Special Tools - OHC 16-V Opel Omega B

Diesel Engine 10 illustrations
KM-135Adapter
To measure engine oil pressure in conjunction with KM-498-B
KM-146-01Remover
To detach steering arm from steering shaft
KM-235-DInstaller
To install crankshaft needle bearing
KM-236-BRemover
To remove joints from steering arm and idler arm
KM-301Gauge Bar
To check piston projection
KM-328-BRemover
To remove injection nozzles from cylinder head in conjunction with KM-931
KM-348Spring Compressor
To compress valve spring in conjunction with KM-653-A
KM-412-AEngine Overhaul Stand
To hold removed engine
KM-412-8-AAdapter
To hold engine in conjunction with KM-412
KM-412-16Adapter
To hold engine in conjunction with KM-412
KM-427Remover / Installer
To install guide pins into engine block
KM-454-BRemover / Installer
To install crankshaft seal ring in conjunction with KM-934
KM-470-BAngular Torque Wrench
To tighten cylinder head bolts
KM-471Adapter
To check pressurised cooling system in conjunction with cooling system tester
KM-498-BOil Pressure Gauge
To check engine oil pressure in conjunction with KM-135
KM-507Remover
To press tie rod joint out of steering arm
KM-523Remover / Installer
To install crankshaft seal ring in conjunction with KM-934
KM-533-BConnecting Piece
To check compression pressure and pressure loss in conjunction with KM-928
KM-535Installer
To install crankshaft seal ring in conjunction with KM-934
MKM-571-BDial Gauge
To check various components
MKM-596-ATemperature Gauge
To measure oil temperature
MKM-604-DTorx Bit and Socket Set
To remove/install Torx bolts
KM-609Electronic Kit I
To diagnose electrical and electronic systems
MKM-610Torque Wrench, 1/2"
Range 30 – 130 Nm / 22 – 96 lbf. ft.
MKM-611Torque Wrench, 3/8"
Range 10 – 60 Nm / 7 – 44 lbf. ft.
KM-652Flywheel Holder
To lock flywheel or drive disc
KM-653-AAdapter
To compress valve springs in conjunction with KM-348
MKM-667-APressure and Vacuum Pump
To check vacuum units for leaks
KM-717Removing Pliers
To remove plug for glow plugs
KM-796-ARemover
To open quick-release fittings for fuel system
KM-805Reamer 6 mm
To ream valve guides oversize 0.075
KM-835-AInstaller
To install valve stem seals
KM-840Remover
To remove valve stem seals
KM-845Suction Device
To remove the hydraulic valve lifters
MKM-883-1Engine Bridge
Holding/Raising the engine in combination with MKM-883-4-A
MKM-883-4-ARetaining hook
Holding/Raising the engine in combination with MKM-883-1
KM-904-BBase Frame
To remove and install various vehicle components with additional adapters
KM-917Remover
To disconnect coolant lines
KM-927Positioning Pin
To lock VE pump in TDC position
KM-928Connecting Piece
To check compression pressure in conjunction with KM-533-B
KM-929Positioning Pin
To lock crankshaft in 1st cylinder TDC position
KM-931Remover
To remove injection nozzle in conjunction with KM-328-B
KM-932Locking Tool
To lock camshaft in 1st cylinder TDC position
KM-933Adjuster
Simplex chain /installation of sprocket
KM-934Installer
To install crankshaft rear seal ring in conjunction with KM-523-1
KM-935Installer
To install crankshaft front seal ring
KM-956Holding Wrench
To remove/install torsional vibration damper in conjunction with KM-977-1
KM-977-1Bracket
To remove and install torsional vibration damper in conjunction with KM-956-1
KM-978Locking Tool
Chain tensioner retaining pin chain tensioner for removing/installing balancer shaft unit
KM-979Locking Tool
Locking balancer shaft unit in TDC position
KM-980Remover/Installer
To remove/install sheathed glow plugs
KM-6014Engine Shackle
To remove and install engine
KM-6086Automatic valve spring lever
Valve Springs and Valve Spring Keepers, Remove/Install
KM-6190Engine / Transmission Holder
To remove/install drive unit
KM-6318Installer
Installing the injection nozzle traverse
