How to Replace the Engine Damping Block, Right Side Opel Vivaro A

Remove

1. 1. Raise vehicle
2. 2. Remove engine undershield from vehicle
3. 3. Install Engine Support KM-6210 to vehicle – see operation “Engine Support KM-6210–A, Install and Remove”
4. 4. Lower vehicle to floor
5. 5. Remove engine damping block • Release engine damping block from inner wing – Remove 3x bolt (2) • Release engine damping block from support bracket – Remove bolt (1)

Install

6. 6. Install engine damping block • Secure engine damping block to support bracket – Install bolt (1); do not tighten at this stage • Secure engine damping block to inner wing – Install 3x bolt (2) 44 Nm • Tighten bolt (1) 44 Nm

7. 7. Raise vehicle
8. 8. Remove Engine Support KM-6210-A from vehicle
9. 9. Install engine undershield to vehicle
10. 10. Lower vehicle
