Engine Control Module (ECM) Diagnostic Trouble Codes - 5 of 9: Other Volvo V50 I рестайлинг

Testing & Diagnostics 5 illustrations ~10390 words

CHECKING THE STATUS

HINT: If the diagnostic trouble code (DTC) for incorrect camshaft position is stored, fault-tracing for this diagnostic trouble code (DTC) must be carried out first.

Scheme 121

Scheme 121: CHECKING THE STATUS
Scheme 121: CHECKING THE STATUS

Scheme 122

Scheme 122
Scheme 122
  1. Start the engine. Read off the fault status from the camshaft position (CMP) sensor to check whether the fault is permanent or intermittent. The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466658-S34370050232012042500000)

VERIFICATION

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 123

Scheme 123
Scheme 123
  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Read off the fault status of the camshaft position (CMP) sensor. If the function is correct, the camshaft position (CMP) sensor fault status must be "No fault detected".

Has the fault been remedied?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S33814506092012042500000)

FAULT-TRACING INFORMATION

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: If the diagnostic trouble code (DTC) for incorrect camshaft position is stored, fault-tracing for this diagnostic trouble code (DTC) must be carried out first.

  1. Start the engine. Read off the fault status from the camshaft position (CMP) sensor to check whether the fault is permanent or intermittent. The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466658-S29967548872012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Read off the fault status of the camshaft position (CMP) sensor. If the function is correct, the camshaft position (CMP) sensor fault status must be "No fault detected".

Has the fault been remedied?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S05750001742012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine and run it to normal operating temperature
  4. Run the engine to 3500 RPM. Read off the value of the knock sensor (KS) signal. The value must be between 2-6.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S05118566822012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine and run it to normal operating temperature
  4. Run the engine to 3500 RPM. Read off the value of the knock sensor (KS) signal. The value must be between 2-6.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S10803095302012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL TOO HIGH

See SIGNAL TOO HIGH

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine and run it to normal operating temperature
  4. Run the engine to 3500 RPM. Read off the value of the knock sensor (KS) signal. The value must be between 2-6.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S26489009522012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL TOO LOW

See SIGNAL TOO LOW

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine and run it to normal operating temperature
  4. Run the engine to 3500 RPM. Read off the value of the knock sensor (KS) signal. The value must be between 2-6.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S08978406982012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine and run it to normal operating temperature
  4. Run the engine to 3500 RPM. Read off the value of the knock sensor (KS) signal. The value must be between 2-6.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S09084739172012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO HIGH

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine and run it to normal operating temperature
  4. Run the engine to 3500 RPM. Read off the value of the knock sensor (KS) signal. The value must be between 2-6.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S35543490432012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine and run it to normal operating temperature
  4. Run the engine to 3500 RPM. Read off the value of the knock sensor (KS) signal. The value must be between 2-6.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S29429260172012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO LOW

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine and run it to normal operating temperature
  4. Run the engine to 3500 RPM. Read off the value of the knock sensor (KS) signal. The value must be between 2-6.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S35913858822012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

  1. Start the engine to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466658-S17691071052012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. The engine must be at idle speed to perform the diagnostic. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S26972066272012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466658-S24640128152012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. The engine must be at idle speed to perform the diagnostic. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S38019429892012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

  1. Start the engine to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466658-S05392078982012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. The engine must be at idle speed to perform the diagnostic. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S17989247122012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

SIGNAL FAULTY/INTERMITTENT FAULT

See SIGNAL FAULTY/INTERMITTENT FAULT

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

CHECKING THE FUEL INJECTION SYSTEM, IGNITION SYSTEM AND COMPONENTS

Note. In the event of diagnostic trouble codes (DTCs), that affect camshaft control or camshaft reset valve, these must be fault-traced first.

HINT: In certain cases, the engine control module (ECM) can determine which cylinder has misfired.

Check the fuel level in the fuel tank.

Check that the engine oil level is correct.

Look for moisture in the electrical terminals for the ignition coils and in the spark plug wells.

Check the spark plugs. Search for damage in the insulation and other damage.

Check the engine intake system for leakage.

Check the crankcase ventilation. Check for blockage.

Check the fuel pressure and residual pressure.

Check the compression of the engine.

Remedy as necessary.

Other information

  1. see «AIR LEAKS IN THE INTAKE SYSTEM, CHECKING»(ref-479169-S42610968362012061200000)
  2. see «FUEL SYSTEM PRESSURE, CHECKING»(ref-466653-S05384690992012042500000)
  3. see «LEAK DETECTING CYLINDER»(ref-479169-S02149746712012061200000)
  1. Continue Refer to «VERIFICATION»(ref-466658-S02843811062012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Check that the misfire counter is not counting upwards. Check that the engine is firing on all cylinders. NOTE: Misfire can occur at different engine speeds and loads.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S16932414332012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

EMISSIONS IMPACT / CATALYTIC CONVERTER DAMAGE / START UP

See EMISSIONS IMPACT / CATALYTIC CONVERTER DAMAGE / START UP

See EMISSIONS IMPACT / CATALYTIC CONVERTER DAMAGE / START UP

See EMISSIONS IMPACT / CATALYTIC CONVERTER DAMAGE / START UP

See EMISSIONS IMPACT / CATALYTIC CONVERTER DAMAGE / START UP

See EMISSIONS IMPACT / CATALYTIC CONVERTER DAMAGE / START UP

see FAULT-TRACING INFORMATION

  1. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". HINT: In some cases several functions of the component will be diagnosed. This affects the amount of time taken to run the diagnostic. The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-466658-S09724462842012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S22829808632012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL MISSING

See SIGNAL MISSING

See SIGNAL MISSING

See SIGNAL MISSING

  1. Start the engine. Check that the engine is firing on all cylinders.
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466658-S30582449682012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Check that the engine is firing on all cylinders.

Is the engine running on all cylinders?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S27215945862012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine. Check that the engine is firing on all cylinders.
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466658-S35042382392012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Check that the engine is firing on all cylinders.

Is the engine running on all cylinders?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S11873820072012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". HINT: In some cases several functions of the component will be diagnosed. This affects the amount of time taken to run the diagnostic. The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-466658-S36601810172012042500000)

Scheme 124

Scheme 124: CHECKING COMPONENTS AND WIRING
Scheme 124: CHECKING COMPONENTS AND WIRING
  1. Check the connector for the camshaft position (CMP) sensor. Check for contact resistance and oxidation.
  2. Check that the camshaft position (CMP) sensor is correctly installed. Check that neither the camshaft position (CMP) sensor nor the housing is damaged. Damage may affect the position of the sensor in relation to the camshaft rotor.
  3. Check the angle position of the camshafts, i. e. that the camshafts are at the correct position in relation to the crankshaft. HINT: This diagnostic trouble code (DTC) may be caused by a damaged camshaft position (CMP) sensor. Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000) see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000) (2005), or «SIGNAL SPECIFICATION»(ref-466592-S15491428272012042500000) (2006-2007) see «CAMSHAFT POSITION SENSOR (CMP)»(ref-466594-S10328050232012042500000) see «CHECKING WIRING AND TERMINALS»(ref-466589-S05251896242012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466658-S10094786342012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S01853209592012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

FAULTY SIGNAL OR SIGNAL MISSING

See FAULTY SIGNAL OR SIGNAL MISSING

  1. Start the engine and let it idle for approximately 30 seconds to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466658-S34974826082012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine and let it idle for approximately 30 seconds to perform the diagnostic. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S36937889002012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine and let it idle for approximately 30 seconds to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466658-S14297656122012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine and let it idle for approximately 30 seconds to perform the diagnostic. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S40432020322012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine and let it idle for approximately 30 seconds to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466658-S16219310722012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine and let it idle for approximately 30 seconds to perform the diagnostic. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S17415592552012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine and let it idle for approximately 30 seconds to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466658-S15823343502012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine and let it idle for approximately 30 seconds to perform the diagnostic. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S21252847252012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

See FAULTY SIGNAL OR SIGNAL MISSING

See FAULTY SIGNAL OR SIGNAL MISSING

  1. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". HINT: In some cases several functions of the component will be diagnosed. This affects the amount of time taken to run the diagnostic. The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-466658-S30131361312012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S19849328442012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S03020160872012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO HIGH

  1. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". HINT: In some cases several functions of the component will be diagnosed. This affects the amount of time taken to run the diagnostic. The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-466658-S21885520592012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S14707672472012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". HINT: In some cases several functions of the component will be diagnosed. This affects the amount of time taken to run the diagnostic. The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-466658-S30292929642012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S04426087892012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO LOW

  1. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". HINT: In some cases several functions of the component will be diagnosed. This affects the amount of time taken to run the diagnostic. The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-466658-S04081637982012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S06126196092012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See FAULTY SIGNAL OR SIGNAL MISSING

See FAULTY SIGNAL OR SIGNAL MISSING

See FAULTY SIGNAL OR SIGNAL MISSING

  1. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". HINT: In some cases several functions of the component will be diagnosed. This affects the amount of time taken to run the diagnostic. The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-466658-S30567642972012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S21483663682012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". HINT: In some cases several functions of the component will be diagnosed. This affects the amount of time taken to run the diagnostic. The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-466658-S28408364632012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S00826570402012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO HIGH

  1. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". HINT: In some cases several functions of the component will be diagnosed. This affects the amount of time taken to run the diagnostic. The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-466658-S26598287622012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S30085234632012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". HINT: In some cases several functions of the component will be diagnosed. This affects the amount of time taken to run the diagnostic. The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-466658-S03959837362012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S24163992912012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO LOW

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

Note. In the event of diagnostic trouble codes (DTCs), that affect camshaft control or camshaft reset valve, these must be fault-traced first.

HINT: In certain cases, the engine control module (ECM) can determine which cylinder has misfired.

Check the fuel level in the fuel tank.

Check that the engine oil level is correct.

Check for moisture in the electrical terminals for the ignition coils and in the spark plug well.

Check the spark plugs. Search for damage in the insulation and other damage.

Check the engine intake system for air leakage.

Check the crankcase ventilation. Check for blockage.

Check the fuel pressure and residual pressure.

Check the compression of the engine.

Remedy as necessary.

Other information

  1. see «AIR LEAKS IN THE INTAKE SYSTEM, CHECKING»(ref-479169-S42610968362012061200000)
  2. see «FUEL SYSTEM PRESSURE, CHECKING»(ref-466653-S09250258202012042500000)
  3. see «LEAK DETECTING CYLINDER»(ref-479169-S02149746712012061200000)
  1. Continue Refer to «VERIFICATION»(ref-466658-S26048466292012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Check the misfire counter for the cylinder indicated by the diagnostic trouble code (DTC). All cylinders must be checked if the engine control module (ECM) has not detected a misfire in any specific cylinder (misfire in at least one cylinder). The misfire counter must not count upwards and the engine must fire on all cylinders. NOTE: Misfire can occur at different engine speeds and loads.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S32796821352012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Note. In the event of diagnostic trouble codes (DTCs), that affect camshaft control or camshaft reset valve, these must be fault-traced first.

HINT: In certain cases, the engine control module (ECM) can determine which cylinder has misfired.

Check the fuel level in the fuel tank.

Check that the engine oil level is correct.

Check for moisture in the electrical terminals for the ignition coils and in the spark plug well.

Check the spark plugs. Search for damage in the insulation and other damage.

Check the engine intake system for air leakage.

Check the crankcase ventilation. Check for blockage.

Check the fuel pressure and residual pressure.

Check the compression of the engine.

Remedy as necessary.

Other information

  1. see «AIR LEAKS IN THE INTAKE SYSTEM, CHECKING»(ref-479169-S42610968362012061200000)
  2. see «FUEL SYSTEM PRESSURE, CHECKING»(ref-466653-S09250258202012042500000)
  3. see «LEAK DETECTING CYLINDER»(ref-479169-S02149746712012061200000)
  1. Continue Refer to «VERIFICATION»(ref-466658-S17538582692012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Check the misfire counter for the cylinder indicated by the diagnostic trouble code (DTC). All cylinders must be checked if the engine control module (ECM) has not detected a misfire in any specific cylinder (misfire in at least one cylinder). The misfire counter must not count upwards and the engine must fire on all cylinders. NOTE: Misfire can occur at different engine speeds and loads.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S41847160772012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

MISFIRE CYL X

See MISFIRE CYL X

MISFIRE, AT LEAST ONE CYLINDER

See MISFIRE, AT LEAST ONE CYLINDER

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Reinstall the connectors, components etc.
  2. Start the engine. Allow the engine to idle. Check that the engine is firing on all cylinders. If the engine idles unevenly, it is not running on all cylinders

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S11594627192012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Reinstall the connectors, components etc.
  2. Start the engine. Allow the engine to idle. Check that the engine is firing on all cylinders. If the engine idles unevenly, it is not running on all cylinders

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S37785441102012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL MISSING

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Reinstall the connectors, components etc.
  2. Start the engine. Allow the engine to idle. Check that the engine is firing on all cylinders. If the engine idles unevenly, it is not running on all cylinders

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S05981486622012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Reinstall the connectors, components etc.
  2. Start the engine. Allow the engine to idle. Check that the engine is firing on all cylinders. If the engine idles unevenly, it is not running on all cylinders

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S00569613892012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO HIGH

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Reinstall the connectors, components etc.
  2. Start the engine. Allow the engine to idle. Check that the engine is firing on all cylinders. If the engine idles unevenly, it is not running on all cylinders

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S18437843122012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Reinstall the connectors, components etc.
  2. Start the engine. Allow the engine to idle. Check that the engine is firing on all cylinders. If the engine idles unevenly, it is not running on all cylinders

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S14235979832012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO LOW

INFORMATION

The diagnostic trouble code (DTC) is an information trouble code and never occurs alone. Therefore fault-trace for another diagnostic trouble code (DTC).

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S01899232142012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Ignition on. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466658-S27250080122012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S11332719632012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Ignition on. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466658-S05630911212012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S21268727752012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Ignition on. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466658-S23620467932012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S39260450812012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CHECKING COMPONENTS AND CONNECTIONS

  1. The status of the valve can be determined by activating the quick test for the EVAP valve. The test sends pressure pulses through the valve so that the functionality of the valves can be checked. The fault is permanent if a fault is detected in the evaporative emission system (EVAP) valve when running the quick test
  2. Engine idling during the entire test. Activate the evaporative emission system (EVAP) valve quick test. The test takes a few seconds to carry out. The tool displays the ranking value as a value between 0 and 255. The functionality is poor if the value is 128 or higher. Check the hose/hose connectors between the evaporative emission system (EVAP) valve and canister. Check for damage, blockage or pinching. The valve may need to be cleaned or replaced. The functionality is good if the value is below 128. If this is the case, check the hose/hose connectors between the EVAP valve and the intake manifold. Check for damage, blockage or pinching. Note the read ranking value. Remedy as necessary. Other information see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-466647-S29464904412012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466658-S20525700662012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Restart the quick test of the EVAP valve and check the ranking values to establish if the work carried out has remedied the problem
  4. Engine idling during the entire test. Activate the evaporative emission system (EVAP) valve quick test. The test takes a few seconds to carry out. Check that the ranking value is lower than 128, and that it is significantly lower than the previous value. A value below 128 indicates that the fault has been remedied and the function is OK.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S39819082472012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. The status of the valve can be determined by activating the quick test for the EVAP valve. The test sends pressure pulses through the valve so that the functionality of the valves can be checked. The fault is permanent if a fault is detected in the evaporative emission system (EVAP) valve when running the quick test
  2. Engine idling during the entire test. Activate the evaporative emission system (EVAP) valve quick test. The test takes a few seconds to carry out. The tool displays the ranking value as a value between 0 and 255. The functionality is poor if the value is 128 or higher. Check the hose/hose connectors between the evaporative emission system (EVAP) valve and canister. Check for damage, blockage or pinching. The valve may need to be cleaned or replaced. The functionality is good if the value is below 128. If this is the case, check the hose/hose connectors between the EVAP valve and the intake manifold. Check for damage, blockage or pinching. Note the read ranking value. Remedy as necessary. Other information see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-466647-S05486220892012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466658-S34013289832012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Restart the quick test of the EVAP valve and check the ranking values to establish if the work carried out has remedied the problem
  4. Engine idling during the entire test. Activate the evaporative emission system (EVAP) valve quick test. The test takes a few seconds to carry out. Check that the ranking value is lower than 128, and that it is significantly lower than the previous value. A value below 128 indicates that the fault has been remedied and the function is OK.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S31903566402012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Test drive the vehicle and perform a TRIP schedule. See «VERIFYING REPAIRS»(ref-479169-S35307607582012061200000)
  4. Connect VCT2000 (or appropriate scan tool) to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the dynamic for the front heated oxygen sensor (HO2S). The value should be higher than 1.0.

Is the value OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S42655753192012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Test drive the vehicle and perform a TRIP schedule. See «VERIFYING REPAIRS»(ref-479169-S35307607582012061200000)
  4. Connect VCT2000 (or appropriate scan tool) to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the dynamic for the front heated oxygen sensor (HO2S). The value should be higher than 1.0.

Is the value OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S34676661222012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING INFORMATION

No fault-tracing has been developed for this diagnostic trouble code (DTC). The diagnostic trouble code (DTC) for this fault is stored first in the central electronic module (CEM), then in the engine control module (ECM). This diagnostic trouble code (DTC) can not be erased before the diagnostic trouble codes (DTC) in the central electronic module (CEM) has been remedied and erased.

First read off the diagnostic trouble codes (DTCs) in the central electronic module (CEM). Fault-trace and remedy as necessary. This diagnostic trouble code (DTC) can then be erased.

CHECKING STATUS

  1. Ignition on. Check whether the fault is permanent or intermittent by reading the signal from the fuel level sensor (via the central electronic module (CEM)) and checking that it is within its permitted range. Also check that it moves if the car is rocked gently, before stabilizing at a reasonable level. An incorrect signal indicates that the fault is permanent. The fault is intermittent if the signal is within the permitted range. HINT: If the tank is completely full, their may be no noticeable change in level if the car is rocked.
  1. Continue Refer to «CHECKING CONNECTOR»(ref-466658-S08625047262012042500000)

CHECKING CONNECTOR

Check the fuel level sensor connector and terminals. Check for contact resistance. Check for oxidation.

Remedy as necessary.

Other information

  1. see «LEVEL SENSOR FUEL TANK»(ref-466610-S10542753632012042500000) (B5244S4), or «LEVEL SENSOR FUEL TANK»(ref-466610-S10672489782012042500000) (B5244S7)
  2. see «CHECKING WIRING AND TERMINALS»(ref-466589-S05251896242012042500000)

Scheme 125

Scheme 125
Scheme 125
  1. Continue Refer to «VERIFICATION»(ref-466658-S32488449412012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Read off the signal from the fuel level sensor (via the central electronic module (CEM)). Check that the signal is within its permitted range. The level should change if the car is rocked gently, before stabilizing to a reasonable level. A reasonable signal indicates that the fault has been remedied. HINT: If the tank is completely full, their may be no noticeable change in level if the car is rocked.

Is the signal within its permitted range?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S36369863212012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CHECKING COMPONENTS

Check the exhaust system for air leakage.

Remedy as necessary.

Note. Try a new catalytic converter if the above fault-tracing does not remedy the fault.

Other information

  1. see «AIR LEAKAGE EXHAUST SYSTEM, CHECK»(ref-479169-S27670670192012061200000)
  2. see «CATALYTIC CONVERTER»(ref-466651-S09894321312012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466658-S32680983492012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Test drive the car and perform a TRIP schedule, see: «VERIFYING REPAIRS»(ref-479169-S35307607582012061200000)
  2. Connect VCT2000 (or appropriate scan tool) to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S05979351662012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

OPEN

See OPEN

CHECKING THE COMPONENT

  1. Slacken off the evaporative emission system (EVAP) valve
  2. Connect a vacuum pump to the evaporative emission system (EVAP) valve terminal (B). Pump a vacuum. Check that there is no leakage through the evaporative emission system (EVAP) valve by listening to and checking via the pump gauge that the pressure is stable
  3. Connect the Evaporative emission system (EVAP) valve connector
  4. Ignition on
  5. Activate the evaporative emission system (EVAP) valve. When the Evaporative emission system (EVAP) valve is activated, the valve opens and clicks. Check on the pump gauge that the vacuum drops (the pressure evens out) when the evaporative emission system (EVAP) valve opens. If the function is OK, there must be no leakage when the evaporative emission system (EVAP) valve is closed (stable pressure on the pump gauge) and the vacuum must drop when the evaporative emission system (EVAP) valve opens (the pressure evens out). The evaporative emission system (EVAP) valve is damaged if the function is faulty. If the function of the Evaporative emission system (EVAP) valve is OK, check: The hose and hose terminals between the Evaporative emission system (EVAP) valve and the intake manifold. Check for leakage and blockages Check the hose and hose terminals between the EVAP canister and the Evaporative emission system (EVAP) valve. Check for leakage and blockages. Remedy as necessary. Other information see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-466647-S22119310112012042500000) see «CHARCOAL FILTER»(ref-466648-S39982519822012042500000)
  1. Continue Refer to «INFORMATION»(ref-466658-S14407670352012042500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

CLOSED

See CLOSED

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the evaporative emission system (EVAP) valve. A click should be heard when the evaporative emission system (EVAP) valve is activated.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S08068783262012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL MISSING

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the evaporative emission system (EVAP) valve. A click should be heard when the evaporative emission system (EVAP) valve is activated.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S42653616182012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO HIGH

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the evaporative emission system (EVAP) valve. A click should be heard when the evaporative emission system (EVAP) valve is activated.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-466658-S17457469012012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO LOW

After this fault tracing, verification is carried out by starting the quick tank system test.

The information can be displayed again or fault-tracing this fault can be interrupted.

FUEL TANK FILLER CAP MISSING

See FUEL TANK FILLER CAP MISSING

CHECKING SOFTWARE

  1. Ignition on. Use the VCT2000 (or appropriate scan tool) to start the read out and check the software version in the Engine control module (ECM).
  1. Continue Refer to «CHECKING THE WIRING»(ref-466658-S20449953132012042500000)

After this fault tracing, verification is carried out by starting the quick tank system test.

The information can be displayed again or fault-tracing this fault can be interrupted.

  1. Ignition on. Use the VCT2000 (or appropriate scan tool) to start the read out and check the software version in the Engine control module (ECM).
  1. Continue Refer to «CHECKING THE WIRING»(ref-466658-S17379410342012042500000)

After this fault tracing, verification is carried out by starting the quick tank system test.

The information can be displayed again or fault-tracing this fault can be interrupted.

  1. Ignition on. Use the VCT2000 (or appropriate scan tool) to start the read out and check the software version in the Engine control module (ECM).
  1. Continue Refer to «CHECKING THE WIRING»(ref-466658-S18209000452012042500000)

After this fault tracing, verification is carried out by starting the quick tank system test.

The information can be displayed again or fault-tracing this fault can be interrupted.

  1. Ignition on. Use the VCT2000 (or appropriate scan tool) to start the read out and check the software version in the Engine control module (ECM).
  1. Continue Refer to «CHECKING THE WIRING»(ref-466658-S01311914992012042500000)

After this fault tracing, verification is carried out by starting the quick tank system test.

The information can be displayed again or fault-tracing this fault can be interrupted.

  1. Ignition on. Use the VCT2000 (or appropriate scan tool) to start the read out and check the software version in the Engine control module (ECM). NOTE: More instructions follow together with the read out.
  1. Continue Refer to «INFORMATION»(ref-466658-S36933062282012042500000)

After this fault tracing, verification is carried out by starting the quick tank system test.

The information can be displayed again or fault-tracing this fault can be interrupted.

Fault-tracing is not followed by verification for this fault.

HINT: After the diagnostic trouble codes (DTCs) are erased, the function of the leak diagnostic unit can be checked by running a quick test of the fuel tank system in the vehicle communication socket. If there is a fault, the fault status will be "FAULT FOUND" on the leak diagnostic unit.

The information can be displayed again or fault-tracing this fault can be interrupted.

Fault-tracing is not followed by verification for this fault.

HINT: After the diagnostic trouble codes (DTCs) are erased, the function of the leak diagnostic unit can be checked by running a quick test of the fuel tank system in the vehicle communication socket. If there is a fault, the fault status will be "FAULT FOUND" on the leak diagnostic unit.

The information can be displayed again or fault-tracing this fault can be interrupted.

See SIGNAL MISSING

Fault-tracing is not followed by verification for this fault.

HINT: After the diagnostic trouble codes (DTCs) are erased, the function of the leak diagnostic unit can be checked by running a quick test of the fuel tank system in the vehicle communication socket. If there is a fault, the fault status will be "FAULT FOUND" on the leak diagnostic unit.

The information can be displayed again or fault-tracing this fault can be interrupted.

Fault-tracing is not followed by verification for this fault.

HINT: After the diagnostic trouble codes (DTCs) are erased, the function of the leak diagnostic unit can be checked by running a quick test of the fuel tank system in the vehicle communication socket. If there is a fault, the fault status will be "FAULT FOUND" on the leak diagnostic unit.

The information can be displayed again or fault-tracing this fault can be interrupted.

More articles — Engine Control Module (ECM) Diagnostic Trouble Codes - 5 of 9
