Illustration Ducts Opel Omega B

1. 1. Air cleaner housing, lower part
2. 2. Air cleaner housing, upper part
3. 3. Air intake hose
4. 4. Hot film mass air flowmeter
5. 5. Air intake hose
6. 6. Turbocharger with exhaust manifold
7. 7. Intake manifold – upper part
8. 8. Charge air hoses
9. 9. Intercooler
10. 10. Air intake manifold

Illustration (Continued)

Note. Any possible contamination (grease, oil, etc.) must be cleaned from hoses and connections prior to assembly.

Strict observance of a torque of 3.5 Nm / 2.6 lbf. ft. must be ensured when tightening the hose clamps.

Caution

Only if the hose clamps are correctly tightened to the specified tightening torque, can sealing of the intake system and thereby operational safety be ensured.
