How to Replace the Timing Belt Opel Vivaro A

Diesel Engine 40 illustrations ~1037 words

Remove

  1. 1. Disconnect battery negative lead
  2. 2. Raise vehicle
  3. 3. Remove engine and transmission undershield from vehicle
  4. 4. Remove right splash shield • Remove 2x bolt, screw • Release wash pipe (if installed) from 2x support clip
  1. 5. Remove blanking bolt (1) from cylinder block

Note. To allow installation of Positioning Pin KM-6031 .

  1. 6. Install Engine Support KM-6210-A – see operation “Engine Support KM-6210-A, Install and Remove”
  2. 7. Remove ribbed V-belt from engine • Rotate tension roller clockwise, then lock using Locating Pin KM-6130

Note. Illustration shows vehicle with air conditioning. For vehicles without air conditioning the tension roller is rotated anti-clockwise.

  1. 8. Remove tension roller for ribbed V-belt from engine • Remove bolt (1)
  1. 9. For vehicles with air conditioning, remove guide roller (1) for ribbed V-belt from support bracket • Remove bolt
  1. 10. Lower vehicle
  2. 11. Remove cylinder head trim cover • Remove 3x bolt • Release 3x clip
  3. 12. Release harness and fuel line (1) from bracket for engine damping block, then move to one side • Release 2x clip
  1. 13. Release power steering reservoir from front panel • Release clip
  1. 14. Remove bracket with engine damping block, right side, and upper engine stabiliser • Remove 12 mm bolt from engine stabiliser • Remove 3x 10 mm bolt from bracket • Remove 3x 10 mm bolt from engine damping block
  1. 15. Release timing belt cover from engine • Remove 2x bolt (1)
  1. 16. Raise vehicle
  2. 17. Install Positioning Pin KM-6031 (1) to crankshaft • Rotate crankshaft clockwise until positioning locates fully into crankshaft recess

Note. To determine top dead centre (TDC).

  1. 18. Lower vehicle
  2. 19. Check mark (1) on camshaft pulley is visible through hole in timing belt cover

Note. If incorrectly aligned, remove Positioning Pin KM-6031 , rotate the crankshaft 360° clockwise, and reinstall the positioning pin.

  1. 20. Raise vehicle
  2. 21. Remove timing belt cover from engine • Remove 2x bolt (1)
  1. 22. Lower vehicle
  2. 23. Apply match mark (1) on rear cover, in-line with mark (2) on camshaft pulley
  1. 24. Raise vehicle
  2. 25. Install Flywheel Locking Tool KM-911
  1. 26. Remove Positioning Pin KM-6031 from crankshaft
  2. 27. Remove crankshaft pulley from engine • Remove bolt (1)
  1. 28. Remove Flywheel Locking Tool KM-911
  2. 29. Install Positioning Pin KM-6031 to crankshaft
  3. 30. Remove timing belt from engine • Release nut (1) from tensioner

Install

  1. 31. Lower vehicle

Important. Ensure the timing belt is installed with the direction arrows pointing clockwise.

  1. 32. Install new timing belt to camshaft pulley and fuel pump pulley • Align mark (2) on timing belt with match mark (1) on rear cover and mark (3) on camshaft pulley
  1. 33. Raise vehicle
  2. 34. Install timing belt to tensioner, crankshaft timing belt pulley and coolant pump • Align mark (1) on timing belt with mark (2) on crankshaft timing belt pulley
  1. 35. Carry out final check of installation of timing belt around pulleys and tensioner
  1. 36. Install spacer (1) of Tensioning Tool KM-6234 to crankshaft toothed pulley • Install spacer with crankshaft bolt

Note. Do not over tighten bolt.

  1. 37. Install bolt (1) to tensioner • Tighten bolt until tensioner pulley touches timing belt
  1. 38. Remove Positioning Pin KM-6031 from crankshaft

Adjust

  1. 39. Tension timing belt • Install Timing Belt Tensioner KM-6234 to crankshaft spacer • Turn bolt of KM-6234 with torque wrench 11 Nm • Remove Timing Belt Tensioner KM-6234 from crankshaft spacer
  1. 40. Adjust tension of timing belt • Place pick up of Tester KM-6225 next to timing belt • Turn bolt (1) until Tester KM-6225 indicates tension of 95 Hz ± 3 Hz
  1. 41. Pre-tighten tensioner nut (1) 10 Nm
  1. 42. Rotate crankshaft 720° clockwise
  2. 43. Install Positioning Pin KM-6031 to crankshaft • Rotate crankshaft clockwise until positioning pin enters recess in crankshaft

Note. To determine top dead centre (TDC).

  1. 44. Remove Positioning Pin KM-6031 from crankshaft
  2. 45. Apply pre-tension to timing belt • Install Tensioning Tool KM-6234 to crankshaft spacer • Turn bolt of tensioning tool with torque wrench 11 Nm • Remove tensioning tool from crankshaft spacer
  1. 46. Check tension of timing belt • Place pick up of Tester KM-6225 next to timing belt and check whether timing belt now has tension of 90 Hz ± 3 Hz • If not, correct adjustment and check again
  1. 47. Secure tensioner nut (1) for timing belt 50 Nm
  1. 48. Remove bolt (1) from timing belt tensioner
  1. 49. Remove spacer (1) of Tensioning Tool KM-6234 from the crankshaft timing belt pulley

Install

  1. 50. Install timing belt cover to engine • Install 2x bolt (1) 10 Nm
  1. 51. Install Flywheel Locking Tool KM-911
  1. 52. Install crankshaft pulley to engine • Install new bolt 20 Nm + 115º ± 15º
  1. 53. Remove Flywheel Locking Tool KM-911
  2. 54. Lower vehicle
  3. 55. Install timing belt cover to engine • Secure 2x bolt (1) 10 Nm
  1. 56. Install bracket with engine damping block, right side, and upper engine stabiliser • Install 3x 10 mm bolt to engine damping block 44 Nm • Install 3x 10 mm bolt to bracket 60 Nm in correct sequence • Install 12 mm bolt to engine stabiliser 100 Nm

Note. Ensure the washers move freely on the bolts.

  1. 57. Secure power steering reservoir to front panel • Secure clip
  2. 58. Secure harness and fuel line (1) to bracket for engine damping block • Secure 2x clip
  1. 59. Install cylinder head trim cover • Secure 3x clip • Install 3x bolt
  2. 60. Raise vehicle
  3. 61. Remove Engine Support KM-6210-A from vehicle
  4. 62. For vehicles with air conditioning, install new guide roller (1) for ribbed V-belt to support bracket • Install bolt 21 Nm
  1. 63. Install new tension roller for ribbed V-belt to engine • Install bolt (1)
  1. 64. Install new ribbed V-belt to engine • Rotate tension roller clockwise, then remove Locating Pin KM-6130

Note. Illustration shows vehicle with air conditioning. For vehicles without air conditioning the tension roller is rotated anti-clockwise.

  1. 65. Install blanking bolt (1) to cylinder block 20 Nm
  1. 66. Install right splash shield • Secure 2x bolt, screw 8 Nm • Secure wash pipe (if installed) to 2x support clip
  2. 67. Install engine and transmission undershield to vehicle
  1. 68. Lower vehicle
  2. 69. Connect battery negative lead
  3. 70. Program all volatile memories
