Engine Control Module (ECM) Diagnostic Trouble Codes - 2 of 9: Other Volvo V50 I рестайлинг

CHECKING COMPONENTS

Check the rear heated oxygen sensor (HO2S) connector. Check for contact resistance and oxidation.

Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.

Remedy as necessary.

Other information

1. see «SIGNAL SPECIFICATION»(ref-466592-S15475582172012042500000)
2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-466651-S32701656862012042500000)
3. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)

Scheme 51

Scheme 52

1. Continue Refer to «VERIFICATION»(ref-466654-S04173419542012042500000)

VERIFICATION

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 53

Scheme 54

1. Test drive the car and ensure that there is a fuel shut-off. The easiest way to do this is to drive at approximately 80 km/h and abruptly release the accelerator pedal (AP) for at least 5 seconds
2. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S29429393242012042500000)

FAULT-TRACING INFORMATION

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check the rear heated oxygen sensor (HO2S) connector. Check for contact resistance and oxidation.

Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.

Remedy as necessary.

Other information

1. see «SIGNAL SPECIFICATION»(ref-466592-S26583508152012042500000)
2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-466651-S32701656862012042500000)
3. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)

1. Continue Refer to «VERIFICATION»(ref-466654-S15375005392012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Test drive the car and ensure that there is a fuel shut-off. The easiest way to do this is to drive at approximately 80 km/h and abruptly release the accelerator pedal (AP) for at least 5 seconds
2. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S14908133992012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine to perform the diagnostic. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S33725319482012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CHECKING THE STATUS

1. Start the engine. Allow the engine to idle for approximately 3-5 minutes to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".

1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466654-S28862431712012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine to perform the diagnostic. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S39618490752012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine. Allow the engine to idle for approximately 3-5 minutes to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".

1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466654-S09224034352012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine to perform the diagnostic. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S37587432182012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine. Allow the engine to idle for approximately 3-5 minutes to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".

1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466654-S17493377532012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine to perform the diagnostic. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S00710555382012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check the rear heated oxygen sensor (HO2S) connector. Check for contact resistance and oxidation.

Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.

Remedy as necessary.

Other information

1. see «SIGNAL SPECIFICATION»(ref-466592-S26583508152012042500000)
2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-466651-S32701656862012042500000)
3. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)

1. Continue Refer to «VERIFICATION»(ref-466654-S07320460442012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Test drive the car and ensure that there is a fuel shut-off. The easiest way to do this is to drive at approximately 80 km/h and abruptly release the accelerator pedal (AP) for at least 5 seconds
2. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S36299793952012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING INFORMATION

1. The ignition must be on to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".

1. Continue Refer to «CHECKING COMPONENTS»(ref-466654-S14500002732012042500000)

Check the heated oxygen sensor (HO2S) connector. Check for contact resistance and oxidation

Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.

Remedy as necessary.

Other information

1. see «SIGNAL SPECIFICATION»(ref-466592-S15475582172012042500000)
2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-466651-S32701656862012042500000)
3. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)

1. Continue Refer to «VERIFICATION»(ref-466654-S06258334362012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. The ignition must be on to perform the diagnostic. NOTE: The battery voltage must be between 11-16V in order to obtain a correct reading. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S04458944992012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. The ignition must be on to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".

1. Continue Refer to «CHECKING COMPONENTS»(ref-466654-S31405859352012042500000)

Check the heated oxygen sensor (HO2S) connector. Check for contact resistance and oxidation

Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.

Remedy as necessary.

Other information

1. see «SIGNAL SPECIFICATION»(ref-466592-S26583508152012042500000)
2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-466651-S32701656862012042500000)
3. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)

1. Continue Refer to «VERIFICATION»(ref-466654-S09962562972012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. The ignition must be on to perform the diagnostic. NOTE: The battery voltage must be between 11-16V in order to obtain a correct reading. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S42166219592012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. The ignition must be on to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".

1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466654-S39579238332012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. The ignition must be on to perform the diagnostic. NOTE: The battery voltage must be between 11-16V in order to obtain a correct reading. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S19213696372012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. The ignition must be on to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".

1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466654-S37079152002012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. The ignition must be on to perform the diagnostic. NOTE: The battery voltage must be between 11-16V in order to obtain a correct reading. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S10232930032012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. The ignition must be on to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".

1. Continue Refer to «CHECKING FUSES»(ref-466654-S18290526162012042500000)

CHECKING FUSES

All heated oxygen sensors are supplied with voltage with the same lead. If the lead is damaged, e. g., fuse on the lead, then diagnostic code for heating for all heated oxygen sensors will be stored.

Therefore, check first if diagnostic trouble codes for heating are also stored for other heated oxygen sensors.

HINT: Brake vacuum pump is supplied with voltage via the same lead as the heated oxygen sensors. A damaged brake vacuum contact can lead to the pump running continuously and in the long-term be overheated and damaged. In turn, this leads to damaged fuse.

HINT: Therefore, check the brake vacuum switch and pump before any continued troubleshooting is done on the heated oxygen sensors.

1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466654-S32363043602012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. The ignition must be on to perform the diagnostic. NOTE: The battery voltage must be between 11-16V in order to obtain a correct reading. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S15493974732012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. The ignition must be on to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".

1. Continue Refer to «CHECKING FUSES»(ref-466654-S29709894422012042500000)

All heated oxygen sensors are supplied with voltage with the same lead. If the lead is damaged, e. g., fuse on the lead, then diagnostic code for heating for all heated oxygen sensors will be stored.

Therefore, check first if diagnostic trouble codes for heating are also stored for other heated oxygen sensors.

HINT: Brake vacuum pump is supplied with voltage via the same lead as the heated oxygen sensors. A damaged brake vacuum contact can lead to the pump running continuously and in the long-term be overheated and damaged. In turn, this leads to damaged fuse.

HINT: Therefore, check the brake vacuum switch and pump before any continued troubleshooting is done on the heated oxygen sensors.

1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-466654-S15550862072012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. The ignition must be on to perform the diagnostic. NOTE: The battery voltage must be between 11-16V in order to obtain a correct reading. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S20954666062012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Start the engine. Allow the engine to idle for at least 1 minute
4. Test drive the car at an even speed (approximately 80 km/h for at least 5 minutes)
5. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S24997864652012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL TOO HIGH/SIGNAL TOO LOW/SIGNAL MISSING

See SIGNAL TOO HIGH/SIGNAL TOO LOW/SIGNAL MISSING

See SIGNAL TOO HIGH/SIGNAL TOO LOW/SIGNAL MISSING

See SIGNAL TOO HIGH/SIGNAL TOO LOW/SIGNAL MISSING

See SIGNAL TOO HIGH/SIGNAL TOO LOW/SIGNAL MISSING

See SIGNAL TOO HIGH/SIGNAL TOO LOW/SIGNAL MISSING

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Start the engine and run it until the engine coolant temperature exceeds 60 °C
4. Switch off the engine and allow it to cool (below 40 °C)
5. Test drive the car on the road (engine speed (RPM) above 2000 RPM, never idling) for at least 15 minutes
6. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S38487698562012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

FAULTY SIGNAL

See FAULTY SIGNAL

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Start the engine and run it until the engine coolant temperature exceeds 60 °C
4. Switch off the engine and allow it to cool (below 40 °C)
5. Test drive the car on the road (engine speed (RPM) above 2000 RPM, never idling) for at least 15 minutes
6. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S29585157982012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Start the engine and run it until the engine coolant temperature exceeds 60 °C
4. Switch off the engine and allow it to cool (below 40 °C)
5. Test drive the car on the road (engine speed (RPM) above 2000 RPM, never idling) for at least 15 minutes
6. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S05417581822012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Start the engine and run it until the engine coolant temperature exceeds 60 °C
4. Switch off the engine and allow it to cool (below 40 °C)
5. Test drive the car on the road (engine speed (RPM) above 2000 RPM, never idling) for at least 15 minutes
6. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S10956029622012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL MISSING

See SIGNAL MISSING

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Start the engine and run it until the engine coolant temperature exceeds 60 °C
4. Switch off the engine and allow it to cool (below 40 °C)
5. Test drive the car on the road (engine speed (RPM) above 2000 RPM, never idling) for at least 15 minutes
6. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S09801198612012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Start the engine and run it until the engine coolant temperature exceeds 60 °C
4. Switch off the engine and allow it to cool (below 40 °C)
5. Test drive the car on the road (engine speed (RPM) above 2000 RPM, never idling) for at least 15 minutes
6. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S00746840212012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL TOO HIGH

See SIGNAL TOO HIGH

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Start the engine and run it until the engine coolant temperature exceeds 60 °C
4. Switch off the engine and allow it to cool (below 40 °C)
5. Test drive the car on the road (engine speed (RPM) above 2000 RPM, never idling) for at least 15 minutes
6. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S37139107042012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Start the engine and run it until the engine coolant temperature exceeds 60 °C
4. Switch off the engine and allow it to cool (below 40 °C)
5. Test drive the car on the road (engine speed (RPM) above 2000 RPM, never idling) for at least 15 minutes
6. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S39993187642012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL TOO LOW

See SIGNAL TOO LOW

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Start the engine
4. Run the engine at idle speed for at least 1 minute. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S29919517182012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL MISSING

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Start the engine
4. Run the engine at idle speed for at least 1 minute. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S21938674782012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO HIGH

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Start the engine
4. Run the engine at idle speed for at least 1 minute. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S37235967112012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO LOW

INFORMATION

This diagnostic trouble code is a collective code for diagnoses regarding electrical malfunctions on the heated oxygen sensor and its heating.

The diagnostic trouble code never appears alone. Therefore, troubleshooting takes place from another diagnostic trouble code for electric fault on rear heated oxygen sensor.

For further information on this diagnostic trouble code, see Diagnostic trouble code (DTC) information.

1. Ignition on. Activate the injector that relates to the diagnostic trouble code (DTC) to check whether the fault is permanent or intermittent. The fault is intermittent if the injector clicks when activated. The fault is permanent if the injector does not click when activated.

1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466654-S09940782882012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Activate the injector that relates to the diagnostic trouble code (DTC). A "click" should be heard when the injector is activated.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S35062843612012042500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

1. Ignition on. Activate the injector that relates to the diagnostic trouble code (DTC) to check whether the fault is permanent or intermittent. The fault is intermittent if the injector clicks when activated. The fault is permanent if the injector does not click when activated.

1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466654-S40580780122012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Activate the injector that relates to the diagnostic trouble code (DTC). A "click" should be heard when the injector is activated.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S02376941952012042500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

CHECKING THE CONNECTOR

Check the connector for the rear heated oxygen sensor (HO2S). Check for contact resistance and oxidation. Remedy if necessary.

Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.

Other information

1. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-466651-S03920303172012042500000)
2. see «CHECKING WIRING AND TERMINALS»(ref-466589-S05251896242012042500000)

1. Continue Refer to «VERIFICATION»(ref-466654-S13403284472012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Start the engine. Allow the engine to idle for at least 1 minute
4. Test drive the car at an even speed (approximately 80 km/h for at least 5 minutes)
5. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S17972653262012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See FAULTY SIGNAL

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Start the engine. Allow the engine to idle for at least 1 minute
4. Test drive the car at an even speed (approximately 80 km/h for at least 5 minutes)
5. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S02765232312012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO HIGH/SIGNAL TOO LOW/SIGNAL MISSING

See SIGNAL TOO HIGH/SIGNAL TOO LOW/SIGNAL MISSING

See SIGNAL TOO HIGH/SIGNAL TOO LOW/SIGNAL MISSING

See SIGNAL TOO HIGH/SIGNAL TOO LOW/SIGNAL MISSING

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Test drive the vehicle and perform a TRIP schedule. See «VERIFYING REPAIRS»(ref-479169-S35307607582012061200000)
4. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the dynamic for the front heated oxygen sensor (HO2S). The value should be higher than 1.0.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S29424674692012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL MISSING

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Test drive the vehicle and perform a TRIP schedule. See «VERIFYING REPAIRS»(ref-479169-S35307607582012061200000)
4. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the dynamic for the front heated oxygen sensor (HO2S). The value should be higher than 1.0.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S36099397862012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Allow the engine to cool (below 40 °C). Then start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S14695637832012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL MISSING

See SIGNAL TOO HIGH/SIGNAL TOO LOW/SIGNAL MISSING

See SIGNAL TOO HIGH/SIGNAL TOO LOW/SIGNAL MISSING

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Test drive the car at an even speed (engine speed (RPM) above 2000 RPM) for at least 5 minutes. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S07712191412012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL MISSING

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Test drive the car at an even speed (engine speed (RPM) above 2000 RPM) for at least 5 minutes. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S08494642362012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO HIGH

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Test drive the car at an even speed (engine speed (RPM) above 2000 RPM) for at least 5 minutes. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S20399922802012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO LOW

INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Test drive the car at an even speed (engine speed (RPM) above 2000 RPM) for at least 5 minutes. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S11284339882012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Test drive the car at an even speed (engine speed (RPM) above 2000 RPM) for at least 5 minutes. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S37721560422012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL MISSING

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Test drive the car at an even speed (engine speed (RPM) above 2000 RPM) for at least 5 minutes
4. Release the accelerator pedal (AP) quickly at least three times to simulate fuel shut-off
5. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S37385556312012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Test drive the car at an even speed (engine speed (RPM) above 2000 RPM) for at least 5 minutes
4. Release the accelerator pedal (AP) quickly at least three times to simulate fuel shut-off
5. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S20857931202012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

FAULT-TRACING

See FAULT-TRACING

See FAULT-TRACING

SIGNAL TOO HIGH / SIGNAL MISSING / FAULTY SIGNAL

See SIGNAL TOO HIGH / SIGNAL MISSING / FAULTY SIGNAL

See FAULT-TRACING

See FAULT-TRACING

See SIGNAL TOO HIGH / SIGNAL MISSING / FAULTY SIGNAL

See FAULT-TRACING

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Test drive the car at an even speed (engine speed (RPM) above 2000 RPM) for at least 5 minutes
4. Release the accelerator pedal (AP) quickly at least three times to simulate fuel shut-off
5. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S16301526692012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO HIGH

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Test drive the car at an even speed (engine speed (RPM) above 2000 RPM) for at least 5 minutes
4. Release the accelerator pedal (AP) quickly at least three times to simulate fuel shut-off
5. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S00532591622012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL TOO LOW

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Test drive the car at an even speed (engine speed (RPM) above 2000 RPM) for at least 5 minutes
4. Release the accelerator pedal (AP) quickly at least three times to simulate fuel shut-off
5. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S13217653112012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Test drive the car at an even speed (engine speed (RPM) above 2000 RPM) for at least 5 minutes
4. Release the accelerator pedal (AP) quickly at least three times to simulate fuel shut-off
5. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S41566634932012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL MISSING

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Test drive the car at an even speed (engine speed (RPM) above 2000 RPM) for at least 5 minutes
4. Release the accelerator pedal (AP) quickly at least three times to simulate fuel shut-off
5. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S21735456372012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Test drive the car at an even speed (engine speed (RPM) above 2000 RPM) for at least 5 minutes
4. Release the accelerator pedal (AP) quickly at least three times to simulate fuel shut-off
5. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S28824077922012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL MISSING

Check the exhaust system for air leakage

Check the cable for a short-circuit to supply voltage or ground.

Check between

1. The cable between engine control module (ECM) terminal #A93 (#B33) and heated oxygen sensor (HO2S) terminal #5
2. The cable for pump current between engine control module (ECM) terminal #A70 (#B10) and heated oxygen sensor (HO2S) terminal #6
3. The cable for calibration current between engine control module (ECM) terminal #B94 (#B34) and heated oxygen sensor (HO2S) terminal #2.

Check the cable between engine control module (ECM) terminal #A69 (#B9) and heated oxygen sensor (HO2S) terminal #1. Check for an open-circuit.

HINT: If the above fault-tracing does not remedy the fault, try replacing the heated oxygen sensors (HO2S), as the diagnostic trouble code (DTC) can also be stored by a defective front/rear heated oxygen sensor (HO2S).

Remedy as necessary.

Other information

1. see «AIR LEAKAGE EXHAUST SYSTEM, CHECK»(ref-479169-S27670670192012061200000)
2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-466651-S03920303172012042500000)
3. see «CHECKING WIRING AND TERMINALS»(ref-466589-S05251896242012042500000)

1. Continue Refer to «VERIFICATION»(ref-466654-S38981021282012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Reinstall the connectors, components etc.
2. Test drive the car at an even speed (engine speed (RPM) above 2000 RPM) for at least 10 minutes
3. Release the accelerator pedal (AP) quickly at least three times to simulate fuel shut-off
4. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read out the deviation between the front and rear heated oxygen sensor (HO2S). Check that the value is between -0.03 and +0.03.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S17681035162012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check the exhaust system for air leakage

Check the cable for a short-circuit to supply voltage or ground.

Check between

1. Engine control module (ECM) #A91 (#B31) and lambda probe #5.
2. Engine control module (ECM) #A68 (#B8) and lambda probe #6 (wiring for pump current).
3. Engine control module (ECM) #A92 (#B32) and lambda probe #2 (wiring for calibration current).

Check the cable for an open-circuit.

Check between

1. Engine control module (ECM) #A67 (#B7) and lambda probe #1.

HINT: If the above fault-tracing does not remedy the fault, try replacing the heated oxygen sensors (HO2S), as the diagnostic trouble code (DTC) can also be stored by a defective front/rear heated oxygen sensor (HO2S).

Remedy as necessary.

Other information

1. see «AIR LEAKAGE EXHAUST SYSTEM, CHECK»(ref-479169-S27670670192012061200000)
2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-466651-S03920303172012042500000)
3. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)

1. Continue Refer to «VERIFICATION»(ref-466654-S35912828882012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Reinstall the connectors, components etc.
2. Test drive the car at an even speed (engine speed (RPM) above 2000 RPM) for at least 10 minutes
3. Release the accelerator pedal (AP) quickly at least three times to simulate fuel shut-off
4. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read out the deviation between the front and rear heated oxygen sensor (HO2S). Check that the value is between -0.03 and +0.03.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S11303355712012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See FAULTY SIGNAL

Check the connectors for the heated oxygen sensors (HO2S). Check for contact resistance. Check for oxidation.

Check the exhaust system for air leakage.

HINT: If the above fault-tracing does not remedy the fault, try replacing the heated oxygen sensors (HO2S), as the diagnostic trouble code (DTC) can also be stored by a defective front/rear heated oxygen sensor (HO2S).

Remedy as necessary.

Other information

1. see «AIR LEAKAGE EXHAUST SYSTEM, CHECK»(ref-479169-S27670670192012061200000)
2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-466651-S03920303172012042500000)
3. see «CHECKING WIRING AND TERMINALS»(ref-466589-S05251896242012042500000)

1. Continue Refer to «VERIFICATION»(ref-466654-S19198212302012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Reinstall the connectors, components etc.
2. Test drive the car at an even speed (engine speed (RPM) above 2000 RPM) for at least 10 minutes
3. Release the accelerator pedal (AP) quickly at least three times to simulate fuel shut-off
4. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read out the deviation between the front and rear heated oxygen sensor (HO2S). Check that the value is between -0.03 and +0.03.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S18065142152012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See SIGNAL MISSING

Check the exhaust system for air leakage

HINT: If the above fault-tracing does not remedy the fault, try replacing the heated oxygen sensors (HO2S), as the diagnostic trouble code (DTC) can also be stored by a defective front/rear heated oxygen sensor (HO2S).

Remedy as necessary.

Other information

1. see «AIR LEAKAGE EXHAUST SYSTEM, CHECK»(ref-479169-S27670670192012061200000)
2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-466651-S03920303172012042500000)

1. Continue Refer to «VERIFICATION»(ref-466654-S30709779892012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Reinstall the connectors, components etc.
2. Test drive the car at an even speed (engine speed (RPM) above 2000 RPM) for at least 10 minutes
3. Release the accelerator pedal (AP) quickly at least three times to simulate fuel shut-off
4. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read out the deviation between the front and rear heated oxygen sensor (HO2S). Check that the value is between -0.03 and +0.03.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S02222588022012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL TOO HIGH / SIGNAL TOO LOW

See SIGNAL TOO HIGH / SIGNAL TOO LOW

See SIGNAL TOO HIGH / SIGNAL TOO LOW

See SIGNAL TOO HIGH / SIGNAL TOO LOW

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Test drive the car at an even speed (engine speed (RPM) above 2000 RPM) for at least 5 minutes
4. Release the accelerator pedal (AP) quickly at least three times to simulate fuel shut-off
5. Connect VCT2000 or appropriate scan tool to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S37076283412012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See FAULTY SIGNAL

CHECKING THE CONNECTORS

Check the rear heated oxygen sensor's connectors for contact resistance and oxidation and rectify.

Try a new rear heated oxygen sensor if the above measure does not remedy the fault.

Other information

1. see «SIGNAL SPECIFICATION»(ref-466592-S15491428272012042500000)
2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-466651-S03920303172012042500000)
3. see «CHECKING WIRING AND TERMINALS»(ref-466589-S05251896242012042500000)

1. Continue Refer to «VERIFICATION»(ref-466654-S24018201252012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, components, etc.
3. Start the engine and allow it to idle for approx. 1 minute. Increase the engine speed to approx. 4000 RPM a few times.
4. Read the diagnostic status and fault status for the diagnostic trouble code by selecting the diagnostic trouble code in the list. HINT: When the scan status does not change to "Implemented", a test drive is necessary for the scan to be implemented.
5. Test drive the vehicle at a constant speed of about 80 kph for at least 5 minutes.
6. Release the accelerator quickly, at least three times, to produce fuel shut-off.
7. Perform heavy braking at least once.
8. Connect VCT2000 or appropriate scan tool to the data link connector without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Check the fault status for the diagnostic trouble code when the scan is "Implemented". When the function is correct the fault status should be "No fault found" when the scan is implemented.

Is the function OK?

1. YES Refer to «INFORMATION»(ref-466654-S25106145732012042500000)
2. NO VERIFICATION FAILED: The fault should have been detected and remedied. As this is not the case fault-tracing has failed. Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SLOW CONTROL

See SLOW CONTROL

See SLOW CONTROL

See SLOW CONTROL

PREPARATORY CHECKS

Check and note which adaptation range is incorrect. Scroll through the list of adaptation ranges.

The adaptation value is considered outside normal range if it is lower than 0.85 (engine runs rich) or higher than 1.15 (engine runs lean).

HINT: The ranges consist of a table where the first digit in the name designates the engine speed range and the second the loading range. Range 1.1 designates a case with low engine speed and with low loading. Range 6.6 designates a case with high engine speed and with high loading.

1. Continue Refer to «CHECKING THE SYSTEM»(ref-466654-S24469643382012042500000)

Scheme 55

1. Engine running. Check and compare the calculated air mass with the actual, read-out from mass air flow sensor. Try measuring at different speeds (RPM). HINT: Differences of more than 20 % between the signals indicate a defective mass air flow sensor. Remedy as necessary. NOTE: When replacing mass air flow sensor. Repeat the check to verify that the replacement solved the problem. For more information about current fuel compensation. Refer to «READ-OUT OF TOTAL FUEL COMPENSATION»(ref-466654-S39661062182012042500000) To continue with resetting adaptation. Refer to «RESETTING ADAPTATION»(ref-466654-S29795302642012042500000)

READ-OUT OF TOTAL FUEL COMPENSATION

1. Engine running.
2. Use VIDA or appropriate scan tool for read-out of total fuel compensation at every given moment. HINT: The read-out value shows the short term fuel trims's and the long term fuel trim's total compensation of injection time in real-time. Positive values indicate addition of fuel. Negative values indicate reduction of fuel. Try measuring at different speeds (RPM) with different engine loading. NOTE: Keep in mind that the EVAP-valve's addition of fuel vapors affects the read-out. Squeeze the hose between the EVAP-valve and inlet pipe to minimize the addition of fuel from the EVAP-system.

1. Continue Refer to «RESETTING ADAPTATION»(ref-466654-S29795302642012042500000)

START ADAPTATIONS

Test-drive the vehicle on road and drive a little in different operating situations for 20 minutes, in order to complete as many adaptations as possible.

Check and note if any adaptation range is still incorrect. Scroll through the list of adaptation ranges.

The adaptation value is considered outside normal range if it is lower than 0.85 (engine runs rich) or higher than 1.15 (engine runs lean).

HINT: Also accelerate at full throttle a number of times to implement the adaptations that are not influenced by normal driving.

For adaptation to start, certain conditions must be fulfilled

1. The engine speed is above 600 RPM.
2. Engine temperature between 80-110°C.
3. Fuel trim active = executed.
4. EVAP-valve not active = 0 μs.

HINT: If fuel vaporization is high, the evaporative emission system (EVAP) valve is active for long periods. In this case, it may be necessary to disconnect the hose between the evaporative emission system (EVAP) valve and the EVAP canister.

Are these values OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S12197887052012042500000)

CHECKING THE SYSTEM

HINT: If fuel adaptations indicate too rich fuel/air mixture (adaptation value below 1.0) in several adaptation ranges, this indicates a fuel malfunction. The cause may be too high fuel pressure.

To investigate what the problem is due to, perform the following

1. Check that the oil level is between the minimum and maximum markings HINT: Adaptations may show rich fuel/air mixture if several short drives have taken place and the engine oil thus has been contaminated by gasoline.
2. Check the EVAP-valve for leakage. HINT: A leaking valve gives a constant contribution of fuel vapors that affect the adaptations.
3. Engine running.
4. Check the fuel pressure for high fuel pressure.
5. Ignition on.
6. Check the residual pressure with regards to too low residual pressure.

Remedy as necessary.

HINT: If the residual pressure is too low, leaking injection valves may be the cause.

Other information

1. see «FUEL SYSTEM PRESSURE, CHECKING»(ref-466653-S09250258202012042500000)

1. Continue Refer to «CHECKING THE MASS AIR FLOW (MAF) SENSOR»(ref-466654-S34918649302012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check and note which adaptation range is incorrect. Scroll through the list of adaptation ranges.

The adaptation value is considered outside normal range if it is lower than 0.85 (engine runs rich) or higher than 1.15 (engine runs lean).

HINT: The ranges consist of a table where the first digit in the name designates the engine speed range and the second the loading range. Range 1.1 designates a case with low engine speed and with low loading. Range 6.6 designates a case with high engine speed and with high loading.

1. Continue Refer to «CHECKING ETHANOL CONTENT»(ref-466654-S01252009212012042500000)

CHECKING THE MASS AIR FLOW (MAF) SENSOR

1. Engine running. Check and compare the calculated air mass with the actual, read-out from mass air flow sensor. Try measuring at different speeds (RPM). HINT: Differences of more than 20 % between the signals indicate a defective mass air flow sensor. Remedy as necessary. NOTE: When replacing mass air flow sensor. Repeat the check to verify that the replacement solved the problem. For more information about current fuel compensation. Refer to «READ-OUT OF TOTAL FUEL COMPENSATION»(ref-466654-S42134716282012042500000) To continue with resetting adaptation. Refer to «RESETTING ADAPTATION»(ref-466654-S27085108462012042500000)

1. Engine running.
2. Use VIDA or appropriate scan tool for read-out of total fuel compensation at every given moment. HINT: The read-out value shows the short term fuel trims's and the long term fuel trim's total compensation of injection time in real-time. Positive values indicate addition of fuel. Negative values indicate reduction of fuel. Try measuring at different speeds (RPM) with different engine loading. NOTE: Keep in mind that the EVAP-valve's addition of fuel vapors affects the read-out. Squeeze the hose between the EVAP-valve and inlet pipe to minimize the addition of fuel from the EVAP-system.

1. Continue Refer to «RESETTING ADAPTATION»(ref-466654-S27085108462012042500000)

Test-drive the vehicle on road and drive a little in different operating situations for 20 minutes, in order to complete as many adaptations as possible.

Check and note if any adaptation range is still incorrect. Scroll through the list of adaptation ranges.

The adaptation value is considered outside normal range if it is lower than 0.85 (engine runs rich) or higher than 1.15 (engine runs lean).

HINT: Also accelerate at full throttle a number of times to implement the adaptations that are not influenced by normal driving.

For adaptation to start, certain conditions must be fulfilled

1. The engine speed is above 600 RPM.
2. Engine temperature between 80-110°C.
3. Fuel trim active = executed.
4. EVAP-valve not active = 0 μs.

HINT: If fuel vaporization is high, the evaporative emission system (EVAP) valve is active for long periods. In this case, it may be necessary to disconnect the hose between the evaporative emission system (EVAP) valve and the EVAP canister.

Are these values OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S05586930112012042500000)

To investigate what the problem is due to, perform the following

1. Check the intake system for air leakage. HINT: Incorrectly installed oil dipstick can cause not measured air to be drawn into the engine. If the oil trap is damaged or dirty this may lead to obstruction of the air flow. The flame trap may need separating and cleaning to achieve full flow in the system.
2. Check the exhaust system for air leakage.
3. Engine running.
4. Check for too low fuel pressure.
5. Ignition on.
6. Check the residual pressure with regards to too low residual pressure.

Remedy as necessary.

1. see «AIR LEAKS IN THE INTAKE SYSTEM, CHECKING»(ref-479169-S42610968362012061200000)
2. see «AIR LEAKAGE EXHAUST SYSTEM, CHECK»(ref-479169-S27670670192012061200000)
3. see «FUEL SYSTEM PRESSURE, CHECKING»(ref-466653-S09250258202012042500000)

1. Continue Refer to «CHECKING THE MASS AIR FLOW (MAF) SENSOR»(ref-466654-S42265298722012042500000)

CHECKING ETHANOL CONTENT

HINT: The cause of the symptom and/or diagnostic trouble code may be that the vehicle has been refuelled with incorrect fuel for that vehicle. The fuel system contains fuel with too high ethanol content.

The energy content in ethanol-diluted fuel is lower than in pure gasoline. This means that the control module compensates for the lower energy content, by increasing the injection volume, to be able to reach lambda=1 at the front heated oxygen sensor. This compensation is normally called "Front lambda control slow" or "Lambda integrator", and varies to compensate for the vehicle's status in the form of component spread, small air leaks, wear, etc. The value of this compensation in the ideal case is 1.0 for pure gasoline. Increased ethanol content of the fuel increases the compensation by approx. 0.05 per 10% ethanol dilution.

The control module is designed to handle an ethanol dilution up to 25%. In combination with other deviations from the ideal case, however, lower ethanol content may be enough to cause customer symptoms. This mainly occurs at engine start with cool engine at outdoor temperatures below 0 °C. Then the diagnostic trouble code may also be set for the engine running on too lean mixture.

Note. In a vehicle intended for gasoline, only pure gasoline shall be used. Even if engine start/operation works, other fuel-related components in the vehicle may be damaged by too high ethanol content.

1. Measure the ethanol content of the fuel according to the instructions below. If measured ethanol content is above 25%, then ethanol dilution is the likely cause of the symptom and/or to the diagnostic trouble code being stored. If measured ethanol content is below 25%, symptoms and/or diagnostic trouble code may have been caused by earlier occurrence of incorrect fuel in the system for that vehicle. HINT: Check refuelling history by talking to customer. If nothing indicates incorrect fuel, neither now nor earlier, continue troubleshooting to check other possible causes of faults.

Other information

1. see «MEASURING THE ETHANOL CONTENT»(ref-466591-S09065369922012042500000)

1. Continue Refer to «CHECKING THE SYSTEM»(ref-466654-S15780328932012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check relevant connectors for contact resistance and corrosion.

HINT: Both a damaged front and/or a damaged rear heated oxygen sensor may be the cause of the stored diagnostic trouble code (DTC).

HINT: Check other stored DTCs to draw relevant conclusions about which heat oxygen sensor(s) should be replaced, this is to avoid incorrect replacement of components.

Remedy as necessary.

Other information

1. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)
2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-466651-S32701656862012042500000)

1. Continue Refer to «VERIFICATION»(ref-466654-S42414140482012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC).
2. Check that the diagnosis is Performed. HINT: To enable performing diagnostic status, special conditions must be fulfilled. These conditions are described in diagnostic trouble code (DTC) information for each diagnostic trouble code (DTC). If the function is correct, the fault status must be No fault found when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S36246714542012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check relevant connectors for contact resistance and corrosion.

Check the exhaust system for air leakage

HINT: Both a damaged front and/or a damaged rear heated oxygen sensor may be the cause of the stored diagnostic trouble code (DTC).

HINT: Check other stored DTCs to draw relevant conclusions about which heat oxygen sensor(s) should be replaced, this is to avoid incorrect replacement of components.

Remedy as necessary.

Other information

1. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)
2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-466651-S32701656862012042500000)

1. Continue Refer to «VERIFICATION»(ref-466654-S37209062042012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC).
2. Check that the diagnosis is Performed. HINT: To enable performing diagnostic status, special conditions must be fulfilled. These conditions are described in diagnostic trouble code (DTC) information for each diagnostic trouble code (DTC). If the function is correct, the fault status must be No fault found when the diagnostic is complete.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S23810312192012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition on. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".

1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466654-S24664313912012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Engine idling. Read off the signal from the fuel pressure sensor. Check that the signal is within its permitted range. The normal value is 480 ± 5 kPa when idling. NOTE: The signal indicates absolute pressure.

Is the signal within its permitted range?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S19791798722012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition on. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".

1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466654-S42129035462012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Engine idling. Read off the signal from the fuel pressure sensor. Check that the signal is within its permitted range. The normal value is 480 ± 5 kPa when idling. NOTE: The signal indicates absolute pressure.

Is the signal within its permitted range?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S29288977042012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition on. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".

1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466654-S04763837862012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Engine idling. Read off the signal from the fuel pressure sensor. Check that the signal is within its permitted range. The normal value is 480 ± 5 kPa when idling. NOTE: The signal indicates absolute pressure.

Is the signal within its permitted range?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S42191701952012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition on. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".

1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466654-S04531004172012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Engine idling. Read off the signal from the fuel pressure sensor. Check that the signal is within its permitted range. The normal value is 480 ± 5 kPa when idling. NOTE: The signal indicates absolute pressure.

Is the signal within its permitted range?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S07766815812012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".

1. Continue Refer to «CHECKING THE CONNECTOR»(ref-466654-S03568505992012042500000)

Check the fuel pressure sensor connector and terminals. Check for contact resistance. Check for oxidation.

Remedy as necessary.

Other information

1. see «PRESSURE SENSOR, FUEL RAIL (FRP)»(ref-466594-S18866848472012042500000)
2. see «FUEL PUMP DRIVER MODULE (2005, 2006)»(ref-466594-S03260019312012042500000)
3. see «CHECKING WIRING AND TERMINALS»(ref-466589-S05251896242012042500000)

Scheme 56

1. Continue Refer to «VERIFICATION»(ref-466654-S36999396852012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall the connectors, components etc.
3. Engine idling. Read off the signal from the fuel pressure sensor. Check that the signal is within its permitted range. Normal value is 480 ± 5 kPa at idle. Read off the signal from the fuel pressure sensor with the ignition on. Check that the fuel pressure has dropped. Normally, the pressure should drop by approx. 100 kPa from the value at idle. NOTE: The signal indicates absolute pressure.

Is the value within its permitted range?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S37064817302012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".

1. Continue Refer to «CHECKING THE CONNECTOR»(ref-466654-S26615210532012042500000)

Check the fuel pressure sensor connector and terminals. Check for contact resistance. Check for oxidation.

Remedy as necessary.

Other information

1. see «PRESSURE SENSOR, FUEL RAIL (FRP)»(ref-466594-S18866848472012042500000)
2. see «FUEL PUMP DRIVER MODULE (2007-2010)»(ref-466594-S41380616252012042500000)
3. see «CHECKING WIRING AND TERMINALS»(ref-466589-S05251896242012042500000)

1. Continue Refer to «VERIFICATION»(ref-466654-S02670627962012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall the connectors, components etc.
3. Engine idling. Read off the signal from the fuel pressure sensor. Check that the signal is within its permitted range. Normal value is 480 ± 5 kPa at idle. Read off the signal from the fuel pressure sensor with the ignition on. Check that the fuel pressure has dropped. Normally, the pressure should drop by approx. 100 kPa from the value at idle. NOTE: The signal indicates absolute pressure.

Is the value within its permitted range?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S38805680142012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: This diagnostic trouble code (DTC) can be stored for faults that are detected by the central electronic module (CEM).

Note. If there are diagnostic trouble codes (DTC) for the fuel pump (FP) or the relay for the fuel pump stored in the central electronic module (CEM), these must be fault traced accordingly.

1. Start the engine to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".

1. Continue Refer to «CHECKING THE CONNECTOR»(ref-466654-S42422292932012042500000)

Check the fuel pressure sensor connector and terminals. Check for contact resistance. Check for oxidation.

Remedy as necessary.

Other information

1. see «PRESSURE SENSOR, FUEL RAIL (FRP)»(ref-466594-S18866848472012042500000)
2. see «CHECKING WIRING AND TERMINALS»(ref-466589-S05251896242012042500000)

1. Continue Refer to «VERIFICATION»(ref-466654-S37581579252012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall the connectors, components etc.
3. Engine idling. Read off the signal from the fuel pressure sensor. Check that the signal is within its permitted range. Normal value is 480 ± 5 kPa at idle. Read off the signal from the fuel pressure sensor with the ignition on. Check that the fuel pressure has dropped. Normally, the pressure should drop by approx. 100 kPa from the value at idle. NOTE: The signal indicates absolute pressure.

Is the value within its permitted range?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S09901885982012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: This diagnostic trouble code (DTC) can be stored for faults that are detected by the central electronic module (CEM).

Note. If there are diagnostic trouble codes (DTC) for the fuel pump (FP) or the relay for the fuel pump stored in the central electronic module (CEM), these must be fault traced accordingly.

1. Ignition on. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".

1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466654-S15075049852012042500000)

Scheme 57

1. Start the engine and run it to normal operating temperature. Read off the fuel pump (FP) load (signal from the engine control module (ECM) to the fuel pump (FP) control module). Check that the signal is approximately 50% (±10 %) with the engine idling at operating temperature. Check the cable between engine control module (ECM) terminal #B20 (#C20) and fuel pump (FP) module terminal #1. Check for a short-circuit to supply voltage. Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000) see «SIGNAL SPECIFICATION»(ref-466592-S15475582172012042500000) see «FUEL PUMP DRIVER MODULE (2005, 2006)»(ref-466594-S03260019312012042500000) «FUEL PUMP DRIVER MODULE»(ref-479171-S13947766192012061200000) see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)

1. Continue Refer to «VERIFICATION»(ref-466654-S31447237322012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Reinstall the connectors, components etc.
2. Start the engine and run it to normal operating temperature. Read off the fuel pump (FP) load (signal from the engine control module (ECM) to the fuel pump (FP) control module). Check that the signal is approximately 50% (±10 %) with the engine idling at operating temperature.

Is the signal within its permitted range?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S13778199372012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: This diagnostic trouble code (DTC) can be stored for faults that are detected by the central electronic module (CEM).

Note. If there are diagnostic trouble codes (DTC) for the fuel pump (FP) or the relay for the fuel pump stored in the central electronic module (CEM), these must be fault traced accordingly.

1. Ignition on. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".

1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466654-S35104811122012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Reinstall the connectors, components etc.
2. Start the engine and run it to normal operating temperature. Read off the fuel pump (FP) load (signal from the engine control module (ECM) to the fuel pump (FP) control module). Check that the signal is approximately 50% (±10 %) with the engine idling at operating temperature.

Is the signal within its permitted range?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S31836849072012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: This diagnostic trouble code (DTC) can be stored for faults that are detected by the central electronic module (CEM).

Note. If there are diagnostic trouble codes (DTC) for the fuel pump (FP) or the relay for the fuel pump stored in the central electronic module (CEM), these must be fault traced accordingly.

1. Ignition on. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".

1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-466654-S09519182402012042500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Reinstall the connectors, components etc.
2. Start the engine and run it to normal operating temperature. Read off the fuel pump (FP) load (signal from the engine control module (ECM) to the fuel pump (FP) control module). Check that the signal is approximately 50% (±10 %) with the engine idling at operating temperature.

Is the signal within its permitted range?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «INFORMATION»(ref-466654-S19776515012012042500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
