Removal (A6) Audi A6 C5

Mechanical 5 illustrations ~112 words

Note. For help in identifying components and component locations, refer to illustrations. (Scheme 16)- (Scheme 20).

  1. Disconnect any wiring harness that attach to the front bumper.
  2. Raise vehicle, remove front tires. Remove lower front engine shield (noise insulator). see scheme 8 Loosen the front half of the wheel housing splash shield (liner). (Scheme 16) Unscrew flange nut (10) on both sides. (Scheme 18)
  3. Unscrew with/washer assembly (6) from wheel housing liner (5). (Scheme 18) Remove socket-head bolts (7) and remove bumper cover together with impact absorbor towards front. (Scheme 18) To move lock carrier into service position. See «LOCK CARRIER»(ref-147486-S40535456302002091600000).

Scheme 16

Scheme 16

Scheme 17

Scheme 17

Scheme 18

Scheme 18

Scheme 19

Scheme 19

Scheme 20

Scheme 20
