Engine Control Module (ECM) Diagnostic Trouble Codes - 4 of 9: Wiring Volvo V50 I рестайлинг

Testing & Diagnostics 4 illustrations ~2849 words

CHECKING THE COMPONENT AND WIRING

Check the fuel pressure sensor connectors. Check for contact resistance and oxidation.

Remedy as necessary.

Try a new fuel pressure sensor if no fault is found during the above fault-tracing.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000)
  2. see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000) (2005), or «SIGNAL SPECIFICATION»(ref-466592-S15491428272012042500000) (2006-2007)
  3. see «PRESSURE SENSOR, FUEL RAIL (FRP)»(ref-466594-S18866848472012042500000)
  4. see «CHECKING WIRING AND TERMINALS»(ref-466589-S05251896242012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S36607974212012042500000)

Check the fuel pressure sensor connectors. Check for contact resistance and oxidation.

Remedy as necessary.

Try a new fuel pressure sensor if no fault is found during the above fault-tracing.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000)
  2. see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000) (2005), or «SIGNAL SPECIFICATION»(ref-466592-S15491428272012042500000) (2006-2007)
  3. see «PRESSURE SENSOR, FUEL RAIL (FRP)»(ref-466594-S18866848472012042500000)
  4. see «CHECKING WIRING AND TERMINALS»(ref-466589-S05251896242012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S18357321412012042500000)

Check the fuel pressure sensor connectors. Check for contact resistance and oxidation.

Remedy as necessary.

Try a new fuel pressure sensor if no fault is found during the above fault-tracing.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000)
  2. see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000) (2005), or «SIGNAL SPECIFICATION»(ref-466592-S15491428272012042500000) (2006-2007)
  3. see «PRESSURE SENSOR, FUEL RAIL (FRP)»(ref-466594-S18866848472012042500000)
  4. see «CHECKING WIRING AND TERMINALS»(ref-466589-S05251896242012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S29958355522012042500000)

Check the fuel pressure sensor connectors. Check for contact resistance and oxidation.

Remedy as necessary.

Try a new fuel pressure sensor if no fault is found during the above fault-tracing.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000)
  2. see «SIGNAL SPECIFICATION»(ref-466592-S15491428272012042500000)
  3. see «PRESSURE SENSOR, FUEL RAIL (FRP)»(ref-466594-S18866848472012042500000)
  4. see «CHECKING WIRING AND TERMINALS»(ref-466589-S05251896242012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S02241570452012042500000)

Check the fuel pressure sensor connectors. Check for contact resistance and oxidation.

Remedy as necessary.

Try a new fuel pressure sensor if no fault is found during the above fault-tracing.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000)
  2. see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000) (2005), or «SIGNAL SPECIFICATION»(ref-466592-S15491428272012042500000) (2006-2007)
  3. see «PRESSURE SENSOR, FUEL RAIL (FRP)»(ref-466594-S18866848472012042500000)
  4. see «CHECKING WIRING AND TERMINALS»(ref-466589-S05251896242012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S31900848182012042500000)

Check the connector for the fuel pump (FP) control module. Check for contact resistance. Check for oxidation.

Check the signal cable. Check for an open-circuit. Check for a short-circuit to ground. Check for a short-circuit to supply voltage.

Take readings between

  1. Engine Control Module (ECM) #B21 (#C21) and control module fuel pump #5.

Remedy as necessary.

HINT: The diagnostic trouble code (DTC) can be caused by a defective fuel pump (FP) control module.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000)
  2. see «SIGNAL SPECIFICATION»(ref-466592-S15491428272012042500000)
  3. see «FUEL PUMP DRIVER MODULE (2005, 2006)»(ref-466594-S03260019312012042500000) , or «FUEL PUMP DRIVER MODULE (2007-2010)»(ref-466594-S41380616252012042500000)
  4. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)

Scheme 81

Scheme 81
  1. Continue Refer to «VERIFICATION»(ref-466656-S16449183872012042500000) .

Check the connector for the fuel pump (FP) control module. Check for contact resistance. Check for oxidation.

Check the cable between the Engine control module (ECM) terminal #B20 (#C20) and fuel pump control module terminal #1. Check for an open-circuit, short-circuit to ground and short-circuit to voltage.

Remedy as necessary.

HINT: The diagnostic trouble code (DTC) can be caused by a defective fuel pump (FP) control module.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000)
  2. see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000)
  3. see «FUEL PUMP DRIVER MODULE»(ref-466594-S03260019312012042500000)
  4. see «CHECKING WIRING AND TERMINALS»(ref-466589-S05251896242012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S30839712962012042500000)

HINT: The fuel temperature sensor is integrated in the fuel pressure sensor.

Scheme 82

Scheme 82: CHECKING THE COMPONENT AND WIRING
  1. Check the fuel pressure sensor connectors. Check for contact resistance and oxidation. Check the fuel pressure sensor between terminals #1 and #2 (sensor side). Check the resistance. Check signal cable for an open-circuit and short-circuit to supply voltage. Take readings between: Engine Control Module (ECM) #A41 (#A41) and fuel pressure sensor #2. Check the ground lead. Check for an open-circuit. Take readings between: Engine Control Module (ECM) #A15 (#A15) and fuel pressure sensor #1. Remedy as necessary. Other information: see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000) see «SIGNAL SPECIFICATION»(ref-466592-S15491428272012042500000) see «COMPONENT SPECIFICATIONS»(ref-466592-S02390340522012042500000) see «PRESSURE SENSOR, FUEL RAIL (FRP)»(ref-466594-S18866848472012042500000) see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S08652606072012042500000)

CHECKING THE COMPONENTS AND WIRING

CAUTIONDo not apply rust solvent spray or grease to the heated oxygen sensor (HO2S) connector.

Check the cable between engine control module (ECM) terminal #A95 (#B35) and heated oxygen sensor (HO2S) terminal #4. Check for a short-circuit to supply voltage.

Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.

Remedy as necessary.

Other information

  1. see «SIGNAL SPECIFICATION»(ref-466592-S15475582172012042500000)
  2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-466651-S32701656862012042500000)
  3. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)

Scheme 83

Scheme 83
  1. Continue Refer to «VERIFICATION»(ref-466656-S21988428142012042500000)
CAUTIONDo not apply rust solvent spray or grease to the heated oxygen sensor (HO2S) connector.

Check the cable between engine control module (ECM) terminal #A95 (#B35) and heated oxygen sensor (HO2S) terminal #4. Check for a short-circuit to supply voltage.

Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.

Remedy as necessary.

Other information

  1. see «SIGNAL SPECIFICATION»(ref-466592-S26583508152012042500000)
  2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-466651-S32701656862012042500000)
  3. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S11897678672012042500000)
CAUTIONDo not apply rust solvent spray or grease to the heated oxygen sensor (HO2S) connector.

Check the cable between engine control module (ECM) terminal #A95 (#B35) and heated oxygen sensor (HO2S) terminal #4. Check for an open-circuit. Check for a short-circuit to ground.

Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.

Remedy as necessary.

Other information

  1. see «SIGNAL SPECIFICATION»(ref-466592-S15475582172012042500000)
  2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-466651-S32701656862012042500000)
  3. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S21917443402012042500000)
CAUTIONDo not apply rust solvent spray or grease to the heated oxygen sensor (HO2S) connector.

Check the cable between engine control module (ECM) terminal #A95 (#B35) and heated oxygen sensor (HO2S) terminal #4. Check for an open-circuit. Check for a short-circuit to ground.

Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.

Remedy as necessary.

Other information

  1. see «SIGNAL SPECIFICATION»(ref-466592-S26583508152012042500000)
  2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-466651-S32701656862012042500000)
  3. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S34169224092012042500000)

HINT: The fuel temperature sensor is integrated in the fuel pressure sensor.

Check the fuel pressure sensor between terminals #1 and #2 (sensor side). Check the resistance.

Check the signal cable between engine control module (ECM) terminal #A66 (#B6) and fuel pressure sensor terminal #2. Check for a short-circuit to ground.

Remedy as necessary.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000)
  2. see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000)
  3. see «COMPONENT SPECIFICATIONS»(ref-466592-S02390340522012042500000)
  4. see «PRESSURE SENSOR, FUEL RAIL (FRP)»(ref-466594-S18866848472012042500000)
  5. see «CHECKING WIRING AND TERMINALS»(ref-466589-S05251896242012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S28679766832012042500000)

HINT: The fuel temperature sensor is integrated in the fuel pressure sensor.

Check the fuel pressure sensor between terminals #1 and #2 (sensor side). Check the resistance.

Check the signal cable. Check for a short-circuit to ground.

Take readings between

  1. Engine Control Module (ECM) #A41 (#A41) and fuel pressure sensor #2.

Remedy as necessary.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000)
  2. see «SIGNAL SPECIFICATION»(ref-466592-S15491428272012042500000)
  3. see «COMPONENT SPECIFICATIONS»(ref-466592-S02390340522012042500000)
  4. see «PRESSURE SENSOR, FUEL RAIL (FRP)»(ref-466594-S18866848472012042500000)
  5. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S42065019672012042500000)

HINT: The fuel temperature sensor is integrated in the fuel pressure sensor.

  1. Check the fuel pressure sensor connectors. Check for contact resistance and oxidation. Check the fuel pressure sensor between terminals #1 and #2 (sensor side). Check the resistance. Check the signal cable between engine control module (ECM) terminal #A66 (#B6) and fuel pressure sensor terminal #2. Check for a short-circuit to supply voltage. Check for an open-circuit. Check the ground lead between engine control module (ECM) terminal #A15 (#A15) and fuel pressure sensor terminal #1. Check for an open-circuit. Remedy as necessary. Other information: see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000) see «SIGNAL SPECIFICATION»(ref-466592-S22657918422012042500000) see «COMPONENT SPECIFICATIONS»(ref-466592-S02390340522012042500000) see «PRESSURE SENSOR, FUEL RAIL (FRP)»(ref-466594-S18866848472012042500000) see «CHECKING WIRING AND TERMINALS»(ref-466589-S05251896242012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S15880227292012042500000)
CAUTIONDo not apply rust solvent spray or grease to the heated oxygen sensor (HO2S) connector.

Check the cable between heated oxygen sensor (HO2S) terminal #1 and the power supply from the system relay. Check for a short-circuit to supply voltage.

Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.

Remedy as necessary.

Other information

  1. see «SIGNAL SPECIFICATION»(ref-466592-S15475582172012042500000)
  2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-466651-S32701656862012042500000)
  3. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S11013120002012042500000)
CAUTIONDo not apply rust solvent spray or grease to the heated oxygen sensor (HO2S) connector.

Check the cable between heated oxygen sensor (HO2S) terminal #1 and the power supply from the system relay. Check for a short-circuit to supply voltage.

Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.

Remedy as necessary.

Other information

  1. see «SIGNAL SPECIFICATION»(ref-466592-S26583508152012042500000)
  2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-466651-S32701656862012042500000)
  3. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S38823888752012042500000)
CAUTIONDo not apply rust solvent spray or grease to the heated oxygen sensor (HO2S) connector.

Note. Diagnostic trouble code (DTC) may be caused by a damaged fuse.

Check the cable between heated oxygen sensor (HO2S) terminal #1 and the power supply from the system relay. Check for an open-circuit. Check for a short-circuit to ground

Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.

Remedy as necessary.

Other information

  1. see «SIGNAL SPECIFICATION»(ref-466592-S15475582172012042500000)
  2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-466651-S32701656862012042500000)
  3. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S20140639382012042500000)
CAUTIONDo not apply rust solvent spray or grease to the heated oxygen sensor (HO2S) connector.

Note. Diagnostic trouble code (DTC) may be caused by a damaged fuse.

Check the cable between heated oxygen sensor (HO2S) terminal #1 and the power supply from the system relay. Check for an open-circuit. Check for a short-circuit to ground

Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.

Remedy as necessary.

Other information

  1. see «SIGNAL SPECIFICATION»(ref-466592-S26583508152012042500000)
  2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-466651-S32701656862012042500000)
  3. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S15389969612012042500000)
  1. Ignition off.
  2. Disconnect the fuel temperature sensor connector.
  3. Check the connectors. Check for loose connections. Check for contact resistance. Check for oxidation. Check the resistance of the sensor between #1 and #2 (to the sensor). Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000) see «SIGNAL SPECIFICATION»(ref-466592-S15491428272012042500000) see «COMPONENT SPECIFICATIONS»(ref-466592-S02390340522012042500000) see «PRESSURE SENSOR, FUEL RAIL (FRP)»(ref-466594-S18866848472012042500000) see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S06290073122012042500000)

HINT: The fuel temperature sensor is integrated in the fuel pressure sensor.

Check the fuel pressure sensor between terminals #1 and #2 (sensor side). Check the resistance.

Check the cable between engine control module (ECM) terminal #A71 (#B11) and fuel temperature sensor terminal #2. Check for a short-circuit to supply voltage.

Remedy as necessary.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000)
  2. see «SIGNAL SPECIFICATION»(ref-466592-S15475582172012042500000)
  3. see «COMPONENT SPECIFICATION»(ref-466592-S17814850062012042500000)
  4. To access/replace the fuel temperature sensor: «PRESSURE SENSOR, FUEL RAIL (FRP)»(ref-466594-S18866848472012042500000)
  5. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S30986535082012042500000)

HINT: The fuel temperature sensor is integrated in the fuel pressure sensor.

Check the fuel pressure sensor between terminals #1 and #2 (sensor side). Check the resistance.

Check the cable between engine control module (ECM) terminal #A71 (#B11) and fuel temperature sensor terminal #2. Check for a short-circuit to supply voltage.

Remedy as necessary.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000)
  2. see «SIGNAL SPECIFICATION»(ref-466592-S26583508152012042500000)
  3. see «COMPONENT SPECIFICATION»(ref-466592-S34085195992012042500000)
  4. To access/replace the fuel temperature sensor: «PRESSURE SENSOR, FUEL RAIL (FRP)»(ref-466594-S18866848472012042500000)
  5. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S41535512532012042500000)

HINT: The fuel temperature sensor is integrated in the fuel pressure sensor.

Check the fuel pressure sensor between terminals #1 and #2 (sensor side). Check the resistance.

Check the cable between engine control module (ECM) terminal #A71 (#B11) and fuel temperature sensor terminal #2. Check for a short-circuit to ground. Check for an open-circuit.

Remedy as necessary.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000)
  2. see «SIGNAL SPECIFICATION»(ref-466592-S15475582172012042500000)
  3. see «COMPONENT SPECIFICATION»(ref-466592-S17814850062012042500000)
  4. To access/replace the fuel temperature sensor: «PRESSURE SENSOR, FUEL RAIL (FRP)»(ref-466594-S18866848472012042500000)
  5. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S37607232652012042500000)

HINT: The fuel temperature sensor is integrated in the fuel pressure sensor.

Check the fuel pressure sensor between terminals #1 and #2 (sensor side). Check the resistance.

Check the cable between engine control module (ECM) terminal #A71 (#B11) and fuel temperature sensor terminal #2. Check for a short-circuit to ground. Check for an open-circuit.

Remedy as necessary.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000)
  2. see «SIGNAL SPECIFICATION»(ref-466592-S26583508152012042500000)
  3. see «COMPONENT SPECIFICATION»(ref-466592-S34085195992012042500000)
  4. To access/replace the fuel temperature sensor: «PRESSURE SENSOR, FUEL RAIL (FRP)»(ref-466594-S18866848472012042500000)
  5. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S37234558352012042500000)

Check the signal cable between engine control module (ECM) terminal #A63 (#B3) and camshaft position (CMP) sensor connector terminal #3. Check for a short-circuit to ground. Check for a short-circuit to supply voltage. Check for an open-circuit.

Check the ground lead between engine control module (ECM) terminal #A19 (#A19) and camshaft position (CMP) sensor connector terminal #2. Check for a short-circuit to supply voltage. Check for an open-circuit.

Check the power supply cable between engine control module (ECM) terminal #A17 (#A17) and camshaft position (CMP) sensor connector terminal #1. Check for a short-circuit to ground. Check for a short-circuit to supply voltage. Check for an open-circuit.

HINT: With the ignition on and the camshaft position (CMP) sensor connector disconnected, the voltage between terminal #1 and ground must be approximately 5 V.

Remedy as necessary.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000)
  2. see «SIGNAL SPECIFICATION»(ref-466592-S15475582172012042500000)
  3. To access/replace the camshaft sensor: «CAMSHAFT POSITION SENSOR (CMP)»(ref-466594-S42403758492012042500000)
  4. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)

Scheme 84

Scheme 84
  1. Continue Refer to «VERIFICATION»(ref-466656-S27705392882012042500000)

Check the signal cable between engine control module (ECM) terminal #A63 (#B3) and camshaft position (CMP) sensor connector terminal #3. Check for a short-circuit to ground. Check for a short-circuit to supply voltage. Check for an open-circuit.

Check the ground lead between engine control module (ECM) terminal #A19 (#A19) and camshaft position (CMP) sensor connector terminal #2. Check for a short-circuit to supply voltage. Check for an open-circuit.

Check the power supply cable between engine control module (ECM) terminal #A17 (#A17) and camshaft position (CMP) sensor connector terminal #1. Check for a short-circuit to ground. Check for a short-circuit to supply voltage. Check for an open-circuit.

HINT: With the ignition on and the camshaft position (CMP) sensor connector disconnected, the voltage between terminal #1 and ground must be approximately 5 V.

Remedy as necessary.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000)
  2. see «SIGNAL SPECIFICATION»(ref-466592-S26583508152012042500000)
  3. To access/replace the camshaft sensor: «CAMSHAFT POSITION SENSOR (CMP)»(ref-466594-S42403758492012042500000)
  4. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S20111445602012042500000)

Check the signal cable between engine control module (ECM) terminal #A63 (#B3) and camshaft position (CMP) sensor connector terminal #3. Check for a short-circuit to ground. Check for a short-circuit to supply voltage. Check for an open-circuit.

Check the ground lead between control module terminal #A19 (#A19) and camshaft position (CMP) sensor connector terminal #2. Check for a short-circuit to supply voltage. Check for an open-circuit.

Check the power supply cable between control module terminal #A17 (#A17) and camshaft position (CMP) sensor connector terminal #1. Check for a short-circuit to ground. Check for a short-circuit to supply voltage. Check for an open-circuit.

HINT: With the ignition on and the camshaft position (CMP) sensor connector disconnected, the voltage between terminal #1 and ground must be approximately 5 V.

Remedy as necessary.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000)
  2. see «SIGNAL SPECIFICATION»(ref-466592-S15475582172012042500000)
  3. To access/replace the camshaft sensor: «CAMSHAFT POSITION SENSOR (CMP)»(ref-466594-S42403758492012042500000)
  4. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S04782451342012042500000)

Check the signal cable between engine control module (ECM) terminal #A63 (#B3) and camshaft position (CMP) sensor connector terminal #3. Check for a short-circuit to ground. Check for a short-circuit to supply voltage. Check for an open-circuit.

Check the ground lead between control module terminal #A19 (#A19) and camshaft position (CMP) sensor connector terminal #2. Check for a short-circuit to supply voltage. Check for an open-circuit.

Check the power supply cable between control module terminal #A17 (#A17) and camshaft position (CMP) sensor connector terminal #1. Check for a short-circuit to ground. Check for a short-circuit to supply voltage. Check for an open-circuit.

HINT: With the ignition on and the camshaft position (CMP) sensor connector disconnected, the voltage between terminal #1 and ground must be approximately 5 V.

Remedy as necessary.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000)
  2. see «SIGNAL SPECIFICATION»(ref-466592-S26583508152012042500000)
  3. To access/replace the camshaft sensor: «CAMSHAFT POSITION SENSOR (CMP)»(ref-466594-S42403758492012042500000)
  4. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S17929625542012042500000)

Check the signal cable between engine control module (ECM) terminal #A64 (#B4) and camshaft position (CMP) sensor connector terminal #3. Check for a short-circuit to ground. Check for a short-circuit to supply voltage. Check for an open-circuit.

Check the ground lead between control module terminal #A43 (#A43) and camshaft position (CMP) sensor connector terminal #2. Check for a short-circuit to supply voltage. Check for an open-circuit.

Check the power supply cable between control module terminal #A39 (#A39) and camshaft position (CMP) sensor connector terminal #1. Check for a short-circuit to ground. Check for a short-circuit to supply voltage. Check for an open-circuit.

HINT: With the ignition on and the camshaft position (CMP) sensor connector disconnected, the voltage between terminal #1 and ground must be approximately 5 V.

Remedy as necessary.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000)
  2. see «SIGNAL SPECIFICATION»(ref-466592-S15475582172012042500000)
  3. To access/replace the camshaft sensor: «CAMSHAFT POSITION SENSOR (CMP)»(ref-466594-S42403758492012042500000)
  4. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S15833134572012042500000)

Check the signal cable between engine control module (ECM) terminal #A64 (#B4) and camshaft position (CMP) sensor connector terminal #3. Check for a short-circuit to ground. Check for a short-circuit to supply voltage. Check for an open-circuit.

Check the ground lead between control module terminal #A43 (#A43) and camshaft position (CMP) sensor connector terminal #2. Check for a short-circuit to supply voltage. Check for an open-circuit.

Check the power supply cable between control module terminal #A39 (#A39) and camshaft position (CMP) sensor connector terminal #1. Check for a short-circuit to ground. Check for a short-circuit to supply voltage. Check for an open-circuit.

HINT: With the ignition on and the camshaft position (CMP) sensor connector disconnected, the voltage between terminal #1 and ground must be approximately 5 V.

Remedy as necessary.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-466591-S26645247992012042500000)
  2. see «SIGNAL SPECIFICATION»(ref-466592-S26583508152012042500000)
  3. To access/replace the camshaft sensor: «CAMSHAFT POSITION SENSOR (CMP)»(ref-466594-S42403758492012042500000)
  4. see «CHECKING WIRING AND TERMINALS»(ref-466589-S38415998382012042500000)
  1. Continue Refer to «VERIFICATION»(ref-466656-S26175146902012042500000)
