»(ref-466671-S29775016212012042500000)
NO Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466671-S17818130822012042500000)

CHECKING THE CONNECTORS AND CABLES

Ignition off
Check the accelerator pedal position sensor and engine control module (ECM) connectors. Check for contact resistance. Check for oxidation. Check the signal cable between engine control module (ECM) terminal #B26 (#C26) and accelerator pedal (AP) position sensor terminal #5 (cable harness side). Check for an open-circuit. Check for loose connections. Try a new accelerator pedal (AP) position sensor if no fault is found and the fault is permanent. Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000) see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000) see «ACCELERATOR PEDAL»(ref-466672-S34630835312012042500000) see «CONTENTS»(ref-466589-S05251896242012042500000)

Continue Refer to «VERIFICATION»(ref-466671-S08290882702012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reconnect the connectors, reinstall components etc.
Start the engine.
Ignition off
Ignition on. Read off the movement of the accelerator pedal by carefully depressing and releasing the accelerator pedal (AP). Check that the value changes with accelerator pedal movement. The value must be between 5 % (released pedal) and a maximum of 90 % (fully depressed pedal). The function is OK if the value is within this range and follows the pedal movement. The fault has been remedied if the values are OK.

Are these values OK?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S12545997742012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See FAULTY SIGNAL

CHECKING THE SIGNAL

Check whether any diagnostic trouble codes (DTCs) are stored in the brake control module (BCM) or in the central electronic module (CEM). If diagnostic trouble codes (DTCs) are stored in the brake control module (BCM) or in the central electronic module (CEM), these shall be taken care of first.

If there are any other diagnostic trouble codes (DTCs) stored for the brake pedal position sensor or for the stop lamp switch, fault-trace these first.

HINT: If diagnostic trouble code ECM-941C is stored in the engine control module (ECM), the brake pedal switch probably is or has been damaged.

Check the signals from the brake pedal switch and the brake pedal sensor during vehicle communication for the engine control module. The switch should be closed and the brake pedal sensor value should be updated when the brake pedal is depressed.

Check the cables for short-circuit to voltage, short-circuit to ground and open circuit.

Remedy as necessary.

Other information

see «STOPLAMP SWITCH»(ref-479181-S37066927572012061200000)
see «POSITION SENSOR, BRAKE PEDAL»(ref-466610-S12198553232012042500000)
see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)

Start the engine.
Ignition off
Ignition on. Read off the movement of the accelerator pedal by carefully depressing and releasing the accelerator pedal (AP). Check that the value changes with accelerator pedal movement. The value must be between 5 % (released pedal) and a maximum of 90 % (fully depressed pedal). The function is OK if the value is within this range and follows the pedal movement. The fault is intermittent at the moment if the values are OK.

Continue Refer to «CHECKING THE POWER SUPPLY»(ref-466671-S08804606942012042500000)

CHECKING THE POWER SUPPLY

Ignition on. Check the power supply (12 V) to the accelerator pedal (AP) position sensor between accelerator pedal (AP) position sensor terminals #4 (cable harness side) and #6 (cable harness side). Check that the power supply is approximately 12 V with the ignition on Other information see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000) see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000) see «ACCELERATOR PEDAL»(ref-466672-S34630835312012042500000) see «CONTENTS»(ref-466589-S05251896242012042500000)

Is the power supply OK?

YES Refer to «CHECKING THE CONNECTORS AND CABLES»(ref-466671-S35895927232012042500000)
NO Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466671-S19206168632012042500000)

Ignition off. Check the signal cable between engine control module (ECM) terminal #B26 (#C26) and accelerator pedal (AP) position sensor terminal #5 (cable harness side). Check for a short-circuit to supply voltage. Try a new accelerator pedal (AP) position sensor if no fault is found and the fault is permanent. Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000) see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000) see «ACCELERATOR PEDAL»(ref-466672-S34630835312012042500000) see «CONTENTS»(ref-466589-S05251896242012042500000) .

Continue Refer to «VERIFICATION»(ref-466671-S28088489762012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reconnect the connectors, reinstall components etc.
Start the engine.
Ignition off
Ignition on. Read off the movement of the accelerator pedal by carefully depressing and releasing the accelerator pedal (AP). Check that the value changes with accelerator pedal movement. The value must be between 5 % (released pedal) and a maximum of 90 % (fully depressed pedal). The function is OK if the value is within this range and follows the pedal movement. The fault has been remedied if the values are OK.

Are these values OK?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S28627231132012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO HIGH

see FAULT-TRACING INFORMATION

Start the engine.
Ignition off
Ignition on. Read off the movement of the accelerator pedal by carefully depressing and releasing the accelerator pedal (AP). Check that the value changes with accelerator pedal movement. The value must be between 5 % (released pedal) and a maximum of 90 % (fully depressed pedal). The function is OK if the value is within this range and follows the pedal movement. The fault is intermittent at the moment if the values are OK.

Continue Refer to «CHECKING THE POWER SUPPLY»(ref-466671-S01353270682012042500000)

Ignition on. Check the power supply (12 V) to the accelerator pedal (AP) position sensor between accelerator pedal (AP) position sensor terminals #4 (cable harness side) and #6 (cable harness side). Check that the power supply is approximately 12 V with the ignition on. Other information see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000) see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000) see «ACCELERATOR PEDAL»(ref-466672-S34630835312012042500000) see «CONTENTS»(ref-466589-S05251896242012042500000)

Is the power supply OK?

YES Refer to «CHECKING THE CONNECTORS AND CABLES»(ref-466671-S28657359802012042500000)
NO Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466671-S25246088672012042500000)

Ignition off
Check the accelerator pedal position sensor and engine control module (ECM) connectors. Check for contact resistance. Check for oxidation. Check the signal cable between engine control module (ECM) terminal #B26 (#C26) and accelerator pedal (AP) position sensor terminal #5 (cable harness side). Check for an open-circuit. Check for a short-circuit to ground. Try a new accelerator pedal (AP) position sensor if no fault is found and the fault is permanent. Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000) see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000) see «ACCELERATOR PEDAL»(ref-466672-S34630835312012042500000) see «CONTENTS»(ref-466589-S05251896242012042500000)

Continue Refer to «VERIFICATION»(ref-466671-S21751381422012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off
Reconnect the connectors, reinstall components etc.
Start the engine.
Ignition off
Ignition on. Read off the movement of the accelerator pedal by carefully depressing and releasing the accelerator pedal (AP). Check that the value changes with accelerator pedal movement. The value must be between 5 % (released pedal) and a maximum of 90 % (fully depressed pedal). The function is OK if the value is within this range and follows the pedal movement. The fault has been remedied if the values are OK.

Are these values OK?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S07570812322012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO LOW

see FAULT-TRACING INFORMATION

Therefore, first read off diagnostic trouble codes in Central electronic module (CEM), perform troubleshooting and perform actions as needed. This diagnostic trouble code (DTC) can then be erased.

Ignition on. Activate the read off for the signals for the brake pedal position sensor and stop lamp switch. Check that the value at the brake pedal position sensor is approximately 7% when the brake pedal is unaffected and approximately 80% when the pedal is fully depressed with the engine running. Check also that the stop lamp switch changes status. When the brake pedal is unaffected, "OFF" must be displayed. If the brake pedal is depressed slightly, the status must change to "ON". NOTE: If an incorrect value is obtained from the brake pedal position sensor, the brake control module (BCM) must initially be searched for the fault cause. The fault is intermittent at present if the values and the status from the brake pedal position sensor and the stop lamp switch correspond as above.

Continue Refer to «CHECKING THE POWER SUPPLY»(ref-466671-S13660416602012042500000)

Ignition on. Check the power supply to the stop lamp switch. Take readings between stop lamp switch terminal #2 (cable harness side) and the ground terminal. The power supply must be approximately 12 V. If there is no power supply: Check the power supply circuit for stop lamp switch terminal #2 (cable harness side). Check for an open-circuit. Check for a short-circuit to ground. Check for a blown fuse in the circuit. Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000) see «SIGNAL SPECIFICATION»(ref-466592-S15475582172012042500000) see «STOPLAMP SWITCH»(ref-479181-S37066927572012061200000) see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)

Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466671-S12617392042012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off.
Reconnect the connectors, reinstall components etc.
Ignition on. Activate the read off for the signals for the brake pedal position sensor and stop lamp switch. Check that the value for brake position sensor at unaffected brake pedal is approx. 7% and when the pedal is fully pressed down approx. 80% when the engine is running. Also check that the brake light switch changes status. The status must be OFF with the brake pedal unaffected and change to ON when the brake pedal is pressed. If values and status from the brake position sensor and brake light switch do not match acc. to the above, this indicates incorrect function.

Is the function OK?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S30912018972012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Ignition on. Activate the read off for the signals for the brake pedal position sensor and stop lamp switch. Check that the value at the brake pedal position sensor is approximately 7% when the brake pedal is unaffected and approximately 80% when the pedal is fully depressed with the engine running. Check also that the stop lamp switch changes status. When the brake pedal is unaffected, "OFF" must be displayed. If the brake pedal is depressed slightly, the status must change to "ON". NOTE: If an incorrect value is obtained from the brake pedal position sensor, the brake control module (BCM) must initially be searched for the fault cause. The fault is intermittent at present if the values and the status from the brake pedal position sensor and the stop lamp switch correspond as above.

Continue Refer to «CHECKING THE POWER SUPPLY»(ref-466671-S05373310012012052400000)

Ignition on. Check the power supply to the stop lamp switch. Take readings between stop lamp switch terminal #2 (cable harness side) and the ground terminal. The power supply must be approximately 12 V. If there is no power supply: Check the power supply circuit for stop lamp switch terminal #2 (cable harness side). Check for an open-circuit. Check for a short-circuit to ground. Check for a blown fuse in the circuit. Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000) see «SIGNAL SPECIFICATION»(ref-466592-S26583508152012042500000) see «STOPLAMP SWITCH»(ref-479181-S37066927572012061200000) see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)

Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466671-S06556182312012052400000)

HINT: After carrying out the repair, check that the fault has been remedied.

Ignition off.
Reconnect the connectors, reinstall components etc.
Ignition on. Activate the read off for the signals for the brake pedal position sensor and stop lamp switch. Check that the value for brake position sensor at unaffected brake pedal is approx. 7% and when the pedal is fully pressed down approx. 80% when the engine is running. Also check that the brake light switch changes status. The status must be OFF with the brake pedal unaffected and change to ON when the brake pedal is pressed. If values and status from the brake position sensor and brake light switch do not match acc. to the above, this indicates incorrect function.

Is the function OK?

YES VERIFIED: Troubleshooting has been completed.
NO Refer to «INFORMATION»(ref-466671-S28483264252012052400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Engine Control Module (ECM) Diagnostic Trouble Codes - 8 of 9: Other Volvo V50 I рестайлинг

REPLACING THE CONTROL MODULE

FAULT-TRACING INFORMATION

FAULTY COMMUNICATION

VERIFICATION

Scheme 208

SIGNAL TOO HIGH/FAULTY SIGNAL

CHECKING THE STATUS

INFORMATION

Scheme 209

SIGNAL TOO LOW

SIGNAL TOO HIGH

FAULT-TRACING

INTERNAL FAULT

REPLACING THE COMPONENT

Scheme 210

Scheme 211

Scheme 212

Scheme 213

FAULTY SIGNAL

CHECKING THE THROTTLE UNIT

Scheme 214

Scheme 215

SIGNAL TOO HIGH / SIGNAL TOO LOW

ADAPTATION OF THE THROTTLE UNIT

CHECKING THE FUNCTION

VERIFICATION, CONTINUED

CHECKING THE FAULT STATUS

PROGRAMMING THE ENGINE CONTROL MODULE (ECM)

CHECKING CONNECTORS AND COMPONENTS

Scheme 216

CHECKING THE CONNECTORS AND CABLES

CHECKING THE SIGNAL

CHECKING THE POWER SUPPLY

More articles — Engine Control Module (ECM) Diagnostic Trouble Codes - 8 of 9

Login / Signup

Enter the code

You have successfully logged in!
