Remove
Remove fastening bolts (1) for starter switch, fastening nut (2) from field winding connection, starter switch from housing.
Remove fastening nuts (1) from cover cap, fastening bolts (2) from brush holder, cover cap (3) from coil housing. Remove brush holder (4) carefully from rotor shaft.
Note. During removal of brush holder, two carbon brushes remain at the coil.
Remove
Remove armature (1) from coil, coil (2) from housing lower part, insulation hoses from stud bolts, stud bolts from planetary gear.
Remove
Remove fastening bolt (1) for release lever from housing lower part.
Remove
Drive shaft assembly (1) with copper drift from housing lower part, remove planetary gear (2) from drive shaft assembly.
Install
Attach planetary gear to drive shaft assembly, insert drive shaft assembly in lower part of housing, install fastening bolt for release lever in lower part of housing.
Install
Install stud bolts (1) at planetary gear (2), slide insulation hoses onto stud bolts, install coil (4) at housing lower part, install rotor (3) in coil.
Connect brush holder (1) to rotor shaft (2). Install cover cap at coil housing, fastening bolt at brush holder, fastening nuts at cover cap.
Install
Install starter switch in housing. Attach fastening nut (2) to field winding connection and fastening bolts (1) to starter switch.
