How to Replace the Engine Damping Block, Left Side Opel Vivaro A

Remove

1. 1. Raise vehicle
2. 2. Remove engine and transmission undershield from vehicle
3. 3. Install Engine Support KM-6210-A to vehicle – see operation “Engine Support KM-6210-A, Install and Remove”
4. 4. Lower vehicle
5. 5. Release engine damping block (1) from transmission bracket and chassis • Remove nut (2), 2x bolt (3)

6. 6. Raise vehicle
7. 7. Lower Engine Support KM-6210-A until transmission bracket and engine damping block separate
8. 8. Lower vehicle
9. 9. Remove engine damping block from transmission bracket

Install

10. 10. Raise vehicle
11. 11. Raise engine to original position using Engine Support KM-6210-A
12. 12. Lower vehicle
13. 13. Install new engine damping block (1) to transmission bracket and chassis • Install 2x bolt (3), nut (2); do not tighten at this stage • Secure 2x bolt (3) 44 Nm , nut (2) 60 Nm

14. 14. Raise vehicle
15. 15. Remove Engine Support KM-6210-A from vehicle
16. 16. Install engine and transmission undershield to vehicle
17. 17. Lower vehicle
